Vicon KOL-3000 User manual

Vicon Part No. 8009-8019-01-00 Section 5 Rev 401
XX019-01-00
KOL-3000/3000P
Security Terminal
Digital Video Recording System
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your
requirements or that the operation will be entirely error free or perform precisely as described in the
documentation. This system has not been designed to be used in life-critical situations and must not be
used for this purpose.
Copyright © 2001 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
Kollector and its logo are registerted trademarks of Vicon Industries Inc.
Kollector uses proprietary Hybrid MPEG/wavelet technology and is property of Sungjin C&C Co., Ltd.
Patents pending
Windows is a registered trademark of Microsoft.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TELEPHONE: 631-952-CCTV (2288) FACSIMILE: 631-951-CCTV (2288)
24-Hour Technical Support: 800-34-VICON (800-348-4266)
TOLL FREE: 800-645-9116 UK: 44/(0) 1489-566300 INFOFAX: 800-287-1207






FCC Notice
NOTE:Complies with Federal Communications Commission Rules & Regulations Part 15,
Subpart B for a Class A digital device.
WARNING
This equipment generates and uses radio frequency energy and if not installed and used
properly, that is, in strict accordance with the manufacturer’s instruction, may cause
interference to radio and television reception. It has been type tested and found to comply
with the limits for a Class A computing device in accordance with the specification in subpart
B of part 15 of the FCC rules, which are designed to provide reasonable protection against
such interference in a commercial installation. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
interference to radio and television reception, which can be determined by turning
equipment off and on, the user is encouraged to try and correct the interference by one or
more of the following measures:
• Reorient the receiving antenna.
• Relocate the equipment with respect to the receiver.
• Relocate the equipment away from the receiver.
• Plug the equipment into a different electrical outlet so that the
equipment and receiver are on different branch circuits.
If necessary, the user should consult the dealer or an experienced radio/television
technician for additional suggestions.
The user may find the following booklet prepared by the Federal Communications
Commission helpful:
“Interference Handbook, Bulletin CIB-2”
This booklet is available from the U.S. Government Printing Office, Superintendent of
Documents, Mailstop SSOP, Washington, D.C. 20402-9328, ISBN 0-16-045542-1.
WARNING: Power must be removed from this unit before removing circuit modules or
Ribbon Cables.
CAUTION: This unit contains circuit cards with integrated circuit devices that can be
damaged by static discharge. Take all necessary precautions to prevent
static discharge.



Important Safeguards
GRAPHIC SYMBOL EXPLANATION
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert
the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the literature
accompanying the unit.
1. Read Instructions - All the safety and operating instructions should be read before the
video product is operated.
2. Retain Instructions - All the safety and operating instructions should be retained for
future reference.
3. Heed Warnings - All warnings on the video product and in the operating instructions
should be adhered to.
4. Follow Instructions - All operating and use instructions should be followed.
5. Cleaning - Step aapplies to equipment that can be disconnected from the CCTV system
without seriously jeopardizing security. Step b applies to equipment that must operate
continuously such as video switching equipment at military installations.
a. Disconnect this video product from its power source before cleaning. Do not use
caustic, abrasive, or aerosol cleaners. Use a damp cloth for cleaning.
b. Use a damp cloth to clean the equipment. Do not allow moisture or liquids to enter any
vents. Do not use caustic, abrasive, or aerosol cleaners.
6. Attachments - Do not use attachments not recommended by Vicon as they may cause
hazards.



