Vertiv Liebert GXT5 Installation and maintenance instructions

Liebert®
GXT5™ UPS
Installer/User Guide
200 V to 240 V, 5,000 VA to 20,000 VA

Vertiv | Liebert® GXT5™ Installer/User Guide
Technical Support Site
If you encounter any installation or operational issues with your product, check the pertinent
section of this manual to see if the issue can be resolved by following outlined procedures.
Visit https://www.VertivCo.com/en-us/support/ for additional assistance.
The information contained in this document is subject to change
without notice and may not be suitable for all applications. While
every precaution has been taken to ensure the accuracy and
completeness of this document, Vertiv assumes no responsibility
and disclaims all liability for damages resulting from use of this
information or for any errors or omissions. Refer to other local
practices or building codes as applicable for the correct methods,
tools, and materials to be used in performing procedures not
specifically described in this document.
The products covered by this instruction manual are manufactured
and/or sold by Vertiv. This document is the property of Vertiv and
contains confidential and proprietary information owned by Vertiv.
Any copying, use or disclosure of it without the written permission
of Vertiv is strictly prohibited.
Names of companies and products are trademarks or registered
trademarks of the respective companies. Any questions regarding
usage of trademark names should be directed to the original
manufacturer.

TABLE OF CONTENTS
Important Safety Information 1
1 GXT5 Description 3
1.1 UPS Features and Available Models 3
1.2 Front Panels 4
1.3 Rear Panels 4
1.4 Removable Power-distribution Boxes 10
1.5 Internal Battery Packs 12
1.6 Major Internal Components and Operating Principle 13
1.6.1 Maintenance Bypass 14
1.7 UPS States and Operating Modes 14
1.7.1 Normal Mode 14
1.7.2 Bypass Mode 15
1.7.3 Battery Mode 16
1.7.4 ECO Mode 17
1.7.5 Maintenance Bypass Mode 18
2 Installation 21
2.1 Unpacking and Inspection 21
2.2 Pre-installation Preparation 21
2.2.1 Installation Clearances 21
2.3 Installing the UPS 22
2.3.1 Tower Installation 22
2.3.2 Rack Installation 22
2.4 Installing External Battery Cabinets 23
2.5 Installing a Power-distribution Box 24
2.6 Hardwired Input/Output Connections 25
2.6.1 Branch Circuit Breaker 26
2.6.2 Terminal-block Connections 27
2.6.3 Connecting to Terminal Blocks on 5-kVA and 6-kVA models 29
2.6.4 Connecting to Terminal Blocks on 8-kVA and 10-kVA models 29
2.6.5 Connecting to Terminal Blocks on 16-kVA and 20-kVA models 30
2.7 Communication Connections 32
2.7.1 Connecting IntelliSlot Communication 32
2.7.2 Connecting to the Dry-contact Port 32
2.7.3 Connecting a Remote Emergency Power-off (REPO) Switch 33
2.7.4 Connecting a USB Cable 34
2.7.5 Connecting CLI Communication Cables 35
2.7.6 Connecting Sensors to the Control Port 35
2.8 Installing a Parallel System 35
2.8.1 First-time Start-up of Parallel System 37
2.8.2 Commissioning Parallel System 37
Vertiv | Liebert® GXT5™ Installer/User Guide | iii

2.8.3 Adding a Single UPS to the Parallel System 38
3 Operating the UPS 39
3.1 Silencingthe Audible Alarm 39
3.2 Starting-up the UPS 39
3.3 Transferring to Battery Mode 39
3.4 Transferring from Normal to Bypass Mode 40
3.5 Transferring from Bypass to Normal Mode 40
3.6 Shutting-down the UPS Completely 40
3.7 Remote Emergency Power-off (REPO) 40
4 Operation and Display Panel 41
4.1 LED Indicators 42
4.2 LCD Menu and Screens 43
4.2.1 Start-up and Flow Screens 43
4.2.2 Main Menu 43
4.3 Editing Display and Operation Settings 51
4.3.1 Changing the Password 51
4.3.2 Selecting the Display Language 52
4.3.3 Setting the Date and Time 52
5 Maintenance 53
5.1 Replacing Batteries 53
5.2 Charging Batteries 55
5.3 Checking UPS Operation 56
5.4 Cleaning the UPS 56
5.5 Removing the Power-distribution Box 56
6 Troubleshooting 59
6.1 Symptoms that Require Troubleshooting 59
6.2 Audible Alarm (Buzzer) 59
6.2.1 Faults 59
6.3 Troubleshooting UPS Issues 60
7 Specifications 61
7.1 Battery Run Times 69
Appendices 73
Appendix A: Technical Support 73
Vertiv | Liebert® GXT5™ Installer/User Guide | iv

