Model F231-I3 & F231-I3-2X
Operator’s Manual
513710 Rev.3

2 F231 OPERATOR’S MANUAL 513710 REV.3
Section 1: Introduction
MAINTENANCEPARTS TROUBLESHOOTING OPERATION INTRODUCTION
A VOLLRATH® DIVISION
This manual provides basic information about the machine. Instructions and suggestions are given covering its operation
and care. This manual follows the guidance set forth in the following industry standards: ANSI Z535.6, ASTM F760-93,
ASTM F1827-13, FDA Food Code.
The illustrations and specifications in this manual are not binding in detail. We reserve the right to make changes to the
machine without notice, and without incurring any obligation to modify or provide new parts for machines built prior to
date of change.
DO NOT ATTEMPT to operate the machine until instructions and safety precautions in this manual are read completely
and are thoroughly understood. If problems develop or questions arise in connection with installation, operation, or ser-
vicing of the machine, contact Stoelting White Glove Service.
Stoelting Foodservice Equipment
502 Highway 67
Kiel, WI 53042-1600
U.S.A.
White Glove Service Network
Phone: [phone]
© 2019 Stoelting
stoeltingfoodservice.com

513710 REV.3 F231 OPERATOR’S MANUAL 3
Section 1: Introduction
MAINTENANCE PARTSTROUBLESHOOTINGOPERATION
INTRODUCTION
This manual is divided into the following five sections:
A. Consistency Adjustment
B. Daily Procedures - Night
C. Daily Procedures Morning
MAINTENANCE
A. Auger Shaft & Front Door Parts
PARTS
A. Troubleshooting Flow Charts
TROUBLESHOOTING
A. Empty the Freezing Cylinders - Start here if cleaning a machine with mix in it
B. Disassemble Parts - Start here if cleaning an empty machine
C. Cleaning Disassembled Parts
D. Cleaning the Machine
E. Assembling the Machine
F. Sanitizing
G. Freeze Down
H. Brushes for Cleaning
I. Lubrication Points
OPERATION
A. Parts of the Machine
B. Specifications
INTRODUCTION

4 F231 OPERATOR’S MANUAL 513710 REV.3
Section 1: Introduction
MAINTENANCEPARTS TROUBLESHOOTING OPERATION INTRODUCTION
A. Parts of the F231-I3 Machine (F231-I3-2X Shown)
IntelliTec3™
Freezing Cylinder
Hopper
IntelliTec3™ Touchpad
Front Door
Spigot Handle
The F231 has two physical designs: the slimline and the large capacity hopper. Operating instructions for the two versions
are identical.
This manual shows large capacity hopper style.

513710 REV.3 F231 OPERATOR’S MANUAL 5
Section 1: Introduction
MAINTENANCE PARTSTROUBLESHOOTINGOPERATION
INTRODUCTION
19 1/8"
15 1/2"
31 3/8"
58 1/8"
20"
52 1/2"
28"
B. F231-I3 Specifications (Slimline)
Model F231-I3
Dimensions Machine as shipped
width 19-1/4’’ (48,9 cm) 32’’ (81,3 cm)
height 58-1/4’’ (148,0 cm) 60’’ (152,4 cm)
depth 28’’ (71,1 cm) 39’’ (99,1 cm)
Weight 400 lbs (181,4 kg) 494 lbs (224,0 kg)
Electrical 60Hz A/C
1 PH, 208-240 VAC
60Hz W/C
1 PH, 208-240 VAC
60Hz A/C
3 PH, 208-240 VAC
60Hz W/C
3 PH, 208-240 VAC
running amps 12A 12A 10A 10A
connection type NEMA 6-20P NEMA 6-20P NEMA L15-20P NEMA L15-20P
International Option 50Hz A/C - 1 PH, 220-240 VAC
Compressor 12,000 Btu/hr
Drive Motor Two - 3/4 hp
Air Flow Air cooled units require 3” (7,6 cm) air space on both sides
Plumbing Fittings Water cooled units require 1/2” N.P.T. water and drain fittings.
Maximum water pressure of 130 psi. Minimum water flow rate of 3 GPM. Ideal EWT of 50°-70°F
Hopper Volume Two - 3 gallon (11,35 liters)
Freezing Cylinder
Volume Two - 0.85 gallon (3,22 liters)

