Vicks VNT275US User manual

Owner’s Manual
REF VNT275US
NonContact
Infrared Body Thermometer

NON CONTACT INFRARED BODY THERMOMETER.................................................. 2
Owner’s manual
TERMÓMETRO INFRARROJO CORPORAL SIN CONTACTO.....................................17
Manual del Usuario
Contact Us
Questions or Comments?
Call us toll-free at: 1-800-477-0457
Email: [e-mail]
Visit: www.VicksThermometers.com
Please be sure to specify the model number.
© 2020 All rights reserved.
Kaz USA, Inc., a Helen of Troy Company
400 Donald Lynch Blvd., Suite 300
Marlborough, MA 01752
Certain trademarks used under license from The Procter & Gamble Company
or its affiliates.
Made in China:
VNT275US
PN:A005127R2
型 号 :
制造商：
东莞市振海电子科技有限公司
HTD8813C

1
Foreword
The Non Contact Infrared Body Thermometer Operating Instructions intend to provide
the necessary information for proper operation of the VNT275US thermometer.
General knowledge of the Non Contact Infrared Body Thermometer and an
understanding of the features and functions of the VNT275US thermometer are
prerequisites for proper use. The Non Contact Infrared Body Thermometer is a medical
device, and can be used repeatedly for 1 year. Please read the manual before using
the device, if you do not fully understand these instructions for use, do not use the
thermometer.
Do not operate the VNT275US thermometer without completely
reading and understanding these instructions.
NOTICE
Purchase or possession of this device does not carry any express or implied license to
use with replacement parts which would, alone or in combination with this device,
fall within the scope of one of the relating patents.

2
Indications for Use
The Non Contact Infrared Body Thermometer is a non-sterile, reusable thermometer
intended to be used for the intermittent determination of human body temperature by
consumers of all ages in a home-use environment (such as home settings or places of
business as an employee screening tool), in no touch mode, with the forehead as the
measurement site.
Safety Information
This device may only be used for the purposes described in these instructions.
The manufacturer cannot be held liable for damage caused by incorrect application.
Important Safety Instructions:
• The Non Contact Infrared Body Thermometer is intended to be used by consumers in a
home-use environment (such as home settings or places of business as an employee
screening tool).
• Keep out of reach of children under 12 years.
• NEVER use the thermometer for purposes other than those for which it has been
intended. Please follow the general safety precautions when using on children.
• NEVER immerse the thermometer into water or other liquids (not waterproof).
For cleaning, please follow the instructions in the “Care and Cleaning” section.
• DO NOT store this thermometer in temperature below -4°F or over 131°F (extremes below
-20°C or over 55°C) or in excessive humidity (up to 93% non-condensing relative humidity).
• Let the thermometer and individual being measured acclimate to the temperature of
the room for 30 minutes in which the measurement will be taken.
• Before using, allow the thermometer to remain in the room in which it will be used for
30 minutes. The room temperature should be between 59°F - 95°F (15°C to 35°C).
• The individual being measured should be indoors for 20 minutes before taking a
measurement, as external temperature can impact skin temperature.
• In the event that you can’t follow the ambient acclimation guidance due to using this
device as a screening tool, the reading displayed may shift up or down as a result of the
temperature subjects are coming from compared to the temperature they are being
measured in. If that is the case, judge individuals against each other, and any individual
that is reading 1.5°F (0.8°C) higher or lower than the normal, should be measured again
following acclimation.
• DO NOT use the thermometer if there are signs of damage on the scanner or on the
thermometer itself. If damaged, DO NOT attempt to repair the product.
• NEVER insert a sharp object into the scanner area or any other open surface on the
thermometer.

