VWR 3500 Standard User manual

Revision 11
15/05/17
Instruction Manual
Standard and Advanced
Orbital Shakers
Orbital Shakers Euro Plug UK Plug Swiss Plug
3500 Standard Orbital Shakers 444-2903 444-2904 444-2905
3500 Advanced Orbital Shakers 444-2906 444-2907 444-2908
3750 Advanced Reciprocating Shakers 444-2909 444-2910 444-2911
5000 Standard Orbital Shakers 444-2912 444-2913 444-2914
5000 Advanced Orbital Shakers 444-2915 444-2916 444-2917
10000-1 Advanced Orbital Shakers 444-2918 444-2919 444-2920
10000-2 Advanced Orbital Shakers 444-2921 444-2922 444-2923
15000-1 Advanced Orbital Shakers 444-2924 444-2925 444-2926
15000-2 Advanced Orbital Shakers 444-2927 444-2928 444-2929
European Catalogue Numbers:
EN - English ......... 1
FR - Français ......... 18
ES - Español ......... 36
IT - Italiano ......... 54
DE - Deutsch ......... 72
PT - Português ......... 90
NL - Nederlands .........108
NO - Norsk .........113
DA - Dansk .........118
SV - Svenska .........123
FI - Suomi .........128
HU - Magyar .........133
PL - Polski ......... 138

Table of ConTenTs
Package Contents ................................................ 1
Warranty ........................................................ 1
Installation ...................................................... 1
Maintenance & Servicing ........................................... 2
Intended Use..................................................... 2
Equipment Disposal ............................................... 2
Environmental Conditions .......................................... 2
Safety Instructions ................................................ 3
Warning ........................................................ 3
Standards & Regulations ........................................... 3
Specications, Model 3500, 3750 .................................... 4
Specications, Models 5000, 10000 .................................. 5
Specications, Models 15000 ....................................... 6
Operating Instructions, Standard Orbital Shaker ......................... 7
Control Panel, Advanced Orbital Shaker ............................... 8
Operating Instructions, Advanced Orbital Shaker ......................9-11
Technical Service ................................................ 12
Troubleshooting ................................................. 12
Accessories...................................................13-17
EC Declaration of Conformity ...................................143-144
PaCkage ConTenTs
Orbital or Reciprocating Shaker, Non-skid rubber mat,
234cm detachable power cord, Instruction manual
WarranTy
VWR International warrants that this product will be free from defects in material
and workmanship for a period of two (2) years from date of purchase. If a defect is
present, VWR will, at its option, repair, replace, or refund the purchase price of this
product at no charge to you, provided it is returned during the warranty period. This
warranty does not apply if the product has been damaged by accident, abuse, misuse,
or misapplication, or from ordinary wear and tear. For your protection, items being
returned must be insured against possible damage or loss. This warranty shall be
limited to the replacement of defective products. IT IS EXPRESSLY AGREED THAT
THIS WARRANTY WILL BE IN LIEU OF ALL WARRANTIES OF FITNESS AND IN
LIEU OF THE WARRANTY OF MERCHANTABILITY.
InsTallaTIon
Upon receiving the VWR Orbital or Reciprocating Shaker, check to ensure that no
damage has occurred during shipment. It is important that any damage that occurred
in transport is detected at the time of unpacking. If you do nd such damage the carrier
must be notied immediately. After unpacking, place the shaker on a level bench or
table, away from explosive vapors. Ensure that the surface on which the unit is placed
will withstand typical heat produced by the unit and place the unit a minimum of 15cm
from vertical surfaces. Always place the unit on a sturdy work surface. The Orbital or
Reciprocating Shaker is supplied with a power cord that is inserted into the IEC con-
nector on the back of the unit rst, then it can be plugged into a properly grounded
outlet. The 230V unit plugs into a 230 volt, 50/60 Hz source. To prevent the rubber
mat from sliding, remove backing from adhesive on the underside of mat, reposition
in tray, and rmly press.
EN
1
Legal Address of Manufacturer: VWR International bvba • Researchpark Haasrode 2020 • Geldenaakesbaan 464 • B-3001 Leuven • + 32 16 385011 • http://be.vwr.com
Country of Origin: United States