6 F231 OPERATOR’S MANUAL 513710 REV.3
Section 1: Introduction
MAINTENANCEPARTS TROUBLESHOOTING OPERATION INTRODUCTION
20 5/8"
57 3/4"
33 3/4"
47 1/4"
30"
25 5/8"
21 5/8"
C. F231-I3-2X Specifications (Large Capacity Hopper)
Model F231-I3-2X
Dimensions Machine as shipped
width 25-5/8’’ (65,1 cm) 40-1/4’’ (102,2 cm)
height 57-3/4’’ (146,7 cm) 64-1/2’’ (163,8 cm)
depth 33-3/4’’ (85,7 cm) 33-1/4’’ (84,5 cm)
Weight 640 lbs (290,2 kg) 730 lbs (331,1 kg)
Electrical 60Hz A/C
1 PH, 208-240 VAC
60Hz W/C
1 PH, 208-240 VAC
60Hz A/C
3 PH, 208-240 VAC
60Hz W/C
3 PH, 208-240 VAC
running amps 13.5A 12A 11.5A 11.5A
connection type NEMA 6-20P NEMA 6-20P NEMA L15-20P NEMA L15-20P
International Option 50 Hz A/C - 1 PH, 220-240 VAC 50 Hz A/C - 3 PH, 380-415 VAC
Compressor Freezing Cylinders - 12,000 Btu/hr
Storage - 1,300 Btu/hr Compressor (R-134a)
Drive Motor Two - 3/4 hp
Air Flow Air cooled units require 3” (7,6 cm) air space on both sides
Hopper Volume Two - 5 gallon (18,9 liters)
Freezing Cylinder
Volume Two - 0.85 gallon (3,22 liters)

513710 REV.3 F231 OPERATOR’S MANUAL 7
Section 2: Operation
MAINTENANCE PARTSTROUBLESHOOTING
OPERATIONINTRODUCTION
A. Empty the Freezing Cylinders
Optional: Add Stera Sheen to cool tap water
before adding it to the hoppers to make
cleaning parts easier after disassembly.
NOTE
The machine must be emptied,
disassembled, cleaned and sanitized
every 3 days or per local health code
requirements (whichever is sooner).
NOTE
Start the clean cycle. Press the Left then the Clean
button. Press the Right then the Clean button.
After about 5 minutes, open the spigots to drain the mix.
Stop the clean cycle by toggling the Clean buttons.
Press the Left then the Clean button. Press the Right
then the Clean button.
A.3
Turn both freezing cylinders
o by toggling the Freeze
button.
Press Left then the Freeze
button. Press Right then the
Freeze button.
A.1
Remove the hopper covers and
remove the mix inlet regulators
from the hoppers.
A.2
Fill each hopper with 1 gallon
of cool tap water and start the
clean cycle.
Scrub the hoppers with a
clean brush.
A.4
Open the spigots to drain.
Refill the hoppers with water as
necessary until the water drains
clear.
A.5
The machine is o when the Freeze, Sleep,
and Clean buttons have the plain white
border (not highlighted in green).
NOTE

8 F231 OPERATOR’S MANUAL 513710 REV.3
Section 2: Operation
MAINTENANCEPARTS TROUBLESHOOTING OPERATION INTRODUCTION
Before using the machine for the first time, complete
machine disassembly, cleaning and sanitizing
procedures need to be followed. Routine cleaning
intervals and procedures must comply with the local
and state health regulations. Inspection for worn or
broken parts should be made at every disassembly
of the machine. All worn or broken parts should be
replaced to ensure safety to both the operator and the
customer and to maintain good machine performance
and a quality product. Check the wear line on the auger
flights on a regular basis and replace as needed.
B. Disassemble Parts
Auger Flight Wear
Remove all o-rings from
parts by first wiping o the
lubrication using a clean
towel. Then squeeze the
o-ring upward to form a
loop. Roll the o-ring out of
the groove.
B.3
Remove the spigot extensions or rosette caps if
installed.
Unscrew the knobs on the front door and remove
the door.
B.1
1. Front Door Disassembly
Stop the clean cycle by
toggling the Clean buttons.
A.6
Remove the front door o-rings
and remove the spigots from the
front door.
B.2

