Victaulic FireLock NXT 764 Series User manual

HANG THESE INSTRUCTIONS ON THE
INSTALLED VALVE FOR EASY FUTURE REFERENCE
WARNING
• Failuretofollowinstructionsandwarningscancauseproduct
failure,resultinginseriouspersonalinjuryandpropertydamage.
• Readandunderstandallinstructionsbeforeattemptingto
installanyVictaulicpipingproducts.
• Wearsafetyglasses,hardhat,andfootprotection.
• Savethisinstallation,maintenance,andtestingmanualfor
futurereference.
Ifyouneedadditionalcopiesofanyliterature,orifyouhaveany
questionsconcerningthesafeinstallationandoperationofthis
product,contactVictaulic,P.O.Box31,Easton,PA18044-0031,
USA,Telephone:1-800PICKVIC,e-mail:[e-mail].
WARNING
FireLockNXT™AlternateWet/DryValve
SERIES764
I-764
INSTALLATION,MAINTENANCE,ANDTESTINGMANUAL
www.victaulic.com
VICTAULIC IS A REGISTERED TRADEMARK OF VICTAULIC COMPANY. © 2007 VICTAULIC COMPANY. ALL RIGHTS RESERVED. PRINTED IN THE USA.
REV_C

TABLEOFCONTENTS
Hazard Identification ......................................1
Installer Safety Instructions .................................2
General ..............................................2
Maintenance and Testing .................................2
Introduction .............................................3
Trim Dimensions .........................................3
Exploded View Drawing – Trim Components ....................4
Exploded View Drawing – Internal Valve Components..............5
Section View Drawing and Description –
Series 776 Low-Pressure Actuator ..........................6
Section View Drawing and Description –
Series 746-LPA Dry Accelerator............................7
Air Supply Requirements ...................................8
Compressor Sizing ......................................8
Base or Riser-Mounted Air Compressors .....................8
Shop Air or Tank-Mounted Air Compressors...................8
Victaulic Series 757 Regulated Air Maintenance
Trim Assembly (AMTA) Option ...........................8
Victaulic Series 757P Air Maintenance Trim Assembly
(AMTA) with Pressure Switch Option ......................9
Compressor Requirements and Settings for
Series 769 FireLock NXT Preaction Valves
Installed with Series 746-LPA Dry Accelerators ..............9
Settings for Air Supervisory Pressure Switches
and Alarm Pressure Switches ...........................9
Remote System Test Valve Requirements.....................9
Important Installation Information ...........................10
Valve/Trim Installation ....................................10
Compression Fitting and Tube Installation ...................11
Hydrostatic Testing ......................................11
Setup Instructions for Placing the Dry Configuration in Service .....12
Setup Instructions for Converting the Dry Configuration to the Wet
Configuration .........................................18
External Inspection ......................................20
Weekly Inspection for the Dry Configuration..................20
Weekly Inspection for the Wet Configuration .................20
Monthly Inspection for the Dry Configuration .................20
Monthly Inspection for the Wet Configuration .................21
Required System Tests ...................................22
Main Drain Test for the Dry Configuration ...................22
Main Drain Test for the Wet Configuration ...................23
Water Flow Alarm Test for the Dry or Wet Configuration .........24
Water Level and Low Air Alarm Tests for the Dry Configuration ...26
Required Operational (Trip) Tests for the Dry Configuration ........29
Partial Operational (Trip) Test for the Dry Configuration .........29
Full Operational (Trip) Test for the Dry Configuration ...........31
Required Internal Inspection ...............................32
Maintenance ...........................................35
Removing and Replacing the Clapper Seal...................35
Removing and Replacing the Clapper Assembly...............37
Installing the Cover Plate Gasket and Cover Plate..............39
Removing and Replacing the Diaphragm Assembly ............40
Replacing the Strainer Screen for
Series 776 Low-Pressure Actuators . . . . . . . . . . . . . . . . . . . . . . 41
Troubleshooting – Series 776 Low-Pressure Actuator .............42
Troubleshooting – Series 746-LPA Dry Accelerator...............42
Troubleshooting – Dry Configuration .........................42
Troubleshooting – Wet Configuration .........................43
HAZARD IDENTIFICATION
Definitions for identifying the various hazard levels are
provided below. When you see this symbol, be alert to the
possibility of personal injury. Carefully read and fully
understand the message that follows.
WARNING
Theuseoftheword“WARNING”identifiesthepresenceof•
hazardsorunsafepracticesthatcouldresultindeathorseri-
ouspersonalinjuryifinstructions,includingrecommended
precautions,arenotfollowed.
CAUTION
Theuseoftheword“CAUTION”identifiespossiblehazardsor•
unsafepracticesthatcouldresultinpersonalinjuryandproduct
orpropertydamageifinstructions,includingrecommendedpre-
cautions,arenotfollowed.
NOTICE
Theuseoftheword“NOTICE”identifiesspecialinstructions•
thatareimportantbutnotrelatedtohazards.
I-764_1
FireLockNXT™AlternateWet/DryValve
SERIES764
I-764INSTALLATION,MAINTENANCE,ANDTESTINGMANUAL
www.victaulic.com
VICTAULIC IS A REGISTERED TRADEMARK OF VICTAULIC COMPANY. © 2007 VICTAULIC COMPANY. ALL RIGHTS RESERVED. PRINTED IN THE USA.
REV_C

