VWR 5600 Series Operating instructions

Model 5600 Signature Series
-86C Upright ULT Freezer
Operating and Maintenance Manual 7035602 Rev. 7

VWR International
MANUAL NUMBER 7035602
7 25866/SI-10308 11/8/10 Black knob on inner doors from 285658 to 120400 - 8602-200-1 & 2 ccs
6 25693/FR-2080 7/29/09 Chg’d drier from 209016 to 209017 (refrig schematics), -205 drawing ccs
5 25283/IN-10127 5/28/09 Updated 8602-200-1-B exploded parts drawing - 28 cu ft door change ccs
4 25411/FR-2049 4/30/09 Changed drier from 209020 to 209016 (refrigeration schematics) ccs
3 25018/FR-2016 10/29/08 Removed reference to VRP tool ccs
2 24767/FR-2004 7/8/08 Added Model 5607 28 cu ft ccs
Preface
Model 5600 Series i
Model Capacity in Cubic Feet Voltage
5602 13 230
5603 13 120
5604 17 120
5605 17 230
5606 23 230
5607 28 230
5656 23 120
Part
Number Description Quantity
34040 Key Ring 1 (2 for double door units)
122005 Key 2 (4 for double door units)
380520 Neoprene Cap 2
510016 1/4-20 x 5-1/2” Bolt 2
195763 Retaining Clip 1
370563 Remote Alarm Connector 1
Important installer and user information:
A redundant temperature sensing device has been included in this ULT freezer.
This device is a type “T” thermocouple. For convenient access, the thermocou-
ple (Figure 1-3) terminates in an interconnect jack (Figure 1-5) behind the
base front cover. (May be located differently in chests. See Section 1.) It is
strongly recommended that this thermocouple be attached to a redundant 24
hour 7 day monitoring system with alarm capabilities. Connecting the sensor
to a monitoring and alarm system separate from the freezer provides the
utmost in product safety, should the integral system fail.
Models covered in this manual
Packing List

VWR Internationalii Model 5600 Series VWR International
Preface
Important Read this instruction manual. Failure to read, understand and follow the instructions in this manual
may result in damage to the unit, injury to operating personnel, and poor equipment performance. s
Caution All internal adjustments and maintenance must be performed by qualified service personnel. s
Material in this manual is for information purposes only. The contents and the product it describes are subject to
change without notice. VWR International makes no representations or warranties with respect to this manual.
In no event shall VWR be held liable for any damages, direct or incidental, arising out of or related to the use of
this manual.
©2007 VWR International. All rights reserved.

VWR International Model 5600 Series iiiVWR International
Preface
Important operating and/or maintenance instructions. Read the accompanying text carefully.
Potential electrical hazards. Only qualified persons should perform procedures associated with this
symbol.
Equipment being maintained or serviced must be turned off and locked off to prevent possible injury.
Hot surface(s) present which may cause burns to unprotected skin, or to materials which may be
damaged by elevated temperatures.
Marking of electrical and electronic equipment, which applies to electrical and electronic equipment
falling under the Directive 2002/96/EC (WEEE) and the equipment that has been put on the market
after 13 August 2005.
This product is required to comply with the European Union’s Waste Electrical & Electronic
Equipment (WEEE) Directive 2002/96/EC. It is marked with the WEEE symbol. VWR International
has contracted with one or more recycling/disposal companies in each EU Member State European
Country, and this product should be disposed of or recycled through them. Further information on
VWR’s compliance with this directive, the recyclers in your country and information on VWR
products will be available at www.vwrsp.com.
4Always use the proper protective equipment (clothing, gloves, goggles, etc.)
4Always dissipate extreme cold or heat and wear protective clothing.
4Always follow good hygiene practices.
4Each individual is responsible for his or her own safety.

