Vinvautz VZ07BI User manual

Wine Cellar User Manual

2
Model no.: VZ07BI / VZ07GBI
Vintvautz is the world’s famous designer and manufacturer of professional Wine Cellar which manufacturers Wine Cellar
for your house and private dwellings. We have created aesthetic masterpieces worldwide by perfectly blending
architectural elements and artistic creations in our Wine Cellar designs.
The Vinvautz Difference (Vin + Vautz = Wine + Safe!)
Vinvautz is one of the first to develop a self-contained wine cellar suitable for big and small family and office with excellent in its French craftsmanship and unique
stylish design sets for the needs of the trendy cosmopolitan life. Vinvautz wine cellar is purposefully engineered for wine storage in a variety of elegant, beautiful
and stylish that enhances the ensembles in your home.
Digital control
A digital control and multiple senses ideal for storage of both red and white wine.
Quietest operation
Without any vibration caused by normal compressors, the thermoselectric conrol system is ideal to provide the best storage environment for wines.
Flexible storage
Retractable shelves are designed to provide easier accomodation.
Durable and High quality
Steel outer frame offers stability in operation and durability for long lasting storage.

3
CONTENT:
IMPORTANT SAFEGUARDS
DISPOSAL
CONNECTION TO THE MAINS SUPPLY
PRODUCT FEATURES
OPERATING YOUR APPLIANCE
CARE AND MAINTENANCE
TROUBLESHOOTING GUIDE
Please read this manual carefully before installing and starting up, and store it in a safe place. If you pass on
the product to another person, hand over this instruction manual along with it.

4
IMPORTANT SAFEGUARDS
When using an electrical appliance, basic
precautions should always be followed to
reduce the risk of fire, electric shock, and
injury to persons, including the following:
FOR YOUR SAFETY
Read all instructions carefully, even if you are
quite familiar with the appliance.
The appliance is intended to be used for the
storage of wine. Use this appliance only as
described in this manual. Other uses not
recommended may cause fire, electric shock or
personal injury.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
Electrical devices are not toys. Always keep
the device out of the reach of children.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be
made by children without supervision. Keep the
mains cord out of the reach of children. Do not
let the mains cord hang over the edge of the
table or worktop on which the appliance stands.
To protect against the risk of electric shock, DO
NOT IMMERSE the unit, cord, or plug in water
or spray any other liquid.
Unplug the appliance from the plug socket when
not in use, when moving from one location to
another and before cleaning.
To disconnect the appliance, grip the plug and
pull it from the wall outlet. Never pull by the cord.
WARNING: Please keep the appliance away
from substance, which can cause ignition. Do
not operate the appliance in the presence of
explosive and/or flammable fumes.
Do not place the appliance or any of its part
near an open flame, cooking or other heating
appliance.
Do not operate the appliance with a damage
cord or plug, if the product malfunctions, or if it is
dropped or damaged in any manner. If the
mains cord is damaged, you must have it
replaced by the manufacturer, or an authorized
service centre or similarly qualified persons in
order to avoid a hazard.
The use of attachments not recommended by
the manufacturer may be hazardous.
Place the unit on a dry level surface.
Do not operate if the housing is removed or
damaged.
A loose fit between the AC outlet (receptacle)
and plug may cause overheating and a distortion
of the plug. Contact a qualified electrician to
replace loose or worn outlet.
Locate the unit away from direct sunlight and
sources of heat (stove, heater, radiator, etc.).
WARNING: This appliance is CFC- and HFC-
free and contains small quantities of Isobutane
(R600a) which is environmentally friendly, but
flammable. It does not damage the ozone layer,
nor does it increase the greenhouse effect. Care
must be taken during transportation and setting
up of the appliance that no parts of the cooling
system are damaged. Leaking coolant can ignite