IMPORTANT SAFETY INFORMATION
IMPORTANT! This manual contains important safety instructions that must be followed during the
installation and maintenance of the UPS and batteries. Read this manual thoroughly and the safety and
regulatory information, available at https://www.vertivco.com/ComplianceRegulatoryInfo, before
attempting to install, connect to supply, or operate this UPS.
1

Vertiv | Liebert® GXT5™ Installer/User Guide
2
This page intentionally left blank

1 GXT5 DESCRIPTION
The Liebert® GXT5 is a compact, online uninterruptible power system (UPS) that continuously conditions
and regulates its output voltage. The Liebert® GXT5 supplies microcomputers and other sensitive
equipment with clean sine-wave input power.
Upon generation, AC power is clean and stable. However, during transmission and distribution it is subject
to voltage sags, spikes, and complete failure that may interrupt computer operations, cause data loss, and
damage equipment.
The Liebert® GXT5 protects equipment from these disturbances. The Liebert® GXT5 continuously
charges its batteries from the mains, enabling it to supply power to connected loads, even when the mains
fail.
1.1 UPS Features and Available Models
The GXT5 includes the following features. Table 1.1 on the next page, lists the available models and
power ratings.
•Enhanced load capacity with an output power factor of 1.
•Optional tower or rack installation to meet varying installation requirements.
•Parallel-connection capability for 10-kVA, 16-kVA, and 20-kVA models achieves up to 2 + 1
parallel redundant power.
•Adapts to areas with unstable power-mains supply via high-frequency double-conversion
topology structure, with high input-power factor, wide input-voltage range, and output
immune to grid interference.
•Full digital-control platform and hardware-design platform adapts to unstable mains supply
and load impact
•Programmable terminals with cascade protection on 5-kVA to 10-kVA models protect key
devices when load is heavy.
•Innovative design layout and process greatly increase product reliability.
•Operation and display panel with model-specific color LCD offers simple configuration and
control of the UPS.
•ECO power-supply mode and smart-sleep mode help you save the maximum amount of energy.
MODEL NUMBER NOMINAL POWER RATING
GXT5-5000IRT5UXLN
5kVA/5kWGXT5-5000IRT5UXLE
GXT5-5000HVRT5UXLN
GXT5-6000IRT5UXLN
6kVA/6kW
GXT5-6000IRT5UXLE
GXT5-8000IRT5UXLN
8kVA/8kWGXT5-8000IRT5UXLE
GXT5-8000HVRT5UXLN
Table 1.1 UPS Models and Power Ratings
1 GXT5 Description 3

MODEL NUMBER NOMINAL POWER RATING
GXT5-10KIRT5UXLN
10kVA/10kWGXT5-10KIRT5UXLE
GXT5-10KHVRT5UXLN
GXT5-16KIRT9UXLN
16kVA/16kW
GXT5-16KIRT9UXLE
GXT5-20KIRT9UXLN
20kVA/20kW
GXT5-20KIRT9UXLE
Table 1.1 UPS Models and Power Ratings
(continued)
1.2 Front Panels
The various GXT5 models have the same general appearance, with the main difference being the
receptacle types on the rear panel. Figure 1.1 below, shows the 5-kVAto10-kVA model in a tower and a
rack configuration. When mounted in a rack, the 5- to 10-kVA units are turned 90 degrees. The
orientation of the 16-kVA to 20-kVA models is the same in a rack or tower configuration.
Figure 1.1 Front View
ITEM DESCRIPTION
1 Operation/Display panel
2 Upper bezel
3 Lower bezel/battery-access door
1.3 Rear Panels
The following figures detail the rear-panel features for each GXT5 model.
Vertiv | Liebert® GXT5™ Installer/User Guide
4

Figure 1.2 GXT5-5000/6000IRT5UXLN (XLE) Rear Panel
ITEM DESCRIPTION
1 Liebert® IntelliSlot™ port
2 Terminal-block communication connectors
3 RS-485 port
4 USB port
5 RS-232 port
6 REPOconnector
7 External-battery-cabinet connector
8 Output circuit breaker
9 Maintenance-bypass breaker
10 Input circuit breaker
11 Removable POD with cable-entry for hard-wire I/O
12 Overload protector, 10-A (x2)
13 Programmable C13 output receptacles (x2)
14 Overload protector, 15-A (x2)
15 C19 output receptacles (x2)
1 GXT5 Description 5

Figure 1.3 GXT5-5000HVRT5UXLN Rear Panel
ITEM DESCRIPTION
1 Liebert® IntelliSlot™ port
2 Terminal-block communication connectors
3 RS-485 port
4 USB port
5 RS-232 port
6 REPOconnector
7 External-battery-cabinet connector
8 Output circuit breaker
9 Maintenance-bypass breaker
10 Input circuit breaker
11 Removable POD with knock-outs/cable-entry for hard-wire I/O
12 Programmable output circuit breaker, 10-A (x2)
13 C19 output circuit breaker
14 Programmable C13 output receptacles (x2)
15 C19 output receptacles (x2)
Vertiv | Liebert® GXT5™ Installer/User Guide
6

