VWR avantor Star-Blender 400 Silent User manual

Instruction manual
VWR®Star-Blender 400 Silent
EU cat. no 710-2143
___
Version 01 Issue 06/2021
For manuals in other languages,
please visit vwr.com

2vwr.com I Instruction manual VWR®Star-Blender 400 Silent
Legal address of Manufacturer
Europe
VWR
®
International bv,
Researchpark Haasrode 2020
Geldenaaksebaan 464 B-
3001 Leuven
[phone]
http://be.vwr.com
UK Importer:
VWR International Ltd
Hunter Boulevard, Magna Park
Lutterworth, Leicestershire, LE17 4XN
http://uk.vwr.com
Country of Origin
France

3vwr.com I Instruction manual VWR®Star-Blender 400 Silent
Table of Contents
Safety Information ........................................................................................................................................................... 4
Package Contents ............................................................................................................................................................ 5
Unpacking ........................................................................................................................................................................ 5
Installation ....................................................................................................................................................................... 6
Intended use .................................................................................................................................................................... 6
Symbols and conventions ................................................................................................................................................ 6
Product Specifications ..................................................................................................................................................... 6
Overview .......................................................................................................................................................................... 8
Description of Buttons and Switches ............................................................................................................................... 8
Operational keys .............................................................................................................................................................. 9
Getting Started ................................................................................................................................................................ 9
Important Guidelines ..................................................................................................................................................... 10
Troubleshooting ............................................................................................................................................................ 11
Repair and maintenance of Star-Blender 400 Silent ..................................................................................................... 11
User replaceable accessories and spare parts ............................................................................................................... 13
Technical service ............................................................................................................................................................ 14
Warranty ........................................................................................................................................................................ 14
Compliance with local laws and regulations .................................................................................................................. 14
Equipment disposal ....................................................................................................................................................... 15

4vwr.com I Instruction manual VWR®Star-Blender 400 Silent
Warning
Before use, please read these instructions thoroughly. Any damage incurred due to non-respect of these
instructions will render the warranty void.
The unit must be placed on its feet, on a stable and horizontal surface. NEVER operate the
Star-Blender 400
Silent
in a different position.
The unit must be used in a well-ventilated room in normal conditions of temperature, pressure and humidity. If it
has been stored at a temperature below 10°C, allow the unit to return to room temperature before operating.
The housing should only be removed by a qualified and authorized technician. If the housing must be removed,
be sure to disconnect the power cord first.
Each unit is delivered in a specific box. Please keep the box and the inside packing for future use.
For best operation, it is important to maintain and clean regularly the
Star-Blender 400 Silent.
Please refer to
the ”MAINTENANCE” section for the cleaning procedure and the list of non-recommended products.
Safety Information
Avoiding Electrical Shock
Please follow the guidelines below, and read this manual in its entirety to ensure safe operation of the unit.
To avoid electrical shock:
The unit must always be powered with a grounded lead in compliance with electrical standards.

5vwr.com I Instruction manual VWR®Star-Blender 400 Silent
Package Contents
Description
Quantity
Integrated security drip tray
1
Set of power cables (EU, UK, CH)
1
User's manual
1
Unpacking
Please check the following diagram showing how to unpack the unit.
Keep the packaging (foam blocks & cardboard box) in case you have to move or ship the unit for maintenance
purposes.
Upper foam
Star-Blender 400
Silent
Box
Lower foam

