Vita Spa 100 Series User manual

Vita Spa®
100 Series
Manual

1
Owner’s Manual
English
Your new spa’s GFCI will trip.
A Ground Fault Interrupter (GFCI) Trip Test must occur to
allow proper spa function.
Spas that come with MXBP20 and MXBP100 control
systems come with special instructions for the installer/
electrician. If they have not already advised you on what
to do or expect from the GFCI Trip Test, please contact
them for instructions.
If the GFCI breaker connected to your spa trips, this is
normal behavior. Please reset the breaker and enjoy
your spa. The trip test has been completed successfully.
If your spa was not wired to a GFCI breaker or your
breaker fails the GFCI Trip Test, the spa will repeatedly
attempt (at preset intervals) to trip the breaker in the fu-
ture until such time that it triggers a GFCI Trip. If a GFCI
does not trip properly, your spa’s display will show an
error message.
GFCI breakers are important safety devices required by
code for your hot tub. For more information, refer to the
MXBP20 and MXBP100 sections of this manual or your
local dealer.
ALERT

2
Owner’s Manual
English
WARNING:
Children should not use spas or hot tubs
without adult supervision.
WARNING:
Do not use spas or hot tubs unless all suction
guards are installed to prevent body and hair
entrapment.
WARNING:
Pregnant, or possibly pregnant, women should
consult a physician before using a spa or hot tub.
WARNING:
People with infectious diseases should not
use a spa or hot tub.
WARNING:
To avoid injury, exercise care when entering
or exiting the spa or hot tub.
WARNING:
Do not use drugs or alcohol before or during
the use of a spa or hot tub to avoid
unconsciousness and possible drowning.
WARNING:
People using medications and/or having an
adverse medical history should consult a
physician before using a spa or hot tub.
WARNING:
Water temperature in excess of 100°F (38°C)
may be injurious to your health.
WARNING:
Before entering the spa or hot tub, measure
the water temperature with an accurate
thermometer.
WARNING:
Do not use a spa or hot tub immediately
following strenuous exercise.
WARNING:
Prolonged immersion in a spa or hot tub may
be injurious to your health.
WARNING:
Maintain water chemistry in accordance with
manufacturer’s instruction.
WARNING:
Do not permit electric appliances (such as a
light, telephone, radio or television) within
5 feet (1.5m) of the spa or hot tub.
WARNING:
The use of alcohol or drugs can greatly
increase the risk of fatal hyperthermia in hot
tubs and spas.
IMPORTANT SAFETY WARNINGS
SAVE THESE INSTRUCTIONS
NOTE: When installing and using this equipment, basic safety precautions should always
be taken to reduce the risk of electrical shock, to ensure safe usage, and to safeguard the
user’s health. Failure to follow instructions and warnings contained in this Owner’s Manual,
Installation Guide and on the spa/swim spa itself may result in severe personal injury,
including death, as well as property damage.