MaInTenanCe & servICIng
The Orbital or Reciprocating Shaker is built for long, trouble-free, dependable service.
No lubrication or other technical user maintenance is required. It needs no user
maintenance beyond keeping the surfaces clean. However at least every three (3)
months you should:
• Unplug the unit.
• Remove any accumulated dirt from the base and tray.
• Check all accessible items to make sure they are properly tightened.
The unit should be given the care normally required for any electrical appliance. Avoid
wetting or unnecessary exposure to fumes. DO NOT use a cleaning agent or solvent
on the front panel which is abrasive or harmful to plastics, nor one which is ammable.
Always ensure the power is disconnected from the unit prior to any cleaning. If the unit
ever requires service, contact your VWR representative.
InTended Use
These Shakers are intended for general laboratory use.
eqUIPMenT dIsPosal
This equipment must not be disposed of with unsorted waste. It is your
responsibility to correctly dispose of the equipment at life-cycle-end by
handing it over to an authorized facility for separate collection and recy-
cling. It is also your responsibility to decontaminate the equipment in case
of biological chemical and/or radiological contamination, so as to protect
the persons involved in the disposal and recycling of the equipment from
health hazards.
For more information about where you can drop off your waste of equipment, please
contact your local dealer from whom you originally purchased this equipment. By
doing so, you will help to conserve natural and environmental resources and you will
ensure that your equipment is recycled in a manner that protects human health.
envIronMenTal CondITIons
sTandard Models
Operating Conditions: Indoor use only.
* For use in dry CO2 environments, incubators, or cold rooms. Not for use in
CO2-incubators with high humidity.
Temperature: 0 to 40°C
Humidity: maximum 80% relative humidity, non-condensing
Altitude: 0 to 2000 M above sea level
Non-Operating Storage:
Temperature: -20 to 65°C
Humidity: maximum 80% relative humidity, non-condensing
Installation Category II and Pollution Degree 2 in accordance with IEC 664.
advanCed & reCIProCaTIng Models
Operating Conditions: Indoor use only.
* For use in dry CO2 environments, incubators, or cold rooms. Not for
use in CO2-incubators with high humidity.
Temperature: -10 to 60°C
Humidity: maximum 80% relative humidity, non-condensing
Altitude: 0 to 2000 M above sea level
Non-Operating Storage:
Temperature: -20 to 65°C
Humidity: maximum 80% relative humidity, non-condensing
Installation Category II and Pollution Degree 2 in accordance with IEC 664.
* Avoid cold starts: Unit is not designed to start after being in a cold room
environment. Bring unit into cold room from a room temperature environment,
operate and remove unit from cold room as soon as operation is complete.
EN
2

safeTy InsTrUCTIons
Please read the entire instruction manual before operating the Orbital Shaker.
WARNING! DO NOT use the Orbital Shaker in a hazardous atmosphere
or with hazardous materials for which the unit was not designed. Also, the
user should be aware that the protection provided by the equipment may
be impaired if used with accessories not provided or recommended by the
manufacturer, or used in a manner not specied by the manufacturer.
Always operate unit on a level surface for best performance and
maximum safety.
DO NOT lift the unit by the tray.
CAUTION! To avoid electrical shock, completely cut off power to the unit by
disconnecting the power cord from the unit or unplug from the wall outlet.
Disconnect unit from the power supply prior to maintenance and servic-
ing.
Spills should be removed promptly. DO NOT immerse the unit for cleaning.
DO NOT operate the unit if it shows signs of electrical or mechanical damage.
Earth Ground - Protective Conductor Terminal
Alternating Current
Pinch Point - Keep ngers clear during operation.
EN
3
sTandards & regUlaTIons
VWR international hereby declares under its sole responsibility that the products
comply with the requirements of the following directives and associated standards:
Associated EU directives:
EMC directive 2014/30/EU
LVD directive 2014/35/EU
ROHS directive 2011/65/EU
WEEE directive 2012/19/EU
Safety standards:
EN 61010-1
EN 61010-2-051
EN 50581
EMC standards:
EN 61326-1