6vwr.com I Instruction manual VWR®Star-Blender 400 Silent
NOTE: The Star-Blender 400 Silent door must be closed and its handle squeezed in the upper foam.
Installation
Remove the
Star-Blender 400 Silent
from its packing and place it on a flat, stable surface. Connect the power
lead to the rear of the unit and put the switch in position “I”. The displays will light up and a green light will flash
at the bottom of the front side. The unit is now ready to use.
If the unit has been stored at a temperature below 10°C, allow it to return to room temperature before operating.
Intended use
The
Star-Blender 400 Silent
is lab paddle blender. It is used to prepare microbiological samples, in blender bags,
prior to their analysis. The
Star-Blender 400 Silent
put into a suspension the germs present in a solid sample to
be analyzed.
The samples to be analyzed with the
Star-Blender 400 Silent
can weigh between 10 and 40 grammes before
dilution. The total recommended volume in the bag should not exceed 400 mL.
Symbols and conventions
The following chart is an illustrated glossary of the symbols that are used in this manual.
CAUTION
This symbol indicates a potential risk and alerts
you to proceed with caution
Product Specifications
Adjustable blending power
Side-by-side paddle stop
Click and Clean®removable paddles
304 L stainless steel body
Integrated security stainless steel drip tray
180 Watts brushless motor

7vwr.com I Instruction manual VWR®Star-Blender 400 Silent
Multifunction digital screen
4 adjustable speeds-
TotalAccess System: door opens flat
LightCode: color status LED
White polycarbonate blending chamber
White LED light in blending chamber
Sound level (with 250 mL of water + 22 g of cheese) 48 dB
Blending time from 1 s to 59 min, ∞/ count-down
Blending speed 4, 6, 8, 10 strokes/s
Dimensions (w x d x h) 27.6 x 45.9 x 35.7 cm
Weight (unit) 24.7 kg
Power 100-240 V~ 50-60 Hz
International Protection marking 31
Optimal blending volume from 50 to 400 mL
Made in France
3-year warranty (after registration)
Shock-absorbers life-time warranty

8vwr.com I Instruction manual VWR®Star-Blender 400 Silent
Overview
Front view of Star-Blender 400 Silent
Digital screen and multifunctional keypad:
Monoblock blending chamber in white polycarbonate,
with inside lighting and drip tray.
Adjustable paddles, with side-by-side stopping and patented
Click & Clean®
system.
Patented
TotalAccess System
with 180° door-opening and leak-tight
Q-Tight®
system.
Brushless motor.
Description of Buttons and Switches
Front View of
1. Timer: Variable time (1 s- 1h, and open running)
2. Speed: Variable speed (4, 6, 8, 10 strokes/s).
3. Open running
4. On/Off
1
2
3
4
5
4
2
1
3
1
2
5
4
3

9vwr.com I Instruction manual VWR®Star-Blender 400 Silent
Rear View
Rear view of Star-Blender 400 Silent
Operational keys
or Timer: Set the blending time using the time keys
or Speed key: Set the blending speed 1, 2, 3, 4 (4, 6, 8, 10 strokes/s)
Open running key
On/Off key
Getting Started
1. Connect the
Star-Blender 400 Silent
to the power mains (100-240 VAC). Put the switch in position “I“.
2. Set the blending time using the time keys (
or
) or the for open running.
3. Set the blending speed 1, 2, 3, 4 (4, 6, 8, 10 strokes/s) with the speed keys (
or
)
4. Pull the lever down to open the door. Place the bag with the sample in the unit on the bagrest.
5. Close the door by raising the lever until it clicks shut.
6. The
Star-Blender 400 Silent
starts automatically and the lighting under the front side
flashes orange slowly.
7. At the end of the cycle, the
Star-Blender 400 Silent
stops automatically. The lighting turns
green, flashes quickly then more slowly. At the end, the unit beeps.
8. Open the door and remove the bag. The
Star-Blender 400 Silent
is ready for the next cycle.
9. After 30 mn of inactivity,
Star-Blender 400 Silent
goes automatically to stand-by mode. To
reactivate it, simply press the key.
La
par
tie
de
l'im
age
ave
c
l'ID
de
rela
tion
rId
30
n'a
pas
été
tro
uvé
dan
s le
fich
ier.
La
par
tie
de
l'im
ag
e
av
ec
l'ID
de
rel
ati
on
rId
30
n'a
pa
s
été
tro
uv
é
da
ns
le
fich
ier.
La partie de
l'image avec
l'ID de
relation
rId30 n'a pas
été trouvé
dans le
fichier.
La
par
tie
de
l'im
age
ave
c
l'ID
de
rela
tion
rId
30
n'a
pas
été
tro
uvé
dan
s le
fich
ier.
La
par
tie
de
l'im
ag
e
av
ec
l'ID
de
rel
ati
on
rId
30
n'a
pa
s
été
tro
uv
é
da
ns
le
fich
ier.

