VOLTA VB1 User manual

www.volta.com.tr
VB2
VB1
VB3
Read this guide as carefully before using your electric pedal assisted cycle.
ELECTRIC PEDAL ASSISTED CYCLES
USER MANUAL

PREFACE
This product has been designed as environment friendly. In the in-
structions in this user’s guide, you can find instructions for use, safety
warnings, care and basic storage. This high-tech vehicle purchased
consists of the following parts:
This user manual will be an irreplaceable part of your vehicle.
sure you have this user manual with the product.
When there is a problem with your vehicle, do not use any parts
other than originals provided by the authorized service. Images and
specifications used here and the vehicle you purchased may not
show the same features.
The main purpose of this manual is to introduce the product and its
parts.
Thank you for choosing our product. Enjoyable rides.
• High eciency direct current brushless motor
• Low voltage protected digital smart driver
• Circuit breaker brake sensor for safe riding
• Long range and high performance with high capacity battery
• Pleasant and comfortable riding with high quality suspension system
• Bicycle equipment ensuring European standards

- According to the laws of some countries, a minimum age and driving license may be
required to use these products.
- Do not demount, replace or modify any part on the vehicle. Processes those are made
without approval of authorized service shop, will impair originality of the vehicle and the
vehicle will be out of the scope of guarantee. Please make all replaces at authorized ser-
vice.
WARNING
WARNING - These headings are written to explain personal accidents and to prevent
possible fatal accidents.
ATTENTION - These headgear protect you from serious injury and indicates mechanical
damage.

www.volta.com.tr
4www.volta.com.tr
4
VB1
VB2
VB3

www.volta.com.tr 5 www.volta.com.tr 5
TABLE OF CONTENTS
Preface ....................................................................................................................02
1. Devices and Accessories ...............................................................................06
2. Functions .............................................................................................................09
3. Assembling the Vehicle ...................................................................................13
4. Charging the Vehicle .........................................................................................14
5. Riding Instructions ..............................................................................................17
6. Safe Use Instructions ...........................................................................................18
7. Folding and Transporting ...............................................................................21
8. Maintenance and Storing ...............................................................................22
9. Storing Guide for the Vehicle ...........................................................................24
10. Technical Specs ...........................................................................................25
11. Authorized Service ················································································26
12. Warranty ·································································································27

www.volta.com.tr
6www.volta.com.tr
6
VB1
1. DEVICES AND ACCESSORIES
Products
1. LCD Display
2. Shifter
3. Thumb Throttle
4. Headlight
5. Disc Brake
6. Charge Input
7. Saddle
8. Lock Set
9. Rear Carrier
10. Folding Latch
11. Folding Pedal
12. Side Stand
13. Motor
14. Controller
12
3
4
5
6
8
9
10 11
12
14
13
7

www.volta.com.tr 7 www.volta.com.tr 7
1. DEVICES AND ACCESSORIES
VB2
1. LCD Display
2. Shifter
3. Thumb Throttle
4. Headlight
5. Disc Brake
6. Folding Latch
7. Charge Input
8. Lock Set
9. Folding Pedal
10. Controller
11. Side Stand
12. Motor
13. Saddle
1
4
2
3
5
6
8
7
10
11
9
12
13

www.volta.com.tr
8www.volta.com.tr
8
VB3
1. DEVICES AND ACCESSORIES
1. LCD Display
2. Shifter
3. Thumb Throttle
4. Headlight
5. Disc Brake
6. Controller
7. Charge Input
8. Lock Set
9. Motor
10. Folding Pedal
11. Side Stand
12. Saddle
13. Rear Carrier
1
2
3
4
5
6
10
8
7
12
9
13
11