INSTALLER SAFETY INSTRUCTIONS
WARNING
Anexperienced,trainedinstallermustinstallthisproductinaccordancewithallinstructions.These•
instructionscontainimportantinformation.
Depressurizeanddrainthepipingsystembeforeattemptingtoinstall,remove,adjust,ormaintainany•
Victaulicpipingproducts.
Failuretofollowtheseinstructionscancauseproductfailure,resultinginseriouspersonalinjuryand/or
propertydamage.
GENERAL
Readandunderstandallinstructionsandrefertothetrim1.
diagramsbeforeproceedingwiththeinstallation,maintenance,
andtestingofthisVictaulicSeries764FireLockNXTAlternate
Wet/DryValve.
Inspecttheshipment.2. Make sure all components are included in
the shipment and that all necessary tools are available for installa-
tion.
Useonlyrecommendedaccessories.3. Accessories and equipment
that are not approved for use with this valve may cause improper
system operation.
Wearsafetyglasses,hardhat,footprotection,andhearing4.
protection. Wear hearing protection if you are exposed to long
periods of noisy job-site operations.
Preventbackinjury.5. Larger and pre-trimmed valves are heavy and
require more than one person or mechanical lifting equipment to
position and install the assembly. Always practice proper lifting
techniques.
Avoidusingelectricallypoweredtoolsindangerousenviron-6.
ments. When using electrically powered tools for installation, make
sure the area is moisture-free. Keep the work area well lit, and
allow enough space to accommodate proper installation of the
valve, trim, and accessories.
Watchforpinchpoints.7. Do not place fingers under the valve
body where they could be pinched by the weight of the valve. Use
caution around spring-loaded components (i.e. clapper assembly).
Keepworkareasclean.8. Cluttered areas, benches, and slippery
floors can create hazardous working conditions.
PROTECTTHESYSTEMFROMFREEZINGCONDITIONS.THE9.
VALVEANDSUPPLYPIPINGMUSTBEPROTECTEDFROM
FREEZINGTEMPERATURESANDMECHANICALDAMAGE.
IFTHEINLETWATERSUPPLYISINTERRUPTEDFORANY10.
REASON,ANDSYSTEMSUPPLYPRESSURETOTHEVALVE
DECREASES,MAKESURETHEDIAPHRAGMCHARGELINEIS
FULLYPRESSURIZEDBEFOREPLACINGTHESYSTEMBACK
INSERVICE.
MAINTENANCEANDTESTING
Notifytheauthorityhavingjurisdiction.1. Always notify the author-
ity having jurisdiction before performing any maintenance that
eliminates the fire protection provided by the system.
FollowNFPArequirementsforsystemtestingandinspection2.
schedules. The building owner or their representative is responsi-
ble for inspecting the system in accordance with current NFPA-25
requirements or in accordance with the requirements of the local
authority having jurisdiction (whichever is more stringent).
Depressurizeanddrainthesystemcompletelybeforeperforming3.
anymaintenance. Water under pressure can cause the cover plate
to blow off during removal if the system is not depressurized and
drained completely.
Protectthevalvefromfreezingtemperatures,foreignmatter,4.
andcorrosiveatmospheres. Any condition that might degrade the
system or affect system performance must be avoided.
I-764_2
FireLockNXT™AlternateWet/DryValve
SERIES764
I-764
INSTALLATION,MAINTENANCE,ANDTESTINGMANUAL
www.victaulic.com
VICTAULIC IS A REGISTERED TRADEMARK OF VICTAULIC COMPANY. © 2007 VICTAULIC COMPANY. ALL RIGHTS RESERVED. PRINTED IN THE USA.
REV_C

INTRODUCTION
The following instructions are a guide for proper installation of Victaulic Series 764 FireLock NXT Alternate Wet/Dry Valves. These instructions involve
pipe that is properly prepared and grooved in accordance with current Victaulic specifications.
NOTICE
Drawingsand/orpicturesinthismanualmaybeexaggeratedforclarity.•
Thisproductandthisinstallation,maintenance,andtestingmanualcontaintrademarks,copyrights,and/orpatentedfeaturesthatarethe•
exclusivepropertyofVictaulic.
TRIMDIMENSIONS
THE4-INCH/114.3-MMCONFIGURATIONISSHOWNBELOW.1–2-INCH/48.3–60.3-MMCONFIGURATIONSCONTAIN-INCH/19-MMDRAINVALVES.
2–3-INCH/73.0–88.9-MMCONFIGURATIONSCONTAIN1-INCH/31-MMDRAINVALVES.4–8-INCH/114.3–219.1-MMCONFIGURATIONSCONTAIN2-INCH/50-MMDRAINVALVES.
GG1*
B
*B1
L
J
H
A
D
A1*
C1*
K
F
E
E1*
Size Dimensions–Inches/mm
Approx.
WeightEach
lbs/kg
Nominal
Size
Inches
mm
Actual
Outside
Dia.
Inches
mm AA1* BB1* C1* D E E1* F G G1* H J KL
Without
Trim
With
Trim
1 ½ 1.900 9.00 16.31 32.50 34.50 16.50 9.75 12.50 15.00 15.75 9.25 11 . 25 10.20 8.50 3.04 6.98 16.7 43.0
40 48.3 228.60 414.27 825 876 419 247 317 381 400 234 285 259.08 215.90 77.21 177. 29 7.6 19.5
22.375 9.00 16.31 32.50 34.50 16.50 9.75 12.50 15.00 15.75 9.25 11. 2 5 10.20 8.53 3.04 6.98 17.0 43.0
50 60.3 228.60 414.27 825 876 419 247 317 381 400 234 285 259.08 216.66 77.21 177.29 7.7 19.5
2 ½ 2.875 12.61 16.44 36.75 44.25 21.25 11. 2 5 14.50 18.25 16.75 10.00 9.75 10.65 9.04 3.76 6.69 41.0 65.0
65 73.0 320.29 417.57 933 1123 539 285 368 463 425 254 247 270.51 229.61 95.50 169.92 18.7 29.5
76.1 mm 3.00 12.61 16.44 36.75 44.25 21.25 11. 2 5 14.50 18.25 16.75 10.00 9.75 10.65 9.04 3.76 6.69 41.0 65.0
76.1 320.29 417.57 933 112 3 539 285 368 463 425 254 247 270.51 229.61 95.50 169.92 18.7 29.5
33.500 12.61 16.44 36.75 44.25 21.25 11. 2 5 14.50 18.75 16.75 10.00 9.75 10.65 9.04 3.76 6.69 41.0 65.0
80 88.9 320.29 417.57 933 112 3 539 285 368 476 425 254 247 270.51 229.61 95.50 169.92 18.7 29.5
44.500 15.03 19.78 38.00 45.50 21.00 10.25 16.00 20.75 15.50 11. 2 5 10.75 13.54 9.56 6.06 8.46 59.0 95.0
100 114.3 381.76 502.41 965 1155 533 260 406 527 393 285 273 343.91 242.82 153.92 214.88 26.7 43.0
165.1 mm 6.500 16.00 22.00 38.25 45.75 20.00 10.25 17. 25 22.25 15.75 11 .50 11. 0 0 13.46 9.94 6.06 8.38 80.0 116 .0
165.1 406.40 558.80 971 1162 508 260 438 565 400 292 279 341.88 252.47 153.92 212. 85 36.2 52.6
66.25 16.00 22.00 38.25 45.75 20.00 10.25 17. 2 5 22.25 15.75 11 .50 11. 0 0 13.46 9.94 6.06 8.38 80.0 116 .0
150 168.3 406.40 558.80 971 1162 508 260 438 565 400 292 279 341.88 252.47 153.92 212.85 36.2 52.6
88.625 17. 50 23.01 38.25 45.75 18.75 10.00 19.00 24.25 16.00 11. 75 11. 0 0 14.80 11. 0 0 6.06 9.72 122.0 158.0
200 219.1 444.50 584.45 971 1162 476 254 482 615 406 298 279 375.92 279.40 153.92 246.88 55.3 71.6
NOTES:
The “A” dimension coupling is not shown in order to clarify dimensional callouts.
Components shown as dotted lines denote optional equipment.
* Measurements denoted with an asterisk take optional equipment into account.
Optional drain connection kit is shown for reference and takeout dimensions.
I-764_3
FireLockNXT™AlternateWet/DryValve
SERIES764
I-764INSTALLATION,MAINTENANCE,ANDTESTINGMANUAL
www.victaulic.com
VICTAULIC IS A REGISTERED TRADEMARK OF VICTAULIC COMPANY. © 2007 VICTAULIC COMPANY. ALL RIGHTS RESERVED. PRINTED IN THE USA.
REV_C

