Vollrath Stoelting E131-I2 User manual

Model E131-I2 / F131-I2
OPERATORS MANUAL
Manual No. 513674 Rev.5
A VOLLRATH® DIVISION

A VOLLRATH® DIVISION
This manual provides basic information about the machine. Instructions and suggestions are
given covering its operation and care. This manual follows the guidance set forth in the follow-
ing industry standards: ANSI Z535.6, ASTM F760-93, ASTM F1827-13, FDA Food Code.
The illustrations and specifications in this manual are not binding in detail. We reserve the right
to make changes to the machine without notice, and without incurring any obligation to modify
or provide new parts for machines built prior to date of change.
DO NOT ATTEMPT to operate the machine until instructions and safety precautions in this
manual are read completely and are thoroughly understood. If problems develop or questions
arise in connection with installation, operation, or servicing of the machine, contact Stoelting
White Glove Service.
For warranty information, visit stoeltingfoodservice.com
stoeltingfoodservice.com
Stoelting Foodservice Equipment
502 Highway 67
Kiel, WI 53042-1600
U.S.A.
White Glove Service Network
Phone: [phone]
© 2021 Stoelting

A Few Words About Safety
Safety Information
Read and understand the entire manual before
operating or maintaining Stoelting equipment.
This manual provides the operator with information
for the safe operation and maintenance of Stoelting
equipment. As with any machine, there are hazards
associated with their operation. For this reason safety
is emphasized throughout the manual. To highlight
specific safety information, the following safety
definitions are provided to assist the reader.
The purpose of safety symbols is to attract your
attention to possible dangers. The safety symbols,
and their explanations, deserve your careful attention
and understanding. The safety warnings do not by
themselves eliminate any danger. The instructions
or warnings they give are not substitutes for proper
accident prevention measures.
If you need to replace a part, use genuine Stoelting
parts with the correct part number or an equivalent
part. We strongly recommend that you do not use
replacement parts of inferior quality.
Safety Alert Symbol:
This symbol Indicates danger, warning or caution.
Attention is required in order to avoid serious personal
injury. The message that follows the symbol contains
important information about safety.
Signal Word:
Signal words are distinctive words used throughout
this manual that alert the reader to the existence and
relative degree of a hazard.
WARNING
The signal word “WARNING” indicates a potentially
hazardous situation, which, if not avoided, may result in
death or serious injury.
CAUTION
The signal word “CAUTION” indicates a potentially
hazardous situation, which, if not avoided, may result in
minor or moderate injury.
NOTICE
The signal word “NOTICE” indicates information relating
to equipment/property damage. The information is not
hazard-related.
NOTE
The signal word “NOTE” indicates additional information
relating to the subject, usually a hint or tip, that is
not hazard-related and does not involve equipment/
property damage.

Section Description Page
Table of Contents
Section 1 - Description and Specifications 1
1.1 Description.......................................................................................................................1
1.2 Machine Models.............................................................................................................1
1.3 Specifications..................................................................................................................2
Section 2 - Installation Instructions 3
2.1 Safety Precautions.........................................................................................................3
2.2 Shipment and Transit ....................................................................................................3
2.3 Machine Installation.......................................................................................................3
2.4 IntelliTec2™ Setup...........................................................................................................4
Section 3 - Initial Set-Up & Installation 7
3.1 Operator’s Safety Precautions ..................................................................................7
3.2 Operating Controls and Indicators ...........................................................................7
3.3 Emptying the Freezing Cylinder.................................................................................8
3.4 Disassembly of Machine Parts....................................................................................8
3.5 Cleaning Disassembled Parts.....................................................................................9
3.6 Assembling Machine.....................................................................................................9
3.7 Sanitizing..........................................................................................................................10
3.8 Freeze Down and Operation ......................................................................................11
3.9 Mix Information...............................................................................................................12
Section 4 - Maintenance and Adjustments 13
4.1 Fine Consistency Adjustment.....................................................................................13
4.2 Preventative Maintenance...........................................................................................13
4.3 Extended Storage..........................................................................................................13
Section 5 - Troubleshooting 15
5.1 Error codes ......................................................................................................................15
5.2 Troubleshooting Error Codes .....................................................................................15
5.3 Troubleshooting Machine............................................................................................17
Section 6 - Replacement Parts 19
6.1 Decals & Lubrication .....................................................................................................19
6.2 Auger & Door ..................................................................................................................20
6.3 Trays & Hopper Cover ..................................................................................................21