5
and may damage the eyes.
In the event of any damage:
- Avoid open flames and anything which creates
a spark,
- Disconnect from the mains,
- Air the room in which the appliance is located
for several minutes and
- Contact the Service Department for advice.
The more coolant there is in an appliance, the
larger the room it should be installed in. In the
event of a leakage, if the appliance is in a small
room, there is the danger of combustible gases
building up. For every 8 g of coolant at least 1
cubic meter of room space is required. The
amount of coolant in the appliance is stated on
the data plate inside the appliance. It is
hazardous for anyone other than an Authorised
Service Person to carry out servicing or repairs
to this appliance. In Queensland of Australia the
authorized person must hold a Gas Work
Authorisation for hydrocarbon refrigerants,
before carrying out servicing or repairs which
involve the removal of covers.
WARNING: Keep ventilation openings, in the
appliance enclosure or in the built-in structure,
clear of obstruction. No liability will be accepted
for any damage incurred owing to misuse of the
appliance or as a result of repairs carried out by
unqualified personnel. In this case neither the
guarantee nor any other liability claims will apply.
WARNING: Do not use mechanical devices or
other means to accelerate the defrosting
process, other than those recommended by the
manufacturer.
WARNING: Do not damage the refrigerant
circuit. Never use an appliance with a damaged
circuit.
WARNING: Do not use any electrical appliance
inside the food storage compartment of the
appliance, unless they are of the type
recommended by the manufacturer.
WARNING: To avoid a hazard due to instability
of the appliance, it must be fixed in accordance
with the instructions.
Do not store explosive substances such as
aerosol cans with a flammable propellant in this
appliance.
This appliance is intended to be used in
household and similar applications such as
- staff kitchen areas in shops, offices and
other working environments;
- farm houses and by clients in hotels, motels
and other residential type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
Do not attempt to repair or replace any part of
your appliance unless it is specifically
recommended in this manual. All other servicing
should be referred to a qualified technician.
Replace all panels after service before operating.
Use two or more people to move and install the
appliance. Failure to do so can result in back or
other injury.
Never clean appliance parts with flammable
fluids. These fumes can create a fire hazard or
explosion. And do not store or use gasoline or
other flammable vapors and liquids in the vicinity
of this or any other appliance. The fumes can
create a fire hazard or explosion.
Do not connect or disconnect the electric plug
when your hands are wet.
It is recommended that a separate circuit,
serving only your appliance be provided. Use
receptacles that cannot be turned off by a switch

6
or pull chain.
If you have a lockable appliance, do not keep
the key near the appliance or within reach of
children.
SAVE THESE INSTRUCTIONS
If you are experiencing problems, check the
Troubleshooting Guide at the back of this manual. It
lists causes of minor operating problems that you
can correct by yourself.
DISPOSAL
Dispose of your appliance packaging properly.
Ensure that any plastic wrappings, bags etc. are
disposed of safely and kept out of the reach of
babies and young children. Danger of suffocation!
Refrigeration equipment must be properly disposed
of in a professional and appropriate way, in
accordance with the current local regulations and
laws which protects the environment this applies to
your old appliance and to your new unit once it has
reached the end of its service life.
WARNING: Please ensure that old, worn appliances
are rendered unusable before disposal by removing
the doors, removing the plug, cutting the network
cable, and removing or destroying any snap
fastenings or bolts. You will thus prevent children
from locking themselves in the appliance during play
(risk of suffocation) or endangering their lives in any
other way. DO NOT dispose of the appliance in
landfill as the insulation (Cyclopentane) and
refrigerant gas (R600a) contained in these
appliances are flammable.
Disposal instructions:
The appliance must not be disposed of in the
dustbin or with normal household rubbish.
The coolant circuit, particularly the heat
exchanger at the back/bottom of the unit, must
not be damaged.
The symbol on the product or its packaging
indicates that this product is not to be handled
as normal household waste but is to be taken to
a recycling collection point for electrical and
electronic goods. By correctly disposing of this
product you are contributing to the protection of
the environment and to the health of your fellow
human beings. Improper disposal endangers
health and the environment. Further information
about the recycling of the product may be
obtained from your town hall, refuse collection
department or the store where you purchased
the product.
CONNECTION TO THE MAINS
SUPPLY
UK, IRL, HK, SINGAPORE
Check that the voltage marked on the product
corresponds with your supply voltage.
This product is fitted with a 13A plug complying with
BS1363. If this plug is unsuitable or needs to be
replaced, please note the following:
WARNING: To reduce the risk of fire,
electric shock or personal injury, unplug
or disconnect the appliance from the
power supply before servicing.