www.volta.com.tr 9 www.volta.com.tr 9
2. FUNCTIONS
LCD Display
1- Function display, speed, remained battery signs, error, total range,
single round range, voltage, operation period.
2- Control, adjustment function, power button control, rim diameter adjust-
ment, idle period adjustment, holding ready automatically, rear lamp bright-
ness control, starting mode adjustment, rider mode adjustment, voltage level
adjustment, rider current limit adjustment.
3-Type of communication: UART
You can view all indicator content as follows (it demonstrates all signs 1 sec-
ond after opening)
88 8
8
.
8888
ODO
12
11 1
24
MILE
MPH
KM/H ASSIST
Km
TRIP
!
M
EC U
I
I
I
I
I
I
I

www.volta.com.tr
10 www.volta.com.tr
10
3.5 Error codes
E-01: Hall sensor warning;
E-02: Brake, Start-up Support Assistant;
E-03: Driver warning;
E-04: Brake lever warning;
E-05: Low voltage warning;
E-06: Communication warning (it means that speedometer cannot
take data from rider)
E-07: Communication warning (it means that rider cannot take data
from speedometer
3.4 In order to adjust electric bicycle support level, 8ASSIST you can use
1, 2, 3 levels for speed options.
3.5 Electric bicycle indicator signals:
: Headlamp : Brake, :Start-up Support Assistant,
: Driver warning : Batttery warning : Speed fixing warning
8
ASSIST
!
M
EC U
!
EC U
2. FUNCTIONS
3.1 Voltage and battery power
3.2 Multiple function display
Single round DIS, Total range ODO (unit: mile, km)
3.3 Speed indicator
Unit Mp/h, km/h
Speed signal comes from hall sensor of engine, it is sent to speedometer
by control device (circle period of each hall sensor, unit: IMS) speedometer
measures real speed according to rim diameter and signal data. If your rim
diameter is entered wrong, your speed will also be calculated wrong. Please
make sure that correct rim diameter is entered
Content View
8888.8
MILE
Km
ODO
TRIP
88
MPH
KM/H

www.volta.com.tr 11 www.volta.com.tr 11
P01: Read lamp brightness (1: the darkest; 3: the brightest)
P02: Kilometer unit, 0; Kilometer. 1: Mile
P03: Voltage unit: 24V, 36V, 48V,
P04: Holding Ready Period: 0 never hold, other figures indicate holding
ready period, time interval is 1-60 minutes)
P05: Gear: 0: 3 level mode,
1: 5 level mode,
2: 9 level mode,
P06: Wheel Diameter: Unit, inch; Sensitivity 0.1
P07: Magnetic Steel Number for Speed Test Range: 1-100
P08: Range: 0-100km / s, 100 means there is no speed limit
1. Communication status (Auditor control): Riding speed is fixed as a
limited value. Error Value: ± 1km / s (valid for assistant power / speed)
Above indicated values are measured with metric unit (kilometer). When
measuring unit (mile) is changed, speed value that is seen on panel, is
automatically passed to related imperial unit, however, speed limit value on
unit interface is not changed based on that.
P09: Zero / Zero Out beginning adjustment, 0: Beginning. 1: Zero Out
beginning adjustment P10: Riding Mode Adjustment
0: Power rider- Special gear of assistant rider decides assistant power
value. In that case, start-up support assistant does not work.
1: Electric Rider- The vehicle is ride with start-up support assistant. In
that case, power gear does not work.
2: Power rider + Electric Rider- Electric rider is non-operational
P11: Assistant Power Sensitivity 1-24
P12: Assistant Power Intensity 0-5
P13: Number of Magnet 5/8/12pcs
P14: Assumed current limit value 12A: Ranger 1-20A
Adjustments
Note:
2. FUNCTIONS