EXPLODEDVIEWDRAWING–TRIMCOMPONENTS
SERIES764FIRELOCKNXTALTERNATEWET/DRYVALVE
(OPTIONALACCESSORIESALSOSHOWN)
5
4
B
Location
2
3
From Water
Supply
To
System
From System
Air Feed
Open – Dry
Closed – Wet
Remove trim from this point up when
installing the optional dry accelerator.
The air gauge (Item 18) must remain in place.
Add a tee to the accelerator to
re-position the air gauge
Remove this plug
when utilizing a
supervisory switch
15
24
9
26
8
23
13
14
16
6
29
30
22
20
22
12
10
27
11
17
22
7
1
Alarm Test Valve
(Normally Closed)
Closed – Dry
Open – Wet
Closed – Dry
Open – Wet
Remove this plug
when utilizing a
supervisory switch
Open – Dry
Closed – Wet
28
21
When eld installation of
a “manual pull station” is
performed, remove this plug
and install necessary ttings.
Open – Dry
Closed – Wet
25
B
To Drip Cup
Location
B
To Drip Cup
Location
B
To Drip Cup
Location
B
To Drip Cup
Location
19
18
Bill of Materials
1Series 764 FireLock NXT Alternate
Wet/Dry Valve
2FireLock Rigid Coupling (Optional/Sold
Separately – Comes Standard when VQR
Assembly is Ordered)
3Water Supply Main Control Valve
(Optional/Sold Separately – Comes
Standard when VQR Assembly is Ordered)
4Drain Swing Check Valve
5Drip Cup with Cap
6Alarm Pressure Switch (Optional/Sold
Separately – Comes Standard when VQR
Assembly is Ordered)
7Series 729 Drip Check Valve
8Diaphragm-Charge-Line Ball Valve
(Lockable – Open/Dry, Closed/Wet)
93-in-1 Strainer/Check/Restrictor
Assembly
10 Series 760 Water Motor Alarm
(Optional/Sold Separately)
11 Alarm Test Ball Valve
12 Diaphragm-Charge-Line Pressure Gauge
(0 – 300 psi/0 – 2068 kPa/0 – 20.7 Bar)
13 Series 749 Auto Drain
1 4 Series 746-LPA Dry Accelerator
Assembly (Optional/Sold Separately)
15 Series 776 Low-Pressure Actuator
16 Air Manifold
17 Air Supervisory Pressure Switch
(Optional/Sold Separately – Comes
Standard when VQR Assembly is Ordered)
18 Dry System Air Pressure Gauge
(0 – 80 psi/0 – 552 kPa/0 – 5.5 Bar with Retard)
19 Water Supply Main Drain Valve -
Flow Test
2 0 Water Supply Pressure Gauge
(0 – 300 psi/0 – 2068 kPa/0 – 20.7 Bar)
2 1 Drain Connection Kit (Optional/Sold
Separately – Comes Standard when VQR
Assembly is Ordered)
2 2 Gauge Valve
2 3 System Main Drain Valve
2 4 Series 748 Ball Check Valve
2 5 Dry System Air Supply Ball Valve
(Lockable – Open/Dry, Closed/Wet)
26 Wet System Bypass Ball Valve
(Lockable – Closed/Dry, Open/Wet)
2 7 Dry Check Isolation Ball Valve
(Lockable – Open/Dry, Closed/Wet)
28 Alarm Line Drain Ball Valve
(Lockable – Closed/Dry, Open/Wet)
29 Series 755 Manual Pull Station (Optional/
Sold Separately)
30 Wet System Pressure Gauge
(0 – 300 psi/0 – 2068 kPa/0 – 20.7 Bar)
Note 1
NOTE1: Connection point for the Series 75D Water Column Device Kit
For information regarding installation of the Series 75B Supplemental Alarm Device or the Series 7C7 Air Maintenance/Compressor Assembly (not
pictured), refer to the instructions supplied with the product. NOTE: When the Series 75D Water Column Device kit is installed in the trim of a Series
764 FireLock NXT Alternate Wet/Dry Valve, a ball valve must be added to the inlet of the Series 75D. This inlet ball valve must be closed while the
valve is in the “wet configuration” to prevent water from continuously draining from the system.
I-764_4
FireLockNXT™AlternateWet/DryValve
SERIES764
I-764
INSTALLATION,MAINTENANCE,ANDTESTINGMANUAL
www.victaulic.com
VICTAULIC IS A REGISTERED TRADEMARK OF VICTAULIC COMPANY. © 2007 VICTAULIC COMPANY. ALL RIGHTS RESERVED. PRINTED IN THE USA.
REV_C