7
WARNING:
THIS APPLIANCE MUST BE EARTHED.
Important: The wires in the mains lead are coloured
in accordance with the following code:
GREEN/YELLOW - EARTH
BLUE - NEUTRAL
BROWN - LIVE
Neutral
(Blue)
Earth
(Green/Yellow)
Live
(Brown)
This appliance is equipped with a plug fitted with a
13 amp fuse. Should the fuse fail, then it must be
replaced with an ASTA approved fuse (conforming
to BS1362) of the same rating. If you need to
replace the plug or if the plug is of the incorrect type
for your socket, remove it and replace it with an
appropriate type. Dispose of the old plug safely.
As the colours of the wires in the mains lead of this
appliance may not correspond with the coloured
markings identifying the terminals in your plug,
proceed as follows: The GREEN/YELLOW wire is
the EARTH and must be connected to the terminal
which is marked with the letter ‘E’ or by the earth
symbol or coloured GREEN or
GREEN/YELLOW.
The BLUE wire is the NEUTRAL and must be
connected to the terminal which is marked with the
letter ‘N’ or coloured BLACK.
The BROWN wire is the LIVE wire and must be
connected to the terminal which is marked with the
Letter ‘L’ or coloured RED.
Always ensure that the plug cord grip is fastened
correctly.
If in doubt consult a qualified electrician who will be
pleased to do this for you. This product conforms to
EC Directive 92/31 /EEC with respect to
Electromagnetic Compatibility.
NON-REWIREABLE MAINS PLUG
If your appliance is supplied with a non-rewireable
plug fitted to the mains lead, you will find that it
incorporates a fuse, the value of which is indicated
either on the base of the plug or on the fuse carrier.
Should the fuse need replacing, you must use an
ASTA approved one (conforming to BS1362) of the
same rating.
If the fuse cover is lost, the plug must not be used
until a replacement is obtained from an electrical
supplier.
If you need to remove the plug, cut it from the mains
lead and immediately dispose of it. Never attempt to
re-use this plug or insert it into a socket outlet as
there is a very great risk of an electric shock.

8
PRODUCT FEATURES
Built-under installation with single temperature
zone.
Continuously variable electronic temperature
control with digital display and touchpad input.
Temperature can be set from 5° to 22°C (40° to
72°F) for either compartment and can be
displayed in either Fahrenheit or Celsius degree.
Can be set to the long time storage maturing
temperature or a specific serving temperature
for red/white/sparkling wines.
Cooling and Heating to maintain the perfect
storaging and/or service condition.
Dynamic compressor type cooling to ensure
interior air circulation with even distribution of
temperature and humidity.
Soft white LED Interior Light with ON/OFF
switch –Function mode and Showcase mode.
Open-door and malfunction warning system.
Sabbath mode will allow the lights to remain off
during certain religious observances.
Temperature memory function - If power is
interrupted (power surge, breaker switch, etc.)
and then powered up again, the unit will operate
with the last temperature set-point.
Automatic defrosting with defrost water
evaporation.
Reversible tempered double pane smoked glass
door protects your wine from UV light and
creates an attractive display with few
condensation and low noise.
Black coated matte steel outer frame and black
plastic interior liner offer lifetime performance
and stability. The black liner prevents excessive
light from damaging the maturity process.
Optional stainless steel-framed glass door with
stainless steel handle.
Environmentally friendly refrigerant and foaming
insulation gas.
ELECTRICAL CONNECTION
WARNING: Improper use of the grounded plug
can result in the risk of electrical shock. If the power
cord is damaged, have it replaced by a qualified
electrician or an authorized service center.
All electrical work should be carried out by a suitably
qualified and competent person in accordance with
local and national safety regulations.
Check that the voltage marked on the product
corresponds with your supply voltage.
Connect this appliance to a separate at least 13A
circuit.
Connection should be made via a suitable switched
socket which is easily accessible. For extra safety it
is advisable to install a residual current device (RCD)
with a trip current of 30mA.
Have the receptacle and the circuit checked by a
qualified electrician to ensure that the socket is
grounded correctly.
Note: In locations where there is frequent lightning,
it is advisable to use surge protectors.
Do not connect the appliance to the mains electricity
supply by an extension lead. Extension leads do not
guarantee the required safety of the appliance (e.g.
danger of overheating).
The appliance must not be connected to an inverter
and must not be used with a plug adapter as these
can cause damage to the appliance’s electronic unit.
The cord must rest securely behind the appliance
and not be allowed to lie or hang unprotected.
WARNING:
THIS APPLIANCE MUST BE EARTHED.

