Walker Edison DW44JUN User manual

P.1
furniture company
Item # : DW44JUN
Assembly Instructions
Revised 06/2017
Please visit our website for the most current instructions, assembly tips, report damage,
or request parts. www.walkeredison.com
Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved.

P.2
General Assembly Guidelines
I. Ensure that all parts and hardware are available before beginning assembly.
II. Follow each step carefully to ensure the proper assembly of this product.
21
III. Two people are recommended for ease in the assembly of this product.
IV. The three main types of hardware used to assemble this product are : wood
dowels , screws and bolts.
V. The provided glue is to secure wood dowels in place . When first inserting dowels ,
locate the appropriate hole for the dowel , place a small amount of glue in the hole
and insert the dowel . Wipe away excess glue immediately.
In future assembly steps when dowels are necessary to attach assembly parts
together , place a small amount of glue on the end of the dowel before attaching
parts together . Wipe away excess glue immediately.
VI. A Phillips head screwdriver is required for the assembly of this product .
VII. Power tools should not be used to assemble this product .
Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved.

P.3
Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved.
Parts List
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16 12
13
14
15
16

Hardware List
The hardware quantities listed above are required for proper assembly.
Some extra hardware may also have been included.
A
Philips head screwdriver required for assembly
(not included)
P.4
B
C
D
E
F
G
H
J
K
pcs
pcs
pcs
pcs
pcs
pcs
pcs
pcs
L
M
N
P
Q
pcs
pcs
pcs
16 pcs
pcs
pcs
R
S
pcs
T
sets
pcs
4
4
4
pcs
8
16
16
1
8
2
2
8
2
6
8
1
24
2
Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved.
Ø8x30mm
Ø15x11mm
Ø6x35mm
Ø6x50mm
Ø15x9mm
Ø30mm
Handle
Wooden dowel
Cam lock
Cam bolt
Bolt
Cam lock
Sticker
Ø4x22mm Handle Bolt
Screw
Ø3x17mm
Plastic wedge
Ø6x12mm Bolt
Ø6x30mm Bolt
Ø6x60mm Bolt
M 4 Wrench
Screw
Ø4x32mm
Screw
Ø3x12mm
* Note: This piece comes preassembled for
shipping purposes and must be disassembled
to complete the desk assembly.
Drawer slider
Glue tube
U
pcs
8
Washer
Ø6x16mm

Step 2
Step 1
P.5
Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved.
Slider bracket
Slider bracket
Slider arm
Slider arm
T
U
T
TT
T
T
U
T
U
T
T T
T
U
T
3
6
54
U
U
Secure drawer slider arms (U) to side panels (3,4,5,6) with screw (T).
Disassemble drawer slider (U) by sliding the slider arm and slider bracket apart. Depress the
small lever of the slider bracket and carefully pull the two pieces apart. Repeat this process
for both drawer sliders ( U).

Step 4
Step 3
P.6
Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved.
36
4
5
A
AA
A
A
A
A
A
A
A
A
A
A
AA
A
B
B
B
B
B
B
B
B
1
Insert wooden dowel (A) into side panel (3,4,5,6).
Secure cam bolt (B) to top panel (1).

Step 6
Step 5
P.7
Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved.
21 3
1
3
4
5
6
CC
C
C
C
C
C
C
7
3
61
Insert side panel (3,4,5,6) into top panel (1), then insert and secure cam lock (C) to side
panel (3,4,5,6) to lock it.
Slide back panel (7) into grooves.

Step 8
Step 7
P.8
Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved.
3
4
5
6
2
2
E x8
P
D
D
D
D
Use wrench (P) to secure panel (2) to side panel (3,4,5,6) with bolt (E).
Place sticker (D) over holes as per diagram.

Step 10
Step 9
P.9
Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved.
P
P
P
M x6
N x2
L x4
8
9
10
11
9
8
10
2
S x2
S x6
Insert part (11) into side frame (8,9), then use wrench (P) to secure it with bolt (L).
Use wrench (P) to secure part (10) to side frame (8,9) with bolt (N) and washer (S).
Use wrench (P) to secure part (10) and side frame (8,9) to panel (2) with bolt (M) and
washer (S).

Step 12
Step 11
P.10
Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved.
B
B
B
B
12
13
14
15
Q
Q
Q
Q
Secure cam bolt (B) to drawer front panel (12). Repeat for both drawers.
Secure drawer side panel (13,14) to drawer back panel (15) with screw (Q). Repeat for both
drawers.

Step 14
Step 13
P.11
Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved.
21 3
12
16
13
14
13
14
15
F
F
F
F
Slide drawer bottom panel (16) into grooves as per diagram. Repeat for both drawers.
Insert drawer front panel (12) into drawer side panel (13,14), then insert and secure cam
lock (F) to drawer side panel (13,14) to lock it. Repeat for both drawers.

Step 16
Step 15
P.12
Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved.
D
D
12
H
G
Secure handle (G) to drawer front panel (12) with handle bolt (H). Repeat for both drawers.
Place sticker (D) over holes as per diagram. Repeat for both drawers.

Step 18
Step 17
P.13
Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved.
Slider bracket
Slider arm
OR
U
U
U
T
T
T
T
T
T
14
13
Secure drawer slider bralket (U) to drawer side panel (13,14) with screw (T). Repeat for both
drawers.
Press down/up the slider lock on slider bracket, then insert the drawer into slider arm to lock it.
Repeat for both drawers.

Final Assembly
Step 20
Step 19
P.14
Copyright © 2017, by Walker Edison Furniture Co., LLC. All rights reserved.
7
J
K
K
Secure plastic wedge (K) to back panel (7) with screw (J).