513710 REV.3 F231 OPERATOR’S MANUAL 9
Section 2: Operation
MAINTENANCE PARTSTROUBLESHOOTING
OPERATIONINTRODUCTION
2. Removing Auger
Remove front auger supports and bushings and
remove the augers from the freezing cylinders. As
the augers are being pulled out, remove the plastic
flights with springs.
B.4
Unscrew springs
from the auger
flights.
B.6
Wipe any remaining
lubricant o the hex
end of the auger and
remove the rear seal
and o-ring. Wipe any
remaining lubricant o
the o-ring and auger.
B.5
C. Cleaning Disassembled Parts
Disassembled parts require complete cleaning,
sanitizing and air drying before assembling. Local
and state health codes will dictate the procedure
required. Some state health codes require a four sink
process (pre-wash, wash, rinse, sanitize, air dry), while
others require a three sink process (without the pre-
wash step). The following procedures are a general
guideline only. Consult your local and state health
codes for the procedures required in your location.
Place all parts in 90° to 110°F (32°C to 43°C) mild
detergentwaterandwashthoroughly. Use the brushes
that shipped with the machine to clean all holes in
the front door, flights, mix pickup assembly, etc.
C.1
Rinse all parts with clean 90° to 110°F (32°C to 43°C)
water. Then place all parts in a sanitizing solution for at
least 1 minute, then remove and let air dry completely
before assembling in machine.
C.2
Be sure to use the brushes that shipped
with the machine to properly clean the
parts.
NOTE

10 F231 OPERATOR’S MANUAL 513710 REV.3
Section 2: Operation
MAINTENANCEPARTS TROUBLESHOOTING OPERATION INTRODUCTION
D. Cleaning the Machine
Wrap the brush in a clean cloth and thoroughly dry
the freezing cylinder.
D.2
The exterior of the machine should be kept clean at
all times to preserve the luster of the stainless steel.
A high grade of stainless steel has been used on the
machine to ease cleanup. To remove spilled or dried
mix, wash the exterior with 90° to 110°F (32°C to 43°C)
mild detergent water and wipe dry.
Do not use highly abrasive materials, as they will mar
the finish. A mild alkaline cleaner is recommended.
Use a soft cloth or sponge to apply the cleaner. For
best results, wipe with the grain of the steel.
D.4
E. Assembling Machine
Total Blend lubricant or equivalent must be
used when lubrication of machine parts is
specified.
The USDA and FDA require that lubricants
used on food processing equipment must
be certified for this use. Use lubricants
only in accordance with the manufacturer’s
instructions.
NOTE
Install the rear seal o-rings onto the augers. Lubricate
the outside of the o-rings with a generous amount of
sanitary lubricant.
E.1
Stoelting recommends allowing the parts
to air dry before assembling.
NOTE
Using a detergent solution and
the large barrel brush provided,
clean the freezing cylinders by
dipping the brush in the solution
and brushing the inside of the
freezing cylinders.
Make sure to thoroughly clean
the rear seal surfaces on the
inside of the freezing cylinders.
D.1
Remove the drain trays from
the front of the machine.
Remove the drip tray from
the front panel. Clean and
replace the trays.
D.3

513710 REV.3 F231 OPERATOR’S MANUAL 11
Section 2: Operation
MAINTENANCE PARTSTROUBLESHOOTING
OPERATIONINTRODUCTION
Lubricate the inside metal surface of the rear seal and
install it onto the auger shaft.
DO NOT lubricate the outside of the rear seal.
E.2
Lubricate the hex end of the auger with Total Blend
lubricant.
E.3
Screw the springs onto
the studs in the plastic
flights. The springs must
be screwed into the
flights completelyto provide
proper compression.
E.4
Install the two plastic flights onto the rear of the auger
and insert it part way into the freezing cylinder.
E.5
Install the remaining plastic
flights, push the auger into the
freezing cylinder and rotate
slowly until the auger engages
the drive shaft.
E.6