9
INSTALLING THE HANDLE
IMPORTANT: Do not overtighten the screws & do
not use power tools to install the handle.
DESIGN 1 –
123
Locate the handle ○ 1 over the fixing pins ○ 3 of the
door and using the supplied allen key, tighten the
securing grub screws ○ 2 to fix the handle.
USE ATTENTION
Only store wine in unopened bottles. Always lay
bottles on their side for storage.
Do not overload the cabinet.
Do not open the door unless necessary.
Do not cover shelves with aluminum foil or any
other shelf material which may prevent air
circulation.
Should the unit be left empty for long periods it
is suggested that the appliance is unplugged,
and after careful cleaning, leave the door ajar to
allow air to circulate inside the cabinet in order
to avoid possible condensation, mold or odours
forming.
OPERATING YOUR
APPLIANCE
This appliance is designed for operation at certain
ambient temperatures. The climate class is
specified on the rating plate.
The appliance may not work properly if it is left for a
long period at a temperature outside the specified
range. For example, placing your unit in extreme
cold or hot conditions may cause interior
temperatures to fluctuate. The range between 5ºC
and 22ºC (41ºF and 72ºF) may not be reached.
Climate class
Ambient room temperatures
ST
+18°C to +38°C
NOTE: Units with no heater will not raise its
internal temperature if the ambient temperature
where the unit is located is lower than the set
temperature.

10
USE AND CONTROL
The Controls of Your Unit
POWER
To turn the appliance on/off, press and hold the
key for 5 seconds.
NOTE: Pressing the key once can switch off the
audible alarm when the alarm is on.
LIGHT
Used to turn the inner light on/off.
UP
Used to increase (warm) the set temperature by
1°C/1ºF.
DOWN
Used to decrease (cool) the set temperature by
1°C/1ºF.
Display
Display the digital temperature and service
indicators.
Indicator Light
The indicator light is located at the right lower corner
of the display. The indicator light will be on when the
multi-key function is selected. To perform the multi-
key function, press and hold the first key, then press
the rest key for at least 5 seconds and then release
all the keys.
ºF/ºC Selector
Select the temperature display setting in Fahrenheit
or Celsius degree. To change the temperature from
Fahrenheit to Celsius or from Celsius to Fahrenheit,
press and hold the LIGHT key for 5 seconds.
Setting the Temperature Control
The unit has single temperature zone. The
temperature can be set between 5ºC and 22ºC
(41ºF and 72ºF) which is ideal for storing red,
white or sparkling wine.
When the unit is plugged in for the first time, the
unit will power up automatically to the preset
defaults. The temperature preset at the factory
is 12°C (54ºF).
You can set the temperature as required by
pressing the UP or DOWN key. When you
press the two keys at the first time, the display
will show the last temperature set previously.
The temperature will increase 1°C/1ºF if you
press the UP key once, or the temperature will
decrease 1°C/1ºF if you press the DOWN key
once. The display flashes while you make the
setting.
NOTE:
When you use the appliance for the
first time or restart the appliance after
having been shut off for a long time,
there could be a few degrees variance
between the temperature you select
and the one indicated on the LED
readout. This is normal and it is due
to the length of the activation time.
Once the unit is running for a few
hours everything will be back to
normal.
If the unit is unplugged, power lost, or
turned off, you must wait 3 to 5
minutes before restarting the unit. If
you attempt to restart before this time
delay, the unit will not start.