3
Owner’s Manual
English
TABLE OF CONTENTS
IMPORTANT SAFETY WARNINGS ........ 2
TABLE OF CONTENTS ............................ 3
IMPORTANT SAFETY INSTRUCTIONS . 4
DOS AND DON’TS OF SPA CARE..............6
Hyperthermia ................................................6
SPA INSTALLATION ................................ 7
European Spas...............................................7
SPA Site and Positioning............................7
Outdoor Installation.................................... 7
Indoor Installation........................................7
Thermal Creep............................................... 8
SPA SYSTEM COMPONENTS................. 9
SPA COMPONENTS .............................. 10
JETS AND AIR CONTROLS................... 11
Jets...................................................................11
Cleaning or Replacing Jets......................11
Cleaning Jets................................................11
Air Controls...................................................12
ELECTRICAL INFORMATION............... 13
Important Safety Instructions................13
GFCI.................................................................13
Residual Current Device...........................13
Installation Options ...................................13
VOLTAGE/AMPERAGE CHART:................16
START UP PROCEDURES ..................... 18
Priming Your Spa ........................................18
TP500 CONTROL PANEL...................... 19
Main Menus..................................................19
Filling Your Spa............................................20
Spa Behavior ................................................20
Temperature & Temp Range...................21
Mode - Rest and Ready.............................22
Show & Set Time of Day ...........................22
Flip (Invert Display)....................................23
Restricting Operation ...............................23
Unlocking......................................................23
Adjusting Filtration....................................23
GFCI Test Feature ........................................24
TP600 CONTROL PANEL.................................. 25
Button Functions..................................................... 25
Main Menus............................................................... 25
Filling Your Spa......................................................... 26
Spa Behavior ............................................................. 26
Temperature & Temp Range................................ 27
Mode - Rest & Ready .............................................. 28
Show & Set Time-of-Day....................................... 28
Flip (invert Display) ................................................ 29
Restricting Operation ............................................ 29
Unlocking................................................................... 29
Adjusting Filtration................................................. 29
GFCI Test Feature ..................................................... 29
WiFi CONNECTIVITY ........................................ 30
SPA SOAKING & EXERCISE GUIDELINES....... 31
EQUIPMENT SAFETY FEATURES .................... 34
Automatic Time Outs ............................................. 34
Common LCD Messages ....................................... 34
MAINTENANCE................................................. 36
Water Chemistry ...................................................... 36
Sanitizing.................................................................... 36
pH Level ...................................................................... 36
Sanitizing with Ozone............................................ 37
Specialty Chemicals................................................ 37
Draining your Spa ................................................... 37
Filter Maintenance .................................................. 38
Winterizing ................................................................ 38
Spa Cabinet Care ..................................................... 39
Spa Surface Care and Cleaning ......................... 39
COMMON WATER PROBLEMS ....................... 40
COMMON HARDWARE PROBLEMS............... 43
SAFETY SIGN..................................................... 45
LIMITED WARRANTY SUMMARY................... 45
COPYRIGHTS AND TRADEMARKS ................. 46
NOTES ................................................................ 47

4
Owner’s Manual
English
IMPORTANT SAFETY INSTRUCTIONS
1. WARNING - To reduce the risk of injury,
do not allow children to use spa unless
they are closely supervised at all times.
2. A wire connector is provided on this unit
to connect a minimum 6 AWG (5.15 mm2)
solid copper conductor between this unit
and any metal equipment, metal enclosu-
res of electrical equipment, metal water
pipe or conduit within 5 feet (1.5m) of
the unit.
3. (For cord-connected/convertible units)
DANGER - Risk of injury.
a. Replace damaged cord immediately.
b. Do not bury cord.
c. Connect to a grounded, grounding
type receptacle only.
4. DANGER - Risk of Accidental Drowning.
Extreme caution must be exercised
to prevent unauthorized access by
children. To avoid accidents, ensure that
children cannot use this spa unless they
are supervised at all times.
5. DANGER - Risk of injury. The suction
ttings in this spa are sized to match the
specic water ow created by the pump.
If you must replace the suction ttings
or the pump, be sure the ow rates are
compatible. Never operate spa if the
suction ttings are broken or missing.
Never replace a suction tting with
one rated less than the ow rate marked
on the original suction tting.
6. DANGER - Risk of Electric Shock. Install
at least 5 feet (1.5m) from all metal
surfaces. As an alternative, a spa may be
installed within 5 feet (1.5m) of metal
surfaces if each metal surface is
permanently connected by a minimum
6 AWG (5.15 mm2) solid copper
conductor to the wire connector on the
terminal box that is provided for
this purpose.
7. DANGER - Risk of Electric Shock. Do not
permit any electric appliance (such as a
light, telephone, radio or television)
within 5 feet (1.5m) of the spa.
8. WARNING - To reduce the risk of injury:
a. The water in a spa should never
exceed 104°F (40°C)..Temperatures be
tween 100°F (38°C) and 104°F (40°C)
are considered safe for a healthy adult.
Lower temperatures are recommended
for young children and when spa use
exceeds 10 minutes.
b. Since excessive water temperatures
have a high potential for causing fetal
damage during the early months of preg-
nancy, pregnant or possibly pregnant
women should limit spa water tempera-
tures to 100°F (38°C).
c. Before entering spa, measure the
water temperature as water temperature
regulating devices vary.
d. The use of alcohol, drugs, or medica-
tion before or during spa use may lead
to unconsciousness with the possibility of
drowning.
e. Obese persons and persons with a
history of heart disease, low or high
blood pressure, circulatory system prob-
lems, or diabetes should consult a
physician before using a spa.
READ AND FOLLOW ALL INSTRUCTIONS