Operators Manual #513674 1 E131-I2 & F131-I2 Model Machines
16 1/8"
15 1/2"
Air In
28 3/8"
28 1/4" Water Outlet
Water Inlet
Air Out
4 5/8"
3 7/8"
12 1/8"
22"
34 3/8"
Section 1 - Description and Specifications
1.1 DESCRIPTION
The Stoelting E131-I2 and F131-I2 counter-top machines are
gravity fed. The machines are equipped with the IntelliTec2™
control which provides a uniform product. The machines are
designed to operate with almost any type of commercial
soft serve or non-dairy mixes available, including: ice milk,
ice cream, yogurt, and frozen dietary desserts.
This manual is designed to assist qualified service per-
sonnel and operators in the installation, operation and
maintenance of the Stoelting E131-I2 and F131-I2 gravity
machines.
1.2 MACHINE MODELS
This manual applies to the following machine models:
• E131-38I2 • F131-38I2
• E131-18I2 • F131-18I2
• E131-309I2 • F131-38I2-YG2
• E131-109I2 • F131-309I2
• E131-38I2YG2 • F131-18I2-YG2
• E131-309I2YG2 • F131-109I2
• E131-109I2YG2 • F131-38I2-WF
• E131-38I2-WF • F131X-102I2
• E131X-102I2 • F131X-302I2
• E131X-302I2 • F131X-302I2-WF
• E131X-314I2 • F131X-314I2
• E131X-314I2-WF • F131X-314I2-WF
• E131-38I2YG2-TCBY • F131-18I2-WF
• F131-309I2-WF
• F131X-302I2-GP
Figure 1-1 Model F131-I2
Figure 1-2 Dimensions

Operators Manual #513674 2 E131-I2 & F131-I2 Model Machines
1.3 SPECIFICATIONS
Model E131-I2
Dimensions Machine with crate
width 22’’ (55,9 cm) 28’’ (71,1 cm)
height 34-3/4’’ (88,3 cm) 40-1/4’’ (102,2 cm)
depth 28-1/2’’ (72,4 cm) 35-1/4’’ (89,5 cm)
Weight 370 lbs (167,8 kg) 450 lbs (204,1 kg)
Electrical 1 Phase, 208-240 VAC, 60Hz 3 Phase, 208-240 VAC, 60Hz
running amps 12A 10A
connection type NEMA6-20P power cord provided NEMA L15-20P power cord provided
International Option 1 Phase, 220-240 VAC, 50Hz
Compressor 8,600 Btu/hr
Drive Motor Two - 3/4 hp
Air Flow Air cooled units require 3” (7,6 cm) air space on both sides
Plumbing Fittings Water cooled units require 3/8” N.P.T. water and drain fittings. Maximum water
pressure of 130 psi. Minimum water flow rate of 3 GPM. Ideal EWT of 50°-70°F.
Hopper Volume Two - 3 gallon (11,35 liters)
Freezing Cylinder
Volume Two - 0.65 gallon (2,46 liters)
Model F131-I2
Dimensions Machine with crate
width 22’’ (55,9 cm) 28’’ (71,1 cm)
height 34-3/4’’ (88,3 cm) 40-1/4’’ (102,2 cm)
depth 28-1/2’’ (72,4 cm) 35-1/4’’ (89,5 cm)
Weight 385 lbs (174,6 kg) 450 lbs (204,1 kg)
Electrical 1 Phase, 208-240 VAC, 60Hz 3 Phase, 208-240 VAC, 60Hz
running amps 12A Air-Cooled / 11A Water-Cooled 10A
connection type NEMA6-20P power cord provided NEMA L15-20P power cord provided
International Option 1 Phase, 220-240 VAC, 50Hz
Compressor 12,000 Btu/hr
Drive Motor Two - 3/4 hp
Air Flow Air cooled units require 3” (7,6 cm) air space on both sides
Plumbing Fittings Water cooled units require 3/8” N.P.T. water and drain fittings. Maximum water
pressure of 130 psi. Minimum water flow rate of 3 GPM. Ideal EWT of 50°-70°F.
Hopper Volume Two - 3 gallon (11,35 liters)
Freezing Cylinder
Volume Two - 0.85 gallon (3,22 liters)

