WAGNER Datamaster User manual

Quick Start Guide
Package Contents
1 DataMaster™ handheld unit
1 Bluetooth®Reader
1 USB power cable
1 SD memory card (installed)
DataMaster™ Quick Start Guide
DataMaster™ manual
Initial Battery Charge
Your DataMaster™ unit will require an initial charge to have
a fully operable battery capacity. To charge the DataMas-
ter™, connect the included USB power cable to the micro
port at the base of the unit and then to a computer USB port
or AC USB adaptor (not included) for use of a conventional
outlet. Allow 2-3 hours for the initial charge.
1Set Date and Time – Power on the DataMaster™ and
from the Main Menu, choose “Settings.” Select “Date/
Time” and set month, day, year, hour, minute and sec-
ond by touching the appropriate box and using the up
or down arrows at the bottom of the screen to select
the correct number. Select “OK” or the return arrow to
return to the “Settings” menu.
2Set Units – From the “Settings” menu, select “Units”.
Select “Fahrenheit” or “Celsius” according to require-
ments, as well as “Inches” or “Millimeters.”
3Set Backlight and Sound – From the “Settings” menu,
select “Backlight & Sound.” The Backlight level can
be modied by sliding the control tab to the desired
setting. Sound can be chosen as “Sound On” (default
setting) or “Sound Off.”
4Set Graph Scales – This optional setting lets you
view measurements in graphical display on the Data-
Master™. From the “Settings” menu, select “Graph
Scales.” From the Graph Scales screen you can set
the Minimum and Maximum RH and Temp values for
scaling purposes. A “Target RH” can also be set as
a reference.

Quick Start Guide
Taking Readings (Measurements)
Note: An SD memory card MUST be installed in order for the
DataMaster™ to take a reading with the Bluetooth® Reader. If
using a lockable SD card, the card must be unlocked to receive
the reading.
1Add a Job – From the “Tools” menu, select “Add Job.”
Job names must be a maximum of 8 alpha-numeric
characters. Once job name is entered, select “OK” to
add to job list. Multiple job names can be added at any
time. The job list can be reviewed at any time by select-
ing “View” from the main menu.
2Begin Taking Readings – Go to an already installed
Smart Sensor. Firmly insert the Bluetooth® Reader into
the Smart Sensor, holding it in place for approximately 3
seconds, then remove. After no more than 5 seconds,
the READING ACQUIRED display should appear on the
DataMaster™, if not, reinsert the Reader. The screen
will dismiss itself after approximately 3 seconds. If this
is the very rst reading for this sensor, you will be taken
to the “Select a Job” screen where you will assign this
sensor to the appropriate job from the job list. The rst
reading at a new site may take 3 to 7 seconds to initiaite
the rst connection. Once connected (indicated by the
BlueTooth icon in the title bar) all subsequent readings
should take only 1 to 2 seconds. Readings from that
sensor will be recorded in the assigned job le. Sensors
are non-transferrable between jobs, once assigned.
3Enter Sensor Information - When the DataMaster™ ac-
quires each initial sensor reading, touch the “Informa-
tion” button (“i” in a circle) on the bottom right corner
of the screen. On the “Sensor Info” screen, enter the
sensor location (Loc:) and the Hole Depth, which are
mandatory for correct reporting according to the ASTM
F2170 reporting protocol. Floor, Slab and Slab thickness
are optional, but may be used to provide additional in-
formation if desired. Once a sensor has been assigned
to a specic Job, subsequent readings from that sen-
sor will automatically be stored under that Job. Job site
data can be viewed on the “Graph” menu of the Data-
Master™, or by selecting individual sensors from the job
listing. Each reading will record the current slab internal
RH and Temperature, sensor serial number, sample (i.e.
2 of 3), date, time, dew point (DP) and ambient RH and
temperature.

Quick Start Guide
Taking Readings (Continued)
4Job site data can be viewed on the “Graph” menu of
the DataMaster™, or by selecting individual sensors
from the job listing. Each reading will record the current
slab internal RH and Temperature, sensor serial num-
ber, sample (i.e. 2 of 3), date, time, dew point (DP) and
ambient RH and temperature.
For more complete information on viewing and using your
Rapid RH®DataMaster™, consult your user manual, or
contact us at www.rapidrh.com.
DataMaster™Layout
Front Back
A. Touch screen D. SD card slot (on side)
B. USB port (on bottom) E. Ambient RH/Temp sensor
C. On/Wake-Up button (on top) F. Hard reset hole