7. Water and Moisture - Do not use this video product in any location where it may be
exposed to water or moisture. This does not apply to outdoor camera housings, outdoor
pan-and-tilt drives, and other equipment designed for direct exposure to outdoor
environments.
8. Accessories - Do not place this video product on any unstable surface or table. The
video product may fall, causing serious injury to a person and serious damage to the video
product. Useonlywithamountingaccessory recommended by Vicon, or sold with the video
product. Any mounting of the video product should follow Vicon’s instructions, and a
mounting accessory recommended by Vicon should be used.
9. Ventilation - If slots and openings are provided in the cabinet, they are to provide
ventilation, ensure reliable operation and protect it from overheating. The openings should
never be blocked by placing the video product on a rug or other similar surface. This video
product should never be placed near or over a radiator or heat register. This video product
should not be placed in a built-in installation such as a bookcase or rack unless proper
ventilation is provided or Vicon’s instructions have been adhered to.
10. Power Sources - This video product should be operated only from the type of power
source indicated on the marking label. If you are not sure of the type of power supplied to
your installation site, consult your Vicon dealer or local power company. For video products
intended to operate from battery power, or other sources, refer to the operating instructions.
11. Grounding - This applies to video products equipped with a 3-wire grounding-type plug,
a plug having a third (grounding) pin. This plug only fits into a grounding-type power outlet.
This is a safety feature. If you are unable to insert the plug into the outlet, contact your
electrician to replace your obsolete outlet. Do not defeat the safety purpose of the
grounding-type plug.
12. Power-Cord Protection - Power supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or against them, paying particular
attention to cords at plugs, convenience receptacles, and the point where they exit from the
video product.
13. Outdoor Cable Grounding - If an outside cable system is connected to the video
product, be sure the cable system is grounded so as to provide some protection against
voltage surges and built-up static charges. Section 810 of the National Electrical Code,
ANSI/NFPA 70-1984, provides information with respect to proper grounding of the lead-in
wire to an antenna discharge unit, size of grounding conductors, location of antenna-
discharge unit, connection to grounding electrodes, and requirements for the grounding
electrode.
14. Lightning - For added protection for this video product when it is not used for long
periods of time, disconnect it from its power source and from the cable system. This
prevents damage to the video product due to lightning and power-line surges.



15. Power Lines - An outside cable system should not be located in the vicinity of overhead
power lines or other electric light or power circuits, or where it can fall into such power lines
or circuits. When installing an outside cable system, extreme care should be taken to keep
from touching such power lines or circuits as contact with them might be fatal.
16. Overloading - Do not overload wall outlets and extension cords as this can result in a
risk of fire or electric shock.
17. Object and Liquid Entry - Never push objects of any kind into this video product
through openings as they may touch dangerous voltage points or short out parts that could
result in a fire or electric shock. Never spill liquid of any kind on the video product.
18. Servicing - Do not attempt to service this video product yourself as opening or removing
covers may expose you to dangerous voltage or other hazards. Refer all servicing to
qualified service personnel.
19. Damage Requiring Service - Disconnect this video product from its power source and
refer servicing to qualified service personnel under the following conditions. Note that step c
does not apply to outdoor camera housings, outdoor pan-and-tilt drives and other equipment
specifically designed for direct exposure to outdoor environments.
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the video product.
c. If the video product has been exposed to rain or water.
d. If the video product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions, as an improper
adjustment of other controls may result in damage and will often require extensive work
by a qualified technician to restore the video product to its normal operation.
e. If the video product has been dropped or the cabinet has been damaged.
f. When the video product exhibits a distinct change in performance - this indicates a need
for service.
20. Replacement Parts - When replacement parts are required, be sure the service
technician has used replacement parts specified by Vicon or that have the same
characteristics as the original part. Unauthorized substitutions may result in fire, electric
shock, or other hazards.
21. Safety Check - Upon completion of any service or repairs to this video product, ask the
service technician to perform safety checks to determine that the video product is in proper
operating condition.
22. ESD Precaution - All normal precautions to avoid component damage due to
Electrostatic discharge should be taken during installation and operation.