Operators Manual #513674 3 E131-I2 & F131-I2 Model Machines
2.1 SAFETY PRECAUTIONS
Do not attempt to operate the machine until the safety
precautions and operating instructions in this manual are
read completely and are thoroughly understood.
Take notice of all warning labels on the machine. The la-
bels have been put there to help maintain a safe working
environment. The labels have been designed to withstand
washing and cleaning. All labels must remain legible for
the life of the machine. Labels should be checked periodi-
cally to be sure they can be recognized as warning labels.
If danger, warning or caution labels are needed, indicate
the part number, type of label, location of label, and quantity
required along with your address and mail to:
Stoelting Foodservice Equipment
502 Hwy. 67
Kiel, Wisconsin 53042
2.2 SHIPMENT AND TRANSIT
The machine has been assembled, operated and inspected
at the factory. Upon arrival at the final destination, the
entire machine must be checked for any damage which
may have occurred during transit.
With the method of packaging used, the machine should
arrive inexcellent condition.THE CARRIERIS RESPONSIBLE
FOR ALL DAMAGE IN TRANSIT, WHETHER VISIBLE OR
CONCEALED. Do not pay the freight bill until the machine
has been checked for damage. Have the carrier note any
visible damage on the freight bill. If concealed damage
and/or shortage is found later, advise the carrier within 10
days and request inspection. The customer must place
claim for damages and/or shortages in shipment with the
carrier. Stoelting cannot make any claims against the carrier.
2.3 MACHINE INSTALLATION
WARNING
Installation must be completed by a qualified
electrician/refrigeration specialist.
Incorrect installation may cause personal injury,
severe damage to the machine and will void
factory warranty.
Installation of the machine involves moving the machine
close to its permanent location, removing all crating, set-
ting in place, assembling parts, and cleaning.
Section 2 - Installation Instructions
A. TOOLS NEEDED
• Level
• Screwdrivers and wrenches
• Straight edge
• Thermometer
• Stopwatch
• Belt tension guide
• Scale
• Refrigeration gauges
B. PRIOR TO INSTALLATION
1. On the startup form, complete the following:
• Buyer Information
• Distributor Information
• Authorized Service Provider Information
• Verify with Store Operator Checklist
• Freezer Configuration Information
2. Prepare a USB flash drive with your service contact
information:
a. Locate a copy of the service contact file (info.txt).
b. Modify the info.txt file with information from the
service company using the instructions in the file.
c. Put the service contact file onto the root level
of a USB flash drive (do not put the files into
any folder).
C. INSTALLATION
1. Uncrate the machine and remove the 3/8" bolts
holding it to the pallet.
2. Install the legs. Loosen the lock nut and screw the
legs into the base of the machine to a height of
about 3/4”. Set the machine in place.
3. Accurate leveling is necessary for correct drainage of
the freezing cylinder and to ensure correct overrun.
Place a bubble level on top of the machine at each
corner to check for level condition. If adjustment is
necessary, level the machine by turning the bottom
part of each leg in or out then tighten the lock nut.
4. The machine hasa basegasketthat mustbe installed.
Install the gasket with the seam to the back. Make
sure the angled side of the gasket is facing up.

Operators Manual #513674 4 E131-I2 & F131-I2 Model Machines
5. In air cooled machines correct ventilation is required.
The right side of the machine is the air intake and
left side is the discharge. Both sides must have 3”
clearance.
CAUTION
Failure to provide adequate ventilation will void
warranty.
In water cooled machines, make sure to use 1/2”
supply and discharge lines. Follow all local and state
codes for connecting the supply and discharge lines.
Turn on the water supply and check all connections
for leaks.
6. Open the rear panel and check the belt tension with
a Burroughs Belt Tension Gauge. The tension should
be 50-58 lbs. Adjust as necessary and check the
pulley alignment with a straightedge.
NOTE
Belt life will be increased if the new drive belts are
tightened after two or three weeks of operation.
7. Connect the power cord to the proper power supply.
Refer to the nameplate on your machine for proper
supply. The unit must be connected to a properly
grounded receptacle. The use of an extension cord
is not recommended. Do not use an adapter to
circumvent the grounding requirement.
WARNING
Do not alter or deform the electrical plug in
any way. Altering the plug to fit into an outlet
of dierent configuration may cause fire, risk of
electrical shock, product damage and will void
warranty.
8. On the startup form, complete the following:
• Technical Equipment Inspection, Check-Out,
Startup and Training Checklist (excluding
IntelliTec2™ checks)
• Refrigeration Cooling Checks
2.4 INTELLITEC2™ SETUP
1. Disassemble, clean, lubricate and assemble the
machine following the steps in Section 3. Train store
personnel at this time.
2. On the startup form, complete the following:
• Owner/Operator Manual Review & Equipment
Training
• Startup Operational/Technical Issues
• Trainee Information
• Startup Survey
• Equipment Startup & Training Check Out &
Acceptance
3. Fill the hoppers with 2 gallons of sanitizer.
A. MOTOR CALIBRATION
Before starting the motor calibration, be sure there is
sanitizer in the freezing cylinders.
1. Press the On/O Left or On/O Right button. The
Motor Calibration screen will be displayed.
2. Move the cursor over the Left side and press the
SEL button then move the cursor over the Right side
and press the SEL button.
NOTE
The motor calibration can be done for both sides
simultaneously.
3. Brush the hopper sides and cover with a clean
sanitized brush.
4. After the calibration is complete, record the
information in the startup form and then press the
left arrow button.
5. Drain the machine of sanitizer.
B. SETTING CONTACT INFORMATION OPTIONAL
1. Plug your USB flash drive into the port located behind
the protective cap on the right side of the machine.
NOTE
The service contact information must be in the info.
txt file on the root level of the drive.
2. From the Current Status screen, press the left arrow
button to access the passcode selection screen.
Press the right arrow, SET, and then the SEL button.

