VIRTUFIT Row 600i User manual

Row 600i Rowing Machine
U ser manual
EN

VirtuFit Row 600i Rowing Machine 2
EN
INDEX
SAFETY INSTRUCTIONS
CHECKLIST
ASSEMBLY INSTRUCTIONS
FOLDING INSTRUCTIONS
MAINTENANCE
TROUBLE SHOOTING
CONTROL PANEL
APP
EXPLODED DRAWING
PARTS LIST
TRAINING INSTRUCTIONS
3 - 4
5 - 7
8 - 13
14
15 -16
17
18 - 19
20
21
22 - 23
24

VirtuFit Row 600i Rowing Machine
3EN
SAFETY INSTRUCTIONS
– It is important to read this entire manual before assembling and using the equipment. Safe and
eective use can only be achieved if the equipment is assembled, maintained and used properly.
It is your responsibility to ensure that all users of the equipment are informed of all warnings and
precautions.
– Before starting any exercise program, you should consult your doctor to determine if you have
any medical or physical conditions that could put your health and safety at risk, or prevent you
from using the equipment properly. Your doctor’s advice is essential if you are taking medication
that aects your heart rate, blood pressure or cholesterol level.
– Be aware of your body’s signals. Incorrect or excessive exercise can damage your health. Stop
exercising if you experience any of the following symptoms: pain, tightness in your chest, irregular
heartbeat, extreme shortness of breath, lightheadedness, dizziness or feelings of nausea. If you do
experience any of these conditions you should consult your doctor before continuing with your
exercise program.
– Keep children and pets away from the equipment. The equipment is designed for adult use only.
– Use the equipment on a solid, at level surface with a protective cover for your oor or carpet. To
ensure safety, the equipment should have at least 0.5 metres of free space all around it.
– Before using the equipment, check that the nuts and bolts are securely tightened.
– The safety of the equipment can only be maintained if it is regularly examined for damage and/or
wear and tear.
– Always use the equipment as indicated. If you nd any defective components while assembling or
checking the equipment, or if you hear any unusual noises coming from the equipment during use,
stop immediately. Do not use the equipment until the problem has been rectied.
ATTENTION
WARNING:
Before beginning any exercise program consult your physician. This is especially
important for people who are over 35 years old or who have pre-existing health
problems. Read all instructions before using any tness equipment. Do not operate this
exercise equipment without properly tted guards, as the moving parts can present a
risk of serious injury if exposed.

VirtuFit Row 600i Rowing Machine 4
EN
SAFETY INSTRUCTIONS
– Wear suitable clothing while using the equipment. Avoid wearing loose clothing that may get caught
in the equipment or that may restrict or prevent movement.
– The max user weight is 130 KGS. Braking ability is independent of speed.
– The equipment is not suitable for therapeutic use.
– Care must be taken when lifting or moving the equipment so as not to injure your back. Always use
proper lifting techniques and/or seek assistance if necessary.
– Please keep the space at least 1 to 2 meter at the end of base frame to escape any accidents!
– Place the device on a clean and at surface. Do not place the equipment on a thick carpet.
– The device is for indoor use and not for outdoor use to prevent damage. Keep the storage location
dry, clean and at. It is forbidden to use the device for purposes other than training.
Warranty claim is excluded if the cause of the defect is the result of:
• Maintenance assembly and repair work not carried out by an ocial dealer.
• In the event of improper use, neglect and / or poor maintenance.
• Failure to maintain the tness equipment in accordance with the manufacturer’s instructions (see
the enclosed manual).