5
Owner’s Manual
English
NOTE: Check with your state/local code enforcement ocer to determine electrical code
requirements and compliance. Use a qualied licensed electrician to complete all nal spa
electrical connections.
TO AVOID RISK OF ELECTRICAL SHOCK:
1. A green colored terminal or a terminal
marked G, GR, Ground, Grounding, or the
international symbol is located on
the side of the supply terminal box or
compartment. This terminal must be
connected to the grounding means
provided in the electric supply service
panel, using a continuous copper wire
equivalent in size to the circuit conductors
supplying this equipment.
*IEC Publication 60417, Symbol 5019.
Never use aluminum wire.
2. At least two lugs marked “BONDING
LUGS” are provided on the external sur-
face or on the inside of the supply termi-
nal box or compartment. Connect the
local common bonding grid (house-hold
ground) in the area of the hot tub or spa
to these terminals, using an insulated or
bare copper conductor not smaller than
No. 6 AWG.
3. All eld-installed metal components such
as rails, ladders, drains or similar hard
ware located within 5 ft (1.5m). of the
spa or hot tub shall be bonded to the
equipment grounding bus with copper
conductors only, no smaller than No. 6
AWG.
4. Never connect unit to a power supply
with a load controller.
5. Install spa in position which provides
drainage of electrical component
compartments.
6. The electrical supply for this product
must include a suitably rated switch
or circuit breaker to open all ungrounded
supply conductors. This disconnecting
means must be readily accessible for
operation but installed at least 5 feet
Caution: Risk of electrical shock. Read and follow all instructions.
SAVE ALL INSTRUCTIONS
f. Persons using medication should
consult a physician before using a spa
since some medication may induce
drowsiness while other medication may
aect heart rate, blood pressure, and
circulation.

6
Owner’s Manual
English
(1.5m) from the spa. All electrical
connections should comply with local
regulations.
DOS AND DON’TS OF SPA CARE
Do:
• Save these instructions!
• Replace the cover immediately after use.
• Keep the cover locked when spa is not
in use.
• Be aware of the dangers of a wet and
slippery surface. Use caution when
entering and exiting your spa.
• Have a licensed electrician or certied
technician make all nal electrical
connections.
• Replace worn, frayed or broken electrical
cords.
• Keep the water chemistry correctly
balanced. Untreated spa water will cause
problems with your spa and equipment
as well as being a health risk.
• Clean the spa lter weekly or as needed.
• Position the spa so that all sides remain
accessible for maintenance.
• Use a bathing cap for long hair.
• Refer to information on hyperthermia.
• Use only authorized spa care products
for the best performance and to keep
the water properly balanced.
Don’t:
• Use the spa at 104°F (40°C) for long
periods of time (more than 30 minutes).
See Hyperthermia, next column.
• Use an extension cord to power your spa.
• Allow anyone to stand on the spa cover.
It is not designed to support weight.
• Power the spa unless it is lled with water
5-6 inches below top of spa lip.
• Operate the pump on high speed for ex-
tended periods of time with the cover in
place. Extended operation can cause heat
build-up and interfere with spa operation.
HYPERTHERMIA
The causes, symptoms, and eects of
hyperthermia may be described as follows:
hyperthermia occurs when the internal
temperature of the body reaches a level
several degrees above the normal body
temperature of 98.6°F (37°C). The symptoms
of hyperthermia include an increase in the
internal temperature of the body, dizziness,
lethargy, drowsiness, and fainting. The eects
of hyperthermia include:
a. Failure to perceive heat
b. Failure to recognize the need to exit spa
or hot tub
c. Unawareness of impending hazard
d. Fetal damage in pregnant women
e. Physical inability to exit the spa or hot
tub
f. Unconsciousness resulting in the danger
of drowning
WARNING  The use of alcohol, drugs,
or medication can greatly increase the
risk of fatal hyperthermia.