Operators Manual #513674 5 E131-I2 & F131-I2 Model Machines
3. After the password is accepted, use the arrows to
move the cursor to the Modify Settings option and
press the SEL button. Then move the cursor to the
User Preferences and press the SEL button.
4. On the User Preferences screen move the cursor
to the Contact Information USB Update and press
the SEL button.
5. The screen will change and show “File Found” for
a quick second while it updates the information.
6. After updating the contact information, the screen
will show the Service Contact Information page.
7. Press the left arrow button to go back to the Current
Status screen and remove the USB flash drive and
install the protective cap over the USB port.
C. SETTING TIME AND DATE
1. Press the right arrow button.
2. Move the cursor to the Modify Settings option and
press the SEL button. Then move the cursor to the
Time and Date option and press the SEL button and
adjust the settings as required.
a. Press the SEL button to enter the Modify Time
and Date screen.
b. Move the cursor up or down to the setting that
needs to be changed and press the SET button.
c. Use the arrow buttons to change the setting and
press the SET button to save the change.
3. Press the left arrow button until the Current Status
screen is displayed.
D. SETTING CONSISTENCY
On water cooled machines, connect refrigeration gauges
to the suction and discharge lines. Check the suction and
discharge pressures as the machine cycles.
1. Install the carburetor.
2. Fill the hopper with liquid mix. Immediately after
filling the hopper, open the spigot to drain any
remaining sanitizer.
3. After the freezing cylinder stops filling, turn on the
freezing cylinder and press the Push to Freeze
button.
4. Water cooled machines require the water condenser
valves to be adjusted to maintain a 225-235 psig
discharge pressure.
5. Draw product from the barrel immediately after
the compressor cycles o and test the product for
consistency and temperature.

Operators Manual #513674 6 E131-I2 & F131-I2 Model Machines
6. Adjust the product consistency by increasing or
decreasing the Consist Oset settings. These
settings are underthe ModifySettings -Basic Settings
menu. Adjust the settings as follows:
• If the product is too soft, increase the CutIn
Consist Oset.
• If the product is too firm, decrease the CutIn
Consist Oset.
NOTE
Make adjustments in increments of 2 for best results.
After adjusting, wait for the compressor to cycle
before testing again.
7. After the consistency is set, record the values on
the startup form.
8. To exit the settings screen on the IntelliTec2™,
press the left arrow button once so that the Modify
Operating Settings screen is displayed.
E. SETTING SERVE TIME AND OVERRUN DETAILS
1. Go to the Advanced Settings (2 of 2) screen and
scroll down to the Time to Dispense 16 oz option.
2. Time how long it takes to dispense 16 oz of product
into a cup and change the value in the control.
3. Measure to overrun of the product and change the
value in the control. To measure overrun, do the
following:
a. Zero a scale with an 8 - 16 oz cup.
b. Fill the cup with liquid mix and weigh it. Make
sure the mix is filled to the rim.
c. Fill the cup with frozen product. Make sure there
are no voids (air pockets) when filling.
NOTE
If installed, remove the rosette cap for this test.
d. Scrape the top of the cup with a straight edge.
e. Weigh the filled cup.
f. Calculate the overrun using the following
equation:
X 100 = % Overrun
Liquid Weight - Frozen Weight
Frozen Weight
4. Go to the Advanced Settings (2 of 2) and change
the value in the control. Record the overrun on the
startup form.
5. Press the left arrow button until the Current Status
screen is displayed.
The startup is completed and the machine is ready to serve.