EXPLODEDVIEWDRAWING–INTERNALVALVECOMPONENTS
Clapper Seal
Latch
Clapper
Diaphragm
Assembly
Seat
Exaggerated for Clarity
NOTE:VALVEISSHOWNABOVEINTHE“SET”POSITION
Bill of Materials
1 Valve Body 12 Cover Plate
2Clapper 13 Cover Plate Gasket
3Clapper Seal 14 Cover Plate Bolts*
4Seal Ring 15 Latch
5Seal Washer 16 Latch Spring
6Seal Retaining Ring 17 Latch Spring Bushing and O-ring (Qty. 2)
7Seal Assembly Bolt 18 Diaphragm
8Bolt Seal 19 Diaphragm Cover
9Clapper Spring 20 Diaphragm Cover Cap Screws (Qty. 8)
10 Clapper Shaft 21 Latch Shaft
11 Clapper Shaft Bushing and O-ring (Qty. 2)
1
12
11
17
17
11
21
20
94
3
18
19
7
5
8
15
16
14
13
210
6
* NOTE: The 1½-inch/48.3-mm and 2-inch/60.3-mm valve sizes contain washers under the heads of
the cover plate bolts.
I-764_5
FireLockNXT™AlternateWet/DryValve
SERIES764
I-764INSTALLATION,MAINTENANCE,ANDTESTINGMANUAL
www.victaulic.com
VICTAULIC IS A REGISTERED TRADEMARK OF VICTAULIC COMPANY. © 2007 VICTAULIC COMPANY. ALL RIGHTS RESERVED. PRINTED IN THE USA.
REV_C

SECTIONVIEWDRAWINGANDDESCRIPTION–
SERIES776LOW-PRESSUREACTUATOR
The Series 776 Low-Pressure Actuator is located in the trim of Series
764 FireLock NXT Alternate Wet/Dry Valves and acts as the trigger for
the system when it is set in the dry configuration.
Diaphragms separate the low-pressure actuator into three chambers.
The upper air chamber controls activation, while the middle and lower
chambers act as the water valve.
During setup, system air is applied to the upper chamber of the low-
pressure actuator. When the Auto Vent Sleeve of the low-pressure
actuator is pulled up, the upper chamber manually sets. Air pressure in
the upper chamber holds the Auto Vent closed, while it exerts force on
the water seal of the middle chamber.
When the diaphragm charge line is opened, water enters the lower
chamber of the low-pressure actuator. Water that enters the low-pres-
sure actuator flows to the middle chamber through the inlet eyelet,
which is pressurized by system air pressure in the upper chamber.
Since the area of the lower diaphragm (exposed to water pressure in
the middle chamber) is greater than the area of the lower chamber, the
lower chamber seals off. Water does not flow to the outlet of the low-
pressure actuator, and the supply water pressure creates the water seal.
When system air pressure decays to 0.5 Bar/48 kPa/7 psi, the force
exerted by the compression spring in the Auto Vent is greater than the
force exerted by air in the upper chamber. The Auto Vent opens, and all
air pressure in the upper chamber evacuates.
The upper diaphragm releases water pressure in the middle chamber
of the low-pressure actuator, which allows the lower diaphragm to lift
and water to flow from the inlet to the outlet. This flow of water releases
pressure from the diaphragm charge line of the Series 764 FireLock
NXT Alternate Wet/Dry Valve, thus allowing the diaphragm to retract.
The clapper opens, and water flows into the sprinkler system.
VENT TO ATMOSPHERE
INLET
AIR IN
OUTLET
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Exaggerated for Clarity
Bill of Materials
1 Auto Vent Sleeve 9Lower Diaphragm Assembly
2Auto Vent Screw 10 Strainer Screen (Replaceable)
3Auto Vent Assembly 11 Strainer O-Ring Seal
4Upper Chamber 12 Strainer Assembly
5Upper Diaphragm Wave Spring 13 Inlet Eyelet
6Lower Diaphragm Wave Spring 14 Middle Chamber
7Outlet Eyelet 15 Upper Diaphragm Assembly
8Lower Chamber
I-764_6
FireLockNXT™AlternateWet/DryValve
SERIES764
I-764
INSTALLATION,MAINTENANCE,ANDTESTINGMANUAL
www.victaulic.com
VICTAULIC IS A REGISTERED TRADEMARK OF VICTAULIC COMPANY. © 2007 VICTAULIC COMPANY. ALL RIGHTS RESERVED. PRINTED IN THE USA.
REV_C

SECTIONVIEWDRAWINGANDDESCRIPTION–
SERIES746-LPADRYACCELERATOR
The Series 746-LPA Dry Accelerator is a quick-opening device, which
exhausts air from the Series 776 Low-Pressure Actuator to speed valve
operation.
A diaphragm separates the Series 746-LPA Dry Accelerator into two
chambers. The closing chamber contains a compression spring, which
maintains the chamber in the closed position. The closed position is
maintained as long as the pressure differential between the opening and
closing chambers is less than 0.2 Bar/21 kPa/3 psi.
When the system introduces air pressure into the dry accelerator, air
enters the closing chamber and passes through a check valve to the
opening chamber. The check valve, which allows flow into the open-
ing chamber, prevents pressure from escaping the opening chamber.
Therefore, air can escape only through the restrictor.
When a rapid loss of system air pressure occurs, such as an open
sprinkler, air escapes from the closing chamber faster than it escapes
from the opening chamber. As the sprinkler system’s pressure continues
to decay, a differential pressure develops across the diaphragm. When
this differential pressure reaches 0.2 – 0.3 Bar/21 – 34 kPa/3 – 5 psi,
the opening chamber’s pressure overcomes the compression spring’s
closing force, causing the closing chamber to open to the atmosphere.
The closing chamber opens immediately and releases pressure from the
actuator, resulting in valve operation.
Exaggerated for Clarity
To Pressure
Gauge
Air Inlet
CROSS-SECTION WITH UPPER CHAMBER ROTATED
45° AND BOLT REMOVED FOR CLARITY
Bill of Materials
1 Opening/Air Chamber 9O-Ring
2Restrictor 10 Seal Support
3Piston 11 Closing Chamber Seal
4O-Ring 12 Button-Head Cap Screw
5Diaphragm 13 Washer
6Actuator Shaft 14 Adjustable Seat
7Closing Chamber 15 Check Valve
8Compression Spring
15
1
14
13
11
12
8
6
7
10
2
3
5
4
9
4
I-764_7
FireLockNXT™AlternateWet/DryValve
SERIES764
I-764INSTALLATION,MAINTENANCE,ANDTESTINGMANUAL
www.victaulic.com
VICTAULIC IS A REGISTERED TRADEMARK OF VICTAULIC COMPANY. © 2007 VICTAULIC COMPANY. ALL RIGHTS RESERVED. PRINTED IN THE USA.
REV_C