11
After the temperature has been set, the display
shows the current inner temperature.
To view the set temperature at any time, press
the UP or DOWN key, the set temperature will
temporarily flash in the display for 5 seconds.
Then the display shows the current inner
temperature again.
DYNAMIC CLIMATE / SILENT MODE
This Dynamic Climate mode enables the relative
humidity inside the unit and the temperature to be
distributed evenly around the interior so you can
store all your wine under exactly the same excellent
conditions. If you would like to use the unit to store
wine long term, the dynamic climate mode is a must.
This will create a continuous climate in the cabinet
which imitates that of a wine cellar.
In the Dynamic Climate mode, the interior fan
circulates the inside air evenly even the set
temperature is reached. Dynamic Climate mode is
NOT the factory preset mode beacause of creating
noises and more energy consumption. To change to
Dynamic Climate mode, touch and hold the DOWN
key for approximately five seconds. The wine cellar
will beep five times to confirm Dynamic Climate
mode is on. To change back to Silent (default) mode
(Also named as energy saving mode), touch and
hold the UP key for approximately five seconds.
The wine cellar will beep three times to confirm
Silent mode is on.
SABBATH MODE
Sabbath mode is available for the observance of
certain religious holidays. This mode turns off the
displays, interior light and audible alarms and
prevents them from turning on again. Normal
cooling operations will still take place.
To initiate Sabbath mode, press the POWER and
LIGHT keys at the same time for at least 5 seconds.
The indicator light will flash four times and confirm
the Sabbath mode is ON.
Sabbath mode can be exited by repeating the above
process. The Sabbath Mode will automatically exit
after 96 hours.
CABINET SHELVES
IMPORTANT - Do not cover any part of the
shelves with aluminum foil or any other material
that will prevent adequate air circulation within
the cabinet.
To prevent damaging the door gasket, make
sure the door is fully open when pulling shelves
out of the rail compartment.
For easy access to the bottles stored, pull the
shelves out approximately 1/3. The shelves are
designed with an emergency stop to prevent
them being removed too far when loaded.
OPERATING NOISES
The unit is cooled by a compressor (refrigeration
aggregate). The compressor pumps coolant through
the cooling system, producing operating noise. Even
when the compressor cuts out, noises caused by
changes in temperature and pressure are
unavoidable. Operating noise will be most audible
immediately after the compressor cuts in. It
becomes quieter as the operating period continues.
The following noises are normal and occur from time
to time:
- Gurgling sound, caused by the refrigerant flowing
through the appliance’s coils,
- Humming noise made by the motor compressor.

12
This noise can get louder for brief periods when
the motor is switching on.
- Cracking/popping sounds, resulting from the
materials contraction and expansion due to
temperature variations,
- Fan operating sound, to circulate the air within
the wine cabinet.
Unusual noise is normally the result of improper
installation. Under no circumstances must tubing
come into contact with a wall, other furniture or with
other tubing.
Where the unit is installed in open-plan kitchen or in
partition walls, the level of operating noise will be
heard more acutely. However, this is due to the
surrounding architecture and not to the unit.
An individual’s perception of noise is directly linked
to the environment in which the unit is located, as
well the specific type of models. Our appliances are
in line with international standards for such
appliance and in line with the latest technical
developments. But please remember that the noise
of the compressor and the coolant circulating in the
system is unavoidable.
DEFROSTING / HYGROMETRY /
VENTILATION
Your unit is designed with an automatic defrost
system. During the “Off-cycle” the evaporator behind
the rear wall of the unit defrosts automatically. The
condensate collects in the drain trough behind the
rear wall of the unit, and part of it flows through the
drainage hole into the drip tray by/above the
compressor. The heat is transferred from the
discharge pipe or compressor and evaporates any
condensation that has collected in the tray. Part of
the remaining water is collected within the unit for
humidity purposes.
This system enables the creation of the correct
humidity level inside your unit required by the
natural cork to maintain a long lasting seal.
The appliance is not totally sealed: fresh air
admission is permitted through the drainpipe. Air is
circulated through the unit by means of a fan / fans
and the hollow shelves.
NOTE: Frost may be accumulated on the
evaporator if the unit is repeatedly opened in a high
heat or high humidity location. If this frost pattern
does not clear within 24 hours, your unit will require
manual defrosting.
BOTTLE STORAGE
Many bottles may differ in size and dimensions. As
such the actual number of bottles you may be able
to store may vary.
Bottle capacities are approximate maximums when
storing traditional Bordeaux 750 ML bottles and
include bulk storage.
You may load your wine bottles in single row or by
stacking while taking note of the following: if you do
not have enough bottles to fill your wine cellar, it is
better to distribute the load throughout the wine
cellar so as to avoid “all on top” or “all below” type
loads.
- Do remove or relocate adjustable wooden
shelves to accommodate larger type of bottles
or increase the capacity of the cellar by
stacking the bottles up when necessary. (See
removing shelves)
- Keep small gaps between the walls and the
bottles to allow air circulation. Like an
underground cellar air circulation is important
to prevent mould and for a better
homogeneous temperature within the cellar.
- Do not over load your wine cellar to facilitate
air circulation.
- Avoid obstructing the internal fans (located
inside on the back panel of the wine cellar).

