Volt VPL-1049-4-BBZ User manual

INSTALLATION INSTRUCTIONS
Specications and product details subject to change without notice.
© Copyright 2022, VOLT® Lighting, Lutz FL USA 33549 • All rights
reserved. [email protected] • 813.978.3700
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
VOLT® Low Voltage Landscape Lighting
VOLT® Low Voltage Path Light
VPL-1049-4-BBZ
- 1 -

VOLT® Low Voltage Path Light
VPL-1049-4-BBZ
INSTALLATION INSTRUCTIONS
www.voltlighting.com
- 2 -
Important: Please Read Before Installation
!
Important Safety Instructions
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO
PERSONS
Lighted lamp is HOT!
WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before reducing lamp.
2. Lamp gets HOT quickly!
3. Do not touch the hot lens, guard or cowl.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time.
6. Use a soft cloth.
7. Oil from skin may damage lamp.
8. Do not operate the xture with a damaged or missing lens or shield.
!
This luminaire is intended for installation in accordance with local
codes and the National Electric Code (NEC). Failure to adhere to
these codes and instructions may result in serious injury, property
damage and void the warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
1. Make sure that the power is turned OFF before installing or servicing
this xture.
2. Warning: this xture is not intended to be installed within 10 feet [3
meters] of a pool, spa or fountain.
3. This xture is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Underground Low Energy Cable must not be buried over 6” (15.2 cm) in
order to connect to the main low voltage cable.
5. Wiring connections must be made with UL Listed wire connectors that
are suitable for the application.
6. Position the wire connector so that it is located within 6 inches (15.2
cm) from a building structure, a luminaire, or tting.

Package Contents
A. (1) Fixture Body
Parts Required (Sold Separately)
A. (1) Mounting Accessory
B. (1) GU4 or M11 LED Bulb
[email protected] • 813.978.3700
- 3 -
Product Dimensions
26”
5”
4.87”
4.87” 7.5”

INSTALLATION INSTRUCTIONS
www.voltlighting.com
VOLT® Low Voltage Path Light
VPL-1049-4-BBZ
1
2
3
- 4 -
Remove Lens
Shade
Screw
Lens
Using a screwdriver, loosen
screws on the lens and
remove the lens from the
shade.
Socket
GU4 or
MR11 Bulb
Insert bulb with correct
wattage and type marked on
xture label and push into
place.
CAUTION: Do not exceed
maximum wattage marked on
xture label.
Shade
Screw
Lens
Place the lens back onto
the shade and secure with
previously removed screws.
Tighten until snug with
screwdriver.
Install Bulb
Install Lens

[email protected] • 813.978.3700
- 5 -
Install Stake
4
5
Determine the desired
location for mounting the
luminaire. Hammer the stake
into the ground until ange
of stake is ush to grade. To
avoid damage to the stake,
place a board on top of the
stake while hammering.
Note: If the ground is hard
and the stake is difcult to
install, make a crosscut in the
ground using a at shovel.
Board
Ground
Soil
Stake
Pass supply wires through
the center hole of the
stake and thread the
stem onto the stake.
Hand tighten until snug.
Clear away area in ground
and lay supply wires into
wireway slots.
Ground
Stem
Supply Wires
Soil
Stake
Install Fixture Body to Stake

INSTALLATION INSTRUCTIONS
www.voltlighting.com
VOLT® Low Voltage Path Light
VPL-1049-4-BBZ
- 6 -
6
7
Install/Replace Bulb
Wire Connections
Strip two leads from xture wires. Using two UL listed wire
connectors (sold separately), connect leads from xture wires to
main supply cable leads.
Main Supply Cable
Fixture Wires
Wire Connectors
Adjust Shade Direction
Loosen the knuckle to adjust
the shade to your desired
angle. Once your desired angle
is achieved, hand tighten the
lock screw to secure the shade
direction.
Shade
Lock Screw ROTATE
Please reverse Step 1 - Step 3 to expose the bulb and replace it
with the correct wattage and type marked on the xture label.
IMPORTANT: The Bulb must be protected from moisture and dust at
all times. Always reinstall the lens when removed.

- 7 -
