WAGNER C575 User manual

Concrete
Moisture Meter
Instruction Manual
for Wagner Model C575
1-800-944-7078

Table of Contents:
Features Page 2-3
Meter Storage & Operation Page 4
Taking Readings Page 4-5
Interpreting Readings Page 5-6
Questions & Answers Page 6-7
Meter Specications Page 7
Repair Service Page 8
Warranty Page 9-10
FCC Compliance Statement Page 11
C575 Features:
Your Wagner Electronics hand-held concrete meter
was designed using electromagnetic wave technology, to
make fast assessment of concrete slab dying patterns
easy and inexpensive. Large areas can be surveyed
quickly and easily. Wagner Electronics meters are
nondestructive; they do not require drilling or driving
pins into the concrete. They deliver information to
the user instantly.
The C575 is designed to give an average moisture
indication of everything within a specic area and
depth penetration. However, readings from concrete
moisture meters should NEVER be used to determine
if a concrete slab is dry enough to install a oor
covering. Electronics inside the C575 converts the
signal reading, which will appear on the analog dial.
This unit requires a 9-volt alkaline battery, which is
supplied. Replace battery when “Low Battery” light
comes on. Calibration of the meter can be checked
by placing the meter on a at, clean, metal surface at
least 1/8 inch (3.2 mm) thick, such as a car or truck
hood or a le cabinet. Press hand meter sensor rmly
on surface, the reading should be 18 plus or minus 1.
The C575 is a rugged instrument, which will give
many years of service if used with care and properly
maintained. Clean the meter case with a soft rag
lightly moistened with water. Do not subject the unit
to temperatures in excess of 125 degrees F (52°C).
Always store in a cool dry place.
Note that the meter sensor is covered with a self-
adhesive replaceable Teon abrasion pad. Replace
Teon pad when worn through to sensor, or when
edges or corners loosen. Do not use the meter with
debris under a loosened edge or corner.
Replacement Teon pads are available from your
distributor or by calling Wagner Electronics
Customer Service [phone].
Other important features include:
Provides fast readings•
Quickly survey concrete surface areas•
The choice of professionals•
Scans• 1½ in. x2½ in. x¾ in. (3.81 cm x6.35 cm x1.91 cm)
Pocket size, easy to read analog meter•
Battery, case, instructions included•
One touch operation, shuts off in one minute•
Designed for continuous use•
One-Year Warranty•
23

also recommended that you take a number of tests
close to one another and use the highest reading.
Moisture readings in concrete may be affected by5.
the following factors:
The type of aggregate used in the mix may•
contain iron or other metals. This could cause
the reading to be high or read the same value no
matter where you place the meter.
A rebar or metal screen too close to the surface•
will cause a high reading. Move the meter to
several areas for more comparisons.
Interpreting the Reading:
Readings are relative and are useful for comparing
moisture levels in various locations of a concrete
slab and to determine where to place additional tests
using ASTM F2170. Place additional tests in locations
where the C575 reads the highest. It is strongly
advised that ASTM F2170 relative humidity testing
methods be used to determine if the oor is ready for
the oor covering. Do not use the C575 to determine
if the concrete slab is ready for a oor covering.
This meter is designed to provide information as to
where the wettest parts of a slab are so further testing
can be done in those areas. The meter does not measure
vapor pressure (the water that leaves during the curing
stage) in the concrete or the pounds of water per
square foot, etc. The information provided by meter
Meter Storage:
For a long service life, it is important to store your
meter properly. Avoid excessively hot or cold locations,
and keep the meter in the case provided. Do not store
the meter in an area with excessive electro-magnetic
interference, such as near an electric motor, or where
it could be crushed, such as in front of a forklift.
To Operate:
Press and release the ON button. Take readings by
pressing the bottom of the meter to the concrete
surface. The meter will automatically shut off after
60 seconds of inactivity. The shutdown timer will
reset anytime the meter reading changes or the ON
button has been pressed.
Taking a Reading:
The surface of the concrete should be brushed1.
clean of loose debris and dust.
Turn on the meter and verify the2.
“Low Battery” light does not
illuminate.
Place the sensor of the meter on the3.
area of the concrete to be tested.
Press down rmly, making sure the
sensor rests at against the concrete.
On a rough surface take a number of readings4.
close to one another. If the readings vary, use the
highest reading. On a normal smooth surface it is
45

readings is affected by a number of variables so the
readings must be considered relative on a slab by
slab basis. Use the meter to determine the best loca-
tions for placement of the manufacturer’s suggested
test. Further testing methods such as relative humidity
testing should always be used to determine if the
concrete is ready for the oor covering installation.
Questions & Answers:
#1 Wagner Electronics Technology
Q: I’m nervous about buying a new technology.
How long has Wagner Electronics been designing
and manufacturing this type of moisture meter?
A: Since 1966, Wagner Electronics has been providing
quality moisture measurement equipment.
#2 Surface Moisture
Q: Is my Wagner Electronics moisture meter
affected by surface moisture?
A: Most moisture meters can be affected by standing
water or visible water on the materials you are
measuring. You should always wipe off as much
excess water as possible.
67
Interpreting the Reading: Cont’d #3 Meter Ruggedness
Q: How rugged is my C575 moisture meter?
A: Your C575 meter is designed for compact
convenience. It can be damaged by being
dropped or slammed down on concrete or other
hard surfaces, as can any meter.
#4 Meter Safety
Q: Is the Wagner Electronics’ technology safe to use?
A: The emissions from Wagner Electronics’
electromagnetic wave technology are as safe as
the emissions from a standard cell phone.
C575 Meter Specications:
Size:
Length: 4 916 inches (11.59 cm)
Width: 2 ¾ inches (6.99 cm)
Height: 1 916 inches (3.97 cm)
Scanning Area:
Length: 2 ½ inches (6.35 cm)
Width: 1 ½ inches (3.81 cm)
Scanning Depth: ¾ inches (1.91 cm)
Power: 9 volt Alkaline battery
Auto Power Shutdown: 60 seconds
Measurement Range: 0 – 20