3
• This thermometer consists of high-quality precision parts. DO NOT drop the instrument.
Protect it from severe impact and shock. DO NOT touch the infrared sensor with your
fingers.
• Use of this thermometer is not intended as a substitute for consultation with your
physician.
• Temperature elevation may signal a serious illness, especially in neonates and infants,
or in adults who are old, frail, or have a weakened immune system. Please seek
professional advice immediately when there is a temperature elevation and if you are
taking temperature on:
– Neonates and infants under 3 months (Consult your physician immediately if the
temperature exceeds 99.4 °F [37.4 °C])
– Individuals over 60 years of age (Fever may be blunted or absent in older patients)
– Individuals having diabetes mellitus or a weakened immune system (e.g., HIV
positive, cancer chemotherapy, chronic immunosuppressant treatment, splenectomy)
– Individuals who are bedridden (e.g., nursing home patient, stroke, chronic illness,
paraplegia, quadriplegia, surgical recovery)
– A transplant recipient (e.g., liver, heart, lung, kidney)
• This thermometer is not intended for pre-term babies or small-for-gestational age
babies. Pre-term is defined as baby, born before 37 weeks of pregnancy are completed..
Small-for-gestational-age is defined as a newborn baby (birth to 4 weeks of age), born
at 37 weeks or later, with a weight below the 10th percentile for newborn babies of the
same gestational age.
• This thermometer is not intended to interpret hypothermic temperatures. If the device
displays a temperature of 96.1°F (35.6°C) or less with no LED backlight color, and the
individual is exhibiting atypical symptoms or behaviors, contact your physician or
health care professional.
• DO NOT allow children to take their temperatures unattended.
• Please consult your physician if you see symptoms such as unexplained irritability,
vomiting, diarrhea, dehydration, changes in appetite or activity, seizure, muscle pain,
shivering, stiff neck, pain when urinating, etc., even in the absence of fever.
• Even in the absence of fever, those who exhibit a normal temperature may still need
to receive medical attention. People who are on antibiotics, analgesics, or antipyretics
should not be assessed solely on temperature readings to determine the severity of
their illness.
• DO NOT modify this equipment without the authorization of the manufacturer.
• DO NOT throw batteries into fire. Only use recommended batteries. DO NOT use
rechargeable batteries.
• If measuring human forehead temperature, please select “body” mode; if measuring
objects, liquids, food, or other objects, please select “surface” mode.

4
Section 1: Overview
Description of Non Contact Infrared Body Thermometer
• Device principle and introduction:
The Non Contact Infrared Body Thermometer is a hand-held, reusable, battery operated
device, which can measure human body temperature using the forehead as the
measurement site (the skin temperature on one’s forehead.) The operating principle is based
on Infrared (IR) Sensor technology. When measuring, the IR Sensor acquires infrared energy
from the target forehead. Taking into account the ambient temperature, the thermometer
turns the signal from the IR Sensor to a digital value and displays it on the LCD.
• Description on Controls, Indicators, and Symbols
Figure 1: VNT275US Non Contact Infrared Body Thermometer
1. LCD display
2. Battery Cover
3. On (Trigger)
button
1. Surface mode
2. Body mode
3. Digital Display
4. Smile or Cry Indicator
5. Battery indicator
Surface M
Body
°
C
°
F
1
2
3
4 5 6
7
8
9
10
4. SET button
5. MEMO button
6. MODE button
7. IR sensor
6. Voice on/off indicator
7. Memory number
8.°F
9. °C
10. Memory

5
Equipment Symbols
Technical Specifications
Caution Operating atmospheric
pressure
Nonsterile
packaging
Recyclable
Consult Instructions
for Use
Compliance with WEEE
Standard
Operating
Temperature
BF Type applied part
Operating
Humidity
Manufacturer
IP22 IP22: Protected against solid foreign objects greater than 12.5 mm in
diameter and dripping water when tilted at 15º
Measurement unit °C/°F
Operating mode Adjusted mode (Body mode) Direct mode (Surface mode)
Measuring site Forehead
Reference body site Axillary
Measuring range Body mode: 93.2°F~109.2°F/34.0°C -42.9°C
Surface mode: 32°F~212°F/0°C~100°C
Laboratory accuracy Body mode:
±0.4°F/±0.2°C for the range 95°F~107.6°F/ 35.0°C -42.0°C
±0.5°F/±0.3°C outside of that range
Surface mode:
±3.6°F/±2.0°C
Display Resolution 0.1°F/0.1°C
Fever InSight (Three-
Color Backlight)
96.2-99.2°F or 35.7-37.3°C: Green Backlight (Normal);
99.3-101.1°F or 37.4-38.4°C: Yellow Backlight (Fever)
>101.1°F or >38.4°C : Red Backlight (High Fever)
Notes: 1. Surface mode always displays temperature with
a Green backlight. 2. In body mode, 93.2-96.1°F (34.0-
35.6°C) will be displayed with a No LED backlight.”
Auto Power Off Time ≤18 seconds
Measuring Time ≤2 seconds
NON
STERILE
70 kPa
106 kPa
0%
93%