Introduction
How to Use this Manual
This manual was designed to provide the best overall instructions for the installation and
operation of this product. The graphics and terminology used in this manual have been
carefully selected to enable a clear and distinct understanding of Kollector and its
components. This manual has been formatted to present distinct methods of installation for
experienced and novice installers.
Unpacking and Inspection
All Vicon equipment is tested and inspected before leaving the factory. It is the carrier’s
responsibility to provide suitable delivery. Inspect the cartons upon delivery and, if damage
is present, make detailed notes on the carrier’s bill. Then, obtain the carrier agent’s
signature and file a damage claim as soon as possible.
Open the cartons and inspect the equipment for damage. Save the cartons and packing
material. If damage is present, contact the carrier and file a damage claim immediately. If
the equipment must be returned to Vicon for repair, follow the instructions in the Shipping
Information section of this manual.
Kollector complies with FCC Class A computing device requirements and complies with
European Community EMC Directive 89/336. The product was subjected to the testing
outlined in European Normalization Standard EN 50081-1 (Electromagnetic Compatibility-
General Emissions Standard Part 1: Residential, Commercial and Light Industry), and EN
50082-1 (Electromagnetic Compatibility-General Immunity Standard Part 1: Residential,
Commercial, and Light Industry).
Vicon strongly recommends the use of line conditioners, voltage regulators for all systems
and components.
NOTE: Read all instructions before beginning any installation.
NOTE: The following instructions are “typical.” It may be necessary to deviate from them for
any particular installation.



Warning
Electric Safety
To reduce a risk of fire or electrical shock,
do not expose this product to rain or moisture.
Caution
Lithium Battery
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type
recommended by the manufacturer.
Dispose of used batteries according
to the manufacturer’s instructions.
Socket-Outlet
The socket-outlet shall be installed near the equipment
and shall be easily accessible.



Table of Contents
Using Kollector
Basic Operation of Kollector .............................................................................11
Screen Layout ..................................................................................................12
Selecting Customized Functions .......................................................................21
Camera Setting .............................................................................................22
Network ........................................................................................................28
Sensor 32
Camera Control ............................................................................................36
Video Input Signal Adjustment...........................................................................44
Kollector Setup...................................................................................................45
Kollector Upgrade..............................................................................................53
Using Kollector Viewer
Basic Operation of Kollector Viewer ..................................................................55
Screen Layout........................................................................................................57
Using Kollector
Dial-up
Installation of Kollector Dial-up ..........................................................................74
Basic Operation of Kollector Dial-up .................................................................77
Screen Layout ..................................................................................................79
Connection .......................................................................................................83
Setting Customized Functions .........................................................................86


 
Using Kollector
Kollector is a user-friendly digital security system that helps businesses
and individuals to effectively manage and protect their valuable properties
and assets from theft and other artificial and/or natural disasters.


 
Basic Operations of Kollector
Kollector is ready for use after proper installation of system program.
1. Plug the power cable of Kollector into the wall outlet.
2. Kollector
starts operation after a routine start-up procedure.
3. The recording automatically starts in 3 seconds after a proper execution of
Kollector
program.
The recorded files are saved on the hard disk by each channel, date and time.
4. To stop the recording, click on
Stop Recording
button on the bottom right side
of the
screen.


 
Screen Layout
The screen layout of Kollector is user-friendly to allow even novice users to easily
learn and use the system.
2
15
3
5
6
8
10
11
13 14
1
7
4
16
9
12


 
1) Current Recording Screen
Current
video recording of live images are displayed on the current recording
screen.
* Note
When the mouse pad is returned to the original position by pressing Push mark, the
Current Recording Screen is enlarged and displayed on entire screen. The indicator
and button bars are instantly retreated from the screen for effective full-screen
image surveillance.
2) Transmission Status Indicator
Transmission Status Indicator flashes whenever off-site users are accessing
Kollector system either through a network or phone line connection. It also
indicates that Kollector Dial-up is connected and is
transmitting images.
* Note
When Transmission Status Indicator flashes, double-click the indicator to view
information on current users connected to the system via Dial-up.
When the system is not connected, double-click the indicator to view full connection
history. The system checks the administrator’s password before the history is
displayed.


 
3) Sensor Indicator
The
indicator flashes when the alarm sensor is activated.
* Note
Double-click Sensor Indicator to check the event list. Kollector Log Viewer appears
to show the list of occurred events by date and type of event.
4) Recording Status Indicator
The indicator shows recording status and is animated when Kollector is
recording images.
5) Time
The current time is displayed in hours, minutes, and seconds format.
6) Date
Current date is displayed in year, month, and day format.
Kollector has an internal clock that maintains the date and time.