VirtuFit Row 600i Rowing Machine
5EN
CHECKLIST
TOOLKIT
When you open the carton, and you will nd the below parts in the carton:
1
31
36
46 55
56
NUMBER DESCRIPTION QTY
1Main Frame 1
31 Rear Plastic Stabilizer 1
36 Main Rail 1
46 Saddle 1
55 Pedal 2
56 Front Stabilizer 1

VirtuFit Row 600i Rowing Machine 6
EN
TOOLKIT
NUMBER DESCRIPTION SHAPE QTY
DAxe Ø 13*126 2
GAxe Ø 13*66 1
ABolt M8*38 2
CBolt M8*15 4
FBolt M8*25 2
BWasher ID8.2 4
ECushion 23*23*19 4
HAllen key 6S 2
IPlum Bolt Knob M8*35 2
JPlum Bolt Knob M8*20 2
CHECKLIST

VirtuFit Row 600i Rowing Machine
7EN
CHECKLIST
TOOLKIT
NUMBER DESCRIPTION SHAPE QTY
KConnecting plate
140*33*4 1
NOpen spanner 1
MBolt M6*10 2
14 Decorative covers 1
16 + 17 Console support 1
OBolt M8*130 1
PNylon locknut 2
WAllen key 5S 1

VirtuFit Row 600i Rowing Machine 8
EN
Missing parts: If you think you are missing certain parts in your package, carefully check the styrofoa and
the rowing machine. Some parts (bolts, screws, etc.) are already attached to / in the rowing machine.
Error message: Ensure that all cables are carefully attached. The aluminum legs are very sensitive and
must remain straight. Do you receive an error message after mounting your rowing machine? Then you
have to straighten these aluminum legs again, this may cause the error message to disappear.
Socket screws: The rowing machine contains socket screws, make sure that the allen key is rmly in the
bolt before you apply force to the key. In this way you prevent the head of the socket head screw from
being rotated.
STEP 1
S6 2 PCS
13x126 2 PCS
C
D
SCP451x8M
B SCP42.8DI
ASSEMBLY INSTRUCTIONS

VirtuFit Row 600i Rowing Machine
9EN
STEP 2
• Upright the main frame onto the style foam to prevent from scratch on the plastic cover while
mounting the front stabiliser to the main frame.
A M8x38 2 PCS
S6 1 PCS
ASSEMBLY INSTRUCTIONS

VirtuFit Row 600i Rowing Machine 10
EN
STEP 3
F M8x25 2 PCS
E 23x23x19 2 PCS
G 13x66 1 PCS
S6 2 PCS
Ø
ASSEMBLY INSTRUCTIONS

VirtuFit Row 600i Rowing Machine
11 EN
STEP 4
NOTE: This step is best carried out by 2 people.
• Carry on the Main Rail (36) moving to the Main Frame (1). Linked the sensor wire taps (51) and (54)
rstly.
• Lighten the knob (I) and knob (J) with the washer (B), bolt (O) and the Nylon locknut (Q) orderly.
ASSEMBLY INSTRUCTIONS

VirtuFit Row 600i Rowing Machine 12
EN
STEP 5
ASSEMBLY INSTRUCTIONS

VirtuFit Row 600i Rowing Machine
13 EN
STEP 6
• The rowing machine is fully installed and can be used.
The console (display) is adjustable in angle. You can train in the right position at all times
and have a good view of the display.
ASSEMBLY INSTRUCTIONS

VirtuFit Row 600i Rowing Machine 14
EN
NOTE: Store your machine in a dry area away from children and high trac areas as shown in
the illustration. Be sure it is secure and cannot fall onto small animals or children.
FOLDING
UNFOLDING
Unscrew the Knob (I) rstly, then pull out
the Knob (J) when it is enough loosen by
releasing. And at the same time, pull the
sliped Rail to the Main frame as the direction
of scrrow. It is ok when a click sound was
heard.
Pull the Knob(J) as the direction of arrow, at
the same time, unfold the Rail to the ground.
Then screw the Knob (I) with the washer (W)
and tighten the Knob (J) at last.
FOLDING INSTRUCTIONS