6
Technical Specifications
Measuring Distance 0.4 inches to 2 inches (1 cm to 5 cm)
Memory 50
Power Supply
Requirements
Batteries 1.5V (AAA) Alkaline battery x 2 (IEC Type LR03)
Operable Voltage Range 2.6V~3.6V
Environmental
Operating Environment Temperature: 59°F – 95°F (15°C – 35°C), Relative
Humidity≤93% non-condensing, Atmospheric Pressure:
0.7 atm to 1.04 atm (70 kPa to 106 kPa)
Transport and Storage
Environment
Temperature: -4 °F – 131°F (-20°C – -55°C), Relative
Humidity ≤93%, non-condensing Atmospheric Pressure:
0.7 atm – 1.04 atm (70 Kpa – 106 Kpa)
Dimensions and Weight
Weight (without batteries) 3.2 ounces (90g)
Size L: 5.4” x W: 3.7” x H: 1.6” (L:138mm X W:95mm X H:40mm)
This infrared thermometer meets requirements established in ASTM Standard E 1965-98 (for the thermometer
system). Full responsibility for the conformance of the product to the standard is assumed by Kaz USA, Inc.,
a Helen of Troy Company, Health & Home, 400 Donald Lynch Blvd., Suite 300, Marlborough, MA 01752
ASTM laboratory accuracy requirements for the thermometer only in the display range of 36 °C to 39°C (96.8
°F to 102.2 °F) for infrared thermometers is ±0.3 °C (±0.5 °F), whereas for mercury-in-glass and electronic
thermometers, the requirement per ASTM Standards E 667-86 and E 1112-86 is ±0.1 °C (±0.2 °F).
This device conforms to the following standards:
IEC 60601-1: Medical electrical equipment. Part 1: General requirements for basic safety and essential
performance
ASTM E1965-98: Standard Specification for Infrared Thermometers for Intermittent Determination of
Patient Temperature
ISO 80601-2-56: Medical electrical equipment - Requirements for basic safety and essential performance of
clinical thermometers for body temperature measurement
IEC 60601-1-2: Medical electrical equipment – Part 1-2: General requirements for basic safety and
essential performance – Collateral Standard: Electromagnetic disturbances – Requirement and tests
NOTE: DO NOT use this device in the presence of electromagnetic or other interference outside the normal
range specified in IEC 60601-1-2.
IEC 60601-1-11: Medical electrical equipment – Part 1-11: General requirements for basic safety and
essential performance – Collateral standard: Requirements for medical electrical equipment and medical
electrical systems used in the home healthcare environment
ISO 15223-1: Medical devices - Symbols to be used with medical device labels, labeling and information to
be supplied - Part 1: General requirements”

7
Safety classification of ME EQUIPMENT
Protection against electric
shock
Internally powered ME equipment
Applied part Type BF Applied Part
Protection against harmful
ingress of water or
particulate matter
IP22
Mode of operation Continuous operation
Note: Not intended to be sterilized. Not for use in an OXYGEN RICH ENVIRONMENT
Figure 2-Measuring position and distance
MEDICAL ELECTRICAL EQUIPMENT needs special precautions regarding EMC.
For detailed description of EMC requirements please contact Consumer Relations.
Portable and mobile RF communications equipment can affect MEDICAL ELECTRICAL
EQUIPMENT.
Remove the battery from the instrument if it is not required for extended periods of time
in order to avoid damage to the thermometer resulting from a leaking battery.
2: Operation
2.1 Battery installation
CAUTION: The Non Contact Infrared Body Thermometer does not operate with dead
batteries and does not input outer power. Install new batteries.
1) Pull the battery door out in the direction of the arrow and then lift up to access
the battery compartment.
2) Insert two AAA size batteries according to the “+” and “-”.
3) Close the battery cover.
2.2 How to Operate
Before Applying the Thermometer
Be sure to read and understand all warnings listed on the instructions before use.
• The thermometer should align with the middle of the forehead to measure body
temperature (between and directly above the eyebrows) at a vertical distance.
Press the On (Trigger) button and the temperature will display immediately,
see figure 2.