VWR Internationaliv Model 5600 Series VWR International
Preface
Do You Need Information or Assistance on
VWR Scientific Products?
The VWR can provide information on pricing and give you quotations. We can take
your order and provide delivery information on major equipment items or make arrangements to have your
local sales representative contact your. Our products are listed on the internet and we can be contacted
through our Internet home page.
1-800-932-5000 VWR, Toll Free, US
http://www.vwrsp.com Internet Worldwide Web Home page
The VWR can supply technical information about proper
setup, operation or troubleshooting of your equipment. We can fill your needs for replacement parts or
provide you with on-site service. We can also provide you with a quotation on our Extended Maintenance
Program for your products.
Whatever VWR or Thermo products you need or use, we will be happy to discuss your applications.
If you are experiencing technical problems, working together, we will help you locate the problem and,
chances are, correct it yourself...over the telephone without a service call.
When more extensive service is necessary, we will assist you with direct factory trained
technicians or a qualified service organization for on-the-spot repair. If your service need is covered by the
VWR Scientific warranty, we will arrange for the unit to be repaired at our expense and to your satisfaction.
Regardless of your needs, VWR support by Thermo's professional telephone technicians is
available to assist you Monday through Friday from 8:00a.m. to 6:30 p.m. Eastern Time. Please call or fax us
at:
If you wish to write, our mailing address is:
VWR International Inc.
1310 Goshen Parkway
West Chester, Pennsylvania 19380
International customers, please contact your local distributor.
Sales Group
Product Service Group at Thermo
1-740-373-4763 Direct
1-800-438-4851 Technical Services, Toll Free, U.S. and Canada
1-740-373-4189 FAX
Http://www.vwrsp.com Internet Worldwide Web Home Page
Technical Services E-Mail [e-mail]

Model 5600 Series vVWR International
Table of Contents
Installation and Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
Control Panel Keys, Displays & Indicators . . . . . . . . . . . . . . . . . . . .1-3
Keypad Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4
Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5
Install the Freezer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5
Choose the Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5
Install the Wall Bumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-6
Install the Shelves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-6
RS-232 Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-6
Remote Alarm Contacts and Analog Output . . . . . . . . . . . . . . . . .1-7
Attach the Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-8
Connect Unit to Electrical Power . . . . . . . . . . . . . . . . . . . . . . . . . .1-8
Freezer Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-9
Set the Operating Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-9
Set the High Temperature Alarm . . . . . . . . . . . . . . . . . . . . . . . . . .1-10
Set the Low Temperature Alarm . . . . . . . . . . . . . . . . . . . . . . . . . .1-10
Access Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-11
Run Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-11
Calibrate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
Calibrate the Control Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
Calibrate the Optional Sample Probe . . . . . . . . . . . . . . . . . . . . . . . . .2-2
Temperature Stabilization Periods . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1
High Alarm Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1
Low Alarm Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1
System Battery Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
BUS Battery Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
Display Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
Clear High Stage Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3
Set Access Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3
RS485 Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
Back-Up System Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
Section 1
Section 2
Section 3

vi Model 5600 Series VWR International
Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1
Wrong Power Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
High Stage System Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
Voltage Compensation Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
Multiple Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
Micro Board Failure Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
Lost Communication Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
Probe Failure Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1
Clean Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1
Clean the Condenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1
Clean the Water-cooled Condenser . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Clean in Place (CIP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Defrost the Chamber . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-3
Clean the Door Gasket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-3
Vacuum Relief Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-4
Vacuum Relief Port Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . .5-5
Prepare the Unit for Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-5
Replace the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6
Preventive Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7
Factory Installed Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1
Back-Up System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1
Install Vent Stack, Solenoid and Injection Assembly . . . . . . . . . . . .6-2
Install the Temperature Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-3
Connect the Probe/Solenoid Harness . . . . . . . . . . . . . . . . . . . . . . .6-4
BUS Operation and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . .6-5
Chart Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-7
Change the Recorder Temperature Range . . . . . . . . . . . . . . . . . . . .6-8
Calibrate the Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-9
Datalogger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-9
Water-cooled Condenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-10
Five Inner Door Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-10
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-1
Exploded Parts Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-1
Refrigeration Schematics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-1
Handling Liquid Nitrogen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-1
Handling Liquid Carbon Dioxide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-4
Table of Contents
Section 4
Section 5
Section 6
Section 8
Section 7
Section 9
Appendix A