www.volta.com.tr
12 www.volta.com.tr
12
P15: Engine Start-up Adjustment 0-100
P16: Riding Function: 0 o, 1 on
P17: Headlamp Synchronization 0 o, 1 on
P99: Press on down button for starting, 99 is demonstrated, after that, press
on up button for 5 seconds for a long time to start.
ODO Zero-Out: Press on down button for 5 seconds for a long time, ODO is
reset.
Key Explanations
1: Press ON/OFF button for a short time to open indicator when it is o. In
order to change interface in ODO / TRIP / RM / TM / ERRO mode when indi-
cator is open, press ON/OFF button for a short time
2: In order to turn o the indicator, press on ON/OFF button for a long peri-
od. In order to increase PAS level, press on up button + for a short period, in
order to decrease PAS level, press on down button + for a short period.
3: In order to adjust parameter, press on + button for a long period.
In order to change parameters on adjustment interface, press on ON/OFF
button for a short period and press on MODE button to add parameter (“A”
on left side) / minus (“d” on left side) After change, in order to pass to next
parameter and save it, press on ON/OFF button for a short period; press on
last parameter or MODE button for a long period; parameter stops flashing
and it is saved. In order to exit from parameter adjustment interface, press on
ON/OFF + MODE button for a long period or wait for 10 seconds and auto-
matically exit from mode.
Note:
The vehicle you purchased, can demonstrate dierence comparing to expla-
nations indicated in these instructions of use.
2. FUNCTIONS

www.volta.com.tr 13 www.volta.com.tr 13
3. ASSEMBLING THE VEHICLE
1- First of all, fix your vehicle and
open the folding apparatus.Then,
make your vehicle ready to fold
towards left.
3- Open the folding latch on
the frame part of the vehicle
and fold the vehicle.
2- Open the folding latch and
fold the handlebars towards the
front wheel.
4- When you fold the handle-
bar and chassis, the vehicle will
be as in the figure.

www.volta.com.tr
14 www.volta.com.tr
14
Power Switch is placed in battery in order to activate your electric bicycle.
Turn the switch on to open. When the bicycle is not in use, keep it always in
o position.
- It means that power is on and the engine can be activated.
- It means that power is o and the battery is locked. I such case, you
can take the switch o.
PUSH - Push the switch in and then turn to counter clockwise.
When it is on “LOCK ON” position,
UNLOCK - You can remove your battery in that position.
Firstly, it begins with 0-6 km/h. It is located on start-up support lever han-
dlebar. Speed limit of start-up support lever is 6 km/h
Battery Locking and Power Switch
Thumb Throttle
ON
.
PUSH
I
UNLOCK
OFF
.
4. CHARGING THE VEHICLE

www.volta.com.tr 15 www.volta.com.tr 15
Operating gears is made by using selector figures on the gear. It is used for
select rate of required gear.
LCD Display is located handlebar.
Shifter
LCD Display
11
22
33
44
55
66
4. CHARGING THE VEHICLE

www.volta.com.tr
16 www.volta.com.tr
16
Remove the batters by turning the switch to “Open Lock” position.
This will ensure that you remove and charge the battery.
1. Charge socket is placed on upper parts of the battery.
2. Plug charger cable on charge socket on the battery.
3. Plug charger on correct electric socket (220v50hz).
Turn network source on to begin charging process.
During charging, the battery charge indicator flashes RED. Charging
time can take 2-8 hours depending on how much is needed. LCD
Display it turns GREEN when fully charged. When GREEN light is
cover, charge will continue to be applied.
NOT:
Always connect the charging cable with the charger turned o.
Removing Battery for Charging
ON
.
PUSH
I
UNLOCK
OFF
.
4. CHARGING THE VEHICLE