12 F231 OPERATOR’S MANUAL 513710 REV.3
Section 2: Operation
MAINTENANCEPARTS TROUBLESHOOTING OPERATION INTRODUCTION
Install the bushing onto the auger
support and install the auger
support into the front of the auger.
Rotate the auger support so that
one leg of the support points
straight up.
E.8
Apply a thin layer of Total Blend lubricant to the inside
and outside of the auger support bushing.
E.7
Install the o-rings onto the spigot bodies and apply a
thin layer of Total Blend lubricant to the o-rings . Install
the spigot bodies through the bottom of the front door.
E.11
Fit the front door o-rings
into the groove on the rear
of the front door.
E.12

513710 REV.3 F231 OPERATOR’S MANUAL 13
Section 2: Operation
MAINTENANCE PARTSTROUBLESHOOTING
OPERATIONINTRODUCTION
Make sure the pins on the front door do
not touch the legs of the auger supports.
NOTE
Place the front door
assembly on the
mounting studs and
push the front door
against the machine
carefully.
E.13
Secure the front door to the machine by placing the
knobsonthestudsandtightenuntilfingertight. Tighten
in a crisscross pattern. Do not overtighten. Proper
o-ring seal can be observed through the transparent
front door.
E.14 When sanitizing the machine, refer to local sanitary
regulations for applicable codes and recommended
sanitizing products and procedures. The frequency of
sanitizing must comply with local health regulations.
Mix sanitizer in quantities of no less than 2 gallons
of 90°F to 110°F (32°C to 43°C) water. Allow sanitizer
to contact the surfaces to be sanitized for 5 minutes.
Any sanitizer must be used only in accordance with
the manufacturer’s instructions and to provide a 100
parts per million strength solution.
F. Sanitizing
Sanitizing must be done after the machine is clean and
just before the machine is filled with mix. Sanitizing
the night before does not ensure sanitization the next
day. However, you should always clean the machine
and parts after using it.
The United States Department of
Agriculture and the Food and Drug
Administration require that all cleaning
and sanitizing solutions used with food
processing equipment be certified for this
use
NOTE

14 F231 OPERATOR’S MANUAL 513710 REV.3
Section 2: Operation
MAINTENANCEPARTS TROUBLESHOOTING OPERATION INTRODUCTION
Check for leaks:
1. Check for leaks at the front door seal.
2. Check the drain trays located under the front door
for leaks coming from the rear of the rear auger
seal.
If any leaks are found, drain the machine and
disassemble it. Inspect the rear seal, front door o-rings,
and rear seal o-rings for damage and replace as
necessary. Properly assemble machine and refill with
sanitizing solution.
F.3
Stop the clean cycle. Press the Left then the Clean
button. Press the Right then the Clean button.
Make sure the freezing cylinder has completely
drained.
F.6
Do not twist the mix inlet regulators when
installing.
NOTE
The machine is now sanitized and ready for adding mix.
Prepare 2gallonsofsanitizing solution for eachfreezing
cylinder. Following the
sanitizer manufacturer’s
instructions for preparing
the solution.
Install the mix inlet
regulators into the
hopper with the air tube
towards the front of the
machine.
F.1
Pour the sanitizing solution
into the hoppers and start
the clean cycle. Press the
Left then the Clean button.
Press the Right then the
Clean button.
F.2
Use a sanitized soft
bristle brush dipped
in sanitizing solution
to clean the hopper
sides, the mix inlet
regulator, and the
underside of the
hopper cover.
F.4
After five minutes, open the spigots
to drain the sanitizing solution.
F.5
The machine is o when the Freeze, Sleep,
and Clean buttons have the plain white
border (not highlighted in green).
NOTE

513710 REV.3 F231 OPERATOR’S MANUAL 15
Section 2: Operation
MAINTENANCE PARTSTROUBLESHOOTING
OPERATIONINTRODUCTION
G. Freeze Down
Place a container under the spigot and open the spigot
to allow the mix to flush out about 8 ounces (0.23 liters)
of sanitizing solution and liquid mix.
G.2
Allow the freezing cylinder to fill about 3/4 full, then
start the freezing cycle. Press the Left then the Freeze
button. Press the Right then the Freeze button
G.3
Fill the hopper with
at least 2.5 gallons
of mix.
G.1
When the product is ready, the display
will read “Ready” above the Freeze
button.
Open the spigot to dispense product.
G.8