Model 5600 Series 1-1VWR International
Section 1 Installation and Start-Up
Control Panel
Optional Back-Up
System Controls
Optional Temp
Recorder
Optional Back-up
System Connections
RS-232 or RS-485
Interface
Power Switch
(mains disconnect)
Power Inlet
Wall Bumper
(pre-tapped holes)
Remote Alarm Contacts
and Analog Output
Shelf
Bracket
Sealant
(Caution: This is a critical seal.
Seal must be maintained.)
Optional - Recorder Probe/Datalogger Probe
Control RTD/Redundant Type T
Thermocouple Probe
Optional Miscellaneous Accessories Probe
Figure 1-1. Front View
Figure 1-2. Rear View
Figure 1-3. Chamber Probes
Figure 1-1
• Control Panel - keypad,
displays and indicators
• BUS (Optional Back Up
System) panel
• Optional temperature
recorder (7 day, one pen)
or datalogger
Figure 1-2
• Remote alarm contacts
and selectable analog
output connection (0-1V,
4-20mA (default), 0-5V)
• Power inlet for power
cord connection.
• Optional BUS
connections for probe and
solenoid
• RS-232 (default) or RS-
485 interface
• Power switch (mains
disconnect)
Figure 1-3
• Vacuum relief port -
pressure equalization port
• Probe cover

1-2 Model 5600 Series VWR International
Section 1
Installation and Start-Up
Figure 1-4
• Probe cover houses control, optional recorder, datalogger, redundant alarm
probes.
Figure 1-5
• Battery mounting bracket(s)
• Battery power switch (freezer and BUS)
• Freezer battery
• Optional BUS battery
• Freezer filter location
Vacuum Relief
Port
Chamber Probe
Cover
Figure 1-4. Vacuum Relief and Probe Cover Location
O
Battery power
switch To
remove filter
Thermocouple
interconnect jack
Battery mounting
bracket
Freezer battery
and optional BUS battery
Figure 1-5. Battery(s) Location and Switch

Model 5600 Series 1-3VWR International
Section 1
Installation and Start-Up
• Mode Select Switch - Used to select Run, Settings, Calibrate and
System Configuration Modes.
Mode Select Indicators -
Run: Run Menu
Settings: Set Points Menu
Calibrate: Calibrate Menu
Configuration: Configuration Menu
• Temperature Display - Displays temperature in degrees Celsius.
• Alarm Indicator - Light pulses on/off during an alarm condition of the
cabinet.
• Mute - Silences the audible alarm.
• Low Battery - indicates a low battery condition of the freezer battery.
• Hot Condenser - indicates a hot condenser condition.
• Message Center - displays system status and alarms.
• Scroll for Parameters Arrows - moves the operator through the choices
of the selected mode.
• Up and Down Arrows - Increases or decreases values, toggles between
choices.
• Enter - Stores the value into memory.
Control Panel Keys,
Displays & Indicators
Mode Temperature Display
Alarm
Indicator
Mute
Low
Battery
Hot
Condenser
Message
Center Scroll for Parameters
Arrows
Up and Down
Arrows
Enter
Figure 1-6. Control Panel

