Volt VWL-703-BBZ User manual

VOLT®Low Voltage Landscape Lighting
VOLT®Salty Dog Brass MR16 In-Grade Light
VWL-703-BBZ
INSTALLATION INSTRUCTIONS
Specications and product details subject to change without notice.
© Copyright 2019, VOLT® Lighting, Lutz FL USA 33549 • All rights
reserved. [email protected] • 813.978.3700
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
–1–

VOLT®Salty Dog Brass MR16 In-Grade Light
VWL-703-BBZ
INSTALLATION INSTRUCTIONS
www.voltlighting.com [email protected] • 813.978.3700
Package Contents
Parts Required (sold separately)
A. (1) Fixture B. (1) Stake
A. (1) MR16 Lamp
Product Dimensions
Important: Please Read Before Installation
Important Safety Instructions
!
!
This xture is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes
and instructions may result in serious injury, property damage and void
the warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
1. Make sure that the power is turned OFF before installing or servicing
this xture.
2. Warning: this xture is not intended to be installed within 10 feet [3
meters] of a pool, spa or fountain.
3. This xture is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Underground Low Energy Cable must not be buried over 6” (15.2 cm) in
order to connect to the main low voltage cable.
5. Wiring connections must be made with UL listed wire connectors that
are suitable for outdoor use.
6. Position the wire connector so that it is located within 6 inches (15.2
cm) from a building structure, a luminaire, or tting.
7. If additional lengths of low voltage cable is required, please call
1-813-978-3700.
LIGHTED LAMP IS HOT!
WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.
1. Turn o/unplug and allow to cool before reducing lamp.
2. Lamp gets HOT quickly!
3. Do not touch the hot lens, guard or cowl.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time.
6. Use a soft cloth.
7. Oil from skin may damage lamp.
8. Do not operate the xture with a damaged or missing lens or shield.
–2– –3–
4.25”
4”

INSTALLATION INSTRUCTIONS
www.voltlighting.com [email protected] • 813.978.3700
VOLT®Salty Dog Brass MR16 In-Grade Light
VWL-703-BBZ
Install/Replace Lamp
2
Install Fixture to Stake
5
Install Lens and Faceplate
3
–4– –5–
Remove Faceplate and Lens
1
Install Stake
4
Unlock the screws and remove the
faceplate, gasket, and lens from the
housing.
Gasket
Faceplate
Lens
Housing
Screw
Insert lamp with correct wattage
and type marked on xture
label.
CAUTION: Do not exceed
maximum wattage marked on
luminaire label.
NOTE: DO NOT touch lamp with
bare hands. Use a soft cloth to
handle lamp.
MR16 Lamp
Socket
Place the lens, gasket and faceplate
back onto the housing. Secure them
with screws previously removed.
Hand tighten until snug, then use a
screwdriver to secure them in a star
pattern.
Screw
Housing
Lens
Faceplate
Gasket
Determine the desired location for
mounting the xture. Hammer the
stake into the ground until ange of
stake is ush to grade. To avoid damage
to the stake, place a board on top of
the stake while hammering.
NOTE: If the ground is hard and the
stake is dicult to install, make a
crosscut in the ground using a at
shovel before hammering the stake.
Board
Stake
Soil
Ground
Clear away an area in the ground at
the wireway slot on top of the stake.
Lay the luminaire pigtail into the
wireway slot and screw the xture
onto the stake. Tighten until snug.
Fixture
Stake
Pigtail
Wireway Slot

INSTALLATION INSTRUCTIONS
www.voltlighting.com
VOLT®Salty Dog Brass MR16 In-Grade Light
VWL-703-BBZ
Wire Connections
6
–6–
[email protected] • 813.978.3700
–7–
Strip both leads from the luminaire pigtail. Using two wire
connectors (sold separately), connect leads from luminaire to the
main supply cable.
Pigtail
Main Supply Cable
Wire Connectors

IS-VWL-703-BBZ-ver1.pdf
Specications and product details subject to change without notice.
© Copyright 2019, VOLT® Lighting, Lutz FL USA 33549 • All rights
reserved. [email protected] • 813.978.3700
www.voltlighting.com
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
–8–