Operators Manual #513674 7 E131-I2 & F131-I2 Model Machines
Section 3 - Initial Set-Up & Installation
Figure 3-1 Controls
3.1 OPERATOR’S SAFETY PRECAUTIONS
SAFE OPERATION IS NO ACCIDENT; observe these rules:
1. Know the machine. Read and understand the
Operating Instructions.
2. Notice all warning labels on the machine.
3. Wear proper clothing. Avoid loose fitting garments,
and remove watches, rings or jewelry that could
cause a serious accident.
4. Maintain a clean work area. Avoid accidents by
cleaning up the area and keeping it clean.
5. Stay alert at all times. Know which switch, push
button or control you are about to use and what
eect it is going to have.
6. Disconnect power for maintenance. Never attempt to
repair or perform maintenance on the machine until
the main electrical power has been disconnected.
7. Do not operate under unsafe operating conditions.
Never operate the machine if unusual or excessive
noise or vibration occurs.
3.2 OPERATING CONTROLS AND INDICATORS
Before operating the machine, it is required that the op-
erator know the function of each operating control. Refer
to Figure 3-1 for the location of the operating controls on
the machine.
WARNING
Hazardous Voltage
The display must show that the freezing cylinder
is o prior to disassembling for cleaning or
servicing. If it is not, press the On/O button to
turn it o prior to disassembling for cleaning or
servicing. Do not operate the machine with the
panels removed.
A. INTELLITEC2™ CONTROL
The Main Power button is used to supply power to the
IntelliTec2™ control, the freezing cylinder circuits and the
storage refrigeration system When the machine is first
plugged in, the control defaults to the On status with
power only to the hopper. If the Main Power On/O button
is pressed and held for 3 secondes, the machine turns o
and a status message is displayed on the screen.
IntelliTec2™ Control
(See Figure 3-2)
Dispense Rate
Adjustor

Operators Manual #513674 8 E131-I2 & F131-I2 Model Machines
Figure 3-2 IntelliTec2™ Control
Help
Pressing the Help button displays help information depen-
dent on the cursor’s location. Pressing the Help button
again exits the help screen.
Selection Button (SEL)
The SEL button is used by technicians to select menu
options.
Set Button (SET)
The SET button is used by technicians to save changes
when modifying control settings.
On/O Button
Power to the freezing cylinders can then be controlled
with the On/O button.
Push to Freeze Button
Pressing the PUSH TO FREEZE button initiates “Serve
Mode”.
Clean Button
The CLEAN button initiates “Clean Mode”.
Arrow Buttons (, , , )
The arrow buttons are used by technicians to navigate
through the control readings and settings.
Dispense Rate Adjustor
The dispense rate adjustor is located under the header
panel, to the immediate right of the spigot handles. Turning
the knob to the right decreases the dispense rate.
USB Access Port
The USB access port is located on the right side panel
of the machine. The port is used by technicians to import
firmware and export machine statistics.
3.3 EMPTYING THE FREEZING CYLINDER
If the machine is empty, go to Section 3.4.
1. Make sure the Main Freezer Power is on. If the
IntelliTec2™ displays the Current Status Screen, then
the main power is on.
2. Turn o the freezing cylinder by pressing the On/
O button
3. Remove thehopper cover andremove thecarburetor
from the hopper.
4. Press the Clean button. After about 5 minutes open
the spigot to drain the mix.
5. Press the Clean button to stop the auger.
6. Fill the hopper with 2 gallons (8 liters) of cool tap
water. Optional: Use detergent solution instead of
tap water to make cleaning the parts easier after
disassembly.
7. Press the Clean button and let the auger rotate for
at least 30 seconds.
8. While the auger is rotating, scrub the hopper with
a clean brush.
9. Drain the water out of the machine.
10. Press the Clean button to stop the auger.
NOTE
If the water does not drain clear, repeat step 6
through 10.
3.4 DISASSEMBLY OF MACHINE PARTS
Before using the machine for the first time, complete ma-
chine disassembly, cleaning, and sanitizing procedures
need to be followed. Routine cleaning intervals and
procedures must comply with the local and state health
regulations. Inspection for worn or broken parts should
be made at every disassembly of the machine. All worn
or broken parts should be replaced to ensure safety to
both the operator and the customer and to maintain good
machine performance and a quality product. Check the
wear line on the auger flights on a regular basis and re-
place as needed.
Figure 3-3 Auger Flight Wear
To disassemble the machine, refer to the following steps:
A. DISASSEMBLY OF FRONT DOOR
1. Press and hold the Main Freezer Power button for
three seconds to turn the power o.
2. Remove the rosette caps or spigot extensions if
installed.
3. Remove the knobs on the front door.
4. Remove the front door by pulling it o the studs.
5. Remove the spigot through the bottom of the front
door.