8
• Before using, allow the thermometer to remain in the room in which it will be used for
30 minutes. The room temperature should be between 59°F and 95°F (15°C and 35°C).
• The ambient temperature around the test person should be stable. DO NOT take human
temperature measurements near air flow from fans, air-conditioning vents, etc.
• When people move from a place of lower temperature a place of higher temperature,
they should remain in the test environment for at least 5 minutes, to be consistent with
the ambient temperature before their temperature is measured.
• In the event that you can’t follow the ambient acclimation guidance due to using this
device as a screening tool, the reading displayed may shift up or down as a result of the
temperature subjects are coming from compared to the temperature they are being
measured in. If that is the case, judge individuals against each other, and any individual
that is reading 1.5°F (0.8°C) higher or lower than the normal, should be measured again
following acclimation.
• Wait at least 1 second for the next measurement. If measuring continuously five times,
it is recommended to wait at least 30 seconds and then continue measurement.
• DO NOT use this thermometer in direct sunlight.
3: General Setup and Use
• Start measuring
Align the device to forehead at a distance of 1-5cm (0.4-2.0 inches), then press the On
(Trigger) button to start the measurement and read the data. The thermometer will
perform a self-test with all segments displayed for 2 seconds.
Note:
1) After full display is over, you will hear a single “beep” for a normal temperature or 4
“double beeps” for an elevated temperature, which means that the measurements have
been completed. The target value of the measured temperature is displayed on the LCD,
while the backlit displays one of three colors red, green, yellow. Green means ready for
the next measurement. If 99.3°F – 101.1°F (37.4°C-38.4°C), yellow is displayed, which
means slight fever warning. Please pay attention to body temperature. When the body
temperature is above 101.1°F, red is displayed, which means high fever. Please take action
to cool down or go to a doctor.
2) To ensure the accuracy of the measurement, wait at least 30 seconds after 5
consecutive measurements.
• Mode conversion
When the device is on, pressing the MODE button to cycle conversion between
“body” mode and “surface” mode.
“body” mode is used for measuring human body temperature, the “surface “ mode is
used to measure the surface temperature. (The factory default is “body” mode).
• Recalling and Erasing Memory Data
The last temperature taken before the thermometer powers off is stored in memory,
up to 50.

9
1) When the thermometer is turned on or off,, press the MEMO button to view the
history of measured values.
2) An empty memory cell shows “----°C” or “----°F”.
3) Temperature readings can be stored in memory. Up to 50 temperature readings can
be stored into the memory cells and automatically overwrite historical data.
4)While the thermometer is on, press the MEMO button until the LCD display “CLR”,
which means that all stored data is cleared completely.
Changing the Temperature Scale – F1
Turn the thermometer on, press and hold the SET button to enter F1, press the “MODE” or
“MEMO” button to switch Celsius and Fahrenheit temperature units, press the trigger to
confirm the unit settings (factory default is Fahrenheit)
Turning the Sound On/Off
While the thermometer is turned on, press the SET button to turn on or off the prompt
sound function.
Advanced Settings:
Warning: The following settings are only meant to be used by professionals.
It is recommended to keep this thermometer at the settings originally
programed on the device.
Fever Alert Set – F2
This setting will change at what point the backlight color of the temperature reading
turns to red. After entering the screen for changing the temperature scale, F1, press
the “SET” button to enter F2. Press the “MODE” button to decrease this value by 0.1°C
(~0.2°F). Press the “MEMO” button to increase this value by 0.1°C (~0.2°F). Press
the “SET” button to save the setting. The factory default and highly recommended
temperature to have this set at is 38.5°C (101.2°F).
Sound Settings – F3
This setting will change the buzzer to be on or off. While in Fever Alert Setting, F2, press
the “SET” button to enter F3. Press the “MODE” or the “MEMO” button to turn the volume
on or off. Press the “SET” button to save this setting. This can also be changed using the
directions outlined in “Turning the Sound On/Off”.
Factory Reset
If at any point you want to return your thermometer to the factory settings ,while
thermometer is turned on, press and hold the “MODE” button until the LCD displays “rst”.
After 2 seconds the factory settings will be restored to the device.

