Passport 10G / 20G Headsets
 Compatible with GN Netcom® and VXI
Passport G-series amplifiers and direct
connect cords. Note: Headset connects to the
quick disconnect on the amplifier’s headset cord.
 Noise-canceling microphone greatly
reduces background noise for a professional
sounding call
 Durable construction to endure the stress of
the 24/7 call center
 Virtually indestructible, highly flexible
gooseneck boom. Rotates for left or right ear
placement. Maintains position for consistent
voice quality
 Sturdy quick disconnect allows fast and easy
detachment from lower cord for greater
mobility
 Adjustable headband secures positional
adjustment, won't slide out of position
 Concave ear cushion for greater comfort
and improved sound
PASSPORT
™
warranty
2YEAR Unconditional
WARRANTY
RECEIVE SPECIFICATIONS
Speaker: Dynamic; 36mm diameter
SPL: 90db @ 1kHz,0.55V input
Impedance: 300 Ohms
Frequency response: 200Hz to 5 kHz
Rated input: 10mW continuous, 100mW peak
TRANSMIT SPECIFICATIONS
Microphone: Noise canceling electret
Ambient noise suppression: 13db @
1kHz, typical
Output impedance: 1.8k Ohms typical
Sensitivity: -44dB @ 1kHz (defined 1" from
talk-side, 82dB SPL)
Frequency response: 20Hz to 15 kHz.
Operating Current: 320 mA max.
Operating Voltage: DC 1.0V min. to 20V max.
MECHANICAL SPECIFICATIONS
Cables: Standard wire, PVC insulation,
polyurethane jacket
Connectors: Gold-plated; quick disconnect
Microphone boom: Flexible with positioning
memory; swivels 300 degrees; left or right ear
placement
Headband: Nylon plastic and #316 stainless;
Passport 10G
Passport 20G