AIRSUPPLYREQUIREMENTS
The required air pressure for Series 764 FireLock NXT Alternate Wet/
Dry Valves is 0.9 Bar/90 kPa/13 psi minimum, regardless of the system
supply pressure. Normal air pressure should not exceed 1.2 Bar/
124 kPa/18psi. Failure to maintain air pressure within the 0.9 Bar/
90 kPa/13psi to 1.2 Bar/124 kPa/18psi range could delay system
operation response time.
Systems with air pressure higher than 1.2 Bar/124 kPa/18 psi may
require the addition of a Series 746-LPA Dry Accelerator. NOTE: The
Series 746-LPA Dry Accelerator must be used only on systems operat-
ing below 2.1 Bar/207 kPa/30 psi of air. If air pressure higher than
2.1 Bar/207 kPa/30 psi is required, the Series 746 Dry Accelerator
should be used.
If multiple Series 764 FireLock NXT Alternate Wet/Dry Valves are
installed with a common air supply, isolate the systems with a spring-
loaded, soft-seated ball check valve to ensure air integrity for each sys-
tem. Good practice is to include a ball valve for isolation and service of
each individual system.
Set the air pressure to the required system air pressure. Air pressure
differing from the required system air pressure could delay system
operation response time.
The engineer/system designer is responsible for sizing the compressor
so that the entire system is charged to the required air pressure within
30 minutes. DO NOT oversize the compressor to provide more airflow.
An oversized compressor will slow down or possibly prevent valve
operation.
If the compressor fills the system too fast, it may be necessary to
restrict the air supply. Restricting the air supply will ensure that air
being exhausted from an open sprinkler or manual release valve is not
replaced by the air supply system as fast as it is being exhausted.
COMPRESSORSIZING
0
2
4
6
8
10
12
System Capacity (in gallons)
Required Flow Rate (CFM)
COMPRESSOR REQUIREMENTS
550 300
50
800
1050 1300 1550 1800
20 psi/138 kPa
13 psi/90 kPa
BASEORRISER-MOUNTEDAIRCOMPRESSORS
For base or riser-mounted air compressors, the recommended air
pressure of 0.9 Bar/90 kPa/13 psi is the “on” or “low” pressure setting
for the compressor. The “off” or “high” pressure setting should be
1.2 Bar/124 kPa/18psi.
When a base or riser-mounted air compressor supplies air to a Series
764 FireLock NXT Alternate Wet/Dry Valve, it is not necessary to install
the Victaulic Series 757 Regulated Air Maintenance Trim Assembly
(AMTA). In this case, the air line of the compressor connects to the trim
at the fitting where the Series 757 Regulated AMTA is normally installed
(refer to the applicable trim drawing). If the compressor is not equipped
with a pressure switch, the Series 757P Air Maintenance Trim Assembly
with Pressure Switch should be installed.
SHOPAIRORTANK-MOUNTEDAIRCOMPRESSORS
In the event a compressor becomes inoperative, a properly sized tank-
mounted air compressor provides the greatest protection for systems.
When shop air or a tank-mounted air compressor is used, the Series
757 Regulated AMTA must be installed. The Series 757 Regulated
AMTA provides proper air regulation from the air reservoir to the
sprinkler system. For tank-mounted air compressors, the recommended
air pressure of 0.9 Bar/90 kPa/13 psi should be used as the set point
for the air regulator. The “on” pressure of the compressor should be at
least
0.3 Bar/24 kPa/5 psi above the set point of the air regulator.
VICTAULICSERIES757REGULATEDAIRMAINTENANCETRIM
ASSEMBLY(AMTA)OPTION
NOTICE
VictaulicrecommendsamaximumoftwoSeries764FireLock•
NXTAlternateWet/DryValvesperSeries757Regulated
AMTA.
16
5
4
2
3
Bill of Materials
1 ⁄"/3.2 mm Restrictor
2Slow Fill Ball Valve (Normally Open)
3Air Regulator
4Strainer (100 Mesh)
5Spring-Loaded, Soft-Seated
Ball Check Valve
6Fast Fill Ball Valve (Normally Closed)
I-764_8
FireLockNXT™AlternateWet/DryValve
SERIES764
I-764
INSTALLATION,MAINTENANCE,ANDTESTINGMANUAL
www.victaulic.com
VICTAULIC IS A REGISTERED TRADEMARK OF VICTAULIC COMPANY. © 2007 VICTAULIC COMPANY. ALL RIGHTS RESERVED. PRINTED IN THE USA.
REV_C

