Viking Designer DFWB300 Operating instructions

4
SITE PREPARATIONS AND CONSIDERATIONS
FULL OVERLAY MODEL 30” W. FULL HEIGHT WINE CELLAR
CABINET OPENING DIMENSIONS
2255””**((6633..55ccmm))
*Full overlay models fit flush in 25” (63.5
cm) deep cabinet openings. They can be
installed in standard 24” (61.0 cm) deep
openings. The door faces and top grille
will protrude 3/4” (1.9 cm) into the room.
3300””((7766..22ccmm))
ooppeenniinngg
883333//44””((221122..77ccmm))MMaaxx..
aannttii--ttiippbbooaarrddaannddooppeenniinngghheeiigghhtt
882277//88””((221100..55ccmm))MMiinn..
aannttii--ttiippbbooaarrddaannddooppeenniinngghheeiigghhtt

6
DOOR SWING AND TIPPING CONSIDERATIONS
BBaacckkwwaarrddTTiippppiinnggRRaaddiiuussSSiiddeeTTiippppiinnggRRaaddiiuuss
9900oo
111100oo
112200oo
113333//88””
((3344..00ccmm))
449933//44””
((112288..99ccmm))
551133//88””
((113300..55ccmm))
552211//22””
((113333..33ccmm))
8877//88””
((2222..55ccmm))
1133//88””
((33..55ccmm))
11006611//22””
((227700..55ccmm))
885511//22””
((221177..11ccmm))
11112211//22””
((228855..77ccmm))
887711//22””
((222222..22ccmm))

Overall dimensions
7

8
CABINET INFORMATION
Full overlay models, (with 3/4” [1.9 cm] thick panels and custom handles locally supplied), fit flush in 25” (63.5 cm)
deep (countertop depth) cabinet openings with no protrusion into room except custom handles.
3300””((7766..22ccmm))3300””((7766..22ccmm))
11//44””
((00..66ccmm))
11//44””((00..66ccmm))SSPPAACCEEIIFF2255””((6633..55ccmm))
CCAABBIINNEETTDDEEPPTTHHIISSUUSSEEDD
2244””
((6611..00ccmm))
33//44””((11..99ccmm))
FFuullllEEnndd
PPaanneell
FFLLUUSSHHFFLLUUSSHH
CCOOUUNNTTEERRTTOOPPDDEEPPTTHH

9
CABINET INFORMATION (continued)
Full overlay models can be installed in standard 24” (61.0 cm) deep openings. However, the door faces and top
ventilation grille will protrude 3/4” (1.9 cm) into the room, ideal for alignment with full overlay cabinet doors.
11//44””((00..66ccmm))SSPPAACCEEIIFF2255””((6633..55ccmm))
CCAABBIINNEETTDDEEPPTTHHIISSUUSSEEDD
2244””
((6611..00ccmm))
RREEFFRRIIGGEERRAATTOORRAANNDD
CCAABBIINNEETTDDOOOORRFFLLUUSSHH
CCAABBIINNEETTDDOOOORR

Custom panel dimensions
10

12
CUSTOM SIDE PANEL DIMENSIONS
For 3/4” (1.9 cm) Side Panels
NNOOTTEE::Adding a 3/4” (1.9 cm) side panel adds an additional 3/4” (1.9 cm) to the
overall width of the product for each side panel used. RReeqquuiirreessssiiddeeppaanneell
hhaarrddwwaarreekkiitt((KKiittmmooddeellnnuummbbeerr--SSPPHHKKDDSS))
82 7/8” (210.5 cm) TO 83 3/4” (212.7cm)
DEPENDING ON HOW HIGH LEVELING
FEET ARE RAISED AND CABINET
ENCLOSURE HEIGHT

2
BASIC SPECIFICATIONS AND DIMENSIONS
DDEESSCCRRIIPPTTIIOONNDDFFWWBB330000
Overall Width 30” (76.2 cm)
Overall Height from Bottom Min. 82 1/2” (209.6 cm) to Max. 83 3/4” (212.7 cm)
Overall Depth from Rear To front edge of side trim 23 13/16” (60.5 cm)
To front edge of cabinet side trim 24 3/4” (62.9 cm)
To front edge of door trim 24” (61.0 cm)
Cutout Width 30” (76.2 cm)
Cutout Height 82 7/8” (210.5 cm) min.; 83 3/4” (212.7 cm) max.
Cutout Depth 25” (63.5 cm) - can be installed in 24” (61.0 cm) deep openings; door faces
and top grille will protrude 3/4” (1.9 cm) into room.
Electrical Requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with grounded
3-prong plug attached to product.
Maximum Amp Usage 2.0 amps
Overall Capacity 150 bottles
Approximate Shipping Weight 560 lbs. (252 kg)
