Volt VHS-6720-X-BBZ-R1 User manual

VOLT®Low Voltage Landscape Lighting
The Original VOLT® G@ Rotatable/ Pivoting Brass Hardscape Light
VHS-6720-X-BBZ-R1
INSTALLATION INSTRUCTIONS
Specications and product details subject to change without notice.
© Copyright 2022, VOLT® Lighting, Lutz FL USA 33549 • All rights
reserved. [email protected] • 813.978.3700
- 1 -
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

The Original VOLT® G@ Rotatable/ Pivoting Brass Hardscape Light
VHS-6720-X-BBZ-R1
Important: Please Read Before Installation
INSTALLATION INSTRUCTIONS
!
www.voltlighting.com
- 2 -
This xture is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes
and instructions may result in serious injury, property damage and void
the warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
1. Make sure that the power is turned OFF before installing or servicing
this xture.
2. Warning: this xture is not intended to be installed within 10 feet [3
meters] of a pool, spa or fountain.
3. This xture is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Underground Low Energy Cable must not be buried over 6” (15.2 cm) in
order to connect to the main low voltage cable.
5. Wiring connections must be made with UL listed wire connectors that
are suitable for outdoor use.
6. Position the wire connector so that it is located within 6 inches (15.2
cm) from a building structure, a luminaire, or tting.
Important Safety Instructions
!
LIGHTED LAMP IS HOT!
WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before reducing lamp.
2. Lamp gets HOT quickly!
3. Do not touch the hot lens, guard or cowl.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time.
6. Use a soft cloth.
7. Oil from skin may damage lamp.
8. Do not operate the xture with a damaged or missing lens or shield.

[email protected] • 813.978.3700
Package Contents
A. (1) Fixture Body
Product Dimensions
- 3 -
Remove Lens
1
8”
1.5”
3.35”
Remove the lens from the
luminaire by loosening the
lock screws.
Lens
Lock Screw
Luminaire

INSTALLATION INSTRUCTIONS
www.voltlighting.com
- 4 -
Install Lamp
2
Install Lens
3
The Original VOLT® G@ Rotatable/ Pivoting Brass Hardscape Light
VHS-6720-X-BBZ-R1
Insert lamp with the correct
wattage and type marked on
the xture label and push
rmly into place.
CAUTION: Do not exceed
maximum wattage marked
on luminaire label.
Socket
Lamp
Install the lens back onto
the luminaire and tighten
with previously removed lock
screws.
Lens
Lock Screw
Luminaire

[email protected] • 813.978.3700
Install Fixture to Mounting Surface
4
- 5 -
Wire Connection
5
Place the xture body onto
the desired location. Mark four
points on the mounting surface
using the holes of the mount
as a guide. Set the xture
aside and drill the proper holes
where you placed the marks
then insert the wall anchors
into the drilled holes.
Place the xture onto the
surface and secure with screws
using a screwdriver.
Fixture Body
Wall Anchor
Screw
Strip both leads from the luminaire pigtail. Using two wire
connectors (sold separately), connect the leads from the
luminaire to the main supply cable leads.
Wire Connectors
Luminaire Wires
Main Supply Cable

www.voltlighting.com
- 6 -
INSTALLATION INSTRUCTIONS
Adjust Luminaire Direction
6
The Original VOLT® G@ Rotatable/ Pivoting Brass Hardscape Light
VHS-6720-X-BBZ-R1
Rotate
Using an Allen Key, loosen the
set screws on the side of the
xture to rotate the luminaire
to your desired direction by
hand. Once you have the
desired angle, tighten down the
set screws with the Allen Key.
Luminaire
Product Dimensions
Remove the lens to expose the lamp and replace it with the
correct wattage and type marked on the xture label. Then,
reinstall the lens.
IMPORTANT: Lamps must be protected from moisture and dust at
all times. Always reinstall the lens when removed.
Set Screw
Set Screw

[email protected] • 813.978.3700
- 7 -

is-VHS-6720-X-BBZ-R1-ver1.pdf
Specications and product details subject to change without notice.
© Copyright 2022, VOLT® Lighting, Lutz FL USA 33549 • All rights
reserved. [email protected] • 813.978.3700
www.voltlighting.com
- 8 -