10
MESSAGE SITUATION SOLUTION
Temperature taken in not within
Typical human temperature range.
(93.2°F~109.2°F or 34.0°C~42.9°C).
Make sure the forehead
thermometer is for forehead
measurement, not another
human body site.
Measured over the distance:
0.4-2in (1-5 cm)
Optimum measurement distance
is .4in (1cm)
Incorrect test position. See figure 2 measuring
Subjects forehead hair,
Antipyretic stickers, head with
sweat, etc.
Have subjects sit quietly 5-10
minutes before the test.
Operating temperature
exceeds the range of specified
temperature.
Move to a room within the
operating range and wait
30 minutes before taking
temperature.
The screen flicker, automatically
turns off.
Replace battery or the product has
been damaged, and needs repairs
Low Battery Warning: When the
battery is running low, the display
flashes the low battery warning
symbol; however, the device can
still work until the battery life
has 0% left
Install a new battery. See
“Replacing the Battery” for
instructions.
Dead Battery Warning: Device
cannot take temperature.
Install a new battery. See
“Replacing the Battery” for
instructions.
Ambient termperature changes
too fast.
Wait until the ambient
temperature is stable.
(1) Power is off.
(2) Improper battery installation.
(3) The battery is exhausted.
(4) Display remains blank.
( 1) Press ON button again.
(2) Check the battery polarity.
(3) Replace with a new battery.
(4) Contact the retailer or service
center.
Troubleshooting
Surface temp
Body MEMO
Room
Time
°
C
°
F
Body °
F
Body °
F
Body °
F
Body °
F

11
4: Replacing the Battery
1. Open and release battery cover following indicator on the surface of battery cover.
Before changing the battery be sure the system is powered off.
2. Remove the battery and replace with 2 new ones, type AAA. Make sure to align
properly as indicated inside the battery cover.
4. Slide the battery cover back in until it snaps in place. Do not dispose of used batteries
in household waste. Take them to special local collection sites.
5. In the instance that the system is latched up after changing battery, you may not
follow the process of rule one. Just take off the batteries, wait 30 sec, then load
batteries again.
WARNING
DO NOT recharge, disassemble or dispose of it in fire.
1. The typical service life of the new and unused batteries is 2000 measurements for the
operation time of 18s.
2. Only use the recommended batteries, do not use rechargeable batteries and do not
burn them.
3. Remove the batteries if the thermometer is not to be used for a long period of time.
5: Cleaning, Care and Storage
• The lens is very delicate.
• It is very important to protect the lens from dirt and damage.
• Use a clean, soft cloth to clean the surface of the device and LCD. Do not use solvents or
immerse the device into water or other liquids.
• Always keep the thermometer within the storage temperature range (-4°F to 131°F or
-20°C to 55°C) –and humidity range (≤93% non-condensing).
• It is recommended to store the thermometer in a dry location free from dust. Do not
expose the thermometer to direct sunlight, high temperature/ humidity or any extreme
environments, otherwise the function will be reduced.
• When the ambient temperature of the thermometer changes too much, such as moving
the thermometer from one place of lower temperature to another place of higher
temperature, allow the thermometer to remain in a room for 30 minutes where the
temperature is between 59°F- 95°F (15°C to 35°C)
6: Disposal
1. Used batteries should not be disposed of in the household rubbish. Used Batteries
should be deposited at a collection point.
2. At the end of its life, the appliance should not be disposed of in household rubbish.
Enquire about the options for environment-friendly and appropriate disposal. Take
local regulations into account.

