VIBIA Halley User manual

1.
Halley
Design by Jordi Vilardell & Meritxell Vidal
ASSEMBLY INSTRUCTIONS
2.
3.
4.
4150
1
Carry bag 1 un.
2
Big base 1 un.
3
Small base 1 un.
4
Profiles set (A), (B) y (C). 1 un.
A
B
C
SUPPLIED MATERIAL
TECHNICAL SPECIFICATIONS
Class I. Product with an additional protection cable (grounds).
Dust-tight product. Protected against water spray.
Product that CAN be in contact with normally-flammable
materials (wood or others).
-If the steel cable or the power cord of this lamp is damaged, it must be replaced only by the manufacturer or their technical service or by a person capacitated to this effect to avoid
any risk.
-We recommend reading the manual before installaing the lamp. Keep this instructions for future reference.
Caution
Before assembling and installing this product, carefully read the following:
-At least two people are needed to install and desinstall the lamp.
4150.
Net Weight 18,9 Kg
1 x LED STRIP 24V 21,6W

1
2
E
C
6
4
5
A
B
F
G
G
A
C
B
“Click”
D
E
3
D
B
HI
J
1.
Remove the top (A) and side (B and C) profiles from the carry
bag. Place the big (D) and small (E) bases where you want to
install the lamp. The distance between the center of the bases
must be 2.10 mt. approx.
2. Connect the top profile (A) to the side one (B) making sure the
release button (F) is in place (G).
NOTE: While assemblying the lamp, gently pull the cable on the
lower part (see Detail X).
3. Connect the top profile (A) to the side one (C) making sure the
release button is in place, just like Step 2.
4. Connect the side profile (B) to the big base (D), with the cable
facing the fabric handle (H).
Keep the button (I) pressed when connecting the profile, push
downwards until a click is heard and the profile is in place (J).
5. Connect the side profile (C) to the small base (E), keeping the
button pressed and the profile is in place, just like in Step 4.
6. Several lamp can be connected together to create multiple
compositions by joining the base. Small bases (E) can be fitted
into the inner space of the big one (D).
ASSEMBLY INSTRUCTIONS
B
A
E
C
D
Aprox.
2
nd
3
rd
4
th
5
th
2,10 mt.
Maintenance
-Use a slightly-wet cotton cloth for cleaning.
-In case of malfunction or damage, please contact the retailer who sold the lamp.
DETAIL X