Operators Manual #513674 9 E131-I2 & F131-I2 Model Machines
6. Remove all o-rings from parts by first wiping o the
lubricant using a clean towel. Then squeeze the
o-ring upward to form a loop. Roll the o-ring out of
the groove.
CAUTION
Do not use any type of sharp object to remove
the o-rings. Damaging the o-rings may cause
leaking.
Figure 3-4 Removing O-Ring
7. Wipe any excess lubricant from all o-rings and parts
before washing.
B. DISASSEMBLY OF AUGER
1. Remove the front auger support and bushing.
2. Remove the auger assembly from the machine. Pull
the auger out of the freezing cylinder slowly. As the
auger is being pulled out, carefully remove each of
the plastic flights with springs.
3. Keep the rear of the auger tipped up once it is clear
of the freezing cylinder to prevent the rear seal
assembly from dropping.
4. Wipe the lubricant o of the hex end of the auger
with a paper towel. Remove the rear seal assembly.
Figure 3-5 Rear Seal Assembly
5. Wipe any excess lubricant o the rear seal.
6. Unscrew the springs from the auger flights.
3.5 CLEANING DISASSEMBLED PARTS
Disassembled parts require complete cleaning, sanitizing
and air drying before assembling. Local and state health
codes dictate the procedure required. Some state health
codes require a four sink process (pre-wash, wash, rinse,
sanitize, air dry), while others require a three sink process
(without the pre-wash step). The following procedures
are a general guideline only. Consult your local and state
health codes for the procedures required in your location.
1. Disassemble all parts. (Refer to Section 3.4 for the
disassembly of machine parts)
2. Place all parts in 90° to 110°F (32°C to 43°C) mild
detergent water and wash thoroughly. Use the
brushes that shipped with the machine to clean all
holes in the front door, flights, mix pickup assembly,
etc.
3. Rinse all parts with clean 90° to 110°F (32°C to 43°C)
water.
4. Place all parts in a sanitizing solution for at least
1 minute, then remove and let air dry completely
before assembling in machine.
A. CLEANING THE MACHINE
Interior
Using detergent solution and the large barrel brush pro-
vided, clean the hoppers and freezing cylinders.
NOTE
Make sure to thoroughly clean the rear seal surfaces
on the inside of the freezing cylinders.
Wrap the brush in a clean cloth and thoroughly dry the
hoppers and freezing cylinders.
Remove the drip tray and drain tray. Clean and replace
the trays.
Exterior
The exterior should be kept clean at all times to preserve
the luster of the stainless steel. A high grade of stainless
steel has been used on the machine to ease cleanup. To
remove spilled or dried mix, wash the exterior with 90° to
110°F (32°C to 43°C) mild detergent water and wipe dry.
Do not use highly abrasive materials, as they will mar the
finish. Use a soft cloth or sponge to apply the solution. For
best results, wipe with the grain of the steel.
3.6 ASSEMBLING MACHINE
To assemble the machine parts, refer to the following steps.
Repeat for each freezing cylinder.
NOTICE
Total Blend sanitary lubricant or equivalent must be
used when lubrication of machine parts is specified.
Do not use more than one packet of Total Blend per
freezing cylinder.