www.volta.com.tr 17 www.volta.com.tr 17
5. RIDING INSTRUCTIONS
• Before each use, ensure that all parts are in good condition. Make sure
the bolts are tightened, brakes are working and properly adjusted.
• Make sure the tires are inflated correctly.
• Wear a helmet while riding your electric bike.
• Do not drive in heavy rain. We recommend that you do not ride in rainy
weather.
• Do not ride in deep waters while riding your electric bike. It could dam-
age your electric bike and make it out of repair.
• Make sure not to touch the battery with wet hands.
• Do not touch it with a metal object. This could cause an electric shock
or a short circuit.
• Do not increase your speed when driving downhill.
• Do not press the initial support assistant while walking beside you.
• Do not cross obstacles while riding your electric bike.
• Do not hang heavy objects on the handlebar.
• Hold the handlebars firmly with your hands, keeping the balance com-
pletely.
• Put your right hand on the starting support arm (turn it slowly.
sudden acceleration).
• The speed of your vehicle will increase when you use the start assist as-
sistant. To stop your electric bike. Slowly pull the accelerator and brake
lever towards you. If you pull the brake lever, don’t start support assistant
will automatically stop the call.
Riding Instructions

www.volta.com.tr
18 www.volta.com.tr
18
Please check before each usage:
1. Check tyre air pressure.
2. Make sure that battery charge is enough for your ride.
3. Make sure that front and rear brake are operational.
4. Make sure that your handlebar is adjusted based on height of your seat.
5. Make sure that front and rear wheels are smooth and fixed.
5. RIDING INSTRUCTIONS
• Make sure your tires are in good condition.
• Make sure that the brake cables and brake levers are well lubricated and
free of oil. Soiling on wheels or brake blocks.
• Do not over-charge your battery. Turn it over if your battery is empty o
until it charges again.
• Please replace worn tires and brake pads.
• Brake cables will fail over time and braking, brake cable needs to be
adjusted and tightened regularly.
• Wipe your battery regularly with a dry soft cloth. Weak link it causes a
decrease in battery capacity.
• Be careful not to leave it outside in bad weather conditions.
• Battery capacity is reduced according to usage. Variable factors will
determine the distance that can be taken with the help of your engine
electric bike.
Safety Suggestions
6. SAFE USE INSTRUCTIONS

www.volta.com.tr 19 www.volta.com.tr 19
• The factors such as weight of rider or load, hills and slopes, type of road
(asphalt, grass, mud), weather conditions (rain, wet, windy etc.), wrong
tyre pressure, can seriously reduce battery eciency.
• Battery life is based on period and conditions of use.
• Certainly, follow trac rules in your country. Besides, perform safety
instructions and suggestions taking place in this handbook.
• In order to prevent personal injuries, do not give your electric bicycle
to the persons who do not know how to ride it. Make notification about
how to ride when you give your electric bicycle to other persons. Make
sure to wear correct safety equipment.
• Check your electric bicycle before each use. If you observe situations
such as a loosen part, lower tyre air, consumed battery, dierent voic-
es while turning or dierent situations, please stop riding. Before fixing
these errors, do not ride your electric bicycle.
6. SAFE USE INSTRUCTIONS
• Before every use, make sure that all parts are in good conditions, nuts
and bolts are tighten, brakes are operational and adjusted appropriately.
• Make sure that tyres are steady before use.
• Check tyre pressures.
• Make sure that all nuts and bolts are tighten suciently.
• Besides, check whether brake cable and other cables are tightened and
operate appropriately.
• Charge battery when it is not in use. Waiting for long period on low
battery level, will reduce battery life.
• Check all rotating parts and lubricate if it is insucient.
• Check all lighting systems.
• Do not increase speed when you go downhill.
Preventing Hazardous Ride

www.volta.com.tr
20 www.volta.com.tr
20
Side Stand: It is used in short term parks.
Do not place heavy and big volume parts on pedal. It impairs balance of
your electric bicycle and can cause danger.
It moves idle for about 10-20 mm distance before seeing left and right brake
levers’ functions. This distance is named “free distance”. By tightening nuts or
make them free, free distances can be adjusted.
Standing Positions
Front and Rear Brake
Folding Pedal
• Avoid sudden turns in crowded areas.
• Do not get on persons more than one on your electric bicycle.
• Do not touch disc brake after usage. Temperature of disc brake is high
after usage.
• Do not free your hands during riding.
6. SAFE USE INSTRUCTIONS