13
- Do not try to slide the shelves outwards
beyond the fixed position to prevent the bottles
from falling.
- Do not pull out more than one loaded shelf at
a time as this may cause the wine cellar to tilt
forward if not properly installed.
WINE SERVING TEMPERATURE CHART
All wines mature at the same temperature, which is
a constant temperature set between 11ºC to 14ºC.
The below chart is an indicative temperature chart to
indicate the best temperature for drinking purposes.
Wine Style
ºC
ºF
Champagne NV, Sparkling,
Spumante
6
43
Dry White Semillon, Sauvignon
Blanc
8
46
Champagne Vintage
10
50
Dry White Chardonnay
10
50
Dry White Gewürztraminer,
Riesling, Pinot grigio
10
50
Sweet White Sauternes,
Barsac, Montbazillac, Ice Wine,
Late Harvest
10
50
Beaujolais
13
55
Sweet White Vintage:
Sauternes…
14
57
White Vintage Chardonnay
14
57
Red Pinot Noir
16
61
Red Grenache, Syrah
16
61
Red Vintage Pinot Noir
18
65
Cabernet & Merlot: French,
Australian, New Zealand,
Chilean, Italian, Spanish,
Californian, Argentinean…
20
68
Vintage Bordeaux …
Room
temperature
not exceeding
20ºC/68ºF
IMPORTANT INFORMATION ABOUT
TEMPERATURE
Your unit has been designed to guarantee optimum
conditions for storing and/or serving your wines.
Fine wines require long and gentle developments
and need specific conditions in which to reach their
full potential.
All wines mature at the same temperature, which is
a constant temperature set between 11ºC to 14ºC.
Only the temperature of “dégustation” (wine
appreciation) varies according to the type of wines
(see “Wine Serving Temperature Chart” above).
This being said and as it is for natural cellars used
by wine producers for long period of storage, it is not
the exact temperature that is important, but its
consistency. In other words, as long as the
temperature of your wine cellar is constant (between
11ºC to 14ºC) your wines will be stored in perfect
conditions.
Not all wines will improve over the years. Some
should be consumed at an early stage (2 to 3 years)
while others have tremendous ageing capability (50
and over). All wines have a peak in maturity. Do
check with your wine merchant to get the relevant
information.
CARE AND MAINTENANCE
WARNING: Failure to unplug the appliance during
service and cleaning could result in electrical shock
or other personal injury.
REMOVING SHELVES
To remove any of the shelves from the rail
compartment, move the shelf to the position
where the notch of wooden shelf is exactly
under the plastic post and then lift it up and out.

14
In order to replace the shelf, repeat steps
described above in reverse. And make sure to
engage the shelves with the small pegs of the
extended rails when the model is equipped with
roller system.
CLEANING YOUR APPLIANCE
Turn off the power, unplug the appliance, and
remove all items including shelves and rack.
Wash the inside surfaces with a warm water and
baking soda solution. The solution should be
about 2 tablespoons of baking soda to a pint of
water.
Wash the shelves with a mild detergent solution.
Wring excess water out of the sponge or cloth
when cleaning any area of the controls.
Wash the outside cabinet with warm water and
mild liquid detergent. Rinse well and wipe dry
with a clean soft cloth.
Do not clean the stainless steel with steel
wool pads. Suggest to using an all-in-one
stainless steel cleaner to clean the stainless
steel and always clean in the direction of grain.
POWER FAILURE
In the event of a power interruption, all previous
temperature settings are automatically
memorized. If power is interrupted (power surge,
breaker switch, etc.) and then powered up again,
the unit will operate with the last temperature
set-point.
Most power failures are corrected within a few
hours and should not affect the temperature of
your appliance if you minimize the number of
times the door is opened. If the power is going to
be off for a longer period of time, you need to
take the proper steps to protect your contents.
NOTE: Irrespective of the cause, if you notice
either abnormal temperature or humidity levels
inside your unit, be reassured that only long and
frequent exposure to these abnormal conditions
can cause a detrimental effect on your wines.
VACATION TIME
Short holidays: Leave the unit in operation for
holidays of less than three weeks.
Long absences: If the appliance will not be
used for several months, remove all items, turn
off the appliance and unplug. Clean and dry the
interior thoroughly. To prevent odour and mold
growth, leave the door open slightly: blocking it
open if necessary.
MOVING YOUR APPLIANCE
Remove all items.
Securely tape down all loose items (shelves)
inside your appliance.
Turn the adjustable leg up to the base to avoid
damage.