7
Owner’s Manual
English
SPA INSTALLATION
The electrical supply for this product must
include a suitably rated switch or circuit
breaker to open all ungrounded supply
conductors to comply with Section 422-20
of the National Electrical Code ANSI/NFPA70-
1987. The disconnecting means must be
accessible but installed at least 5 feet (1.5 m)
from the spa water. All electrical connections
should comply with article 680-D of the NEC.
EUROPEAN SPAS
The appliance should be supplied through
a residual current device (RCD) with a rated
tripping current not exceeding 30 mA. Means
for disconnection must be incorporated in
the xed wiring in accordance with the wiring
rules. Parts containing live parts, except parts
supplied with safety extra-low voltage not
exceeding 12 V, must be inaccessible to a
person in the bath. Earthed appliances must
be permanently connected to xed wiring.
SPA SITE AND POSITIONING
Locate the spa on solid, level foundation or
ooring, keeping in mind the weight of the
lled spa in excess of 3,968lbs (1.800 kg) on
some models. If you have any doubts about
the load bearing ability of your chosen site,
contact an architect/building contractor. The
entire perimeter of the spa cabinet and spa
bottom must be evenly supported. If your
spa is installed outdoors, we recommend
you provide a concrete pad for the spa to
rest on 8ft x 8ft x 4in (2.5m x 2.5m x 10cm).
Failure to provide a level surface could
structurally damage your spa and void
the warranty. The spa must be installed to
allow access for service and maintenance on
all four sides; therefore, below grade level or
below deck installation is not
recommended.
OUTDOOR INSTALLATION, Consider
the following:
1. Local codes pertaining to fencing.
2. Local electrical and plumbing codes.
3. View from your house.
4. Wind direction.
5. Exposure to sunlight.
6. Distance to trees (twigs, leaves and shade).
7. Dressing and bathroom location.
8. Storage area for equipment and chemicals.
9. Location to facilitate adult supervision.
10. Landscaping and nighttime lighting.
11. Accessibility to equipment.
12. Power supply location and foot trac.
INDOOR INSTALLATION, Consider the
following:
1. Indoor spas promote high humidity. Using
ventilation fans or commercial grade de-
humidiers will help to reduce humidity.
2. Floor drains must be provided near the
spa to drain o water that may cause
falls and/or water damage.
3. Floor area should be at with a non-skid
nish. Carpeting is not recommended.
4. Walls/ceilings should be made of
materials able to withstand high humidity.
5. Floor load bearing capacities must be able
to support the concentrated spa weight.
6. Spas should be double checked for leaks
before installing to avoid possible water
damage. Dealer installation may include
this service.
7. Indoor sun rooms can maintain high
ambient temperatures which may eect
the spa water temperature. It is NOT
recommended that you operate your lter
cycles for longer than 4 hours per day
under these conditions.

8
Owner’s Manual
English
8. For units for use in other than single-family
dwellings, a clearly labeled emergency
switch shall be provided as part of the
installation. The switch shall be readily
accessible to the occupants and shall be
installed at least 5 feet (1.52 m) away,
adjacent to, and within sight of the unit.
THERMAL CREEP
Your spa is manufactured with energy-e-
cient components and systems that capture
heat generated by the equipment, then trans-
fer that heat back to the spa water. In warmer
weather or in situations with extended run
times, “Thermal Creep”may occur. Thermal
Creep is a condition whereby the actual water
temperature is higher than the set tempera-
ture. To manage “Thermal Creep”you may:
- Vent your cover. Newer covers have remov-
able center seal padding. To remove this pad-
ding, open the Velcro on one side of the vinyl
pouch and slide the white padding out. If
your spa does not have removable center seal
padding, you may instead place a folded cloth
about ¾” (2cm) thick under all four corners of
the cover before you lock it down. Opening
the cover at night will also quickly cool the
water down if desired.
- Open all air controls
- Set your ltration cycles to run during the
cooler times of the day or at night
- Reduce the length of your lter cycles
- Visit your local dealer for additional guidance
Thermal Creep only occurs in well-insulated
hot tubs. It is not an indication that something
is wrong with your spa or its equipment.
IMPORTANT: Proper drainage must be pro-
vided to keep base dry, especially if installed
below ground/in a pit.
Danger: Electrical shock risk. Install at least
5 feet (1.5m) from all metal surfaces