Figure 1.4 GXT5-8000/10KIRT5UXLN (XLE) Rear Panel
ITEM DESCRIPTION
1 Liebert® IntelliSlot™ port
2 Terminal-block communication connectors
3 RS-485 port
4 USB port
5 RS-232 port
6 REPOconnector
7 External-battery-cabinet connector
8 Output circuit breaker
9 Maintenance-bypass breaker
10 Bypass circuit breaker
11 Input circuit breaker
12 Removable POD with cable-entry for hard-wire I/O
13 Programmable C19 output receptacle
14 Overload protector, 10-A
15 Programmable C13 output receptacles
16 Overload protector, 15-A (x4)
1 GXT5 Description 7

Figure 1.5 GXT5-8000/10KHVRT5UXLN Rear Panel
ITEM DESCRIPTION
1 Liebert® IntelliSlot™ port
2 Terminal-block communication connectors
3 RS-485 port
4 USB port
5 RS-232 port
6 REPOconnector
7 External-battery-cabinet connector
8 Output circuit breaker
9 Maintenance-bypass breaker
10 Bypass circuit breaker
11 Input circuit breaker
12 Removable POD with knock-outs/cable-entry for hard-wire I/O
13 Programmable output circuit breaker, 15-A
14 Programmable C19 output receptacle
15 Programmable output circuit breaker, 10-A
16 Programmable C13 output receptacles
17 C19 output circuit breaker, 15-A
Vertiv | Liebert® GXT5™ Installer/User Guide
8

Figure 1.6 GXT5-16K/20KIRT9UXLN (XLE) Rear Panel
ITEM DESCRIPTION
1 Liebert® IntelliSlot™ port
2 Terminal-block communication connectors
3 RS-485 port
4 USB port
5 RS-232 port
6 REPOconnector
7 DB9 ports (parallel communication)
8 Input circuit breaker
9 Bypass circuit breaker
10 Knock-outs/cable-entry for hard-wire I/O
11 Output circuit breaker
12 POD breaker
13 Cover for optional POD-installation location
14 External-battery-cabinet connector
1 GXT5 Description 9

1.4 Removable Power-distribution Boxes
The 16-kVA and 20-kVA do not ship with an installed power-distribution box (POD). The optional PODs
for the 16-kVA and 20-kVA models models are:
•PD2-108 for models ending in "N"only (North America)
•PD2-200
•PD2-201
•PD2-202
•PD2-204 for models ending in "E"only (European Union)
The 5-kVA to 10-kVA models ship with the POD installed. This POD includes the input circuit breaker for
the UPS, and the features for each POD are detailed in the following figures.
Figure 1.7 PD5-CE6HDWRMBS for GXT5-5000/6000IRT5UXLN (XLE)
ITEM DESCRIPTION
1 PODPanel view (on rear of unit)
2 POD inner-surface view
3 Quick connect
Vertiv | Liebert® GXT5™ Installer/User Guide
10

Figure 1.8 PD5-CE6HDWRMBSU for GXT5-5000HVRT5UXLN
ITEM DESCRIPTION
1 PODPanel view (on rear of unit)
2 POD inner-surface view
3 Quick connect
Figure 1.9 PD5-CE10HDWRMBS for GXT5-8000/10KIRT5UXLN (XLE)
ITEM DESCRIPTION
1 PODPanel view (on rear of unit)
2 POD inner-surface view
3 Quick connect
1 GXT5 Description 11

Figure 1.10 PD5-CE10HDWRMBSU for GXT5-8000/10KHVRT5UXLN
ITEM DESCRIPTION
1 PODPanel view (on rear of unit)
2 POD inner-surface view
3 Quick connect
1.5 Internal Battery Packs
The internal battery packs for all GXT5 models, shown in Figure 1.11 below, are located behind the access
door on the front of the UPS. 5-kVA to 10-kVA units have 2 battery packs, and 16-kVA to 20-kVA units
have 4 battery packs.
Figure 1.11 Internal Battery Pack
ITEM DESCRIPTION
1 Handle
2 Connector
Vertiv | Liebert® GXT5™ Installer/User Guide
12