10 vwr.com I Instruction manual VWR®Star-Blender 400 Silent
Important Guidelines
Adjusting the blending power
The blending power is determined by the distance between the paddles and the door. The smaller the gap, the
more powerful the blending.
The initial paddle setting is factory set for a standard use with a standard power. When the unit is empty, without
a bag, the paddles just touch the door. From this position, you can move the paddles 3 mm forward or retract
them by 15 mm, depending on your requirements.
Depending on the nature of the sample, you may need to increase or reduce the blending power, i.e. advance or
retract the paddles. To do this, simply turn the handle at the rear of the unit counter-clockwise to advance the
paddles or clockwise to retract them. For information, one complete revolution corresponds to a displacement of
1.5 mm.
To revert to the factory setting (“standard setting”), please follow the instructions at the back of the unit.
Handle for setting the blending power
Operating Instructions
You can decide to activate or deactivate some functions of the
Star-Blender 400 Silent
such as: the beeps, the
lighting under the unit and the lighting in the blending chamber.
All these operations must be carried out in “standby” mode.
At any time, you can go back to the factory settings.
To revert to the factory settings
Put the unit in “standby” mode by pressing the key.
Press simultaneously the key and the “speed ” key.
On the display, after a series of hyphens, “rSEt” will appear.
This confirms the reinitialization of the factory settings.
Presence/absence of beeps
Put the unit in “standby” mode by pressing the key.
Press simultaneously the key and the “time ” key
After 4 seconds, 4 hyphens will appear: "----"
You can now release the keys.
Then press continuously on the “time ” key until you obtain the desired result, i.e. “SOn1” to active the sound or
“SOn0” to deactivate it.
Presence/absence of the lighting under the unit
Put the unit in “standby” mode by pressing the key.
Press simultaneously the key and the “time ” key
After 4 seconds, 4 hyphens will appear: "----"
You can now release the keys.
Then press continuously on the key until you reach the obtain result, i.e. “dEl1” to activate the lighting
under the unit or “dEl0” to deactivate it.

11 vwr.com I Instruction manual VWR®Star-Blender 400 Silent
Presence/absence of lighting in the blending chamber
Put the unit in “standby” mode by pressing the key.
Press simultaneously the key and the “time ” key
After 4 seconds, 4 hyphens will appear: "----"
You can release the keys.
Then press continuously on the “speed ” key until you obtain the desired result, i.e. “lin1” to activate the lighting
or “lin0” to deactivate it.
Troubleshooting
Review the information in the table below to troubleshoot operating problems.
Problem
Cause
Solution
Unit does not start
• The power cord is not correctly
connected.
• The switch is on “0” (OFF).
• The fuses or voltage are not
appropriate.
• The door is not fully closed
• Check that the power cord is
correctly connected.
• Check that the switch is on “I”
(ON).
• Check the fuses and the mains
voltage are ok.
• Check that the door closes well.
If needed clean the blending
chamber.
The screen indicates “Err I”
This alarm is activated when an
over intensity is detected in the
motor
Increase the gap between the
door and the paddles.
The screen indicates “Err 2”
This code indicates an electronic
or a motion defect.
Disconnect the StarBlender from
the mains and contact our
Technical Service.
The blending time is not
convenient
N/A
Set the timer (time) on the
appropriate blending time.
The blending speed is not
convenient
N/A
Set the speed (speed) on the
appropriate blending speed.
The blending bags leak during
the blending process
Bags are not appropriate for the
application
Check the quality of the bags.
The blending bags leak during
the blending process for hard or
heavy samples (wood, cloths…)
• Bags are not appropriate for the
application
• The pressure on the bag is too
important
You may increase the space
between the door and the
paddles of 5 mm and/or decrease
the speed of blending.
The sample spits out of the door
• The bag is not positioned
correctly on the bag rest
• The upper seal is worn out
• Position the bag on the bag rest
• Check the state of the seal on
top of the blending chamber. If
needed, turn it a quarter turn.
Repair and maintenance of Star-Blender 400 Silent
Encountering problems
Do not use sodium hypochlorite (bleach) or quaternary ammonium to clean the unit.
It is important to keep the unit clean, in particular the blending chamber and the door.
Daily maintenance of the housing and blending chamber
The housing of the blender can be cleaned with a wet cloth or a product to clean stainless steel.
The inside of the unit, the paddles and the drip tray can be cleaned and disinfected with 70° ethanol. Make sure
that the mains switch is in position “0”.
To clean the blending chamber:

12 vwr.com I Instruction manual VWR®Star-Blender 400 Silent
- Unplug the power cord.
- Put the unit on the edge of the table.
- Open the door flat.
- Remove the drip tray and clean it.
- Click the paddles and remove them.
- Clean the blending chamber.
- Reposition the paddles by clicking them and put back the drip tray in the blending
chamber.

13 vwr.com I Instruction manual VWR®Star-Blender 400 Silent
- Lift up the door and plug the power cord.
- Position the switch at the back of the unit on “I”.
- Close the door. Test the good functioning of the unit.
Cleaning of door seals
Regularly lubricate the door seals with a lubricant containing silicone.
Annual maintenance
Lubricate the paddle rods with lubricating silicone grease. Apply with a brush or a spray.
User replaceable accessories and spare parts
Description
Quantity
Cat. No.
Paddle
1
005 990
Drip tray for Star-Blender 400
Silent
1
006 867

14 vwr.com I Instruction manual VWR®Star-Blender 400 Silent
Technical service
Web Resources
Visit the VWR website at
www.vwr.com
for:
• Complete technical service contact information
• Access to the VWR Online Catalogue, and information about accessories and related products
• Additional product information and special offers
Contact us
For information or technical assistance contact your local VWR representative or visit.
www.vwr.com.
Warranty
VWR
warrants that this product will be free from defects in material and workmanship for a period of two (2)
years from date of delivery. If a defect is present, VWR will, at its option and cost, repair, replace, or refund the
purchase price of this product to the customer, provided it is returned during the warranty period. This warranty
does not apply if the product has been damaged by accident, abuse, misuse, or misapplication, or from ordinary
wear and tear. If the required maintenance and inspection services are not performed according to the manuals
and any local regulations, such warranty turns invalid, except to the extent, the defect of the product is not due to
such non-performance.
Items being returned must be insured by the customer against possible damage or loss. This warranty shall be
limited to the aforementioned remedies. IT IS EXPRESSLY AGREED THAT THIS WARRANTY WILL BE IN LIEU OF
ALL WARRANTIES OF FITNESS AND IN LIEU OF THE WARRANTY OF MERCHANTABILITY.
Compliance with local laws and regulations
The customer is responsible for applying for and obtaining the necessary regulatory approvals or other
authorisations necessary to run or use the Product in its local environment. VWR will not be held liable for any
related omission or for not obtaining the required approval or authorisation, unless any refusal is due to a defect
of the product.

15 vwr.com I Instruction manual VWR®Star-Blender 400 Silent
Equipment disposal
This equipment is marked with the crossed out wheeled bin symbol to indicate that this equipment must not be
disposed of with unsorted waste.
Instead it's your responsibility to correctly dispose of your equipment at lifecycle -end by handling
it over to an authorized facility for separate collection and recycling. It's also your responsibility to
decontaminate the equipment in case of biological, chemical and/or radiological contamination,
so as to protect from health hazards the persons involved in the disposal and recycling of the
equipment.
For more information about where you can drop off your waste of equipment, please contact your local dealer
from whom you originally purchased this equipment.
By doing so, you will help to conserve natural and environmental resources and you will ensure that your
equipment is recycled in a manner that protects human health.
Thank you

