VEVOR 9526 User manual

Bench Vice
Operating Instruction
6inch Mechanic Bench Vise
Model：9526
E-mail: CustomerSe[e-mail]

Have product questions? Need technical suppo?
Please feel free to contact us:
CustomerSe[email protected]
NEED HELP? CONTACTUS!
Bench Vice
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR resees a clear interpretation
of our user manual. The appearance of the product shall be subject
to the product you received. Please forgive us that we won't inform
you again if there are any technology or software updates on our
product.
01 02 03 04
Model： 9526
Designation： 6inch Mechanic Bench Vise
Material: Ductile Iron
Overallsize: 365*151*189mm
Baking width: 151mm
Maximum opening: 150mm
Maximum clamping force: 20KN
Color: Grey+Orange
Weight: About 12.55kg
1 x Bench Vise Table Top Clamp Press
1 x User Manual
4 x Nuts
4 x Screws
1 x Base mount paperboard
1 x Mat nylon clamp mouth pad
SPECIFICATIONS
DESCRIPTION
Solid Ductile iron
Rotation table 360° rotation
Suitable for installation on the table.
Bench vice is used to clamp workpieces. It is installed on the work
stations to clamp the workpieces. It is an necessa tool in the
schlosserei. Rotating disc type clamp body can revolve so that make
the workpiece rotate to the suitable place. Most work of tter are ni-
shed on the bench vice. For example, the saw, the le, the chisel
and components in stalling and dismantling.
PACKAGE
Install the pliers on the clamp table
1、 Operating instruction
The height of operator working will be suitable because
the bench vice is installed on the work bench. Usually the
jaw height is ushed with elbow just right. This is ok.
Put the elbow on the bench vice peak and half clenched sts
that the st just suppo the mandible. Length and width of work
bench will be decided by the work.
2、 Cautions
（1）Appropriate degree of tightness when clamp the workpiece.
Just tight the hand shank by the hand only. Do not add strength
with the help of other tools. No clamp-holding force shall be
exceeded .
（2）When work strongly, you need t your best to make
strength facing to clamp body.
（3）Do not knocking on the clamp body and smooth suace.
（4）Clean and lubricate the suace of lead screw and
nut so that it will not rust.
INSTALLATION
APPLICATION
Impoer: WAITCHX
Address: 250 bis boulevard Saint-Germain 75007 Paris
Impoer: FREE MOOD LTD
Address: 2 Holywell Lane, London, England, EC2A 3ET
EUREP UK LTD
UNIT 2264, 100 OCK STREET, ABINGDON
OXFORDSHIRE ENGLAND OX14 5DH
UK REP
EUREP GmbH
Unterlettenweg 1a, 85051 Ingolstadt,
Germany
EC REP
Manufacturer:WEIFANG JINTAILAI BENCH VISE
MANUFACTURING CO.,LTD
Address:TA ER BAO INDUSTRIAL PARK,CHANGYI CITY,
SHANDONG,CHINA
Model：9526
Made in china