Model 3500
Overall dimensions LxWxH 41,3 x 35,6 x 14,6cm
Tray dimensions LxW 33 x 28cm
Electrical 230 volts, 2,5 amps, 75 watts
Fuses 5mm x 20mm, 5 amp quick acting
Speed Range (Advanced) 15 to 500 rpm
(Standard) 25 to 500 rpm
Speed Accuracy (Advanced)
Above 100rpm ±1% of set speed
Below 100rpm ±1rpm
Orbit 19mm
Capacity ~16kg @ 75 rpm
~2,3kg @ 300 rpm
Timer (Advanced) 1 second to 160 hours
(Standard) 1 to 120 minutes
Controls (Advanced) See page 8
(Standard) See page 7
Ship Weight 22,2kg
European Catalog Numbers: (Standard) (Advanced)
Euro plug: 444-2903 444-2906
UK plug: 444-2904 444-2907
Swiss plug: 444-2905 444-2908
EN
sPeCIfICaTIons
4
Model 3750
Overall dimensions LxWxH 41,3 x 35,6 x 14,6cm
Tray dimensions LxW 33 x 28cm
Electrical 230 volts, 2,5 amps, 40 watts
Fuses 5mm x 20mm, 5 amp quick acting
Speed Range 20 to 300 rpm
Speed Accuracy (Advanced)
Above 100rpm ±1% of set speed
Below 100rpm ±1rpm
Orbit 19mm Total Travel
Capacity 6,8kg @ 300 rpm
Timer 1 second to 160 hours
Controls See page 8
Ship Weight 22,2kg
European Catalog Numbers: (Advanced)
Euro plug: 444-2909
UK plug: 444-2910
Swiss plug: 444-2911

Model 10000
Overall dimensions LxWxH 71,8 x 67,8 x 17,8cm
Tray dimensions LxW 61 x 61cm
Electrical 230 volts, 2,5 amps, 80 watts
Fuses 5mm x 20mm, 5 amp quick acting
Speed Range 10000-1 =15 to 500 rpm
10000-2 =15 to 300 rpm
Speed Accuracy (Advanced)
Above 100rpm ±1% of set speed
Below 100rpm ±1rpm
Orbit 10000-1 = 2,54cm
10000-2 = 5,0cm
Capacity ~45,3 @ 100 rpm
~18,1 @ 300 rpm
Timer 1 second to 160 hours
Controls See page 8
Ship Weight 90,7kg
European Catalog Numbers: (10000-1 Advanced) (10000-2 Advanced)
Euro plug: 444-2918 444-2921
UK plug: 444-2919 444-2922
Swiss plug: 444-2920 444-2923
EN
sPeCIfICaTIons (ConT’d)
5
Model 5000
Overall dimensions LxWxH 59,9 x 67,8 x 15,2cm
Tray dimensions LxW 45,7 x 61cm
Electrical 230 volts, 2,5 amps, 75 watts
Fuses 5mm x 20mm, 5 amp quick acting
Speed Range (Advanced) 20 to 500 rpm
(Standard) 25 to 500 rpm
Speed Accuracy (Advanced)
Above 100rpm ±1% of set speed
Below 100rpm ±1rpm
Orbit 25.4mm
Capacity ~22,3kg @ 125 rpm
~4,5kg @ 300 rpm
Timer (Advanced) 1 second to 160 hours
(Standard) 1 to 120 minutes
Controls (Advanced) See page 8
(Standard) See page 7
Ship Weight 49,5kg
European Catalog Numbers: (Standard) (Advanced)
Euro plug: 444-2912 444-2915
UK plug: 444-2913 444-2916
Swiss plug: 444-2914 444-2917

Model 15000
Overall dimensions LxWxH 71,8 x 67,8 x 17,8cm
Tray dimensions LxW 61 x 91,4cm
Electrical 230 volts, 2,5 amps, 80 watts
Fuses 5mm x 20mm, 5 amp quick acting
Speed Range 15000-1 =15 to 500 rpm
15000-2 =15 to 300 rpm
Speed Accuracy (Advanced)
Above 100rpm ±1% of set speed
Below 100rpm ±1rpm
Orbit 15000-1 = 2,54cm
15000-2 = 5,0cm
Capacity ~68,0kg @ 100 rpm
~18,1kg @ 300 rpm
Timer 1 second to 160 hours
Controls See page 8
Ship Weight 104,3kg
European Catalog Numbers: (15000-1 Advanced) (15000-2 Advanced)
Euro plug: 444-2924 444-2927
UK plug: 444-2925 444-2928
Swiss plug: 444-2926 444-2929
sPeCIfICaTIons (ConT’d)
EN
6

