OPERATORS MANUAL
AND PARTS LIST
MANUFACTURED AND SOLD BY:
“pick up with us”

We have spent a lot of time and money to design our products to the highest quality
standards… yours!
In order to continue to meet your expectations, we invite your comments.
Thank you for helping us to do the best for you.
Watch for this symbol. It identifies potential hazards to health or
personal safety. It points out safety precautions. It means:
ATTENTION - Be Alert. Your Safety is involved.
OPERATING SAFETY
1. Operate pickup smoothly avoiding sharp or
sudden turns, start and stops.
2. Watch where you are going, especially near
ditch slopes and around obstacles such as
trees, poles and towers.
3. Stay clear of machine when operating,
raising, or lowering pickup.
4. Do not use pickup for any other purpose than
what it is designed for.
TRANSPORT SAFETY
1. When transporting, always lift pickup as high
as possible.
2. Turn or maneuver combine slowly being
aware of pickup width.
3. Drive slowly over train tracks and rough
terrain.
MAINTENANCE SAFETY
1. Never adjust or lubricate machine while it is
moving or running.
2. Always use proper tools required for job.
3. Escaping hydraulic oil under pressure can
penetrate the skin causing serious injury. See
a doctor immediately if injured. Ensure all
connections are tight and all hoses are
undamaged. Before disconnecting any
hydraulic lines relieve all pressure in system.
4. Wear gloves and goggles and use a piece of
cardboard or wood as a backstop against
spurting fluid when searching for hydraulic
leaks.
5. Always maintain tire pressure at 10 PSI
Never stand over tire while inflating.
ASSEMBLY SAFETY
1. Prepare a clear work area large enough to
accommodate the pickup size.
2. At least two people should be available for
assembly, especially when lifting or aligning
heavy components.
SAFETY DECALS
1. Keep decals clean. Remove all dirt with wet
cloth when necessary.
2. Replace safety decals if destroyed, missing,
painted over, or unreadable.
3. If a part or section of the pickup is replaced
that carries a safety decal, apply a new decal
immediately.
4. New safety decals are available from your
Victory dealer.

WARRANTY
POLICY
Wheatheart Manufacturing will warrant each new Victory Pick Up to be free from factory
defects in material and workmanship under normal use and service when set up and operated in
accordance with factory instructions.
The Warranty will apply under the following conditions.
CONDITIONS
Wheatheart Manufacturing has received the Warranty Registration.
The Warranty will be limited to two years normal use.
The Warranty is limited to the supplying of replacement parts in exchange for parts defective due
to material or factory workmanship.
In cases where dealer personnel must be involved, a reasonable labor allowance will be allowed.
The Warranty is void on any unit that has been tampered with or has been subject to misuse,
negligence or accident.
The Warranty on belts is void if the failure is due to uneven roller tension, excess belt tension, or
weed wrapping on the rollers.
In case of belt failure the Warranty will be limited to belt replacement only under the following
conditions:
A. Apron belts (plain); belt replacement only.
B. Draper belts (with tines) replacement belt only, the user will be responsible for exchange of
tines.
PROCEDURE
Customer will have to bring the defective part to the dealer. Dealer will replace from his stock.
Dealer shall hold defective parts until disposal authorization is received.
Dealer must complete Warranty claim in full including serial number and date of sale and
forward to Wheatheart Manufacturing.

OPERATING YOUR PICKUP
1. Before operating the pickup, be sure that
all nuts are tight, all safety shields are in
place and belts not over tight.
2. Do not over tighten your belts, it will not
improve performance, it will only cause
more maintenance.
3. Operate the pickup at slow speeds to
assure that all parts operate freely.
4. The Super Series pickups are a unit body
design, which hinge on the combine
platform. In order to accommodate
various crop conditions, the drive roller
position is adjustable.
The tines should be at right angles to the
ground for best results as in the
illustration below. The distance of the
tines to the ground surface can be
adjusted by adjusting the wheel arm
spacers.
Fig. 1
Under normal conditions the pickup
should operate with the header
approximately twelve inches off the
ground.
Make sure that the castor wheels and
uprights are well greased prior to use.
The windguard can be adjusted for
varying conditions. In heavy canola
swath the unit can be moved up so as not
to interfere with the swath coming in.
We do not recommend operating the
pickup without the wind guard.
SPEED: The belt surface speed should
approximate the ground speed. To achieve
this the drive shaft RPM should be fifty
times ground speed in miles per hour. For
example at four miles per hour the drive
shaft should be operating at two hundred
RPM.
CAUTION: After three to four hours
operation the tines should be checked. Some
may require tightening.
For adverse swath conditions optional
double (Spyder) tines are available.