15
Tape the door shut.
Be sure the appliance stays secure in the upright
position during transportation. Also protect
outside of appliance with a blanket, or similar
item.
ENERGY SAVING TIPS
The appliance should be located in the coolest
area of the room, away from heat producing
appliances, and out of the direct sunlight.
Ensure that the unit is adequately ventilated.
Never cover air vents. Clean dust and dirt from
the condenser at regular intervals.
Only open the door for as long as necessary and
for as short a time as possible.
Store the content in an organised way.
Do not over-fill the appliance to allow air to
circulate.

16
PROBLEMS WITH YOUR APPLIANCE
You can solve many common problems easily, saving you the cost of a possible service call.
Try the suggestions below to see if you can solve the problem before calling customer service.
TROUBLESHOOTING GUIDE
PROBLEM
POSSIBLE CAUSE
REMEDY
Appliance does not
operate.
Appliance is not connected to a power
supply.
The appliance is turned off.
The circuit breaker tripped or a blown fuse.
Connect the appliance.
Switch on the appliance.
Switch on circuit breaker or
replace fuse.
Appliance is not
cold enough.
The temperature is not set correctly.
The ambient temperature could require a
higher temperature setting.
The door was opened too often.
The door was not closed completely.
Door is not hermetically-sealed.
The condenser is too dirty.
The ventilation opening is blocked or too
dusty.
Check the set temperature.
Set a higher temperature.
Do not open the door more often
than necessary.
Close door properly.
Check the door seal and clean or
replace.
Clean the condenser when
necessary.
Clear the obstructions and clean
the dust.
Appliance turns
itself on and off
frequently.
The room temperature is higher than
average.
A large amount of bottles has been added to
the unit.
The door is open too often.
The door is not closed completely.
The door gasket does not seal properly.
Put the appliance in a cooler
place.
Leave the appliance to work for a
while until the set temperature
has been reached.
Do not open the door more often
than necessary.
Close door properly.
Check the door seal and clean or
replace.
The light does not
work.
Appliance is not connected to a power
supply.
The circuit breaker tripped or a blown fuse.
The light was switched off on the control
panel.
Connect the appliance.
Switch on circuit breaker or
replace fuse.
Switch on the light.

17
Vibrations.
The appliance is not properly level.
Level the appliance with the
adjustable feet.
The appliance
seems to make too
much noise.
The rattling noise may come from the flow of the refrigerant, which is normal. As each
cycle ends, you may hear gurgling sounds caused by the flow of refrigerant in your
appliance.
If temperature fluctuations occur, the contraction and expansion of the inner walls may
cause popping and cracking noises.
The appliance is not properly level.
Level the appliance with the
adjustable feet.
The door will not
close properly.
The appliance is not properly level.
The door was reversed and not properly
installed.
The gasket is dirty.
The shelves are out of position.
Level the appliance with the
adjustable feet.
Check the door hinge and
reassemble correctly.
Clean the door gasket.
Check the shelves and refit
correctly.
Display “E1”. “E2”,
“E3”, “E4”, “E5”.
“E1”or “E2”indicates that the air
temperature sensor is failed.
“E3”or “E4”indicates that the defrost
sensor in the evaporator is failed.
E5”indicates the defrost heater failure.
Call for service.
The icon “--” is lit
up and flashing in
the temperature
display.
The display temperature is out of the range.
Only temperatures within the
range 0~99°F/-9~37°C the
appliance can display will be
shown. If the temperature is not
within this range, the icon “--” will
be displayed instead. That is
normal.

18
