Volt VSAL-9001-25-BBZ User manual

VOLT®LOW VOLTAGE LANDSCAPE LIGHTING
V O LT ®Solar Spotlight Kit
ITEM: VSAL-9001-25-BBZ
INSTALLATION INSTRUCTIONS
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

V O LT ®Solar Spotlight Kit - VSAL-9001-25-BBZ
INSTALLATION INSTRUCTIONS
IMPORTANT: PLEASE READ BEFORE INSTALLATION
!
IMPORTANT SAFETY INSTRUCTIONS
!
PACKAGE CONTENTS
A. (1) Spot Light
813.978.3700 • [email protected] • www.voltlighting.com
2
This luminaire is intended for installation in accordance with local codes and
the National Electric Code (NEC). Failure to adhere to these codes and instruc-
tions may result in serious injury, property damage and void the warranty.
These instructions do not intend to cover all variations in installation, operation
maintenance or mounting situations.
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO
PERSONS
Lighted lamp is HOT!
WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.
1. Lamp gets HOT quickly!
2. Do not touch the hot lens, guard or enclosure.
3. Keep lamp away from materials that may burn.
4. Do not touch lamp at any time. Use a soft cloth. Oil from skin
may damage lamp.
5. Do not operate the luminaire tting with a missing or dam-
aged shield.
SAVE THESE INSTRUCTIONS
Required Parts (sold separately)
A. (1) Solar Panel with Bracket

PRODUCT DIMENSIONS
INSTALL STAKE
1
813.978.3700 • [email protected] • www.voltlighting.com
3
1.5”
2.5”
2.5”
4”~ 5”
Determine the desired loca-
tion for mounting the stake
mount. Hammer the stake
into the ground until ange
of stake is ush to grade.
To avoid damage to the
stake, place a board on top
of the stake while hammer-
ing.
Note: If the ground is hard
and the stake is difcult
to install, make a crosscut
in the ground using a at
shovel.
Board
Stake
Ground
Soil

INSTALL FIXTURE BODY TO STAKE
2
3
V O LT ®Solar Spotlight Kit - VSAL-9001-25-BBZ
INSTALLATION INSTRUCTIONS
813.978.3700 • [email protected] • www.voltlighting.com
4
Pass the xture wire
through the center
opening of the stake.
Thread the xture onto
the stake. Hand tight-
en until snug.
Fixture
Ground
Fixture Wire
Stake
Soil
Wire Connection: Option A (Recommended)
Solar Panel
Connection Hub
Spot Light
Spot Light Supply Wire
Solar Panel Supply Wire
OPTION A: Connect with Connection Hub

4
813.978.3700 • [email protected] • www.voltlighting.com
5
Wire Connection: Option B
You can choose from Option A or Option B to complete the instal-
lation. Option A is the recommended method to install the solar
lights.
Optional A: Strip the supply wire leads from the solar panel and the
supply wire leads from the spot lights. Insert both the lead wires
into the connection hub. There is a maximum of 7 xtures that can
be connected to the hub.
Optional B: Strip the supply wire leads from the solar panel and the
supply wire leads from the spot light. Using two wire connectors
(sold separately), connect the leads from the solar panel to the
spot light.
OPTION B: Connect with Wire Connectors
Spot Light Supply Wire
Solar Panel Supply Wire
Solar Panel
Spot Light
Wire Connector
5
Adjust Fixture Direction
Using the Allen wrench,
loosen the screw on the
knuckle and adjust the x-
ture to your desired direc-
tion. Once your direction is
achieved, tighten the screw
until snug.
Fixture
Screw
Allen Wrench

Specications and product details subject to change without notice.
© Copyright 2023, VOLT® Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected] • www.voltlighting.com
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