12
7: Warranty
A. This 1 year limited warranty applies to repair or replacement of product found to be
defective in material or workmanship. This warranty does not apply to damage resulting
from commercial, abusive, unreasonable use or supplemental damage. Defects that
are the result of normal wear and tear will not be considered manufacturing defects
under this warranty. KAZ IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES
OF ANY NATURE, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO THE DURATION OF
THIS WARRANTY. Some jurisdictions do not allow the exclusion or limitation of incidental
or consequential damages or limitations on how long an implied warranty lasts, so
the above limitations or exclusions may not apply to you. This warranty gives you
specific legal rights, and you also may have other rights which vary from jurisdiction to
jurisdiction. This warranty applies only to the original purchaser of this product from the
original date of purchase.
B. At its option, Kaz will repair or replace this product if it is found to be defective in
material or workmanship.
C. This warranty does not cover damage resulting from any unauthorized attempts to
repair or from any use not in accordance with the instruction manual.
Call us toll-free at 1-800-477-0457 or e-mail: [e-mail].
Please be sure to specify the reference number. NOTE: IF YOU EXPERIENCE
A PROBLEM, PLEASE CONTACT CONSUMER RELATIONS FIRST OR SEE YOUR
WARRANTY. DO NOT RETURN THE PRODUCT TO THE ORIGINAL PLACE OF PURCHASE.
DO NOT ATTEMPT TO OPEN THE DEVICE HOUSING YOURSELF, DOING SO MAY VOID
YOUR WARRANTY AND CAUSE DAMAGE TO THE PRODUCT OR PERSONAL INJURY.

13
8: Calibration
The thermometer is initially calibrated at the time of manufacture. If this thermometer
is used according to the use instructions, periodic re-adjustment is not required. If at any
time you question the accuracy of temperature measurements, please contact us.
9: EMC Declaration
1. This equipment needs to be installed and put into service in accordance with the
information provided in the ACCOMPANYING DOCUMENTS;
This product needs special precautions regarding EMC and needs to be installed
and put into service according to the EMC information provided, and this unit can
be affected by portable and mobile RF communications equipment.
2. Do not use a mobile phone or other devices that emit electromagnetic fields,
near the unit. This may result in incorrect operation of the unit.
3. This unit has been thoroughly tested and inspected to assure proper performance
and operation.
4. This machine should not be used adjacent to or stacked with other equipment and
that if adjacent or stacked use is necessary, this machine should be observed to verify
normal operation in the configuration in which it will be used.
Guidance and manufacturer’s declaration – electromagnetic immunity
The VNT275 is intended for use in the electromagnetic environment specified below.
The customer or the user of the VNT275 should ensure that it is used in such an
environment.
Phenomenon Basic EMC standard
or test method
Immunity Test Levels
Home Healthcare Environment
Electrostatic Discharge IEC 61000-4-2 ±8 kV contact
±2 kV, ±4 kV, ±8 kV, ±15 kV air
Radiated RF EM fieldsaIEC 61000-4-3 10 V/mf
80 MHz – 2,7 GHzb
80% AM at 1 kHzc
Proximity fields from RF
wireless communications
equipment
IEC 6100-4-3 See RF wireless communication
equipment immunity table below
Rated power frequency
magnetic fieldsd, e
IEC 6100-4-8 30 A/mg
50 Hz or 60 Hz

