E9 Pro Electric Scooter
User's Manual

Package Contents --------------------------------------------------
Product Description -------------------------------------------------
Product Installation -------------------------------------------------
Charger Connection ------------------------------------------------
How toRide and Park -------------------------------------------
Ambient Light Control ---------------------------------------------
Safety Instructions-------------------------------------------------
Folding And Handling-----------------------------------------------
Daily Maintenance --------------------------------------------------
Product Parameter Table -------------------------------------------
Contents
02
03
04
07
09
10
12
13
14
16
1

1 Package Contents
Accessories
Charger
E Scooter Charger Tool bag user's manual
The E9 Pro packaging box contains the following parts,
if any are missing, please consult the seller:
5mm inner hexagon wrench
2
01 02 03 04

3
2 Product Description
Multi-function code table
Atmosphere light sign
Atmosphere Light button
Switch / Gear adjustment button
Accelerator
Electric quantity display
E: maximum speed-5 MPH
N: maximum speed-6.5 MPH
S: maximum speed-9.5MPH
Speed
Upright pole
Rear mudguard brake
Rear Wheel
Folding Mechanism
Accelerator
Charging Port
Foot Brace
Mood Lamp
Front Wheel
S
E
N

4
3 Product Installation
Loosen the two screws on the riser clip counterclockwise with a 5mm inner hexagon wrench.
Insert the upright pole in place.
Tighten the two screws clockwise with a
5mm inner hexagon wrench

5
the folding wrench to unfold the scooter
Put the handle into the handle fixing device
and pass the screw through the hole on the
lock the handle
Turn the 5mm inner hexagon wrench

6
Adjust the height of the handle, relax the
quick release lock and adjust the telescopic
lock and remove it quickly.
The tightness of quick disassembly can be
adjusted by manually tightening or loosening
the inner hexagonal bolts, and be careful not
to over-tighten. It can be opened and locked
quickly by hand, and the telescopic rod will
not slide and shake.

7
4 Charger Connection
Remove the dust plug
of the charging port
Plug in the charger Cover the dust plug
after charging
Note: Please use the original lithium battery charger of
the scooter to charge it indoors. It is prohibited to use
non-original chargers such as lead-acid battery chargers
to charge the scooter.
When charging the scooter, please check whether the
charging port of the scooter is dry. If it is wet, please
wipe the charging port clean before charging. Connect
the charger output terminal to the charging port of the
scooter, and then connect the charger plug to the power
source.
The charger indicator light shows red to indicate that the
scooter is charging, and green shows that the charging has
beencompleted. At this time,the charger power should be
damage to the scooter battery.
After charging is completed, the charging port of the
scooter should be plugged with the dust plug to avoid
water entering the charging port during use and causing
the scooter to short-circuit.

8
5 How to Ride and Park
Before you drive the scooter, for your safety, please be sure to wear the necessary safety gear.
You can learn to drive on different terrains, and you must slow down if you encounter
unfamiliar terrain. Never let the scooter off the ground at any time. The scooter is a
supplementary transportation tool designed for use on flat roads. When users are driving on
uneven roads, they should slow down and drive slowly.
When riding, you must keep your feet on the pedals of the scooter to avoid the danger of
unbalanced bikes.
1.Press the power switch button and
check if the power indicator light is on

9
2. Step on the pedal power switch
with one foot, and slide the other
foot on the ground
stop in a safe position, and then press the
power switch button to switch. The maximum
speed of E gear is 5MPH 9.5MPH, the
maximum speed of N gear is 6.5MPH, the
maximum speed of S gear is 6.5MPH
3. When the scooter is sliding at a
certain speed, put your feet on the
pedals.
Note: Do not step on the
accelerator until the scooter
reaches a speed of 3 Km/h.
The scooter must travel at least
3km/h before the motor will
work.
5. When you need to stop, step on
the rear wheel mudguard to apply
friction to brake.
s

10
6 Ambient Light Control
Press the power switch button to
power on the scooter and check that
the power LED is on. Short press the
atmosphere light switch button on the
atmosphere lights.