1.6 Major Internal Components and Operating Principle
Figure 1.12 below, shows the UPSoperating principle. Table 1.2 on the next page, describes the function
of the major components in the UPS.
NOTE: Figure 1.12 below, is one example of basic operation. The actual I/O connections for the
various models may be divided into different types. See Hardwired Input/Output Connections on
page25.
Figure 1.12 Basic Operating Principle Diagram
ITEM COMPONENT OPERATION/FUNCTION
1
Transient
Voltage Surge
Suppression
(TVSS) and
EMI/RFI Filters
Provide surge protection. Filter electromagnetic interference (EMI) and radio frequency interference
(RFI). Minimize surges or interference present in the utility power and protect devices connected on the
same branch as the UPS.
2 Battery Charger Continuously float-charges the batteries from precisely-regulated utility power whenever the UPS is
plugged in.
3 Batteries
Valve-regulated, non-spillable, lead-acid batteries.
NOTE: To maintain battery design life, operate the UPS in an ambient temperature of 59°F to 77°F
(15°C to 25°C).
4DC-to-DC
Converter
Raises the DC voltage from the battery to the optimum operating voltage for the inverter. This allows the
inverter to operate continuously at its optimum efficiency and voltage, thus increasing reliability.
5
Rectifier/Power
Factor
Correction
(PFC) Circuit
In normaloperation, converts utility AC power to regulated DC power for use by the inverter while
ensuring that the wave shape of the input current used by the UPS is near ideal. Extracting this sine-wave
input current ensures efficient use of utility power and reduces reflected harmonic distortion making
cleaner power available to devices that are not protected by the UPS.
Table 1.2 Major Components
1 GXT5 Description 13

ITEM COMPONENT OPERATION/FUNCTION
6 Inverter
In normal operation, inverts the DC output of the PFC circuit into precise, regulated sine-wave AC power.
When utility power fails, the inverter receives DC power from the DC-to-DC converter. In either
operating mode, the UPS inverter remains on-line, generating clean, precise, regulated AC-output
power.
7 Internal Bypass
In the unlikely event of UPS failure such as overload or over-temperature, automatically transfers the
connected load to bypass.
To manually transfer the connected load from inverter to bypass, see Transferring from Normal to
Bypass Mode on page40.
8 Outlet group Output receptacles.
Table 1.2 Major Components (continued)
1.6.1 Maintenance Bypass
On 5-kVA to 10-kVA models, the UPS includes manual maintenance bypass in a removable section of the
rear of the UPS. Maintenance bypass keeps connected equipment powered with utility power and allows
replacement of the UPS in the event of a UPS malfunction.
NOTE: The bypass power path does not protect the connected equipment from disturbances in the
utility power supply.
1.7 UPS States and Operating Modes
NOTE: See LED Indicators on page42, for description of the run-indicator and alarm-indicator LEDs
mentioned in this section.
1.7.1 Normal Mode
When utility power is normal, Normal mode employs the rectifier and inverter to provide voltage- and
frequency-stabilized power to the load. The charger charges the battery in normal mode. On the front-
panel display, the run-indicator (green)is On, the alarm indicator is OFF, and the buzzer is silent. Figure
1.13 on the facing page, shows a diagram of normal mode.
Vertiv | Liebert® GXT5™ Installer/User Guide
14

Figure 1.13 Normal-mode Operation
ITEM DESCRIPTION
1 Mains/Utility input (by-pass input)
2 Rectifier/PFC
3 Inverter
4 Battery charger
5 Battery
6 Bypass static switch
7 UPS output
1.7.2 Bypass Mode
Bypass mode supplies power to the load from the bypass source (utility power) if an overload or fault
occurs during normal operation. On the front-panel display, the run indicator (green) is On, the alarm
indicator (yellow)is On, and the buzzer beeps once each seconds. The LCD "Current" screen displays "On
Bypass." Figure 1.14 on the next page, shows a diagram of bypass mode.
NOTE: If utility power fails or if the utility voltage goes outside of the permissible range during bypass-
mode operation, the UPS shuts down and no output is supplied to the load.
1 GXT5 Description 15

Figure 1.14 Bypass-mode Operation
ITEM DESCRIPTION
1 Mains/Utility input (by-pass input)
2 Rectifier/PFC
3 Inverter
4 Battery charger
5 Battery
6 Bypass static switch
7 UPS output
1.7.3 Battery Mode
Battery mode supplies battery power to the load if utility power fails or if the utility voltage goes outside of
the permissible range. On the front-panel display, the run indicator (green) is On, the alarm indicator
(yellow)is On, and the buzzer beeps once each second. The LCD "Current" screen displays "On Battery."
Figure 1.15 on the facing page, shows a diagram of battery mode.
NOTE: The batteries are fully-charged before shipment. However, transportation and storage
inevitably cause some loss of capacity. To ensure adequate back-up time, charge the batteries for at-
least 8 hours before first start-up.
NOTE: If utility power fails and the batteries are charged, you may cold-start the UPS in battery mode
and use battery power to extend system availability for a time.
Vertiv | Liebert® GXT5™ Installer/User Guide
16
