VOLT®Low Voltage Landscape Lighting
Soft Splash LED Wall Wash light
INSTALLATION INSTRUCTIONS
Specications and product details subject to change without notice.
© Copyright 2015, VOLT® Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected] • 813.978.3700
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

VOLT®Soft Splash LED Wall Wash light Package Contents
Product Dimensions
Important: Please Read Before Installation
IMPORTANT SAFETY INSTRUCTIONS
INSTALLATION INSTRUCTIONS
This luminaire is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situation.
1. Make sure that the power is turned OFF before installing or servicing
this luminaire.
2. WARNING: risk of electrical shock. Install all luminaires 10 feet
(3.05M) or more from pool, spa or fountain.
3. This luminaire is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Wiring connections must be made with wire connectors that is suitable
for outdoor use.
5. Position the low voltage wire and wire connector so that it is located
within 6 inches (15.2 cm) from a building structure, a luminaire or
tting.
6. The main low voltage cable is intended for shallow burial - less than 6
inches (152 mm)
7. If additional lengths of low voltage cable is required, please contact
www.voltlighting.com or call 1-813-978-3700.
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
Lighted lamp is HOT!
WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before replacing lamp.
2. Lamp gets HOT quickly! Contact only switch/plug when turning on.
3. Do not touch the hot lens, guard or enclosure.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time. Use a soft cloth. Oil from skin may
damage lamp.
6. Do not operate the luminaire tting with a missing or damage shield.
SAVE THESE INSTRUCTIONS
A. (1) Luminaire
!
!
www.voltlighting.com [e-mail] • 813.978.3700
4.25”
B. (1) Stake
Install Stake
1
Determine desired location for mounting
luminaire. Hammer stake into ground until
ange of stake is ush to grade. To avoid
damage to stake, place a board on top of stake
while hammering.
NOTE: If ground is hard and stake is difcult to
install, make a crosscut in ground using a at
shovel.
Board
Stake
Soil
Ground
Parts Required
A. (1) Bipin Lamp
4”

INSTALLATION INSTRUCTIONS
www.voltlighting.com [e-mail] • 813.978.3700
VOLT®Soft Splash LED Wall Wash light
Remove Threaded Top
Install Lamp
2
3
Unscrew the threaded top and
remove it from the luminaire.
Insert lamp with correct wattage and
type marked on luminaire label.
CAUTION: Do not exceed maximum
wattage marked on luminaire label.
NOTE: DO NOT touch lamp with
bare hands. Use soft cloth to handle
lamp.
NOTE: “Wafer” bi-pin LED lamp also can
be used for this luminaire.
Luminaire
Lamp
“Wafer” Bi-pin
LED Lamp
Threaded Top
Threaded Top
Socket
Thread the threaded top back onto
the luminaire and hand tighten until
snug.
Clear away area in ground at
wireway slot in top of stake. Align
the wireway slots on base and stake.
Lay luminaire pigtail into wireway
slots and screw luminaire into stake.
Tighten until snug to secure base.
Install Threaded Top
Install Luminaire to Stake
4
5
Luminaire
Luminaire
Stake
Pigtail
Wireway Slot
Wire Connection
6
Strip two leads from luminaire pigtail. Using two wire connectors (not
provided), connect leads from luminaire to main low voltage supply
cable leads.
Pigtail
Main Low Voltage
Supply Cable
Wire Connectors

INSTALLATION INSTRUCTIONS
www.voltlighting.com
VOLT®Soft Splash LED Wall Wash light
Install/Replace Lamp
Please reverse Step 6 - Step 3 to expose the Lamp and replace it with
correct wattage and type marked on luminaire label. Reinstall Diffuser.
IMPORTANT: Lamp must be protected from moisture and dust at all times.
Always re-install diffuser when moved.