9
Owner’s Manual
English
SPA SYSTEM COMPONENTS
A. Filter Skimmer/Weir: Removes
oating debris from the water surface,
provides a water return path to equipment,
and houses water lter element.
B. Topside Control Panel: Used to control
temperature setting, pump for jets,
and light.
D. Manufacturer’s Identication Label:
Contains identication information
for warranty service (serial number, model
number, etc.) and electrical information
(amperage rating and amperage
requirements).
E. Equipment Pack Service Panel (no user
serviceable parts): Spa support system
consisting of 2-speed pumps, heater, and
associated electrical controls are inside
this front panel (not shown).
F. Air Controls: Increases or decreases air
entering the jets. Close during heating for
maximum eciency.
G. Digital/Fiber Optic Lighting: Lighting
system that displays multiple colored
lights in pre-programmed random, solid or
alternating colors (not shown).
J. Drain Access: (Adjacent to the equipment
service panel) Spa drain faucets.

10
Owner’s Manual
English
SPA COMPONENTS
Reference only. Equipment is not always as shown.
A. Pumps (one pump or more,
depending on model): Low speed for
ecient water circulation during ltration
and heating; high speed for maximum
action of the jets. The pump functions are
activated by topside controls.
B. Manufacturer’s Identication Label:
Contains identication information
for warranty service (serial number, model
number, etc.) and electrical information
(ampere rating and ampere requirements).
C. Slice Valve: Used to shut o water ow
from the spa to the equipment while
servicing. Quantity will vary depending
on model. All should be open during
normal operations.
D. Electrical Connections: Electrical inputs/
wires for the unit connect here.
E. Heater Assembly: Thermostatically
controlled and equipped with an
overheat safety shut-o.
G. Ozone Generator (Optional)
Note: No consumer serviceable parts.
Do NOT attempt to service any of these
components yourself. Contact your dealer
for assistance.
D C E AG B

11
Owner’s Manual
English
JETS AND AIR CONTROLS
JETS
All spa jets are individually engineered
to provide a unique hydro-massage.
Depending on the model, your spa will have a
combination of the following jets.
Swim Spa Jets
Swim spa jets are designed to produce a
smooth ow of water with high output to
create a consistent swim stream. Whether you
want to swim or walk/jog against the force
of the jets, you will nd the ow of water
deep enough and swift enough to meet your
individual needs.
Hydrotherapy Area Jets
All spa jets are individually engineered
to provide a unique hydro-maassage.
Depending on the model, your spa will have a
combination of the following jets.
Directional Jets
Positioned to focus on large muscle groups,
these jets deliver a concentrated, high volume
stream of water for a deep massage. Each jet
is fully adjustable, allowing users to set the
water ow to the most comfortable setting.
Nozzle can be rotated to target sore muscles.
Rotating Jets
Positioned to focus on muscle tension zones,
these jets deliver a spinning V-shaped water
stream for a gentle, pulsating massage. Each
jet is fully adjustable, allowing for comfortable
water ow settings for everyone to enjoy.
Euro Jets
Positioned in the foot well or shoulder areas,
these jets deliver a penetrating massage to
dissolve tension. This jet may be the entry
point for ozone produced during automatic
ltration and therefore it is not adjustable.
Note: Ozone production is stopped when
functions are activated on control panel.
CLEANING OR REPLACING JETS
Hard water can cause calcium/mineral
buildup that can restrict or bind the jets. A jet
consists of a face plate and a nozzle. Rotate
these parts weekly and remove/clean to
ensure free movement, including the aurora
cascades jets.
NOTE: It is not necessary to drain the spa to
clean or remove the jets.
Rotating Jets
• Rotate the jet face left and right
• Return face plate to full open position
• Turn the jets on high speed
• Twist the nozzle left and right
• Rotate the nozzle in the socket
NOTE: If the jet insert disengages from the
spa housing, see steps to reinstall below.
CLEANING JETS
• To REMOVE the jet insert, use the palm of
your hand to exert pressure on the face of the
jet. Turn counterclockwise until the jet ‘clicks’.
Gently pull the jet assembly from the housing.
• To REMOVE the smaller adjustable jet
insert, wear latex or rubber gloves. Turn
counterclockwise until you reach the stopping
point. Exert more pressure to turn past the
stopping point and as the jet ‘clicks’ pull the
insert toward the center of the spa. Gently pull
the jet insert from the housing.
• To CLEAN the jet insert and housing, use a
pressurized hose and spray the inside of the

