Vimar ELVOX Pixel Up Series User manual

Installation and wiring manual
PIXEL UP
40404 - 40424
Panel with Due Fili Plus audio and audio/video electronic unit, display and alphanumeric keyboard

Video entrance panel with Due Fili Plus audio and audio/video elec-
tronic unit, display and alphanumeric keyboard
The instruction manual is downloadable from the site www.vimar.com
1.1 Description
Outdoor video entryphone unit with call from contacts list.
The panel has a hole (size 40x40mm), for tting an access control reader.
The device is supplied with a display and keyboard used to make calls using the contacts list or by directly entering the extension
number to be called.
2 EN
PIXEL UP: 40404 - 40424

1.2 Technical characteristics
• Operating temperature: -25° C / +55° C.
• IP54 degree of protection
• IK08 degree of protection against impact
The audio and audio/video module is distinguished by:
- Power supply from Due Fili Bus, via terminals B1 and B2: 28VDC nominal.
- Minimum voltage on terminals B1 and B2: 21Vcc
- Local power via terminals E+, E- if the electronic unit needs to be powered via an additional power supply unit.
The additional power supply unit should be installed if the system's maximum consumption exceeds the power
supply unit's capacity.
- Absorption from Bus or from additional power supply unit:
• in Stand by 120 mA
• in communication 280 mA
• lock activation + 50 mA
• maximum 330 mA
- Video signal output 16 dBm (in the case of video operation)
The 3.5” display has
- 320 x 480 pixels, 65K colours, 500 lux.
- power supply from audio-video module.
The keyboard has:
- 2 congurable relays. The rst relay acts by default as an actuator opening the lock (together with S+ S- in the
audio/video unit). By default the second opens when a “Stair light” or “Aux1” command is given.
- power supply from audio-video module.
3
EN
PIXEL UP: 40404 - 40424

Interface module
41030UP
Terminal functions
CA- Input programmable using conguration
software (e.g. lock release command, door
open signal sensor, command of actuator
available in system). Note: connect to an
isolated SELV voltage free-contact.
CA+
Terminal functions
OUT1
NO Relay output with NO and NC contacts cho-
sen by the installer.
The contact can control resistive loads exter-
nally powered with maximum current 1 A and
maximum voltage 60 Vdc (maximum voltage
permitted by 60950-1 for the SELV).
C
NC
OUT2
NO Relay output with NO and NC contacts cho-
sen by the installer.
The contact can control resistive loads exter-
nally powered with maximum current 1 A and
maximum voltage 60 Vdc (maximum voltage
permitted by 60950-1 for the SELV).
C
NC
Terminal functions
B2 Due Fili Bus
B1
E+ Additional external power supply, from power supply unit
6923 (output +U).
E-
CA+ Lock control additional button (Default).
Alternatively (if congured via SaveProg), sensor input
to signal “Door Open”.
CA-
S+
Electric lock output
Note: S+/S- outputs. The entrance panel supplies a
current peak IT>1A for 10ms after which there follows a
maintenance current IM=200mA for the entire duration of
the lock command (see lock time).
S-
40404 audio/video entrance panel rear view
4 EN
PIXEL UP: 40404 - 40424
Due Fili Plus
audio video unit
41005UP
Display
41018UP
Alphanumeric
keyboard
41019UP
Terminal block for connection tot he audio/video unit
Terminal block for connection to display
Terminal block for connection to keyboard
Hole (size 40x40mm), for tting
an access control reader

Interface module
41030UP
Terminal functions
CA- Input programmable using conguration
software (e.g. lock release command, door
open signal sensor, command of actuator
available in system). Note: connect to an
isolated SELV voltage free-contact.
CA+
Terminal functions
OUT1
NO Relay output with NO and NC contacts cho-
sen by the installer.
The contact can control resistive loads exter-
nally powered with maximum current 1 A and
maximum voltage 60 Vdc (maximum voltage
permitted by 60950-1 for the SELV).
C
NC
OUT2
NO Relay output with NO and NC contacts cho-
sen by the installer.
The contact can control resistive loads exter-
nally powered with maximum current 1 A and
maximum voltage 60 Vdc (maximum voltage
permitted by 60950-1 for the SELV).
C
NC
Terminal functions
B2 Due Fili Bus
B1
E+ Additional external power supply, from power supply unit
6923 (output +U).
E-
CA+ Lock control additional button (Default).
Alternatively (if congured via SaveProg), sensor input
to signal “Door Open”.
CA-
S+
Electric lock output
Note: S+/S- outputs. The entrance panel supplies a
current peak IT>1A for 10ms after which there follows a
maintenance current IM=200mA for the entire duration of
the lock command (see lock time).
S-
Display
41018UP
Alphanumeric
keyboard
41019UP
Terminal block for connection to display
Terminal block for connection to keyboard
Hole (size 40x40mm), for tting an access control
reader
40424 audio entrance panel rear view
MVideo signal input for external CCTV camera
(V= coaxial core, M=earth)
V
Outdoor video camera connection terminal block
(only for 40424)
Due Fili Plus
41002UP audio
unit
Morsettiera di collegamento alla unità audio/video
5
EN
PIXEL UP: 40404 - 40424

