VEVOR QJD-01-012A User manual

Technical Support and E-Warranty Certificate www.vevor.com/support
BOTTLE JACK
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only
represents an estimate of savings you might benefit from buying certain
tools with us compared to the major top brands and doses not necessarily
mean to cover all categories of tools offered by us. You are kindly
reminded to verify carefully when you are placing an order with us if you
are actually saving half in comparison with the top major brands.

- 1 -
<Picture Only For Reference >
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
Have product questions? Need technical support? Please feel free to
contact us:
[e-mail]
NEED HELP? CONTACT US!
Bottle Jack

- 2 -
OPERATION INSTRUCTIONS:
+To raise: Using the slotted opening at the end of the handle, turn the
release-valve clock wise to tighten it. And then put the jack under the load
to be lifted. Turn the adjustable screw rod until it contacts with the load, Put
the handle in the pressing handle holder and press up the down; the piston
rod will rise slowly till the specified range is reached.
WARNING
THIS IS A LIFTNG DEVICE ONLY. IT IS DESIGNED TO LIFTPART OF
THE TOTAL VEHICLE (ONE WHEEL OR AXLE.ALWAYS WEAR SAFETY
GLASSES WHEN USING THIS EQUIPMENT CENTER LOAD ON
SADDLE BEFORE LIFTING. NEVER WORK ON,UNDER OR AROUND
LOAD UNTIL IT IS PROPERLY SUPPORTED,TRANSFER THE LOAD
IMMEDIATELY TO APPROPRIATE LYRATED JACK STANDS DO NOT
USE THIS PRODUCT FOR ANY PURPOSE OTHER THAN THAT FOR
WHICH IT WAS INTENOED. IT IS OWNER'S RESPONSIBILITY TO KEEP
LABELS AND MANUALS ARE AVAILABLE FROM THE MANUFACTURER
FAILURE TO HEED THESE AND ALL OTHER WARNINGS PERTAINING
TO THIS PRODUCT CAN RESULT IN SUDDEN LOSS OF LIFTED LOAD
RESULTING IN DEATH PERSONAL INJURY OR PROPERTY DAMAGE.
+To lower: Remove the pressing handle. Using the slotted opening at the
end of the handle turn the release-valve slightly counter clock wise to
loosen it. And then the piston rod will move down slowly. When loaded. the
release-valve should not be turned quickly, otherwise too speedy lowering
will lead to danger.

- 3 -
WARNING
BE SURE ALL TOOLS AND PERSONNEL ARE CLEAR BEFORE
LOWERING LOAD，DANGEROUS DYNAMIC SHOCK LOADS ARE
CREATED BY QUICKLY OPENING AND CLOSING THE RELEASE
VALVE AS THE LOAD IS BEING LOWERED THE RESULTING
OVERLOAD MAY CAUSE HYDRAULIC SYSTEM FAILURE, WHICH
COULD CAUSE SEVERE PERSONAL INJURY AND/OR PROPERTY
DAMAGE.
FOR SAFETYS SAKE
Lifting weight should not exceeded the specified duty of this jack.
(Max.watch box) The bottom of the jack should always be placed on the
leveled and hard ground.
The contact between the top and the lifted body must be perfect.
Without a supporting rack, it is not allowed to work under the lifted heavy
body after it is raised.
When several jacks are used together, the raising speed should be
coincident with each other and the duty of each should be balanced,
otherwise the danger of topping over will happen.
ROUTINE MAINTENANCE
Proper quantity of oil should be maintained, otherwise the specified lifting
height would not be reached.
When in operation, the jack should be seated in rectangular angle with the
lifted heavy body, and to avoid piston and screw top cracking no
crookedness should be allowed.
To avoid damaging, the jack should be kept from shocking while in
operation.
The jack is not allowed to stand on one side or upside down.
This product is not suitable to the operation environment full or acid
alkaline corrosive air.

- 4 -
Adding oil
1. With saddle fully lowered and pump piston fully depressed,set jack in its
upright,level position. Remove oil filler plug.
2. Fill until oil is level with the filler plug hole,reinstall oil filter plug.
Changing oil
For best performance and longest life , replace the complete fluid supply at
least once per year.
1. With saddle fully lowered and pump piston fully depressed, remove the
oil filler plug.
2. Lay the jack,on its side and drain the fluid into a suitable container.
Note: Dispose of hydraulic fluid in accordance with local regulations
3. Fill with good quality jack oil. Reinstall oil filler Plug.We recommend
Mobil DTE 13 or equivalent.
Lubrication
1. A coating of light lubricating oil to pivot points axles and hinges will help
to prevent rust and assure that wheels, casters and pump assemblies
move freely.
2. Periodically check the pump piston and ram for signs of rust or
corrosion. Clean as needed and wipe with an oily cloth.
NEVER USE SANDPAPER OR ABRASIVE MATERIAL ON THESE
SURFACES.
3. When not in use, store the jack with pump piston and ram fully retracted.
4.
WARNING
DO NOT ADJUST THIS VALVE

- 5 -
Structural composition
PART LIST
ITEM
No.
DESCRIPTION
QTY
ITEM
No.
DESCRIPTION
QTY
1
WIRE PIN
2
17
"O" RING
1
2
PIN
2
18
STEEL BALL 1/4"
3
3
PISTON
1
19
SEAL
1
4
"O" RING
1
20
GASKET
1

- 6 -
5
BACK-UP RING
1
21
CYLINDER
1
6
U-SEAL
1
22
RELEASE VALVE
1
7
PISTON PUMP
1
23
SEAL
1
8
GASKET
1
24
SCREW
1
9
PLUG ADDING
OIL
1
25
"O" RING
1
10
HANDLE
SOCKET
1
26
SCREW
1
11
OIL TANK
1
27
COMPRESSION
SPRING
1
12
SEAL
1
28
BACKING PIN
1
13
TOP TANK
1
29
STEEL BALL 3/16"
1
14
"O" RING
1
30
BASE
1
15
PISTON ROD
1
31
FRONT
HANDLE ,LOWER
1
16
BACK-UP RING
1
32
REAL HANDLE,
LOWER
1
Parameter table
Model
Lifting
Capacity
(TON)
Max
Altitude
(mm)
Min
Altitude
(mm)
Lifting
Altitude
(mm)
Regulating
Altitude
(mm)
Net
Wei
ght
(kg)
QJD-01-0
12A
12
355
190
105
60
5.8
QJD-01-0
20A
20
450
240
150
60
9.6