12
Owner’s Manual
English
jet. Soak the jet in a diluted spa cleaning
solution, rinse. Wipe the inside of the housing
to remove any debris.
• To REINSTALL the jet, line up the tab on
the backside of the barrel with the groove in
the body. Use the palm of your hand to gently
tap the jet until it snaps into position.
AIR CONTROLS
The intensity of the jet action can be
controlled by altering the amount of air
injected with water through the jets. Your
spa has one or more air controls located on
the lip of the spa. Each control activates air to
specic jets in the spa allowing you to create
various combinations and levels of jet action
to suit individual preferences. Turn the control
counter-clockwise to turn the air o and
clockwise to turn air on.
NOTE: Air controls should be closed
during heating cycles for maximum
energy eciency.
NOTE: At the start of a ltration cycle, the
Optional Air System is activated to purge
the lines and ensure complete ltration.
Ensure that at least one air control is always
fully open.
NEVER SHUT ALL FULL SIZED
JETS OFF AT ONE TIME!

13
Owner’s Manual
English
ELECTRICAL INFORMATION
IMPORTANT SAFETY INSTRUCTIONS
All electrical connections to this spa
package MUST be done by a qualied
licensed electrician or certied technician
in accordance with National Electrical Code
(NEC) and with state/local electrical codes in
eect at the time of installation.
NOTE: Prior to performing any service to
the spa equipment, turn OFF all primary
electrical power at the main circuit breaker
or disconnect panel.
To make spa electrical connections, remove
the exterior equipment access panel, locate
the electrical control box, remove the control
box cover and follow the wiring diagram
on the inside of the control box cover.
Connections should be made using copper
conductors only; DO NOT use aluminum.
Connecting wires, circuit breakers or fuses
must all be sized to accommodate the Total
Ampere load as specied on the equipment
label.
This equipment is designed to operate on
50Hz or 60Hz alternating current only, at 240
volts or 120 volts, as required.
NOTE: All unions must be hand-tight and
all slice valves must be locked in the OPEN
position before lling or relling spa!
A clip is provided to help keep the slice
valve open. Run spa and check for union
water leaks before reinstalling front panel.
FOR EUROPE ONLY
The spa is intended for use only in premises
having a service current capacity ≥ 100 A per
phase, supplied from a distribution network
having a nominal voltage of 230 V. The user
shall determine in consultation with the
supply authority, if necessary, that the service
current capacity at the interface point is
sucient for the spa.
Equipment complying with IEC 61000-3-11.
GFCI
(Ground-Fault Circuit Interupter)
A qualied licensed electrician must con-
nect the spa to a circuit protected by a GFCI.
This is a requirement by the National Electric
Code, article 680.44, and is also in compli-
ance with Underwriter’s Laboratories, Inc.
RESIDUAL CURRENT DEVICE
The appliance should be supplied through
a residual current device (RCD) or Ground
Fault Interruper (GFCI) with a rated tripping
current not exceeding 30mA. Means for
disconnection must be incorporated in the
xed wiring in accordance with the wiring
rules. Parts containing live voltage, except
parts supplied with safety extra-low voltage
not exceeding 12V, must be inaccessible to a
person in the bath. Earthed appliances must
be permanently connected to xed wiring.
INSTALLATION OPTIONS
Refer to the manufacturer’s nameplate
located on the kick plate to determine your
spa’s amperage requirements.
Note: Copper wire is strongly recommended
for all electrical connections.
Spas installed for 120 volt operation require
a 3-wire, 40, 30, 20 or 15 amp., 120 volt
sub-feed in non-metallic pipe to the spa
Caution: Risk of electrical shock.
Read and follow all instructions.