VirtuFit Row 600i Rowing Machine
15 EN
SEMI-ANNUAL MAINTENANCE
DAILY MAINTENANCE
• Clean and remove sweat after each use Do not use aggressive cleaning agents and ensure that
the device remains free of moisture.
• Check that the rail and the wheels under the seat are free from dust and dirt.
• Inspect all bolts and nuts in connection with moving parts of the device, tighten as required.
• Check the mobility of moving parts and components of the use equipment, silicone spray if
necessary.
TENSION KNOB
1
2
3
4
5
6
7
8
9
1
0
1
1
1
2
1
3
1
4
1
5
1
6
TENSION KNOB ADJUSTMENT
You could adjust the tension for varied
resistance as shown in the illustration.
NOTE: You should begin your “Exercise
Period” at the resistance level and speed
to suit your needs. Remember to start out
slow and easy, and work your way up to the
tness level you desire.
Safeandeectiveusecanonlybeachievedifthedevicewillbeassembledandmaintained
well. It is your responsibility to ensure that the equipment is regularly maintained. Parts
that are already used and / or damaged must be replaced before continuing using. The
rower machine may only be used indoors and stored away, prolonged exposure to
weathering and changes in temperature / humidity can have a serious impact on the
electrical components and moving parts of the rowing machine.
MAINTENANCE

VirtuFit Row 600i Rowing Machine 16
EN
BATTERY
MAINTENANCE
AA BATTERY
The monitor uses on “AA” battery. You can
replace the battery through the back of the
unit.
ADVICE FOR HANDLING BATTERIES
CHANGING THE BATTERIES
1. Remove the batteries when they are exhausted or if you do not use the product for an extended
period of time in order to avoid hazards through leaking batteries.
2. Do not recharge batteries nor dissemble or throw then into re. Danger of explosion!
3. Pay attention to the polarity (+) and (-). Always replace all the batteries; do not mix old and new batteries,
or dierent battery types.
4. Use preferably alkaline batteries, as they have a longer operation time then usual zinc-coalbatteries.
5. A change of batteries is necessary when the display becomes weaker or completely faded.
1. If you see an improper display on the monitor, please replace the batteries to have a good result.
2. Please use 2pcs of 1.5v AA batteries as a power supply. (See step 5).

VirtuFit Row 600i Rowing Machine
17 EN
TROUBLE SHOOTING
Display does not work
If the display no longer works, you can replace the batteries. These are at the back of the display.
Display shows no values
If the display does not show any values, you can try to check the sensor cables and the cables in the back
of the display. If this still does not work, you can move the sensor slightly.
Rowing machine beeps
Check that all bolts and nuts are tightened securely. Spray silicone spray if necessary. Also check the wheels
under the seat.
PROBLEM SOLUTIONS

VirtuFit Row 600i Rowing Machine 18
EN
CONSOLE
CONTROL PANEL
BUTTON FUNCTION
RESET By holding down the reset button for 3 seconds you can clear the settings. With
this button you can reset the value to zero.
MODE Press the MODE button to select a desired function.
SET Set the values for: “TIME” , “DISTANCE” and “CALORIES”.

VirtuFit Row 600i Rowing Machine
19 EN
BUTTON EXPLANATION
SCAN The following functions are displayed in the SCAN position: TIME, COUNT, TOTAL
COUNT, CALORIE, COUNT / MIN.
TIME Counts rowing time from the beginning of the exercise to the end.
CALORIES Counts total calories from the beginning to the end of rowing.
RPM Counts the number of rowing strokes per minute.
COUNT Counts the rowing strokes from start to nish.
DISTANCE The distance traveled during the exercise is displayed.
PULSE
(PUL) Heart rate during your exercise 40 ~ 240 BPM.
FUNCTION
CONTROL PANEL

VirtuFit Row 600i Rowing Machine 20
EN
DOWNLOAD THE FITNESS DATA APP
STEP 2
Open the app and enter
your details.
STEP 4
Start training.
STEP 3
Connect the rowing machine with the app via
Bluetooth. Click “connect device”and select the
device from the list. Make sure the console is on.
STEP 1
Download the Fitness Data app in the App Store or Google Play Store.
APP STORE GOOGLE PLAY STORE
STEP 2 STEP 3 STEP 4
APP