11
7 Safety Instructions
Helmets and protective gear must be worn during driving.
It is forbidden to ride into the motor vehicle lanes, residential areas
where people and vehicles are mixed, and it is forbidden to ride in the
stagnant water exceeding 2cm. It is forbidden for more than one person
to ride at the same time or ride with a child. It is forbidden to ride up and
down stairs or escalators. If you encounter speed bumps, elevators, door
thresholds, potholes, etc, please keep the speed low or stop using it.
Electric scooter is a kind of sports and entertainment, not a means of
transportation, but once you drive it into a public area, it will also have
the attributes of a means of transportation. Therefore, it also has the safety
risks that all vehicles may have. Strictly following the instructions in this
manual will protect the safety of you and others to the greatest extent.
At the same time, you need to understand: Once you ride on public roads
or other public places, even if you ride normally in accordance with
this manual, you may face risks caused by illegal driving and improper
operation of others or other vehicles. Just like walking or biking can also
be injured by other vehicles. As with all vehicles, the faster the driving
speed, the longer the distance required for braking. Emergency braking on
smooth ground may also cause the wheels to slip and lose their balance
and fall. Therefore, it is very important to be vigilant, maintain a proper
speed, and keep a reasonable distance from other people and vehicles
during riding. Please stay alert and drive at low speed before driving into
unfamiliar terrain.

12
Please respect pedestrians' right of way when driving. Avoid frightening
pedestrians, especially children. Remind pedestrians when passing behind
and slow down when passing, passing as far as possible from the left side
of the pedestrian (for countries where vehicles are driving on the right,
Electric scooters must be driven in accordance with relevant standards,
national and regional regulations. Please be sure to strictly abide by the
safety requirements of this manual for cyclists. Our company will not bear
direct and joint liability for all property and personal damage accidents,
legal disputes, and all other unfavorable events that cause conflicts of
interest caused by the violation of the use of this manual.
Charging each time you use it can greatly extend the life of the battery, try
to avoid rechargingthe battery after it iscompletely depleted. According to
batteries is the highest at 25±3°C. As the ambient temperature continues to
a downward trend. Typically, in an environment of 0°C, the cruising range
of the scooter may be only half or even lower than that at 25°C, but this
process is reversible, that is, as the ambient temperature recovers, the
Please perform a basic inspection of the scooter before each driving. If
there are obvious abnormalities such as loose parts, reduced battery life,
excessive wear of parts, and abnormal noises from the body, please stop
using it immediately and do not ride forcibly. Please contact our customer

13
8 Folding And Handling
scooter.
Lift the upright pole of the scooter with one hand or both hands to carry it.
Folding

14
9 Daily Maintenance
Cleaning and Maintenance
Battery Maintenance
If there are stains on the surface of the scooter body, use a soft cloth
dipped in a small amount of clean water to wipe it. If there are stains that
then clean with a damp cloth.
Tips: Do not use alcohol, gasoline, kerosene or other corrosive and
volatile chemical solvents to clean, otherwise it will seriously damage
the appearance and internal structure of the scooter. It is forbidden to use
pressure washer gun to spray, drench, flush or brush. Please make sure
that the scooter is turned off when cleaning, and the charging cable has
been unplugged and the dust plug of the charging port is tightly plugged,
otherwise there may be an electric shock or serious failure due to water
entering the scooter.
When not in use, try to store it indoors in a dry and cool place, and try
to avoid storing it outdoors for a long time. Sun exposure, overheating,
cold outdoor environment will accelerate the aging of the appearance of
the scooter, the aging of the tires, and reduce the service life of its battery
pack.
Please do not place the battery in a high temperature over 50°C or a low
temperature environment below 20°C (such as the interior of a car exposed

15
It is forbidden to throw the battery pack into a fire, otherwise it
may cause the battery to fail, overheat, or even risk of fire. For
other battery maintenance precautions, please consult the seller.
Avoid recharging after the battery is completely depleted, and try
to charge after each use, which can greatly extend the life of the
battery. In addition, when used at room temperature, the battery
pack can provide a longer riding distance and better performance,
the battery life performance will decrease if it is used in an
environment below 0°C. Typically, in an environment of 0°C,
the riding distance may be only half or less than that at room
temperature. The riding distance provided by the battery pack will
recover when the temperature rises.
Tips: A fully charged scooter will exhaust its stored power after
about 20-90 days of standby, and an under-charged scooter will
exhaust its power after about 20-50 days of standby. In this case,
if the battery is not charged in time, it may cause the battery to
be over-discharged and damaged. This damage is irrecoverable.
In this case, the damaged scooter will not be able to be recharged
and will not be able to enjoy free warranty service. (Note: Non-
professionals are forbidden to disassemble the battery pack at will,
otherwise it may cause serious safety accidents due to electric

Performance Index Project Parameters
Product size
855X366X317
825X366X856
775X175X325
Weight
70
6.5
Riding requirement
6-15
100-150
Main parameters of the
whole vehicle
10
6-10
Applicable land type degrees, steps not higher than 1cm, trenches not exceeding
1cm
Waterproof grade
Battery parameters
24
25.2
2.5
Intelligent BMS / overheating
Motor parameters 120
Charging parameters
12.5
100-240
25.2
0.5
About 5
16
Product Parameter Table
kind. Only part of the data range is listed here. Please consult the dealer for details.
