Villeroy & Boch Omnia architectura Compact 9M66 E1 User manual

Model 9M66 E1 Omnia architectura Compact toilet seat, incl. 9224 08 61
universal top mounted toggle hinge
Product Description Omnia architectura Compact toilet seat in Wrap Over design
made of colour ingrained duroplast with hinge in stainless steel
and plastic
- incl. universal top mounted toggle hinge in
stainless steel
- centre distance: 103-203mm
- load of ring seat: 240 kg
- 10 year guarantee
Colour Programme 01 White (Alpin)
09 Pergamon
Hinge Finish 61 Stainless steel
Spare Parts A) 9224 08 61 Universal top mounted toggle hinge
B) 9220 81 00 Buffers for seat and cover
Cleaning Instructions Use a mild soap solution. Seat and hinge should not be left
damp, but be dried with a soft cloth. When using abrasive, cor-
rosive or chlorine based cleaners for the bowl, avoid contact with
seat and hinge as it may lead to damages or flash rust.Therefore,
when cleaning the bowl, make sure that seat and cover are in an
upright position until all the cleaner has been flushed away
Toilet seat Omnia architectura Compact
B
A
103 - 203
210
345
271
367-
417

Instruction manual
Villeroy & Boch UK limited
Bathroom & Wellness
267 Merton Road . London, GB
Tel.: [phone]
E-mail.: [email protected]
www.villeroy-boch.com
Material Description TOILET SEAT:The material is colour ingrained duroplast (UF A 10 = urea formaldehyde) that contains
no environmentally hazardous substances. UF plastic comprises 67% urea formaldehyde resin, 28%
cellulose, as well as 5% minerals, pigments, lubricants and moisture content.The raw material from
the supplier contains less than 0,03% formaldehyde after a special curing process.
BUFFERS: EVA (copolymer made of ethylene and vinyl acetate).
DAMPER KIT: Hydraulic damper with stainless steel damper casing and plastic parts.
Damper liquid: Anti-friction liquid.
MOUNT/HINGE: Stainless steel.
Guarantee The guarantee includes faults or defects in the material of our products within a periode of 10 years.
Products subject to minor technical modifications and design deviations E. & O.E.
Toilet seat Omnia architectura Compact
9224 08 61
12/05
BQ6
12
3
45
6
12/05
Patent pending
78
9
CLICK
Press
Press
03/15