VICTAULICSERIES757PAIRMAINTENANCETRIMASSEMBLY
(AMTA)WITHPRESSURESWITCHOPTION
NOTICE
VictaulicrecommendsamaximumoftwoSeries764FireLock•
NXTAlternateWet/DryValvesperSeries757PAMTAwith
PressureSwitch.
RefertotheI-757PAirMaintenanceTrimAssemblywith•
PressureSwitchInstallationInstructions,suppliedwiththe
product,forcompleteinstallation,electrical,andpressure
switchadjustmentinformation.
5
2
12
7
8
15
10
16
9
6
4
1
13
3
14
11
TO
SYSTEM
FROM
COMPRESSOR
Bill of Materials
Item Qty. Description
1 1 Restrictor (½-inch NPT)
2 1 Strainer (½-inch NPT)
3 1 Swing Check (½-inch NPT)
4 1 Slow-Fill Ball Valve
(Normally Open)
5 1 Spring-Loaded, Soft-Seated
Check Valve
6 1 Pressure Switch
7 2 Compression Fitting, Straight
(¼-inch NPT x ¼-inch Tube)
8 1 Copper Tubing (¼-inch OD)
9 11 Close Nipple
(½-inch NPT x 1.13)
10 1 Nipple (½-inch NPT x 4.00)
11 1 90° Female Elbow (½-inch NPT)
12 4 Female Tee (½-inch NPT)
13 3 Union (½-inch NPT)
14 2 Reducing Bushing
(½-inch NPT x ¼-inch NPT)
15 1 Fast-Fill Ball Valve
(Normally Closed)
16 1 Pressure Switch Isolation Ball
Valve (Normally Open -
Lockable)
COMPRESSORREQUIREMENTSANDSETTINGSFORSERIES764
FIRELOCKNXTALTERNATEWET/DRYVALVESINSTALLEDWITH
SERIES746-LPADRYACCELERATORS
Set the air regulator of the Series 757 Regulated AMTA to a minimum of
0.9 Bar/90 kPa/13 psi.
TheSeries757PAirMaintenanceTrimAssemblywithPressure
SwitchMUSTNOTbeusedonaSeries764FireLockNXTAlternate
Wet/DryValveinstalledwithaSeries746-LPADryAccelerator,unless
atankandairregulatorareadded.
In the event a compressor becomes inoperative, a properly sized tank-
mounted air compressor provides the greatest protection for systems
installed with a Series 746-LPA Dry Accelerator. In this situation, air can
be supplied continuously to the sprinkler system for an extended time
period. NOTE: The Series 757 Regulated AMTA should be used with
a tank-mounted air compressor to supply air to a Series 764 FireLock
NXT Alternate Wet/Dry Valve when the Series 746-LPA Dry Accelerator
is used. The use of an air regulator with a base or riser-mounted air
compressor could cause short cycling, resulting in premature wear of
the compressor.
The air regulator of the Series 757 Regulated AMTA is a relief-type
design. Any pressure in the system that is above the set point of the air
regulator will be released. Therefore, charging the air regulator above
the set point could cause premature operation of a valve installed with a
Series 746-LPA Dry Accelerator.
SETTINGSFORAIRSUPERVISORYPRESSURESWITCHESAND
ALARMPRESSURESWITCHES
Air supervisory pressure switches are required for dry systems and must
be set according to the following notes:
Wire the air supervisory pressure switches to activate a low-1.
pressure alarm signal. NOTE: In addition, the local authority having
jurisdiction may require a high-pressure alarm. Contact the local
authority having jurisdiction for this requirement.
1a. Set the air supervisory pressure switches to activate at
0.1 – 0.3 Bar/14 – 28 kPa/2 – 4 psi below the minimum air
pressure required (but not lower than 0.7 Bar/69 kPa/10psi).
1b. Wire the alarm pressure switch to activate a water flow alarm.
1c. Set the alarm pressure switch to activate on a pressure rise of
0.3 – 0.6 Bar/28 – 55 kPa/4 – 8psi.
REMOTESYSTEMTESTVALVEREQUIREMENTS
The remote system test station (inspector’s test connection) contains a
valve, which can be opened to simulate the operation of a sprinkler.
The remote system test valve (inspector’s test connection) should be
located at the most hydraulically demanding location in the release
system. NOTE: Multiple restrictions on the remote system test valve
(inspector’s test connection) may slow the air decay rate and cause the
system to respond slower than required.
The remote system test valve (inspector’s test connection) should termi-
nate with an orifice equal to the smallest orifice in the releasing system.
The remote system test valve (inspector’s test connection) is used to
ensure that water reaches the most remote part of the system within 60
seconds.
I-764_9
FireLockNXT™AlternateWet/DryValve
SERIES764
I-764INSTALLATION,MAINTENANCE,ANDTESTINGMANUAL
www.victaulic.com
VICTAULIC IS A REGISTERED TRADEMARK OF VICTAULIC COMPANY. © 2007 VICTAULIC COMPANY. ALL RIGHTS RESERVED. PRINTED IN THE USA.
REV_C

IMPORTANTINSTALLATIONINFORMATION
1. For proper operation and approval, the Series 764 FireLock NXT
Alternate Wet/Dry Valve must be installed in accordance with the
specific trim diagrams included with the shipment. NOTE: Victaulic
provides specific trim diagrams for vertical installations and instal-
lations involving a Series 746-LPA Dry Accelerator.
2. Before installing the Series 764 FireLock NXT Alternate Wet/Dry
Valve, flush the water supply piping thoroughly to remove all
foreign material.
3. Series 764 FireLock NXT Alternate Wet/Dry Valves MUST NOT
be located in an area where the valve can be exposed to freezing
temperatures. In addition, the Series 764 FireLock NXT Alternate
Wet/Dry Valve MUST NOT be located in an area where physical
damage may occur.
4. It is the system designer’s responsibility to confirm material
compatibility of the Series 764 FireLock NXT Alternate Wet/Dry
Valve, trim, and associated accessories when a corrosive environ-
ment or contaminated water is present.
5. SERIES764FIRELOCKNXTALTERNATEWET/DRYVALVES
MUSTBEINSTALLEDONLYINTHEVERTICALPOSITIONWITH
THEARROWONTHEBODYPOINTINGUPWARD.
6. Air or nitrogen supply to the dry piping system must be clean, dry,
and oil-free.
7. Air supplies must be regulated, restricted, and continuous.
8. When the Series 764 FireLock NXT Alternate Wet/Dry Valve is
used with a water motor alarm, Victaulic recommends the use
of an uninterrupted, low-pressure alarm that is installed on the
diaphragm charge line downstream of the strainer/check restric-
tor. Another option is to install a Series 75B Supplemental Alarm
Device.
9. Piping must be pitched so that systems can drain properly. For
areas that are subject to high levels of condensation, or where
piping is not properly pitched, an optional Series 75D Water
Column Device kit is available to assist in automatically draining
water out of the riser when the valve is in the “dry configuration.”
NOTE: When the Series 75D Water Column Device kit is installed
in the trim of a Series 764 FireLock NXT Alternate Wet/Dry Valve,
a ball valve must be added to the inlet of the Series 75D. This inlet
ball valve must be closed while the valve is in the “wet configura-
tion” to prevent water from continuously draining from the system.
VALVE/TRIMINSTALLATION
1. Make sure the trim drawing matches the system’s requirements.
CAUTION
Makesurethefoamspacerisremovedfrom•
insidethevalvebodybeforeattemptingto
installthevalve.
Failuretofollowthisinstructioncouldcause
impropervalveoperation,resultinginpersonal
injuryand/orpropertydamage.
2. Remove all plastic caps and foam spacers from the valve.
3. Apply a small amount of pipe joint compound or Teflon* tape to
the external threads of all threaded pipe connections. DO NOT get
any tape, compound, or other foreign material into the valve body,
pipe nipples, or valve openings.
CAUTION
Makesurenoforeignmaterialgetsintothevalvebody,pipe•
nipples,orvalveopenings.
IfusinganymaterialotherthanTeflontape,useextracaution•
sothatnomaterialgetsintothetrim.
Failuretofollowtheseinstructionscouldcauseimpropervalve
operation,resultinginpersonalinjuryand/orpropertydamage.
4. Install the valve, trim, and accessories per the trim drawing.
TO ACTUATOR
TRIM
5. FORVALVESINSTALLEDWITHASERIES746-LPADRY
ACCELERATOR: Make sure the Series 746-LPA Dry Accelerator is
installed in accordance with the trim drawing provided. The end
with the vent seal “button” must be installed facing down (toward
the trim, as shown above).
6. Supply pressure to the diaphragm charge line by providing an
uninterrupted source of water from upstream of the main control
valve.
* Teflon is a registered trademark of the DuPont Company
I-764_10
FireLockNXT™AlternateWet/DryValve
SERIES764
I-764
INSTALLATION,MAINTENANCE,ANDTESTINGMANUAL
www.victaulic.com
VICTAULIC IS A REGISTERED TRADEMARK OF VICTAULIC COMPANY. © 2007 VICTAULIC COMPANY. ALL RIGHTS RESERVED. PRINTED IN THE USA.
REV_C