16 F231 OPERATOR’S MANUAL 513710 REV.3
Section 2: Operation
MAINTENANCEPARTS TROUBLESHOOTING OPERATION INTRODUCTION
H. Brushes for Cleaning
208135
208465
208380
208467
208401
208387
Part Number Where Used
208135 Freezing cylinder
208380 Mix inlet regulator
208387 Front door, mix inlet regulator
208401 Front door, mix inlet regulator
208465 Front door, spigot holes
208467 Front door, side ports

513710 REV.3 F231 OPERATOR’S MANUAL 17
Section 2: Operation
MAINTENANCE PARTSTROUBLESHOOTING
OPERATIONINTRODUCTION
I. Lubrication Points
O-Ring & Hex
End of Auger
ONLY Inside
Metal Adapter
Inside & Outside
of Bushing
All O-Rings*

18 F231 OPERATOR’S MANUAL 513710 REV.3
Section 3: Maintenance
MAINTENANCEPARTS TROUBLESHOOTING OPERATION INTRODUCTION
Product consistency can be adjusted under
the Product Settings screen.
C. Consistency Adjustment
Enter the passcode as shown below starting with the
button in the upper left corner.
C.3
Press the gear icon and
then press the Product
Settings button.
C.1
As soon as the password is correctly
entered, the consistency setting screen is
displayed.
NOTE
Make adjustments in increments of 2 for
best results. Allow 3-4 draws or 30 minutes
for the changes to take eect.
NOTE
Select the Left
Consistency or Right
Consistency button to
change the value.
C.2
1
2
3
4
5
Press the up and down
arrows to adjust the
consistency.
Press the Set button to
save the change.
The Default button reverts to the last saved value.
C.4
Press the Home button when done making
changes to return to the home screen.
C.5

513710 REV.3 F231 OPERATOR’S MANUAL 19
Section 3: Maintenance
MAINTENANCE PARTSTROUBLESHOOTINGOPERATIONINTRODUCTION
D. Daily Procedures - Night E. Daily Procedures - Morning
Daily Procedures
Clean the underside of the clear front door and the
exposed portion of the spigots with brushes and a
mild detergent water and then with sanitizing solution.
E.1
Remove the spigot extensions and rosette caps if
installed. Clean and sanitize them and let them air dry.
D.2 Install the spigot extensions and rosette caps.
E.2
Check the mix level in the hoppers and remove any
foam sitting on top of the liquid mix.
Add new mix as necessary.
E.3
Drain about 3/4 of the mix out of the freezing cylinder
into a clean and sanitized container.
Pour the mix into the hopper and allow mix to fill the
freezing cylinder about 3/4 full.
E.4
Wipe the exterior clean with a mild detergent water to
remove spilled or dried mix and wipe dry.
D.4
Removethedriptrayfrom
the front panel. Clean the
tray and reinstall it.
D.1
Clean the underside of the clear front door and the
exposed portion of the spigots with mild detergent
water and then with sanitizing solution.
D.3
Press the Sleep button
for each freezing
cylinder if the night
mode schedule is not
set.
D.5
Press the Freeze button
for each freezing
cylinder to start freezing
the product.
E.5

20 F231 OPERATOR’S MANUAL 513710 REV.3
Section 4: Troubleshooting
MAINTENANCEPARTS TROUBLESHOOTING OPERATION INTRODUCTION
Contact Stoelting White
Glove Service for further
assistance
Is the product still
too firm? Yes
Continue normal
operation.
No
Product is Too
Firm
Decrease the
consistency.
Contact Stoelting White
Glove Service for further
assistance
Is the product still
too Soft? Yes
Continue normal
operation.
No
Product is Too
Soft
Increase the
consistency.
Is there an air flow
restriction around
the machine?
Move anything blocking
the louvered panels and
make sure there is
enough air clearance
around the machine.
Is the problem
fixed?
No
Yes No
Yes