1.3 Installation
1. Install the ush-mounted or external surface mounting box at a height of approx. 1.65 m or 1.20 m for accessibility for the disabled, from the
upper edge of the box to the oor.
2. Connect the terminal block of the electronic unit to the system.
3. Having connected the device it will work with the default parameters. If special congurations are required, refer to the relative Programming
manual.
4. Close the panel, xing the front cover plate to the box using the screws.
.
1.8
m
(83°)
1m
1,65m1,20 m
2,6 m (104°)
1m
H angle (opening at 1m) 104° (2.6m)
V angle (opening at 1m) 83° (1.8m)
Diagonal angle 129°
1.3.1 Videocamerainstallationheightandeldofview.
1.8 m
(83°)
1m
1,65m1,20 m
2,6 m (104°)
1m
6 EN
PIXEL UP: 40404 - 40424

1.3.2 Installationwithushmountingbox
1.3.3 Installationwithexternalsurfacemountingbox
7
EN
PIXEL UP: 40404 - 40424
Remove the support brackets from the box
and turn them downwards to the horizontal po-
sition. Hook the panel to the brackets through
the slots on the side of the metal frame.

1.4 Wiring diagram
D - Audio-video entrance panel with display and keyboard 40404
F - System power supply unit 6922.1
P - Electric lock
L - Additional lock control button
X - Twisted cable 732H.E, 732I.E
PRI
B22
1B1
21
B2
B1
CA+
CA-
S-
S+
E-
E+
41005UP
41019UP
41018UP
41030UP
NC
C
NO
CA-
CA+
NC
C
NO
OUT2 OUT1
Video entryphone/entryphone riser
Mains
F
6922.1
P
L
XD
8 EN
PIXEL UP: 40404 - 40424

PRI
-+U+I
PRI
B22
1B1
21
B2
B1
CA+
CA-
S-
S+
E-
E+
41005UP
41019UP
41018UP
41030UP
NC
C
NO
CA-
CA+
NC
C
NO
OUT2 OUT1
Video entryphone/entryphone riser
Mains Mains
F
6922.1
F1
6923
P
L
X
D
Note: If the distance between the additional power supply unit 6923 and the power supply is more than 3m, use the lter code 41021 installed
near the audio/video module and inside the box”.
Caution: observe the correct polarity when connecting.
D - Audio-video entrance panel with display and keyboard 40404
F - System power supply unit 6922.1
F1 - Additional power supply unit 6923
P - Electric lock
L - Additional lock control button
X - Twisted cable 732H.E, 732I.E
9
EN
PIXEL UP: 40404 - 40424
1.4.1 Version of wiring additional power supply with power supply unit 6923

Caution: The camera must be equipped with its own power supply unit with suitable characteristics. Check that the type of power supply unit
and the connections do not cause any interference with the operation of the electronic unit. Otherwise an insulation lter such as art. 692G
can be used.
D - Audio-video entrance panel with display and keyboard 40425
F - System power supply unit 6922.1
F3- Power supply unit for external CCTV camera
P - Electric lock
L - Additional lock control button
X - Twisted cable 732H.E, 732I.E
ConnectionvariantforAudiopanel41425withexternalCCTVcamera
We recommend you insert a 100 Ohm termination at the video input of the entrance panel if the camera does not play back any video.
10 EN
PIXEL UP: 40404 - 40424
PRI
B22
1B1
21
B2
B1
CA+
CA-
S-
S+
E-
E+
41005UP
41019UP
41018UP
41030UP
NC
C
NO
CA-
CA+
NC
C
NO
OUT2 OUT1
V
M
PRI
F
6922.1
P
L
X
D
F3
Video entryphone/entryphone riser
Mains Mains

11
EN
PIXEL UP: 40404 - 40424
Installation rules
Installation should be carried out by qualied personnel in compliance with the current regulations regarding the installation of
electrical equipment in the country where the products are installed.
Conformity
EMC directive
Standards EN 60065, EN 61000-6-1 and EN 61000-6-3.
REACH (EU) Regulation no. 1907/2006 – Art.33. The product may contain traces of lead.
WEEE - Information for users
If the crossed-out bin symbol appears on the equipment or packaging, this means the product must not be included
with other general waste at the end of its working life. The user must take the worn product to a sorted waste center,
or return it to the retailer when purchasing a new one. Products for disposal can be consigned free of charge (without
any new purchase obligation) to retailers with a sales area of at least 400m2, if they measure less than 25cm. An e󰀩cient
sorted waste collection for the environmentally friendly disposal of the used device, or its subsequent recycling, helps avoid
the potential negative e󰀨ects on the environment and people’s health, and encourages the re-use and/or recycling of the
construction materials.