Operators Manual #513674 10 E131-I2 & F131-I2 Model Machines
NOTICE
The United States Department of Agriculture and
the Food and Drug Administration require that lubri-
cants used on food processing equipment be certi-
fied for this use. Use lubricants only in accordance
with the manufacturer’s instructions.
A. ASSEMBLE THE REAR SEAL
1. Install the rear seal o-ring onto the auger. Lubricate
the outside of the o-ring with a generous amount
Total Blend lubricant.
2. Lubricate the inside metal surface of the rear seal
and install it onto the auger shaft. DO NOT lubricate
the outside of the rear auger seal.
Lubricate with Total BlendLubricate with Total Blend
Figure 3-6 Lubricate Rear Seal
3. Lubricate the hex drive end of the auger with a small
amount of Total Blend lubricant.
B. ASSEMBLE THE AUGER
1. Screw the springs onto the studs in the plastic
flights. The springs must be screwed into the flights
completely to provide proper compression.
2. Install the two plastic flights onto the rear of the
auger and insert it part way into the freezing cylinder.
Figure 3-7 Inserting Auger
3. Install the remaining plastic flights, push the auger
into the freezing cylinder and rotate slowly until the
auger engages the drive shaft.
4. Apply a thin layer of sanitary lubricant to the inside
and outside of the auger support bushing. Install
the bushing onto the auger support and install the
auger support into the front of the auger. Rotate
the auger support so that one leg of the support
points straight up.
C. ASSEMBLE THE FRONT DOOR
1. Install the o-rings onto the spigot bodies and apply a
thin layer of sanitary lubricant to the o-rings. Install the
spigot bodies through the bottom of the front door.
2. Fit the front door o-rings into the grooves on the
rear of the front door.
Figure 3-8 Install Front Door O-Rings
3. Place the front door assembly on the mounting studs
andthe pushfront dooragainst themachine carefully.
NOTE
Make sure the pin of the front door do not touch the
legs of the auger support.
4. Secure the front door to the machine by placing
the knobs on the studs and tightening until finger
tight. Proper o-ring seal can be observed through
the transparent front door.
5. Optional:Install therosette capsor spigotextensions.
3.7 SANITIZING
Sanitizing must be done after the machine is clean and
just before the machine is filled with mix. Sanitizing the
night before does not ensure sanitization the next day.
However, you should always clean the machine and parts
after using it.
NOTE
The United States Department of Agriculture and
the Food and Drug Administration require that all
cleaning and sanitizing solutions used with food
processing equipment be certified for this use.

Operators Manual #513674 11 E131-I2 & F131-I2 Model Machines
When sanitizing the machine, refer to local sanitary regula-
tions for applicable codes and recommended sanitizing
products and procedures. The frequency of sanitizing
must comply with local health regulations. Mix sanitizer in
quantities of no less than 2 gallons of 90°F to 110°F (32°C
to 43°C) water. Allow sanitizer to contact the surfaces to
be sanitized for 5 minutes. Any sanitizer must be used only
in accordance with the manufacturer’s instructions and
provide a 100 parts per million strength solution.
1. Prepare 2 gallons of Stera-Sheen sanitizing solution
following the manufacturer’s instructions.
2. Place the carburetors into the hoppers. Do not
install them yet.
3. Pour the sanitizing solution into the hoppers.
4. Press the Main Power button, then press the CLEAN
buttons.
5. Check for leaks.
a. Check for leaks at the front door seal.
b. Check the drain tray located under the front
door for leaks coming from the rear of the rear
auger seal.
6. Use a sanitized soft bristle brush dipped in sanitizing
solution to clean the sides of the hoppers, the
carburetors, and the undersides of the hopper
covers.
7. After the five minute timer expires, open the spigots
to drain the sanitizing solution.
8. Press the CLEAN buttons to stop the augers. Allow
the freezing cylinder to drain completely.
9. Install the carburetors.
NOTE
Do not twist the carburetor when installing.
• Standard Carburetor: install with the air tube
towards the front of the machine.
Air tube towards
front of machine
Figure 3-9 Standard Carburetor
• Adjustable Carburetor: install with the bend on the
regulator towards the right. Install the insert and
turn it to the proper flow rate position depending
on the mix.
Bend towards
right of machine
Figure 3-10 Adjustable Carburetor
The machine is now sanitized and ready for adding mix.
3.8 FREEZE DOWN AND OPERATION
Sanitize immediately before use.
1. Fill the hopper with at least 2.5 gallons of mix.
2. Place a container under the spigot and open the
spigot to allow the mix to flush out about 8 ounces
(0.23 liters) of sanitizing solution and liquid mix.
3. Allow the freezing cylinder to fill.
NOTE
The freezing cylinder is filled when the mix level
in the freezing cylinder reaches the top o-ring on
the spigot.
4. Press the On/O button to turn on the freezing
cylinder. Then press the PUSH TO FREEZE button.
5. When theproduct isready, the displayreads “SERVE”.
Open the spigot to dispense product.
NOTE
If the product consistency needs to be adjusted,
use the Technician passcode and go to the Basic
Settings menu. Adjust the CutIn Consistency O-
set higher to increase the consistency or lower to
decrease the consistency. Make adjustments in
increments of 2 for best results.