14
Guidance and manufacturer’s declaration – electromagnetic immunity
a) The interface between the PATIENT physiological signal simulation, if used, and the ME
EQUIPMENT or ME SYSTEM shall be located within 0,1 m of the vertical plane of the uniform
field area in one orientation of the ME EQUIPMENT or ME SYSTEM.
b) ME EQUIPMENT and ME SYSTEMS that intentionally receive RF electromagnetic energy for
the purpose of their operation shall be tested at the frequency of reception. Testing may be
performed at other modulation frequencies identified by the RISK MANAGEMENT PROCESS.
This test assesses the BASIC SAFETY and ESSENTIAL PERFORMANCE of an intentional receiver
when an ambient signal is in the passband. It is understood that the receiver might not
achieve normal reception during the test.
c) Testing may be performed at other modulation frequencies identified by the RISK
MANAGEMENT PROCESS.
d) Applies only to ME EQUIPMENT and ME SYSTEMS with magnetically sensitive components
or circuitry.
e) During the test, the ME EQUIPMENT or ME SYSTEM may be powered at any NOMINAL
input voltage, but with the same frequency as the test signal. (see Table 1)
f) Before modulation is applied.
g) This test level assumes a minimum distance between the ME EQUIPMENT or ME SYSTEM
and sources of power frequency magnetic field of at least 15 cm. If the RISK ANAYLSIS
shows that the ME EQUIPMENT or ME SYSTEM will be used closer than 15 cm to sources of
power frequency magnetic field, the IMMUNITY TEST LEVEL shall be adjusted as appropriate
for the minimum expected distance.
Guidance and manufacturer’s declaration – electromagnetic emissions
The VNT275 equipment is intended for use in the electromagnetic environment specified
below. The customer or the user of the VNT275 should ensure that it is used in such an
environment.
Emissions Test Compliance Electromagnetic environment – guidance
RF Emissions
CISPR 11
Group 1 The ME equipment uses RF energy only for its
internal function. Therefore, its RF emissions
are very low and are not likely to cause any
interference in nearby electronic equipment.
RF Emissions
CISPR 11
Class B Complies
Harmonic emissions
IEC 61000-3-2
Not
Applicable The ME equipment is
solely battery powered
Voltage fluctuations/
flicker emissions
Not
Applicable

15
Guidance and manufacture’s declaration –
RF wireless communication equipment immunity
Test
frequency
(MHz)
Banda
(MHz)
Servicea Modulation
b
Maximum
power
(W)
Distance
(m)
Immunity
Test Level
(V/m)
385 380 –
390
TETRA 400
Pulse
modulationb
18 Hz
1,8 0,3 27
450 430 –
470
GMRS 460,
FRS 460
FMc
±5 kHz
deviation
1 kHz sine
20,3 28
710
704 –
787
LTE Band
13, 17
Pulse
modulationb
217 Hz
0,2 0,3 9745
780
810
800 –
960
GSM
800/900.
TETRA 800,
IDEN 820,
CDMA 850,
LTE Band 5
Pulse
modulationb
18 Hz
20,3 28
870
930
1720
1700 –
1990
GSM 1800,
CDMA 1900,
GSM 1900,
DECT,
LTE Band 1, 3,
4, 25, UMTS
Pulse
modulationb
217 Hz
20,3 28
1845
1970
2450 2400 –
2570
Bluetooth,
WLAN,
802.11 b/g/n,
RFID 2450,
LTE Band 7
Pulse
modulationb
217 Hz
20,3 28
5240
5100 –
5800
WLAN
802.11,
a/n
Pulse
modulationb
217 Hz
0,2 0,3 95500
5785
a) For some services, only the uplink frequencies are included. b) The carrier shall be modulated using a
50% duty cycle square wave signal. c) As an alternative to FM modulation, 50% pulse modulation at
18 Hz may be used because while it does not represent actual modulation, it would be worst case.

Manual del Usuario
REF VNT275US
Termómetro Infrarrojo
Corporal Sin Contacto

Prólogo
Las Instrucciones de Operación del Termómetro Infrarrojo Corporal Sin Contacto están
diseñadas para proporcionar la información necesaria para la correcta operación del
termómetro VNT275US. El conocimiento general del Termómetro Infrarrojo Corporal
Sin Contacto y el entendimiento de las características y las funciones del termómetro
VNT275US son requisitos previos para un uso adecuado. El Termómetro Infrarrojo
Corporal Sin Contacto es un dispositivo médico y se puede utilizar repetidamente
durante 1 año. Por favor lea el manual antes de utilizar el dispositivo, si no entiende
completamente estas instrucciones de uso, no use el termómetro.
No opere el termómetro VNT275US sin leer y comprender
completamente estas instrucciones.
AVISO
La compra o posesión de este dispositivo no conlleva ninguna licencia explícita
o implícita para utilizar con repuestos que pudieran corresponder, por sí solos o
en conjunto con este dispositivo, estén dentro del ámbito de una de las patentes
relacionadas.
