Volt VSPL-1045-BBZ-R1 User manual

INSTALLATION INSTRUCTIONS
VOLT®Low Voltage Landscape Lighting
VOLT®Solar Integrated LED Path Light
VSPL-1045-BBZ-R1 & VSPL-1045-PBK-R1
Specications and product details subject to change without notice.
© Copyright 2023, VOLT® Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected] • 813.978.3700
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
- 1 -

Important: Please Read Before Installation
INSTALLATION INSTRUCTIONS
!
www.voltlighting.com
Important Safety Instructions
!
- 2 -
VOLT®Solar Integrated LED Path Light
VSPL-1045-BBZ-R1 & VSPL-1045-PBK-R1
This luminaire is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
Please note that these solar xtures are equipped with built-in photocells, so
they will not turn on until it is dark enough. These xtures will also require
plenty of sunlight to function properly. It’s best to have the xture in an
area where the sun will get to it at all times throughout the day and where
no ambient lighting will affect the photocell at night. If your xture is not
functioning at night, be sure that the on/off button has been engaged. See
step one for details.
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
Lighted lamp is HOT!
WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.
1. Lamp gets HOT quickly!
2. Do not touch the hot lens, guard or enclosure.
3. Keep lamp away from materials that may burn.
4. Do not touch lamp at any time. Use a soft cloth. Oil from skin may
damage lamp.
5. Do not operate the luminaire tting with a missing or damaged shield.
SAVE THESE INSTRUCTIONS

[email protected] • 813.978.3700
- 3 -
Product Dimensions
Package Contents
Parts Required
A. (1) Fixture Body
B. (1) Battery
A. (1) Mounting Accessory B. (1) Riser
8.68”
7.57”
4.55”

INSTALLATION INSTRUCTIONS
www.voltlighting.com
- 4 -
2
1
VOLT®Solar Integrated LED Path Light
VSPL-1045-BBZ-R1 & VSPL-1045-PBK-R1
3
Remove Battery Compartment Cover
Screw
Battery
Compartment
Cover
Using a screwdriver, remove
the battery compartment
cover from the xture body.
Fixture Body
Install Battery
Insert the battery into the battery
compartment.
Battery
Battery
Compartment
Reinstall Battery Compartment Cover
Screw
Battery
Compartment
Cover
Place the battery
compartment cover back
onto the xture body and
secure with the previously
removed screws.
Fixture Body

[email protected] • 813.978.3700
- 5 -
4
Test Solar Light
1
2
Slide the ON/OFF switch of the xture to the “ON” position.
Cover solar panels completely by using black materials. The xture will
light up when the solar panel is covered and turn back off when it is
uncovered.
Now you can proceed to next steps of installations knowing the xture is
in ON mode.
Black Material
Fixture Body
On/Off Switch
Solar Panel
5
Install Riser
Thread the riser onto the xture
and hand tighten until snug.
Fixture Body
Riser

INSTALLATION INSTRUCTIONS
www.voltlighting.com
- 6 -
6
Install Stake
Determine the desired location
for mounting the stake mount.
Hammer the stake into the
ground until ange of stake
is ush to grade. To avoid
damage to the stake, place a
board on top of the stake while
hammering.
Note: If the ground is hard and
the stake is difcult to install,
make a crosscut in the ground
using a at shovel.
Board
Ground
Soil
Stake
7
Install Stake
Riser
Thread the riser on to the stake
and hand tighten until snug.
Ground
Soil
Stake
VOLT®Solar Integrated LED Path Light
VSPL-1045-BBZ-R1 & VSPL-1045-PBK-R1

[email protected] • 813.978.3700
- 7 -
