INSTALLATION MANUAL

Wall-Hung Electrical Toilet Bidet :LT611

• 2015 Uniform Plumbing Code ( UPC )

• 2018 International Plumbing Code ( IPC )

• 2018 International Residential Code ( IRC )

®

Compliance with the following codes & standard:

ASME A112.4.2/CSA B45.16-2015(R2020)Personal Hygiene

Devices for Water Closet

ASME A112.18.1/CSA B125.1-2018 Plumbing Supply Fittings

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

www.woodbridgebath.com

R

WOODBRIDGE

Content

Before installation

Procedures

1

3

6

7

Safety precautions

List of materials

Installation

Technical drawings

Pre-installation confirmation

5

Installation toolings

Dimension of installation position 6

8

Required accessories for in-wall hanger

10

6

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

www.woodbridgebath.com 1

R

WOODBRIDGE SAFETY PRECAUTIONS

READ ALL INSTRUCTIONS BEFORE USING

When using electrical products, especially when children are present, basic safety precautions

should always be followed, including the following:

1. This product is not intended for children (without proper adult supervision).

2. This product is not intended for individuals with reduced physical, sensory,

or mental capabilities.

DANGER–To reduce the risk of electrocution:

1. Do not place or store product where it can fall or be pulled into a tub or sink.

3. Do not reach for a product that has fallen into water. Unplug immediately.

4. Do not wash the main unit or electrical plug with water or detergent.

5. Do not handle the electrical plug with wet hands.

6. Never block the outlet of the air dryer.

7. Never disassemble, repair or modify this product.

8. Ensure Power Cable is unplugged during the installation and maintenance of the appliance.

WARNING–To reduce the risk of burns, electrocution, fire, or injury to persons.

2. Do not place in or drop into water or other liquid.

1. Close supervision is necessary when this product is used by, on, or near children or

individuals with disabilities.

2. Use this product only for its intended use as described in this manual. Do not use

attachments which are not recommended by the manufacturer.

3. Never operate this product if it has a damaged cord or plug, if it is not working properly,

if it has been dropped or damaged, or dropped into water.

4. If the electric cord is damaged, it must be replaced by the manufacturer, its service center

or equivalent specialist.

5. Keep the cord away from heated surfaces.

6. Never use while sleepy or drowsy.

7. Never drop or insert any object into any opening or hose.

8. This appliance MUST be plugged directly into a properly grounded electrical outlet.

Extension cords are NOT permitted. (See Grounding Instructions)

9. Do not throw cigarettes and/or other ignited materials into toilet.

10. This product is an electric appliance, please avoid direct contact with water or other liquids.

11. Do not position the product on its side or upside down while making electrical

connections.

12. It is not recommended to use other electric appliances in the same outlet.

13. Do NOT reuse any existing water supply hoses, otherwise it might cause leakage,

fire or electrical shock. Installation of the bidet seat should include specified

components and new water supply hose.

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

www.woodbridgebath.com

2

IMPORTANT SAFETY INSTRUCTIONS

CAUTION–Failure to follow the instructions may cause bodily injury orproperty damage.

GROUNDING INSTRUCTIONS

This product should be grounded. In the event of an electrical short circuit, grounding reduces

the risk of electric shock by providing an escape wire for the electrical current.

The plug must be plugged into an outlet that is properly installed and grounded.

DANGER –Improper use of the grounding plug can result in a risk of electric shock.

If repair or replacement of the cord or plug is necessary, do not connect the grounding wire to

either flat-head terminal.

Check with a qualified electrician or serviceman if the grounding wire instruction are not

completely understood, or if in doubt as to whether the product is properly grounded.

This product is factory equipped with a specific electric cord and plug to permit connection to

a proper electric circuit. Make sure that the product is connected to an outlet having the same

configuration as the plug.

No adapter should be used with this product. Do not modify the plug provided — if it will not

fit the outlet, please have the proper outlet installed by a qualified electrician.

If the product must be reconnected for use on a different type of electric circuit, the reconnection

should be made by qualified service personnel.

SAVE THESE INSTRUCTIONS

1. Do not install or use the product in wet or damp locations such as a steam room.

2. Ensure the electrical outlet is positioned where it will not come in contact with water.

3. This product should be used with 110V-120V,50/60Hz electrical current only,load current

is at least 15A. Power plug must be equipped with ground fault circuit interrupter or ground

fault electrical leakage protector or similar high sensitive, rapid type leakage switch

(Rated sensitive current under 6mA).

4. It is recommended to unplug the unit during thunderstorms to prevent electrical damage.

5. Do not stand on product, seat or seat cover.

6. Do not lean against the seat cover when using the product.

7. This product is equipped with a soft-closing seat cover. Do not push the toilet seat closed,

or damage may occur.

8. Do not use any caustic chemicals to clean this product.

9. Exposure to direct sunlight is not recommended.

10. Use only tap water or bottled water to clean,otherwise it may cause irritation to skin or

malfunction.

11. Do not connect water supply to a HOT water supply. Make sure inlet water temperature

is between 37.4~95ºF.

12. Do NOT expose the Bidet Seat or Toilet to freezing conditions.

13. If the unit will not be used for an extended period of time (over 3 days), it is recommended

to unplug the electrical connection, turn off water supplies, and drain any water present in

the product.

14. If the unit is malfunctioning, unplug from electrical connections, and turn OFF water supply.

15. The product itself is not equipped with an emergency power circuit breaker, a power circuit

breaker should be connected in series in the power input loop of the same room where the

product is installed before safe use.Otherwise, the accidental failure of this product may

cause bodily injury or property damage.

16. If this product is installed without a power cord plug, a switch device capable of disconne-

cting the power supply of this product must be installed at the front end of the fixed wiring.

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

www.woodbridgebath.com 3

R

WOODBRIDGE Part List

Transition piece

Main Unit Remote control

Installation Manual

Locking nut（M12）Rubber washer

Decorative cap

Pad

Velcro

Ball valve switch

R

WOODBRIDGE

Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Paciﬁc Time)

OrEmail: [email protected]

www.woodbridgebath.com

20210909 REV.1