The Model 5600 Series freezer has four basic modes which allow freezer
setup: Run, Settings, Calibrate and Configuration.
Run is the default mode for the freezer during normal operation.
Settings is used to enter system set points for freezer operation.
Calibrate is used to calibrate various system parameters.
Configuration allows for custom setup of various options.
The chart below shows the selections under each of the modes.
Scroll for Parameters Arrows: Steps the operator through the parameters
of SETTINGS, CALIBRATE and CONFIGURATION Modes. The right
arrow goes to the next parameter, the left arrow returns to the previous
parameter.
Up Arrow: Increases or toggles the parameter value that has been selected
in the SETTINGS, CALIBRATE, and CONFIGURATION Modes.
Enter: Must press Enter key to save to memory any changed values.
Down Arrow: Decreases or toggles the parameter values that have been
selected in the SETTINGS, CALIBRATE and CONFIGURATION
Modes.
Mute Key: Press to silence the audible alarm. See Section 4 for alarm
ringback times.
1-4 Model 5600 Series VWR International
Section 1
Installation and Start-Up
Keypad Operation
Run Settings Calibrate Configuration
Default Mode
SYSTEM OK Control Set Point Control Probe High Alarm Test
LINE VOLTAGE High Alarm Set Point Optional Sample Probe Low Alarm Test
COMPENSATED
VOLTAGE Low Alarm Set Point System Battery Test
HSHX
TEMPERATURE
Optional Back Up
System SetPoint BUS Battery Test
Display Temperature
Clear High Stage Alarm
Set Access Code
RS485 Address
BUS type CO2 or LN2

Message Center: Displays the system status (Mode) at all times. Displays
SYSTEM OK during normal operation, or alarm messages if the system
detects an alarm condition. See Alarms, Section 4.
Caution If tipped more than 45°, allow the unit to set upright for 24 hours
before start up. s
To remove the freezer from the pallet, use the 7/16" wrench to remove all
the bolts securing the shipping bracket to the pallet.
Remove the shipping bracket. Remove the ramp boards from the pallet
and place the slotted end over the ramp brackets on the pallet. The
support blocks on the ramps will be facing down. Before moving the
freezer, make sure the casters are unlocked and moving freely. Align the
caster with the ramp boards. Use adequate personnel to roll the freezer off
the pallet.
The freezer can be easily pushed to the desired approved location,
described below. If necessary, the doors and lower front panel may be
opened to move the unit through tight openings. When the freezer is in
position, set the front caster brakes.
Caution The freezer must not be moved with the product load inside. s
Locate the freezer on a firm, level surface in an area with an ambient
temperature between 18°C and 32°C. Provide ample room to reach the
mains disconnect switch (power switch) located on the rear of the freezer.
Caution For proper ventilation and airflow, a minimum clearance of 5” at
the rear and top, and a clearance of 8” on the side of the freezer is
required. Allow adequate space in front of the freezer for door opening. s
Model 5600 Series 1-5VWR International
Section 1
Installation and Start-Up
Displays
Install the Freezer
Choose the Location

The parts bag, located inside the cabinet, contains the following parts.
Install the bolts into the pre-tapped holes on the back of the compressor
section. Install a neoprene cap on each bolt. Refer to Figure 1-2 for the
location of the pre-tapped holes.
Install the shelf clips into the shelf pilasters (front and back) at the desired
shelf level. Install the shelves in the cabinet onto the clips.
Note On units having the optional 5 inner door option, refer to the
instructions accompanying the inner door kit. s
The Model 5600 Series freezer has a data communications interface. The
factory default setting is RS-232.
The wiring identification for the interface is shown in Figure 1-7. One
nine pin, sub "D" style connector is located on the back of the freezer. See
Figure 1-2 for the location of the connector on the freezer.
The freezer transmits temperature information every 60 minutes. A
standard DB9 serial extension cable can be used to connect the freezer to a
serial device. Some serial devices may require a null modem adapter.
Data format:
Baud . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1200
Data bits . . . . . .8 (7 bit ASCII with leading zero)
Start bits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Stop bits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Parity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .none
1-6 Model 5600 Series VWR International
Section 1
Installation and Start-Up
Install the Wall Bumpers
Quantity Stock # Description Purpose
2510016 1/4-20x5-1/2” Bolt Wall Bumper
2380520 Neoprene Cap Cap Protector
Install the Shelves
RS-232 Communications
Figure 1-7. Wiring Identification