CompressionFittingandTubeInstallation
Compression Fitting and Tube Configuration
for Auto Drain and Drip Check
Compression Fitting and Tube Configuration
for Actuator
Compression fittings and tubes are provided for connection from the
outlet of the auto drain, drip check, and actuator to the drip cup or
drain. These compression fittings and tubes must be installed, in accor-
dance with the trim drawing provided. NEVER insert a plug into the out-
let of the auto drain, drip check, or actuator in place of the compression
fitting/tube.
HYDROSTATIC TESTING
WARNING
Ifairtestingisrequired,DONOTexceed•
3.4Bar/345kPa/50psiairpressure.
Failuretofollowthisinstructioncouldresult
inseriouspersonalinjuryand/orproperty
damage.
The Victaulic Series 764 FireLock NXT Alternate Wet/Dry Valve is
approved for a maximum working pressure of 20.7 Bar/
2068 kPa/300 psi and is factory tested to 41.4 Bar/4137 kPa/600 psi for
all sizes. The valve can be hydrostatically tested against the clapper at
13.8 Bar/1379 kPa/200 psi or 3.4 Bar/345 kPa/50 psi above the normal
water supply pressure (2-hour limited time period) for acceptance by
the authority having jurisdiction.
I-764_11
FireLockNXT™AlternateWet/DryValve
SERIES764
I-764INSTALLATION,MAINTENANCE,ANDTESTINGMANUAL
www.victaulic.com
VICTAULIC IS A REGISTERED TRADEMARK OF VICTAULIC COMPANY. © 2007 VICTAULIC COMPANY. ALL RIGHTS RESERVED. PRINTED IN THE USA.
REV_C

SETUPINSTRUCTIONSFORPLACINGTHEDRY
CONFIGURATION IN SERVICE
CAUTION
TheSeries764FireLockNXTAlternateWet/DryValveand•
supplypipingmustbeprotectedfromfreezingtemperatures
andmechanicaldamage.
Failuretofollowthisinstructioncouldcauseimpropervalve
operation,resultinginpersonalinjuryand/orpropertydamage.
1. Open the system main drain valve. Confirm that the system is
drained.
2. Close the system main drain valve.
3. Confirm that all system drains are shut and that the system is free
of leaks.
3a. Confirm that the system has been depressurized. The gauges
should indicate zero pressure.
4. If a Series 746-LPA Dry Accelerator is installed, confirm that the
isolation ball valve is closed.
5. If a Series 746-LPA Dry Accelerator is installed, open the ¼-turn
vent ball valve.
6. Open the dry system air supply ball valve.
I-764_12
FireLockNXT™AlternateWet/DryValve
SERIES764
I-764
INSTALLATION,MAINTENANCE,ANDTESTINGMANUAL
www.victaulic.com
VICTAULIC IS A REGISTERED TRADEMARK OF VICTAULIC COMPANY. © 2007 VICTAULIC COMPANY. ALL RIGHTS RESERVED. PRINTED IN THE USA.
REV_C

7. Close the wet system bypass ball valve.
8. Open the drip check isolation ball valve.
9. Close the alarm line drain ball valve.
10. Open the diaphragm-charge-line ball valve.
Screw
(Not in “set”
position)
Seal
Compression
Fitting
Drain
Hose
Body
Spring
Stem
Screw
(In “set”
position)
Sleeve
11. Confirm that water is flowing steadily from the Auto Drain. Pull up
on the Auto Drain Sleeve, and confirm that water is flowing through
the Series 776 Low-Pressure Actuator.
I-764_13
FireLockNXT™AlternateWet/DryValve
SERIES764
I-764INSTALLATION,MAINTENANCE,ANDTESTINGMANUAL
www.victaulic.com
VICTAULIC IS A REGISTERED TRADEMARK OF VICTAULIC COMPANY. © 2007 VICTAULIC COMPANY. ALL RIGHTS RESERVED. PRINTED IN THE USA.
REV_C

12. Close the diaphragm-charge-line ball valve.
13. Confirm that the alarm test ball valve is closed.
14. Charge the system with air by turning on the compressor or by
opening the fast-fill ball valve on the AMTA (fast-fill ball valve is
shown above). Charge the system to 0.9 Bar/90 kPa/13 psi mini-
mum. Refer to the “Air Supply Requirements” section.
14a. Confirm that the system is charging by observing the air pressure
gauge. If the gauge is not showing an increase in air pressure,
there is a leak or an opening in the line. Repair any leaks or
openings and restart the setup procedures.
14b. Confirm that no water is being exhausted from the Auto Vent of
the Series 776 Low-Pressure Actuator. If water is being exhausted
from the Auto Vent, continue to run air through the system in
order to remove moisture from the upper chamber of the Series
776 Low-Pressure Actuator. If a Series 746-LPA Dry Accelerator is
installed, make sure the accelerator is not flooded.
15. When the system reaches approximately 0.7Bar/69 kPa/10psi,
and no additional moisture is being released from the Auto Vent,
pull up on the Auto Vent Sleeve of the Series 776 Low-Pressure
Actuator. NOTE: The Auto Vent Screw should seal and remain in
the set (“UP”) position.
16. When system air pressure is established, close the fast-fill ball
valve on the AMTA.
I-764_14
FireLockNXT™AlternateWet/DryValve
SERIES764
I-764
INSTALLATION,MAINTENANCE,ANDTESTINGMANUAL
www.victaulic.com
VICTAULIC IS A REGISTERED TRADEMARK OF VICTAULIC COMPANY. © 2007 VICTAULIC COMPANY. ALL RIGHTS RESERVED. PRINTED IN THE USA.
REV_C