 
To change the date and time,
1. Click on the figures that show date and time on the Kollector main screen and
then enter proper password using the keyboard icon ( )
2. After entering the password, the date/time setting box appears.
3. Select the desired date and time by using down-arrow button and then click
Modify button.


 
* Daylight Saving Time
To set daylight saving time, user can select either the equivalent country or the
starting and finish time.
Both functions can be executed by checking on “Automatically adjust clock for
daylight saving changes”.
* Note
Kollector stops recording if date/time setting has been changed. Click Start
Recording button to start recording with new date/time setting.
7) Start Recording
Starts recording of live images.
8) Stop Recording
Stops recording of live images.


 
9) Overlay Button
Overlay function is image-display in real-time(30fps) mode in PC monitor. It
provides users with more vivid and clearer motion-pictures in surveillance.
When you press ( ) button on the bottom of main screen, set up window will
appear. This makes possible to see the current screen as real time images
using overlay function. ( It is possible to set the same screen as TV monitor )
!
warning - Overlay card has to be built- in . If it had not, Kollector system does
not show button on the screen.
Overlay Setup

One channel or four channel mode should be selected in
order to set up overlay.

Click on the overlay button ( ) on main Kollector screen, then the
dialogue box will appear on top right.
(Dialogue box of Ovelay Setup )

Functions of each tab on dialogue box.
: Replace current data on screen display with originally
initialized data.
: Real time image screen shows the cameras title in PC
monitor. It does not appear on TV monitor
10) Starting Kollector Viewer
Starts Kollector
Viewer search engine. Refer to
Using Kollector Viewer
section for detailed instructions on using Kollector Viewer.


 
1
2
3
4
5
6
11) Selecting Customized Functions
Starts the customized function screen on which the recording range, image
quality, recording time, etc. can be selected. Refer to Selecting Customized
Functions section for detailed instructions.
12) Camera Control Button
Enables users to instantly control Pan/Tilt/Zoom, Focus, Iris and Preset
position on the main Kollector screen.
Click on to display Camera Control Unit
on top
right of the screen.
1.Pan/Tilt: Camera with installed P/T controller
will move in each direction while the
button is pressed down.
2. Zoom: The size of image will be enlarged or
reduced while the button is pressed
down.
3.Focus: Objects on the screen will be focused
while the button is pressed down.
4.Iris: Adjusts the brightness of image by
opening or closing the Iris
5.Preset: Instantly moves the camera to a selected
preset position.
6. Preset name box: Displays the title of each preset position.
13) Channel Selection
S witches fast and conveniently between several channels to view images from
each camera. 16 numbered-buttons correspond to each camera connected to
the system.
Example: Number 2 button corresponds to camera number 2.
14) Next Channel
Images
from next numbered-camera are displayed on current recording screen
each time
Next Channel
button is clicked.


 
15) Display Mode/Split Screen Mode
Splits
the current recording screen to display 1, 4, 6, 9, 13, or 16 cameras
simultaneously on a single screen. ( The number in the picture corresponds to
the number of cameras).
When
the number of a split - screen mode is more than the actual
number of cameras connected to the system, the vacant screen
displays the VICON logo.
Example:
When 6-screen mode is selected on a 4-amera system, the screens
for
channel number 5 and 6 will display the VICON logo.
* Note
Viewing Enlarged Screen
A particular screen on 4, 6, 9, 13, or 16 split-screen mode can be instantly
enlarged for detailed inspection of the image. Click left mouse button on the
desired screen for instant enlargement of the image.
To return to the previous mode, click desired mode button again.
2
1
3
4 5 6
6-screen mode
1 2
3 4
4-screen mode
1
1-screen mode
1 2 3 4
5 6 7 8
9 10 11 12
13 14 15 16
16-screen mode
2 3
1
4 5
6 7 8 9
10 11 12 13
13-screen mode
1 2 3
4 5 6
7 8 9
9-screen mode
3
1 2
3 4
Click on
number 3 screen


 
16) Kollector Info
Double
click the VICON logo(
)
on the right bottom of main screen to view
general information on the
Kollector system.