16 vwr.com I Instruction manual VWR®Star-Blender 400 Silent
Local VWR offices in Europe and Asia Pacific
Austria
VWR International GmbH
Graumanngasse 7
1150 Vienna
Tel.: [phone]
Email: [e-mail]
Belgium
VWR International BV
Researchpark Haasrode 2020
Geldenaaksebaan 464
3001 Leuven
Tel.: [phone]
Email: [email protected]
China
VWR (Shanghai) Co., Ltd
Bld.No.1, No.3728 Jinke Rd,
Pudong New District
Shanghai, 201203- China
Tel.: [phone]
Email: [email protected]
Czech Republic
VWR International s. r. o.
Veetee Business Park
Pražská 442
CZ - 281 67 Stríbrná Skalice
Tel.: [phone]
Email: [email protected]
Denmark
VWR International A/S
Tobaksvejen 21
2860 Søborg
Tel.: [phone]
Email: [email protected]
Finland
VWR International Oy
Valimotie 9
00380 Helsinki
Tel.: [phone]
Email: [email protected]
France
VWR International S.A.S.
Le Périgares – Bâtiment B
201, rue Carnot
94126 Fontenay-sous-Bois cedex
Tel.: [phone]* (national)
Tel.: [phone]
(international)
Email: [email protected]
* 0,18 € TTC/ min + prix appel
Germany
VWR International GmbH
Hilpertstrasse 20a
D - 64295 Darmstadt
Freecall: 0800 702 00 07
Tel.: [phone] (international)
Email: [email protected]
Hungary
VWR International Kft.
Simon László u. 4.
4034 Debrecen
Tel.: [phone]
Email: [email protected]
India
VWR Lab Products Private Limited
No.139. BDA Industrial Suburb,
6th Main, Tumkur Road,
Peenya Post,
Bangalore, India – 560058
Tel.: [phone]
Email: [email protected]
Ireland / Northern Ireland
VWR International Ltd / VWR
International (Northern Ireland) Ltd
Orion Business Campus
Northwest Business Park
Ballycoolin
Dublin 15
Tel.: [phone]
Email [email protected]
Italy
VWR International S.r.l.
Via San Giusto 85
20153 Milano (MI)
Tel.: [phone]-487791
Email: [email protected]
Korea
VWR International ~
17, Daehak 4-ro, Yeongtong-gu,
Suwon-si, Gyeonggi-do
Tel.: [phone]
[email protected]
Middle East & Africa
VWR International FZ-LLC
DSP Laboratory Complex
125, Floor 01
Dubai, United Arab Emirates
Tel.: [phone]
[e-mail]
The Netherlands
VWR International B.V.
Postbus 8198
1005 AD Amsterdam
Tel.: [phone]
Email: [email protected]
Norway
VWR International AS
Brynsalleen 4
0667 Oslo
Tel.: [phone]
Email: [e-mail]
Poland
VWR International Sp. z o.o.
Limbowa 5
80-175 Gdansk
Tel.: [phone]
Email: [email protected]
Portugal
VWR International - Material de
Laboratório, Lda
Centro Empresarial de Alfragide
Rua da Indústria, nº 6
2610-088 Amadora
Tel.: [phone]
Email: [email protected]
Singapore
VWR Singapore Pte Ltd
18 Gul Drive
Singapore 629468
Tel: [phone]
Email: [email protected]
Spain
VWR International Eurolab S.L.
C/ Tecnología 5-17
A-7 Llinars Park
08450 - Llinars del Vallès
Barcelona
Tel.: [phone]
Email: [email protected]
Sweden
VWR International AB
Fagerstagatan 18a
163 94 Stockholm
Tel.: [phone]
Email: [email protected]
Switzerland
VWR International GmbH
Lerzenstrasse 16/18
8953 Dietikon
Tel.: [phone]
Email: [email protected]
UK
VWR International Ltd
Customer Service Centre
Hunter Boulevard
Magna Park
Lutterworth
Leicestershire
LE17 4XN
Tel.: [phone]
Email: [email protected]