PICKUP PARTS LIST FOR SUPER 7 AND 8 BELT PICKUP
PLEASE CONSULT YOUR DIAGRAM TO DETERMINE PART NUMBER REQUIRED
Part # Description
1 359001 Pick up Tine
1 359100 Bag Tines (50)
2 129003 Elevator Bolt
2 129300 Bag Elevator Bolt (100)
3 29940 Flange Nut 1/4" - SEE
237100
3 237100 Bag 1/4" Nuts (100)
4 110001 Front Belt w. teeth &
fasteners (belt only)
4 999512 Front Belt w. teeth &
fasteners (complete)
5 138002 U bolt 1/2" x 3" X 2-5/8"
6 110003 Rear belt w/guide
6 999515 Rear belt w/guide &
fasteners (complete)
7 700531 Front strawguard
8 700530 Rear strawguard
9 30334 1/2" flange nut
10 700529 3/4" windguard bushing
11 12090 1/2x2" hex head bolt
12 403456 Windguard bracket left
12 403457 Windguard bracket right
13 403454 Windguard support 8 belt
13 403455 Windguard support 7 belt
14 403448 Windguard rod clamp
15 18605 1/2" flat washer
16 221007 Fibreglass rod (Pkg. 33)
16 221008 Fibreglass rod
17 700537 Windguard Adjuster bracket
(R)
17 700538 Windguard Adjuster bracket
(L)
18 12231 1/4x 3/4" hex bolt
19 18603 3/8" flat washer plated
20 700499 Caster cap tube
21 29803 3/8" flange nut
22 254001 Snapper pin
23 700521 Windguard support right
23 700522 Windguard support left
24 700545 9/16" spacer
25 700546 1-1/16" spacer
26 700547 1-11/16 spacer
27 700367 Axle bolt
28 707406 Left wheel arm
28 707407 Right wheel arm
29 360003 Tire soft trac
30 707687 Caster fork, Super
31 86754 3/4" Nylon Locknut
32 327001 Grease seal
33 404008 Long wheel spacer
34 1974 Bearing/wheel rim
35 404001 Wheel race for rim
36 402003 Rim c/w races
37 700503 3-1/2" roller Plain 8 belt
37 700508 3-1/2" roller Plain 7 belt
38 700504 Stabilizer bar 8 belt
38 700509 Stabilizer bar 7 belt
39 700501 Drive Roller 4-1/2" 8 belt
40 700502 3-1/2" roller c/w washer 8
belt
40 700507 3-1/2" roller c/w washer 7
belt
41 121063 3/8x6" full thread carriage
bolt
42 12112 5/8" nut
43 126071 7/16x 3/4" carriage bolt
44 12339 3/8x3/4" carriage bolt
45 700534 End guard
46 700645 Large bearing tightener
47 83003 1-1/4" bearing
48 5000001 #50 Roller Chain x 51"
49 700615 Keystock 1/4x1-1/2"
50 348080 50B14 sprocket
51 50029 5/8" flange nut
52 350001 5013 idler sprocket 5/8"
bore
53 157001 5/8" machinery bushing
54 700569R1 Large idler sprocket bracket
55 700582 Idler adjuster bolt
56 12111 5/8x2" hex bolt
57 700646 Small bearing tightener
58 700647 Tightener bracket
59 121059 3/8x4" full thread carriage
bolt
62 12131 3/8" nylon locknut
63 180004 Victory decal
64 347001 Cover latch spring
65 702580 Cover latch
66 700523 Cover plate left
66 700524 Cover plate right
67 403520 Warning rotating parts
decal
68 12012 3/8x3/4" hex bolt
69 700518 Gusset/cover
70 174003 Connecting link #50 chain
71 175003 Offset link #50 chain
86 702574 Pickup side right
86 702575 Pickup side left
87 700516 Fender right
87 700517 Fender left
89 232004 7/16" flange nut
90 7770 1/4" nut
90 18601 1/4" flat washer
90 129001 1/4x1/2" elevator bolt
90 701005 Fastener package for bolts
96 12110 5/8" lock washer
97 12072 5/8x1-1/4" hex bolt
98 12484 5/8" nylon locknut
107 415 Valve stem
109 8005 Lube fitting
110 12085 1/2x1-1/4" hex bolt
111 180006 Super 8 decal
111 180007 Super 7 decal
111 324007 Seal kit/Hyd motor
111 360010 Tire inner tube
112 157006 Bushing machinery 1-1/2"
heavy
113 12338 3/8x1" carriage bolt
114 18608 Washer steel 3/4"
118 - 5/8x2" carriage bolt
Hydraulic Drive Motor Kit
Part # Description
9 30334 1/2" flange nut
21 29803 3/8" flange nut
68 12012 3/8x3/4" hex bolt Gr5
100 177002 shaft coupler half
101 177005 shaft coupler half-keyed
102 203001 hydrualic motor
103 700999 motor mount
104 12038 3/8x1-1/4" hex bolt Gr5
105 12258 1/2x2-1/2" hex bolt Gr5
106 221012 rubber cushion
128 8800000 hydraulic motor guard
- 700615 1/4" keystock (1-1/4")
Table Rod Kit
Part # Description
9 30334 1/2" flange nut
62 12131 3/8" nylon locknut
79 704961 bushing 4-1/4"
80 171023 right hand swivel
80 171024 left hand swivel
81 14187 3/8x2" hex bolt Gr5
82 700525 table rod (5 foot)
83 500013 chain long link
84 176001 quick link
88 347004 table rod spring
116 26424 1/2x5-1/2" hex bolt Gr5
117 704960 header support bracket
- 12008 1/2x1-1/2" hex bolt Gr5
- 18605 1/2" flat washer
Shock Absorber Kit
Part # Description
9 30334 1/2" flange nut
80 171023 right hand swivel
80 171024 left hand swivel
119 700541 bushing 3-1/2"
120 703695 bushing 1/2"
121 720121 shock mount bracket
122 100462 long spring, stubble treader
123 98507 locking collar
124 82146 1/2x7" hex bolt
125 12083 1/2" nylon locknut
126 12540 1/2x2" hex bolt Gr5
127 18605 1/2" flat washer
128 703699 shock absorber
