Viking FWCI1240GR Manual

REFRIGERATION
Undercounter/Freestanding 24”W. Wine Cellar
PLANNING AND DESIGN GUIDE
V I K I N G R A N G E . C O M • 1 - - V I K I N G 1
All models include:
• Electronic controls with digital
temperature readout
oInside temperature can be adjusted
from 40 – 65ºF
oFactory set at 50ºF
oSabbath mode
oTemperature can be displayed in
either Fahrenheit or Celsius
• Capacity—45 bottles
• Five full-extension wine shelves cradle
bottles horizontally to keep corks moist
o Shelves are coated to reduce vibration
and hold bottles snugly in place
o Shelves can be removed and
adjusted to store large bottles
• Dual pane and argon-filled Low-E
energy efficient glass doors protect
wine from harmful light
• Maple wood wine shelf fronts
• LED display lighting
• Forced air cooling system with
powerful 700 BTU compressor
• Tru-Flush™design allows unit to fit
flush in 24” deep cutout
• Undercounter or freestanding
installation
• Self-closing door
• Super quiet 32-39 db sound rating
• Black kickplate
• Must be ordered right or left hinge.
(As you face unit, RIGHT has hinge on
right side and handle on left side;
LEFT has hinge on left side and
handle on right side.)
VWCI1240G
Profess onal
FINISH DETAILS FOR FWCI MODEL
• Clear glass doors
• Stainless steel interior
• Handle not included—opt for custom
handle, or purchase a Viking
Professional Series handle kit (see
Installat on Notes & Accessor es).
• Accept 3/4”-thick custom wood frame
• See Custom Panels section or more
information and additional
specifications.
FINISH DETAILS FOR VWCI MODEL
• Clear and fluted glass doors
o Stainless Steel (SS)—stainless steel
frame around large window door,
stainless steel handle with chrome-
plated brackets, stainless steel
exterior cabinet, and stainless steel
interior.
FWCI1240G
Custom Panel
Standard Features & Accessories
ORDERING INSTRUCTIONS
First specify model number, then specify hinge preference (“R” for right or “L” for left), and then color code (VWCI1240GRSS).
R E L E A S E D 1 1 / 1 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
Model Options

REFRIGERATION
Undercounter/Freestanding 24”W. Wine Cellar
PLANNING AND DESIGN GUIDE
V I K I N G R A N G E . C O M • 1 - - V I K I N G 1
✪
Please see
Installat on Notes &
Accessor es
for important
information,
including handle
kits.
Dimensions & Specifications
VWCI1240G FWCI1240G
Ove all width 23-7/ ” (60.6 cm)
Ove all height (f om bottom) 34-1/4” ( 7.0 cm) min. to 35” ( 9.0 cm) max.
Ove all depth (f om ea )
To f ont of handle 26-9/16” (67.5 cm) Va ies
App ox. ship. weight 215 lbs. (98.0 kg)
VWCI1240G
Profess onal
FWCI1240G
Custom Panel
PRODUCT DIMENSIONS
See Custom Panels section for
more information and additional
specifications.
R E L E A S E D 1 1 / 1 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
22-1/16”
(56.0cm)
24-1/16”
(61.1cm)
26-9/16”
(67.5cm)
34-1/4”
(87.0cm)
min.
to
35”
(89.0cm)
max.
23-7/8”
(60.6cm)
23-7/8”
(60.6 cm)
23-7/8”
(60.6cm)
30-1/8”
(76.5cm)
PROFESSIONAL

PLANNING AND DESIGN GUIDE
V I K I N G R A N G E . C O M • 1 - - V I K I N G 1
REFRIGERATION
Undercounter/Freestanding 24”W. Wine Cellar
Dimensions & Specifications
DOOR SWING
See Custom Panels section for
more information and additional
specifications.
R E L E A S E D 1 1 / 1 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
FWCI1240G
Custom Panel
VWCI1240G
Profess onal
7-9/16”
(12.9 cm)
94.0 Swing
required for
pull-out shelf
clearance
2-27/32”
(5.6 cm) min.
clearance
from a corner
to achieve 94°
door swing
24-25/32”
(40.1 cm)
min. clearance
for door swing
Power cord 6-7/16”
(16.8 cm) off floor.*
50” (127.0 cm) area in which
electrical outlet must be located
PROFESSIONAL

REFRIGERATION
Undercounter/Freestanding 24”W. Wine Cellar
PLANNING AND DESIGN GUIDE
V I K I N G R A N G E . C O M • 1 - - V I K I N G 1
UTILITY
REQUIREMENTS
GAS
Not applicable
ELECTRICAL
• Three-wire cord
with grounded
three-prong plug
attached to
product
• 115V/60 Hz; 15
amp dedicated
circuit
• Maximum amp
usage—3.0
PLUMBING
Not applicable
Installation Requirements
34-1/2” (87.6 cm) min.
35-1/2” (90.2 cm) max.
24”
(61.0cm)
24” (61.0 cm)
ACCESS REQUIREMENTS
All models
Cutout width 24” (61.0 cm)
Cutout height 34-1/2” (87.6 cm) m n. to 35-1/2” (90.2 cm) max.
Cutout depth 24” (61.0 cm)
VWCI1240G
Profess onal
FWCI1240G
Custom Panel
See Custom Panels section for
more information and additional
specifications.
R E L E A S E D 1 1 / 1 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE

REFRIGERATION
Undercounter/Freestanding 24”W. Wine Cellar
PLANNING AND DESIGN GUIDE
V I K I N G R A N G E . C O M • 1 - - V I K I N G 1
Handle Kits
• For use with custom panel 24”W. wine cellar
• For use on locally supplied custom panels
•Handles allow custom panel products to coordinate with other Professional products
• Kit includes one handle and installation hardware
Compliance Information
WARRANTY SUMMARY*
• Three-year full warranty—complete unit
• Six-year full warranty—sealed refrigeration system (includes compressor, condenser,
dryer/strainer, evaporator, and connecting tubing)
• Twelve-year limited warranty—sealed refrigeration system
• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items
*For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.
✪Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
PHK30-SS P ofessional handle (Stainless Steel) 6 (2.7)
R E L E A S E D 1 1 / 1 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