17. Open the slow-fill ball valve on the AMTA. NOTE: Failure to leave
the slow-fill ball valve open may allow system pressure to drop,
resulting in valve operation in the event of a system leak.
18. Open the diaphragm-charge-line ball valve. Allow water to flow
through the Auto Drain tube.
19. Pull up on the Auto Drain Sleeve until the screw is in the set
(“UP”) position. Verify that there is pressure on the gauge to the
diaphragm charge line.
20. When the diaphragm charge line is pressurized, temporarily close
the diaphragm-charge-line ball valve. Confirm that the diaphragm
charge line is maintaining pressure by observing the diaphragm-
charge-line pressure gauge (Item #12 on page 4).
20a. If pressure in the diaphragm charge line drops, the diaphragm
must be replaced and/or any leaks in the diaphragm charge line
must be corrected. Refer to the “Removing and Replacing the
Diaphragm Assembly” section.
20b. If pressure in the diaphragm charge line does not drop, re-open
the diaphragm-charge-line ball valve, and proceed to the following
step.
I-764_15
FireLockNXT™AlternateWet/DryValve
SERIES764
I-764INSTALLATION,MAINTENANCE,ANDTESTINGMANUAL
www.victaulic.com
VICTAULIC IS A REGISTERED TRADEMARK OF VICTAULIC COMPANY. © 2007 VICTAULIC COMPANY. ALL RIGHTS RESERVED. PRINTED IN THE USA.
REV_C

21. If a Series 746-LPA Dry Accelerator is installed, close the ¼-turn
vent ball valve.
22. If a Series 746-LPA Dry Accelerator is installed, open the isolation
ball valve. This will set the accelerator.
23. Observe the system air pressure over a 24-hour period to confirm
system integrity. If there is degradation in system air pressure, find
and correct all leaks. NOTE: Victaulic recommends less than
0.1-Bar/10-kPa/1½-psi leakage in 24 hours.
24. Open the water supply main drain valve.
CAUTION
Takeprecautionswhenopeningthewatersupplymaincontrol•
valve,sincewaterwillflowfromallopensystemvalves.
Failuretofollowthisinstructioncouldresultinpropertydamage.
Water Supply Main
Control Valve
25. Open the water supply main control valve slowly until water flows
steadily from the open water supply main drain valve.
26. Close the water supply main drain valve when a steady flow of
water occurs.
I-764_16
FireLockNXT™AlternateWet/DryValve
SERIES764
I-764INSTALLATION,MAINTENANCE,ANDTESTINGMANUAL
www.victaulic.com
VICTAULIC IS A REGISTERED TRADEMARK OF VICTAULIC COMPANY. © 2007 VICTAULIC COMPANY. ALL RIGHTS RESERVED. PRINTED IN THE USA.
REV_C

27. Confirm that there is no leakage from the intermediate valve
chamber. The drip check in the alarm line should not be leaking
water or air.
Water Supply Main
Control Valve
28. If water is flowing from the drip check, close the water supply
main control valve, and start over at step 1. Refer to the
“Troubleshooting” section.
Water Supply
Main Control
Valve
29. Open the water supply main control valve fully.
30. Record the system air pressure and the water supply pressure.
31. Confirm that all valves are in their normal operating positions (refer
to the table to the right).
Valve
NormalOperating
PositionforDry
Configuration
Diaphragm-Charge-Line Ball Valve Open
Alarm Test Ball Valve Closed
Water Supply Main Control Valve Open
Water Supply Main Drain Valve Closed
System Main Drain Valve Closed
Isolation Ball Valve for Series 746-LPA Dry Accelerator
(if applicable) Open
¼-Turn Vent Ball Valve for Series 746-LPA Dry Accelerator
(if applicable) Closed
Slow-Fill Ball Valve of the Victaulic AMTA (if applicable) Open
Fast-Fill Ball Valve of the Victaulic AMTA (if applicable) Closed
Dry System Air Supply Ball Valve Open
Wet System Bypass Ball Valve Closed
Drip Check Isolation Ball Valve Open
Alarm Line Drain Ball Valve Closed
32. Notify the authority having jurisdiction, remote station alarm moni-
tors, and those in the affected area that the system is in service.
33. ONAWEEKLYBASIS,WHENTHEVALVEISRESETAFTERAN
OPERATIONALTEST(ORAFTERANYSYSTEMOPERATION):
The low-body drain valve and any low-point drain valves should
be partially opened and then closed to drain water that might
be present in the riser. Continue this procedure until all water is
released. NOTE: The optional Series 75D Water Column Kit can be
installed to automate this step.
I-764_17
FireLockNXT™AlternateWet/DryValve
SERIES764
I-764INSTALLATION,MAINTENANCE,ANDTESTINGMANUAL
www.victaulic.com
VICTAULIC IS A REGISTERED TRADEMARK OF VICTAULIC COMPANY. © 2007 VICTAULIC COMPANY. ALL RIGHTS RESERVED. PRINTED IN THE USA.
REV_C

SETUPINSTRUCTIONSFORCONVERTING
THE DRY CONFIGURATION TO THE WET
CONFIGURATION
CAUTION
TheSeries764FireLockNXTAlternateWet/DryValveand•
supplypipingmustbeprotectedfromfreezingtemperatures
andmechanicaldamage.
Forproperoperationofalarmsinawetsystem,itisimportant•
toremoveallairfromthesystem.Auxiliarydrainsmaybe
requiredtoreleasealltrappedairfromthesystem.
Failuretofollowtheseinstructionscouldcauseimpropervalve
operation,resultinginpersonalinjuryand/orpropertydamage.
1. Notify local fire companies that the system is being serviced.
2. Confirm that system drains are shut and the system is free of
leaks.
2a. Confirm that the system has been depressurized. The gauges
should indicate zero pressure.
3. Open the remote system test valve (inspector’s test connection)
and any auxiliary drains to remove all air from the system.
4. Confirm that the alarm test ball valve is closed.
5. Close the dry system air supply ball valve.
6. Open the wet system bypass ball valve.
7. Close the drip check isolation ball valve.
8. Open the alarm line drain ball valve.
I-764_18
FireLockNXT™AlternateWet/DryValve
SERIES764
I-764
INSTALLATION,MAINTENANCE,ANDTESTINGMANUAL
www.victaulic.com
VICTAULIC IS A REGISTERED TRADEMARK OF VICTAULIC COMPANY. © 2007 VICTAULIC COMPANY. ALL RIGHTS RESERVED. PRINTED IN THE USA.
REV_C