8 9
TECHNICAL SERVICES
In the event of damage or failure, download the
C575 repair form at www.wagnerrepair.com. Once
you have completed the repair form, please package
the form with the meter and ship to Wagner Electron-
ics as indicated below. When you send your meter,
be sure it is insured. We cannot be responsible for
items that do not reach us.
The Technical Services Department is available dur-
ing normal business hours—7:30 a.m. to 4:00 p.m.
Pacic Standard Time, Monday through Friday.
Voice: [phone]
Fax: [phone]
E-Mail: [email protected]
Mail: Technical Services Department -Repair
Wagner Electronics
326 Pine Grove Road
Rogue River, Oregon 97537 USA
Repair Service: Wagner Electronics Limited Warranty
Wagner Electronic Products, Inc. warrants this product
against defects in material and workmanship for one (1)
year from the date of purchase, subject to the following
terms and conditions:
Wagner’s liability under this warranty shall be limited,
at Wagner’s option, to the repair or replacement of this
product or any part thereof, which is demonstrated to
be defective. To exercise this warranty, the customer
must telephone for a repair form or download it from
www.wagnerrepair.com and follow factory instructions
for shipment. This limited warranty does not apply if
the product has been damaged by accident, negligent
handling, misuse, alteration, damage during shipment,
or improper service. Wagner Electronic Products, Inc.,
shall in no event be liable for any breach of warranty
or defect in this product, which exceeds the amount
of purchase price of the product. Wagner Electronic
Products, Inc., shall not be liable for incidental or
consequential damages for the breach of any express or
implied warranty with respect to this product or its
calibration.
With proper care and maintenance, the meter should
stay in calibration; however, because Wagner Elec-
tronic Products, Inc., has no control over the manner in
which the unit will be used, it makes no warranty that
the meter will stay in calibration for any specic period
of time. Wagner Electronic Products, Inc., recommends
returning the unit to the factory for a diagnostic checkup
and recalibration in the event the meter is dropped or

11
10
Warranty: cont’d.
otherwise damaged, or the meter accuracy is suspect.
This warranty is in lieu of all other warranties, whether
oral or written, express or implied. Any implied war-
ranties, including implied warranties of merchantability
and tness for a particular purpose, are excluded. If
this product is not in good working order as warranted
above, the customer’s sole remedy shall be repair or
replacement as provided above. Wagner Electronic
Products, Inc. shall not be liable for incidental or con-
sequential damages for the breach of any express or
implied warranty with respect to this product.
This warranty is personal to the customer purchasing
the product from Wagner Electronic Products, Inc. and
is not transferable. This warranty also gives you specic
legal rights, and you may also have other rights, which
may vary, from state to state.
The agents and employees of Wagner Electronic
Products, Inc. are not authorized to make modica-
tions of this warranty or additional warranties binding
on Wagner Electronic Products, Inc. Accordingly,
additional statements, whether oral or written, except
written statements from an ofcer of Wagner Electronic
Products, Inc. do not constitute warranties and should
not be relied upon by the customer.
Wagner Electronic Products, Inc. shall in no event
be liable for any breach of warranty or defect in this
product, which exceeds the amount of the purchase
price of the product.
FCC Compliance Statement
This equipment has been tested and found to comply within the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in residential
installations. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause interference to radio or television equipment reception,
which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.•
Move the equipment away from the receiver•
Plug the equipment into an outlet on a circuit different from that to which•
the receiver is powered.
If necessary, the user should consult the dealer or an experienced radio/•
television technician for additional suggestions.
CAUTION: Only equipment certied to comply with Class B (computer input/
output devices, terminals, printers, etc.) should be attached to this equipment.
Finally, any changes or modications to the equipment by the user not expressly
approved by the grantee or manufacture could void the user’s authority to operate
such equipment. This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Canadian Department of Communications compliance statement
This equipment does not exceed class B limits per radio noise emissions for digital
apparatus, set out in the Radio Interference Regulation of the Canadian Department of
communications. Operation in a residential area may cause unacceptable interference
to radio and TV reception, requiring the owner or operator to take whatever steps
are necessary to correct the interference.
Avis de conformité aux normes du ministère des Communications du Canada
Cet équipement ne dépasse pas les limites de Classe B d’émission de bruits radioé-
lectriques pour les appareils numériques, telles que prescrites par le Réglement sur
le brouillage radioélectrique établi par le ministère des Communications du Canada.
L’exploitation faite en milieu résidentiel peut entrainer le brouillage des réceptions
radio et télé, ce qui obligerait le propriétaire ou l’opérateur à prendre les dispositions
nécessaires pour en éliminer les causes.

Wagner Electronics
326 Pine Grove Road, Rogue River, OR 97537 USA
Phone: [phone] Fax: [phone]
E-mail: [email protected]
Visit us on the Web at:
www.wagnermeters.com
© 2009 WEPI Wagner Part No:500-57501-001 Rev. D