The data transfer sequence is transmitted in the following format. X refers
to numerical temperature data.
(NUL) (-) XXX (SP) C (SP) (OVERTEMP) (SP) (LF) (CR) (EOT) (SP)
(UNDER TEMP)
The words "OVER TEMP" or "UNDER TEMP" are transmitted when
an alarm condition exists along with the temperature. If no alarm
condition exists, spaces will be sent. A total of 20 characters will be sent.
SP - Space LF - Line feed
CR - Carriage return EOT - End of text (4)
NUL - Null character (00)
The Model 5600 Series freezer has remote alarm contacts and analog
output. See Figure 1-2 for the location of the remote alarm contacts. The
remote alarm connector is located in the parts bag provided with the
manual. It must be installed if connecting the freezer to an alarm system.
After installing the wiring from the alarm system to the connector, install
the connector to the freezer microboard and secure with the two screws
provided. The remote alarm provides a NO (normally open) output, a NC
(normally closed) output and COM (common). The contacts will trip on a
power outage, high temperature alarm or low temperature alarm. Figure 1-
8 shows the remote contacts in alarm state.
The analog output function allows the freezer to output signals
representing the temperature of the freezer cabinet. The factory default
setting is 4-20 mA. Refer to Figure 1-9 for output specifications.
Model 5600 Series 1-7VWR International
Section 1
Installation and Start-Up
RS-232 Communications
(continued)
Remote Alarm Contacts
and Analog Output
4-20 mA 0-1V 0-5V
Temperature -100 to +50°C -100 to +50°C -100 to +50°C
Figure 1-8. Remote Alarm Contact Pins
Figure 1-9. Specifications
IMPORTANT USER INFORMATION
IMPORTANT USER INFORMATION
Caution! Stored product should be protected
by a redundant 24 hour/day monitoring
system with alarm capability. An interconnect
jack and thermocouple are installed
for centralized monitoring should on-board
system fail.

Insert the power cord into the power inlet module. Place the retaining
bracket (P/N 195763) over the connector. Tighten retaining screws to
secure.
Caution See the serial tag on the side of the unit for electrical specifications
or refer to the electrical schematics in this manual. s
The freezer should be operated on a dedicated grounded service. Check the
voltage rating on the serial tag of the unit and compare it with the outlet
voltage. Then, with the power switch turned off, plug the line cord into
the wall outlet.
First turn on the freezer power switch. Then open the lower front door by
grasping the bottom left corner. Locate the battery switch (Figure 1-5) and
turn it to Standby mode ( ). During initial freezer start-up, the system
battery may require charging and the Low Battery message may appear in
message center.
Caution Ensure the battery switch is turned to Standby mode ( ). The
rechargeable batteries require 36 hours to charge at initial start-up. A “Low
Battery” alarm may occur until the batteries are fully charged. Should a
power failure occur during the initial start-up period, the electronics will
have limited operation. s
1-8 Model 5600 Series VWR International
Section 1
Installation and Start-Up
Attach the Power Cord
Connect Unit to Electrical
Power
Figure 1-10. Power Cord Connection

With the freezer properly installed and connected to power, system
setpoints can be entered. The following setpoints can be entered in
Settings mode: Control temperature, high temperature alarm setpoint, low
temperature alarm setpoint, and (optional) BUS setpoint. Default settings
are shown in the table below.
Caution If the setpoint is changed and the low temperature and high
temperature alarms are set 10° from the set point, the alarm setpoints will
be adjusted automatically to maintain a distance of at least 10° from
setpoint. s
All Model 5600 Series freezers have an operating temperature range of
-50°C to -86°C, depending on ambient temperature. The freezer is shipped
from the factory with a temperature set point of -80°C. To change the
operating temperature setpoint:
1. Press the Mode key until the Settings indicator lights.
2. Press the right arrow until “SET PT = -XX” is displayed in the message
center.
3. Press the up/down arrow key until the desired temperature set point is
displayed.
4. Press Enter to save the set point.
5. Press the Mode key until the Run indicator lights for Run mode or
press the right/left arrow keys to go to next/previous parameter.
If no control keys are pressed, the freezer will automatically return to RUN
mode after 5 minutes.
Model 5600 Series 1-9VWR International
Section 1
Installation and Start-Up
Set the Operating
Temperature
Freezer Start-Up
Control Set Point -80°C
High Temperature Alarm -70°C
Low Temperature Alarm -90°C
Optional BUS Set Point -60°C

