Instruction Manual
Analog Vortex Mixer with Fixed Cup Head

1
Table of ConTenTs
Package Contents . . . . . . . . . . . . 1
Warranty . . . . . . . . . . . . 1
Installation . . . . . . . . . . . . 2
Maintenance & Servicing . . . . . . . . . . . . 2
Environmental Conditions . . . . . . . . . . . . 2
Safety Instructions . . . . . . . . . . . . 2
Standards & Regulations . . . . . . . . . . . . 3
Specifications . . . . . . . . . . . . 3
Introduction . . . . . . . . . . . . 4
Operating Instructions . . . . . . . . . . . . 4
WarranTy
Manufacturer warrants this product to be free from defects in material and workmanship
when used under normal conditions for two (2) years. Register your equipment or
instrument online at www.vwrsp.com/warranty for US residents or www.vwrcanlab.
com/warranty for Canadian residents. For your reference, make a note of the serial
number, date of purchase and supplier here.
Serial Number: _______________________________________________________
Date of Purchase: ____________________________________________________
Supplier: ____________________________________________________________
PaCkage ConTenTs
Analog Vortex Mixer
72” (183cm) power cord
Instruction manual

2
InsTallaTIon
Upon receiving the VWR Vortex Mixer, check to ensure that no damage has occurred during
shipment. It is important that any damage that occurred in transport is detected at the time of
unpacking. If you do find such damage the carrier must be notified immediately.
After unpacking, place the Vortex Mixer on a level bench or table, away from explosive vapors.
Ensure that the surface on which the unit is placed will withstand typical heat produced by the
unit. Always place the unit on a sturdy work surface.
The Vortex Mixer is supplied with a power cord that should be plugged into a properly grounded
outlet. If the supplied power cord does not meet your needs, please use an approved power
cord that suits local codes and electric supply. Replacement of the plug must be made by a
qualified electrician.
MaInTenanCe & servICIng
The Vortex Mixer is built for long, trouble-free, dependable service. No lubrication or other
technical user maintenance is required. The unit should be given the care normally required
for any electrical appliance. Avoid wetting or unnecessary exposure to fumes. Spills should be
removed promptly. DO NOT use a cleaning agent or solvent on the front panel which is abrasive
or harmful to plastics, nor one which is flammable. Always ensure the power is disconnected from
the unit prior to any cleaning. If the unit ever requires service, contact your VWR representative.
envIronMenTal CondITIons
Operating Conditions: Indoor use only.
Temperature: 4 to 40°C (39.2 to 104°F)
Humidity: 20% to 85% relative humidity, non-condensing
Altitude: 0 to 6,562 ft. (2000 M) above sea level
Non-Operating Storage:
Temperature: -20 to 65°C (-4 to 149°F)
Humidity: 20% to 85% relative humidity, non-condensing
Installation Category II and Pollution Degree 2 in accordance with IEC 664.
safeTy InsTruCTIons
Please read the entire instruction manual before operating the Vortex Mixer.
WARNING! DO NOT use the Vortex Mixer in a hazardous atmosphere or
with hazardous materials for which the unit was not designed. Also, the
user should be aware that the protection provided by the equipment may
be impaired if used with accessories not provided or recommended by
the manufacturer, or used in a manner not specified by the manufacturer.
Always operate unit on a level surface for best performance and
maximum safety.
Cup head is permanently attached to the unit. DO NOT try to remove or
permanent damage will occur.
CAUTION! To avoid electrical shock, completely cut off power to the unit
by disconnecting the power cord from the wall outlet. Disconnect unit from
the power supply prior to maintenance and servicing.
Spills should be removed promptly. DO NOT immerse the unit for
cleaning.
DO NOT operate the unit if it shows signs of electrical or mechanical damage.
Earth Ground - Protective Conductor Terminal
Alternating Current

3
sTandards & regulaTIons
Henry Troemner LLC hereby declares under it’s sole responsibility that the con-
struction of this product conforms in accordance with the following standards:
Safety standards:
IEC 61010-1 Safety requirements for electrical equipment for
measurement, control and laboratory use. Part I:
General Requirements.
IEC 61010-2-051 Part II: Particular requirements for laboratory
equipment for mixing and stirring.
UL Std. No. 61010-1
EMC standards:
IEC45501 IEC6100-3-2/3-3
IEC61000-4-2 IEC61000-4-3
IEC61000-4-4 IEC61000-4-5
IEC61000-4-6 IEC61000-4-11
EN55022A
Associated EU guidelines:
EMC directive 2004/108/EC
LVD directive 2006/95/EC
RoHS directive 2011/65/EU
analog vorTexer MIxer sPeCIfICaTIons
Overall dimensions (L x W x H): 7.75 x 6 x 5.5”
(19.7 x 15.2 x 14cm)
Electrical (50/60 Hz): 120V, 1.2 amps, 150 watts
Speed range*: 300 to 3200rpm
Orbit: 0.194” (4.9mm)
Duty rating: intermittent duty
Controls: auto/off/on rocker switch,
speed knob: variable 1 to 10 dial marks
Ship weight: 11.7lbs (5.3kg)

vorTex MIxer InTroduCTIon
Your Vortex Mixer is ready for most one-handed applications. The Vortex Mixer
operates by mixing tubes just prior to testing.
OPERATING TIPS
These units are not intended for continuous use over extended periods of time. A
built-in temperature sensor will prevent the unit from overheating by shutting the
motor down. If this occurs, allow the motor to cool down and the unit will be able
to resume normal operation. Decrease the duration of the time unit is used between
rest periods.
NOTE: The cup head is permanently attached to the unit. DO NOT try to remove
or permanent damage will occur.
analog vorTex MIxer oPeraTIng InsTruCTIons
1. Make sure the 3-way rocker switch is in the center, off position. Plug the power
cord into a properly grounded outlet.
2. For continuous operation, push the rocker switch to the right, on position. For
intermittent/touch operation, push the rocker switch to the left, auto position.
3. In either case, turn the speed knob to 1. In the on position, you will see the
head in motion immediately. In the auto position, the vessel you are using must
be pushed down on the head attachment to achieve motion. To get the desired
mix, vary the speed, using the speed knob, and/or vary the angle of contact
and pressure against the head.
4. When finished with either continuous or intermittent operation, return rocker
switch to the center, off position.
5. The intermittent, auto mode is intended for short mixing times of one (1)
minute or less at full speed. A rest period of two (2) minutes is recommended
to minimize the possibility of overheating the motor. The unit can become
warm to the touch with constant use. There is nothing wrong with it. At high
performance settings the motor (UL recognized component) simply puts out
more heat.
6. To completely cut off power to the unit, disconnect the power cord from the
wall outlet.
Manufactured by:
201 Wolf Drive • Thorofare, NJ 08086-0087
Phone: [phone] • Fax: [phone] • E-mail: [email protected]
www.troemner.com
715115-00 (REV 2- 8/15)
TROEMNER LLC