14
Owner’s Manual
English
equipment compartment (line 1, neutral and
ground). A green colored terminal (or wire
connector marked “G”, or “GR”, or “Ground-
ing”) is provided in the control box. To
reduce the risk of electrical shock, connect
this terminal or connector to the grounding
terminal of your electrical service or supply
panel with a continuous green insulated cop-
per wire equivalent to the circuit conductor
supplying this equipment, but no smaller
than No. 12 AWG. A second pressure wire
connector is provided on the surface of the
control box for bonding to local ground
points. To reduce the risk of electrical shock,
this connector should be bonded with a No. 6
AWG copper wire to any metal ladders, water
pipes, or any metal within 5 ft. of the spa.
Spas installed for 240 volt, 60 Hz, single phase
operation require a 4-wire, 60, 50, 40 or 30
amp., 240 volt sub-feed in non-metallic pipe to
the spa equipment compartment (line 1, line 2,
neutral and ground). A green colored terminal
(or wire connector marked “G”, or “GR”, or
“Grounding”) is provided in the control box. To
reduce the risk of electrical shock, connect this
terminal or connector to the grounding termi-
nal of your electrical service or supply panel
with a continuous green insulated copper wire
equivalent to the circuit conductor supplying
this equipment, but no smaller than No. 12
AWG. A second pressure wire connector is
provided on the surface of the control box for
bonding to local ground points. To reduce the
risk of electrical shock, this connector should
be bonded with a No. 6 AWG copper wire to
any metal ladders, water pipes, or any metal
within 5 feet (1.5m) of the spa.
CORD CONNECT
Certain models may be connected with a
power cord which contains the GFCI or RCD
breaker. All electrical connections from the
control pack to the outlet should be done by
a qualied electrician. For your safety, when
the electrician is installing the single electrical
outlet and waterproof cover, the outlet should
be no further than 10 feet (3m) from the spa
[N.E.C. Article 680 and all local codes].
The Ground Fault Circuit Interrupter (GFCI)
or Residual Current Device (RCD) is located
on the power cord. This device is for your
protection. It is very important to protect it
along with the moisture resistant cover from
damage. Test once a month, with the plug
connected to the power supply.
NEVER CONNECT SPA TO EXTENSION CORD!
A pressure wire connector is provided on
the exterior surface of the control box inside
the spa. This is to permit the connection of a
ground bonding wire between this point and
any metal equipment, enclosures, reinforced
concrete pad, pipe, or conduit within 5
feet (1.5m) of the spa (if needed to comply
with local building code requirements). The
bonding wire must be at least a #10 AWG solid
copper wire.
Bond the spa to all exposed metal equipment
or xtures, handrails, and concrete pad per
N.E.C. Article 680 and all local codes.
1. Push the“TEST” button on the GFCI/RCD
breaker. The spa should stop operating and
the GCFI power indicator will go out.
2. Wait 30 seconds, then push the “RESET”
button. Power will be restored to the spa and
the GFCI/RCD power indicator will turn on. If
the GFCI/RCD fails to operate in this manner,
your spa may have an electrical malfunction,
and you may be risking electrical shock. Turn
o all circuits and do not use the spa until the
problem has been corrected by an authorized
service agent.
WARNING: Removal of the GFCI/RCD from the

15
Owner’s Manual
English
spa’s power cord will result in an unprotected
spa and will void the spa’s warranty.
IMPORTANT: Should you ever nd the need to
move or relocate your spa, it is essential that
you understand and apply these installation
requirements. Your spa has been carefully
engineered to provide maximum safety
against electrical shock.

16
Owner’s Manual
English
240 Volt Installation Units
Electrical Requirements
Requirement
- 240 volt/60 amp, 50 amp, 40 amp, or 30 amp.
- 60 Hz
- Single phase
- 4-wire service (line 1, line 2 neutral and ground)
NOT NORTH AMERICAN
- 240 volt
- 50 Hz
- Single-, two-, or three- phase service
- Refer to wiring diagram or pouch on control
system inside cabinet for specic wiring and phase
information.
120 Volt Installation Units
Electrical Requirements
Requirement
- 120 volt/30 amp or 15 amp.
- 60 Hz
- Single phase
- 3-wire service (line 1, neutral and
ground)
Number Meaning
1The heater will only remain running with no more than two pumps on high speed.
All pumps will run on high speed when heater is o.
2
The heater will only remain running with Pump 1 on low speed. Only the spa light
can operate at the same time without disabling the heater. All pumps will run on
high speed when heater is o.
VOLTAGE/AMPERAGE CHART:
THIS SECTION
APPLIES TO SPAS
INSTALLED OUTSIDE OF
NORTH AMERICA