Operators Manual #513674 12 E131-I2 & F131-I2 Model Machines
6. The machine dispenses product at a reasonable
draw rate. If the machine is overdrawn, the result
is a soft product or a product that will not dispense
at all. If this occurs, allow the machine to run for
approximately 30 seconds before dispensing more
product. A dispense rate adjustor is located under
the header panel, to the immediate right of the spigot
handle. Turning the knob to the right decreases the
dispense rate.
7. Do not operate the machine when the MIX LOW
message is displayed. Refill the hopper immediately.
NOTE
After a preset number of freezing cycles in Serve
mode, the control enters sleep mode and remains
there until someone draws product or presses the
PUSH TO FREEZE button. In the sleep mode, the
machine keeps the product below 41°F (5°C). Sleep
modes do not take the place of cleaning and sanitiz-
ing. Federal, State, and local regulatory agencies
determine frequency of cleaning and sanitizing.
3.9 MIX INFORMATION
Mix can vary considerably from one manufacturer to an-
other. Dierences in the amount of butterfat content and
quantity and quality of other ingredients have a direct
bearing on the finished frozen product. A change in ma-
chine performance that cannot be explained by a technical
problem may be related to the mix.
Proper product serving temperature varies from one
manufacturer’s mix to another. Most dairy mixes provide
a satisfactory product in the 18°F to 21°F range. No Sugar
Added (NSA) and water-based mixes typically freeze to
proper consistency at higher temperatures.
When checking the temperature, stir the thermometer in
the frozen product to get an accurate reading.
Old mix, or mix that has been stored at too high a tempera-
ture, can result in a finished product that is unsatisfactory.
To retard bacteria growth in dairy based mixes, the best
storage temperature range is between 33° to 38°F (0.5°
to 3.3° C).

Operators Manual #513674 13 E131-I2 & F131-I2 Model Machines
Section 4 - Maintenance and Adjustments
This section is intended to provide maintenance personnel
with a general understanding of the machine adjustments.
It is recommended that any adjustments be made by a
qualified person.
WARNING
Hazardous voltage
The machine must be disconnected from
electrical supply before servicing. Failure to
disconnect power before servicing could result
in death or serious injury.
4.1 FINE CONSISTENCY ADJUSTMENT
Product consistency can be adjusted on the Fine Consis-
tency Adjustment screen. To get to the Fine Consistency
Adjustment Screen, press the right arrow then the SEL
button from the Current Status screen. Then move the
cursor to the Fine Consistency Adjustment option and
press the SEL button.
Figure 4-1 Fine Consistency Adjustment
Increasing the Fine Consistency number increases the
product consistency (firmer product). The Consistency
Limits show the Fine Consistency adjustment added to
the Consistency number.
NOTE
Make adjustments in increments of 2 for best results.
4.2 PREVENTATIVE MAINTENANCE
It is recommended that a preventative maintenance
schedule be followed to keep the machine clean and
operating properly. The following steps are suggested as
a preventative maintenance guide.
A. DAILY CHECKS
Check for worn or broken parts and replace parts as
necessary.
Check for any unusual noise or condition and repair im-
mediately.
B. MONTHLY CHECKS
Have a qualified service technician check the condenser
filter for dirt and clean if necessary.
C. QUARTERLY CHECKS
Have a qualified service technician check drive belts for
wear and have them tightened if necessary.
WARNING
Service must be completed by a qualified
electrician/refrigeration specialist.
Improper service may cause severe personal
injury, or damage to the machine.
4.3 EXTENDED STORAGE
Refer to the following steps for storage of the machine
over any long period of shutdown time:
1. Thoroughly clean all parts that come in contact with
mix with warm detergent water. Rinse in clear water
and dry all parts. Do not sanitize.
NOTE
Do not let cleaning solution stand in the freezing
cylinder or hopper during the shutdown period.
2. Remove, disassemble, and clean the front door,
and auger shaft. Leave disassembled during the
shutdown period.
3. Place the auger flights and auger support bushing in
a plastic bag with a moist paper towel. This prevents
them from becoming brittle if exposed to dry air over
an extended period (over 30 days).

Operators Manual #513674 14 E131-I2 & F131-I2 Model Machines
4. For water-cooled machines that are left in unheated
buildings, or buildings subject to freezing, the water
must be shut o and disconnected.
a. Disconnect the water inlet fitting. The fitting is
located at the rear of the machine.
b. Press the PUSH TO FREEZE button to run the
compressor for 2 - 3 minutes which opens water
valve (temporarily place the front door on the
machine for the compressor to run).
c. While the machine is running, use compressed
air to blow out all of the water through water inlet.
d. Drainthe watersupply linecoming tothe machine.
e. Disconnect the water outlet fitting.
5. Press the Main Power On/O button to turn the
machine o.
6. Disconnect the machine from the power source.