The high temperature alarm will activate an audible/visual warning when
the freezer chamber temperature has reached or exceeded the high
temperature alarm set point. To set the high temperature alarm set point:
1. Press the Mode key until the Set indicator lights.
2. Press the right arrow until “HI ALM = -XX” is displayed in the
message center.
3. Press the up or down arrow key until the desired high temperature
alarm set point is displayed.
4. Press Enter to save the setting.
5. Press the Mode key until the Run indicator lights or press the right or
left arrow to go to the next or previous parameter.
If no control keys are pressed, the freezer will automatically return to RUN
mode after 5 minutes.
Caution The high alarm set point must be set at least 5°C from the
control set point. At initial start-up, the high temperature alarm is disabled
until the cabinet reaches set point, or 12 hours elapse. s
The low temperature alarm will activate an audible/visual warning when
the freezer chamber temperature has reached or decreased below the low
temperature alarm set point. To set the low temperature alarm set point:
1. Press the Mode key until the Settings indicator lights.
2. Press the right arrow until “LO ALM = -XX” is displayed in the
message center.
3. Press the up or down arrow key until the desired low temperature
alarm set point is displayed.
4. Press Enter to save the setting.
5. Press the Mode key until the Run indicator lights or press the right or
left arrow to go to the next or previous parameter.
If no control keys are pressed, the freezer will automatically return to RUN
mode after 5 minutes.
Note The low alarm set point must be set at least 5°C from the control set
point. s
1-10 Model 5600 Series VWR International
Section 1
Installation and Start-Up
Set the High Temperature
Alarm
Set the Low Temperature
Alarm

An access code of 000 is required to access the Settings, Calibrate or
Configuration modes. If the access code is not set at the default ‘000’, a
code must be entered to leave RUN mode. See Section 3 for instructions
on modifying the access code.
Run is the default mode for the freezer. The run mode will display the
cabinet temperature on the temperature display and ‘SYSTEM OK’ on the
message center under normal operating conditions. In addition, this mode
allows display of the following information:
LINE VOLTAGE
COMPENSATED VOLTAGE
HSHX TEMPERATURE (heat exchanger temperature)
This information is scrolled individually by pressing the right arrow key. In
each case, the message center returns to SYSTEM OK in 10 seconds if no
keys are pressed.
Model 5600 Series 1-11VWR International
Section 1
Installation and Start-Up
Access Code
Run Mode

1-12 Model 5600 Series VWR International
Section 1
Installation and Start-Up

Model 5600 Series 2-1VWR International
Section 2 Calibrate
Once the freezer has stabilized, the control or sample probe may need to be
calibrated. Calibration frequency is dependent on use, ambient conditions
and accuracy required. A good laboratory practice would require at least an
annual calibration check. On new installations, all parameters should be
checked after the stabilization period.
Caution Before making any calibration or adjustments to the unit, it is
imperative that all reference instruments be properly calibrated. s
Plug a type T thermocouple reader into the receptacle located inside the
lower door (see Figure 1-5). Compare the control temperature set point to
the temperature of the measuring device. See Chart 2-1 at the end of this
section for more detail.
1. Press the Mode key until the Calibrate indicator lights.
2. Press the right arrow until “CONT T = -XX.X” appears in the message
center.
3. Press up/down arrow to match the display to calibrated instrument.
4. Press Enter to store calibration.
5. Press the Mode key to return to Run or the right/left arrow to go to
next/previous parameter.
Calibrate the Control
Probe