17
Owner’s Manual
English
NOTE: ALL SPAS IN THIS TABLE LEAVE THE FACTORY AS 240V AND CAN BE CONVERTED
DOWN TO 120V
SPAS THAT ARE CONVERTIBLE (240V TO 120V)
North America
Model 120V/30A 120V/15A 240V/40A 240V/30A
Lune 1 2 1 2
Duet 1 2 1 2
Voeux 1 2 1 2
Image 1 2 1 2
NOTE: Electrical service requirements will change after conversion.
See previous page for explanation of corresponding letters and numbers.

18
Owner’s Manual
English
START UP PROCEDURES
Follow recommendations for site location
and electrical connection. 6” (15.5cm) below
the top lip of the spa is the level at which the
water should be maintained.
1. Fill the spa through the lter hole to 6”
(15.5cm) below the top of the spa with tap
water. Never use ‘softened’ water in
your spa. Softened water can impact the
chemical balance of the water and lead to
degradation of metal plumbing ttings
and possible jet plastic damage.
2. After you have assured that the spa/swim
spa is full of water and that all plumbing
valves are open, turn power on to unit at
circuit breaker or disconnect panel.
3. Open the air controls, located on the top
lip, and cycle the jets from high to low.
Water should come from the therapy jets.
If water ow is not established, turn o jets
and see Priming Your Spa (next column).
4. Add chemicals. See Chemical Treatment
and Water Maintenance section.
Follow Operating Insutructions for your
particular model to set heat to the desired
temperature. Initially, you may nd that
the spa requires 12 to 14 hours (18 to 24
hours for swim spas) on 230 Volt
installations to reach temperature. Keep
your thermal cover on the unit and close
the air controls to help the heating
process.
5. Verify all drain valves are closed, some are
under the spa.
PRIMING YOUR SPA
When lling your spa for the rst time or
after draining and relling the spa, you
may need to bleed air from the system.
Should you experience an air-lock on
Pump 1, remove the lter cover,
insert a garden hose through each center
hole that holds the lter as far as possible
without using force. Hold the hose in place
and turn on the water. Cycle pump 1 from low
to high several times, this forces water into the
pump and forces the air out. If this does not
work or you experience an air-lock on Pump 2,
remove the side panel and locate the pump.
With the pump on high speed, slowly loosen
the discharge (top) pump union until water
starts to trickle out. Once water is trickling out,
hand tighten the union (do not over tighten
as this could cause the union to crack) and
replace the side panel.
Pr - Prime/Purge Pumps
This is Not an Error Message.
The Spa has just been powered up and is in
Priming Mode for 4 Minutes. Pumps can be
turned ON and OFF to remove any air from
the plumbing lines and the Heater. Cycle the
pumps on and o to verify good water ow
and wait 4 minutes or press any temp related
button to exit Priming Mode.
Important: Do not operate the spa
without full water ow.

19
Owner’s Manual
English
TP500 CONTROL PANEL
MAIN MENUS
If panel has Up & Down temp buttons, pressing
either will cause the temperature to ash.
Pressing a Temp Button again with adjust the set
temp in the direction indicated on the button.
When LCD stops ashing, spa will heat to the
new set temp when required.
If panel has a single Temp Button, pressing the
button will cause temp to ash. Pressing the
button again will cause the temp to change in
one direction (up). After allowing the display
to stop ashing, pressing the Temp Button will
cause the temp to ash and the next press will
change the temp in the opposite direction
(down).
The LIGHT button is used to activate spa lights
Used to access and cycle through menues
BUTTON NAME FUNCTION
Jets 1
Blower
Temperature
Light
Activates jets on
low or high setting
Activates blower
Changes
temperature
and allows for
navigation
through system
Activates lights
and chooses
Menu
NOTE: The look of your topside control panel design and buttons will vary according to
features available on your spa. See table below for explanations of TP500 Control Panel
button functions.
