Victrola Stream User manual

QUICK START
GUIDE

PLACE THE PLATTER ONTO
THE TURNTABLE.
SETUP YOUR TURNTABLE
CAREFULLY REMOVE THE
TAPED GUIDE STRING AND
PULL THE BELT OVER THE
MOTOR PIN. DISCARD
THE GUIDE STRING.
PLACE THE SLIPMAT ON
THE PLATTER.
INSERT THE HEADSHELL
INTO THE TONEARM
AND TIGHTEN THE
TONEARM COLLAR
COUNTER-CLOCKWISE
UNTIL HEADSHELL IS
SECURE.
ORTOFON 2M SERIES:
PUSH THE STYLUS COVER
TAB DOWN / FORWARD AND
GENTLY SLIDE THE
COVER OFF.
AUDIO TECHNICA VM95:
GENTLY SLIDE THE COVER
OFF OF THE CARTRIDGE.

ONCE ALIGNED WITH THE
CORRECT GROOVE, TURN
THE TOP SCREW
CLOCKWISE TO TIGHTEN
THE COUNTERWEIGHT.
SET THE ANTI-SKATE KNOB
WITHIN THE RECOMMENDED
RANGE: 1.5-2.0
note: you may need to adjust
the anti-skate if you notice
distortion, skipping, or
looping during playback.
33
45
USE THE SPEED
SELECTOR KNOB TO
SELECT YOUR
RECORD SPEED.
PLUG THE POWER CORD
INTO THE UNIT AND WALL
OUTLET. THE TURNTABLE
WILL AUTOMATICALLY
BOOT UP. ONCE THE
ILLUMINATED CONTROL
KNOB BEGINS FLASHING
GREEN, TURNTABLE IS
READY TO CONNECT TO
A NETWORK.
IDENTIFY YOUR CARTRIDGE.
SLIDE THE COUNTERWEIGHT
ONTO THE TONEARM UNTIL
IT IS ALIGNED TO THE
PROPER GROOVE.
ORTOFON 2M SERIES
COUNTERWEIGHT SLIDES TO
THE FIRST GROOVE.
AUDIO TECHNICA VM95 SERIES
COUNTERWEIGHT SLIDES TO
THE SECOND GROOVE.

DOWNLOAD
& CONNECT
DOWNLOAD THE VICTROLA STREAM APP AND FOLLOW
THE STEPS WITHIN THE APP TO CONNECT YOUR
TURNTABLE TO YOUR SONOS SYSTEM.
START
STREAMING

VPT-3000
INSTRUCTION MANUAL

TURNTABLE
OVERVIEW
TOP VIEW
BACK VIEW
AC POWER PORT
ETHERNET PORT
RCA OUTPUT
CONTROL KNOBORTOFON 2M RED CARTRIDGE
TONEARM
TONEARM
HOLDER
TONEARM
LIFT LEVER
ANTI-SKATE
KNOB
SLIPMAT
PL AT T ER
COUNTER
WEIGHT
SPEED
SELECTOR
45 RPM
ADAPTOR
REMOVABLE
HEADSHELL
DUST
COVER

TURNTABLE DUST COVER POWER CORD
REMOVABLE
HEADSHELL
45 RPM
ADAPTOR
COUNTER
WEIGHT
PL AT TE R SILICONE
SLIPMAT
PARTS
INCLUDED
SPECIFICATIONS
GENERAL
POWER REQUIREMENTS....................................................................... AC 100-240V~50/60HZ, 5W
DIMENSIONS (W X D X H).......................................................................16.93” X 13.58” X 4.37”
WEIGHT.......................................................................................................13.2 LBS
TURNTABLE
MOTOR.......................................................................................................DC BRUSHLESS STEPPER
WOW & FLUTTER .....................................................................................<0.175%
TONEARM......... ........................................................................................CARBON FIBER
EFFECTIVE ARM LENGTH ...................................................................... 225MM
OVERHANG...............................................................................................18.5MM
TRACKING ERROR ..................................................................................<2 DEGREES
PRE-INSTALLED CARTRIDGE ................................................................ORTOFON 2M RED

FAQ
GENERAL
POWER REQUIREMENTS....................................................................... AC 100-240V~50/60HZ, 5W
DIMENSIONS (W X D X H).......................................................................16.93” X 13.58” X 4.37”
WEIGHT.......................................................................................................13.2 LBS
TURNTABLE
MOTOR.......................................................................................................DC BRUSHLESS STEPPER
WOW & FLUTTER .....................................................................................<0.175%
TONEARM......... ........................................................................................CARBON FIBER
EFFECTIVE ARM LENGTH ...................................................................... 225MM
OVERHANG...............................................................................................18.5MM
TRACKING ERROR ..................................................................................<2 DEGREES
PRE-INSTALLED CARTRIDGE ................................................................ORTOFON 2M RED
TURNTABLE NOT SPINNING
• ENSURE YOU HAVE INSTALLED THE PLATTER BELT AND SELECTED A RECORD
SPEED USING THE SPEED SELECTOR KNOB.
TURNTABLE NOT STREAMING TO SONOS
• ENSURE YOU HAVE SELECTED A DEFAULT SONOS PLAYER OR GROUP WITHIN
THE VICTROLA APP AND AUTOPLAY IS ENABLED. IF AUTOPLAY IS DISABLED,
PRESS AND HOLD THE CONTROL KNOB FOR 1 SECOND TO SET YOUR
TURNTABLE AS THE SOURCE FOR YOUR DEFAULT SONOS PLAYER OR GROUP.
AUDIO IS SKIPPING WHEN STREAMING TO SONOS
• SKIPPING WHILE STREAMING IS MOST COMMONLY CAUSED BY POOR WI-FI
QUALITY. WITHIN THE VICTROLA STREAM APP, VISIT THE ADDITIONAL SETTINGS
PAGE OF YOUR TURNTABLE AND ADJUST THE WIRELESS AUDIO DELAY UNTIL
YOUR TURNTABLE NO LONGER SKIPS WHILE STREAMING.
TURNTABLE IS MAKING A HUMMING NOISE
• A HUMMING NOISE IS USUALLY CAUSED BY A GROUND LOOP ISSUE, REMOVING
AND REINSTALLING THE REMOVABLE HEADSHELL WILL USUALLY FIX THIS ISSUE.
CHANGE OR REPLACE A STYLUS OR CARTRIDGE
• VISIT STREAM.VICTROLA.COM/CARTRIDGE FOR STYLUS AND CARTRIDGE
REPLACEMENT INFORMATION.
ADDITIONAL FAQ
• STREAM.VICTROLA.COM/FAQ

CUSTOMER
SUPPORT
STREAM.VICTROLA.COM/SUPPORT
1(877)-553-6079
[e-mail]
USER
GUIDE
STREAM.VICTROLA.COM/GUIDE