Standard Orbital Shaker
with optional platform and
ask clamps
speed knob time knob rocker switch
EN
The Standard Orbital Shaker is used for general laboratory shaking needs.
Models 3500 and 5000
1. Getting ready:
a. The speed and time knobs have a built in on-off switch at their extreme
counter-clockwise position. Turn both knobs to the off position.
b. Make sure the rocker switch is in the standby position.
c. Plug the cord into a properly grounded outlet.
oPeraTIng InsTrUCTIons - sTandard orbITal shaker
2. Setting speed:
a. To run in continuous mode, push rocker to the run position. Set speed knob to
desired setting and adjust if necessary. Unit will run until you move the rocker
switch to the standby position. The microprocessor speed control slowly ramps
to set speed to avoid splashing.
3. Setting time:
a. To run in timed mode, set timer and the speed knob to the desired settings.
Press the rocker switch to the time position and release. The shaker will now
run for the set time.
b. To exit the timed mode turn the time knob to the extreme counter-clockwise
position.
4. Turning unit off:
a. To stop shaking function, turn the speed knob to the extreme counter-clock-
wise position and push the rocker switch to the standby position. The shaker
should be kept in the standby position when not in use. To completely cut off
power to the unit, disconnect the power cord from the unit or unplug from the
wall outlet.
OPERATING TIPS
Centering your sample and even weight distribution on the tray helps with balance
and stability. As a safety feature, a built-in program will shut power off to the motor if
the tray is prevented from rotating, or the unit is overloaded beyond its recommended
weight capacity. To reset the unit, press the rocker switch to standby and then press
the rocker switch to the on position. The shaker will automatically restart after a power
interruption. Built-in memory maintains the last used speed and time settings during
a power interruption.
To prevent the rubber mat from sliding, remove backing from adhesive on the under-
side of mat, reposition in tray, and rmly press.
7

A.
B.
EN
The front panel of the Advanced Orbital Shaker contains all the controls and displays
needed to operate the unit.
A. Standby button/standby indicator light: The standby indicator light will
illuminate when the unit is plugged in. The unit will be in standby mode. Press the
standby button to start the speed and time functions. The standby indicator light
will shut off. Press the standby button again and the unit will once again be in
standby mode.
B. Speed display: Displays the speed of the shaker.
C. Up/down arrows: For set-point control. On/off button starts/stop shaking function.
D. Time display: Displays accumulated time (continuous mode) or how much time
is remaining (timed mode). The display range is from 0 to 9999 minutes in one (1)
second increments. The display will indicate minutes and seconds until the timer
reaches 99 minutes and 59 seconds (99:59), then the display will automatically
display minutes up to 9999.
E. Up/down arrows for setpoint control. On/off button starts/stops the timer function.
ConTrol Panel - advanCed orbITal shaker
C.
D.
E.
8

EN
Advanced Orbital Shaker
with optional platform
1. Getting ready:
a. Plug the cord into a properly grounded outlet. The standby indicator light will
illuminate, verifying power to the shaker.
b. Press the standby button to move the unit from standby mode. The standby
indicator light will turn off and the speed and time displays will illuminate,
displaying the previously used settings.
2. Setting speed:
a. Press the up/down arrow below the speed display until you reach the desired
speed. When you release the button, the display will blink off and then on
indicating the new set speed has been accepted.
b. Press the on/off button to start the shaking function. The indicator light below
the speed display will illuminate and blink until the setpoint is reached. Once
the set-point is reached the light will stop blinking and remain lit until shaking
has ceased. The microprocessor controlled ramping feature slowly increases
speed until the set-point is reached which helps to avoid splashing, and pro-
vides excellent low end control.
c. Speed adjustments can be made without interrupting shaking by using the up/
down arrows below the speed display. After the change has been made and
you release the button, the display will blink off and then on indicating the new
set speed has been accepted.
d. To stop the shaking function press the on/off button below the speed display.
The speed indicator light will turn off.
3. Setting time to zero (0:00) and continuous mode: Accumulated time.
a. Press and hold the on/off button below the time display. After three (3) sec-
onds, the display will indicate the previous set time.
oPeraTIng InsTrUCTIons - advanCed orbITal shaker
The Advanced Orbital Shaker is used for general laboratory shaking needs.
Advanced Models
The Advanced Orbital Shaker has been designed for the speed and time functions to
work independently of one another. The speed can be reset without resetting the timer
and the timer can be stopped and started without interrupting the shaking function.
9
