VEVOR XRSS2305 User manual

Technical Support and E-Warranty Certificate www.vevor.com/support
CABINET HARDWARE JIG
MODEL: XRSS2305
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.

-1-
MODEL: XRSS2305
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
CABINET HARDWARE JIG

-2-
SAFETY INSTRUCTIONS
1. This product contains small parts. If swallowed, it will pose a choking
hazard. Keep these small parts away from children !
2. Read, understand and follow your power tool manufacturer's instructions
for safety. Always wear safety glasses or eye shields before commencing power
tool operation. Always keep hands, face, hair, loose clothing, and body at a
safe distance from spindles and cutting tools. Always keep a firm grip on tool
handles when in operation. Always disconnect from the power source before
adjusting power tools.
MODEL AND PARAMETERS
Model
XRSS2305
Material
Aluminium Alloy
Longitudinal scale range
0-25cm/0-10inch
Horizontal scale range
0-20cm/0-8inch
STRUCTURE DIAGRAM AND COMPONENTS
1
3
4
6
8
2
5
7
9
Multi-delivery x1
5
10
11
12
13

-3-
No.
Name
Qty
1
Main Ruler with Drill Guide
1
2
Hand Screw 1
6
3
Main Stop
1
4
Adjustable Drill Guide
3
5
Guide Sleeve(Φ4+Φ5)
6
6
Transverse Ruler
1
7
Hand Screw 2
2
8
End Stop
1
9
Bushing Holder/Slide
1
10
Wrench
2
11
Twist Bit(Φ4+Φ5)
2
12
Borehole Positioner
1
13
Storage Bag
1
14
User Manual
1
OPERATION
A: KNOB ON DRAWER FRONT(Center of width and height)
① ② ③
①Measure the width and height of the drawer .
②Set Large Stop at half of the drawer height, and set the sliding end stop at

-4-
half of the drawer width. Finally,drill holes .
（NOTE: Using a center punch for positioning is more convenient .)
③Install the handle and you're done .
B: HANDLE ON DRAWER FRONT(Center of width and height)
① ② ③ ④
①:Measure hole centers of handles,adjust and tighten Sliding Drill Guides .
(Cover unused bushing with tape)
②:Measure the width and height of the drawer .
③:Set Large Stop at half of the drawer height, and set the sliding end stop at
half of the drawer width. Finally,drill holes .
（NOTE: Using a center punch for positioning is more convenient .)
④:Install the handle, and you're done .
C: KNOB ON DOOR INSTALLATION (Off center of width and height)
① ② ③
①:Place the knob to find a position you like and mark it .
②:Measure from the top of the door to mark and set Sliding End Stop to the
measurement .

-5-
③:Measure from side of door to mark and set Large Stop to the measurement .
④ ⑤ ⑥
④:Place the tool as picture and drill hole through the drill bushing .
（NOTE: Using a center punch for positioning is more convenient .)
⑤:The flipping tool punches a hole in the other cabinet door .
⑥: Install the handle, and you're done .
D:HANDLE ON DOOR INSTALLATION(Off center of width and height)
① ② ③
①:Place the handle to find position you like and mark the bottom hole
location .
②:Measure from the top of the door to mark and set Sliding End Stop to the
measurement .
③:Measure from the side of the door to mark and set Large Stop to the
measurement .

-6-
④ ⑤ ⑥
④:Place the tool as picture and drill hole through the drill bushing .
（NOTE: Using a center punch for positioning is more convenient .)
⑤:The flipping tool punches a hole in the other cabinet door.
⑥: Install the handle, and you're done .
MAINTENANCE
1. After each use, please install it in time and keep it properly to avoid losing
parts .
2.Clean the surface after each use .
