AssemblyInstructions
Item# : BU48RAD3D
Revised 24/05/2019 (E)
Copyright 2019 byWalker Edison Furniture Co., LLC. All rightsreserved.
Please visit our websitefor the most current instructions, assemblytips, report damage,
or request parts. www.walkeredison.com
Walker Edison
TM

P.2
Copyright 2019, by Walker Edison Furniture Co., LLC. All rightsreserved.
General Assembly Guidelines
I.Ensurethatallpartsandhardwareareavailablebeforebeginning assembly.
II.Followeachstepcarefullytoensuretheproperassemblyof thisproduct.
21
III.Twopeoplearerecommendedforeaseintheassemblyof thisproduct.
IV.Thethreemaintypesofhardwareusedtoassemblethisproduct are: wood
dowels,screwsand bolts.
V.Theprovidedglueistosecurewooddowelsinplace.Whenfirstinserting dowels,
locatetheappropriateholeforthedowel,placeasmallamountofglue inthe hole
andinsertthedowel.Wipeawayexcessglue immediately.
Infutureassemblystepswhendowelsarenecessarytoattachassemblyparts
together,placeasmallamountofglueontheendofthedowelbefore attaching
partstogether.Wipeawayexcessglueimmediately.
VI.APhillipsheadscrewdriverisrequiredfortheassemblyof thisproduct.
VII.Powertoolsshouldnotbeusedtoassemblethisproduct.
.Concealedhingesarethree-wayadjustable.
Horizontal
byscrewadjustment In-and-Out
bylooseningthehinge-arm
mountingscreworviacam
adjustment
Vertical
Viaslotsinthemounting
plateorviacamadjustment
Door
Sidepanels Sidepanels Sidepanels
Door Door
VIII.Drillmaybeneededforsecuringproducttowall.

P.3
PartsList
1
Copyright 2019 byWalker Edison Furniture Co., LLC. All rightsreserved.
2
3
7
10
4
5
6
89
11
12
13
14
15
16
16
12
14

A
B
C
D
E
F
G
H
J
K
pcs
pcs
L
M
N
P
16 pcs
Wooden dowel
8x30mm
6x35mm Cambolt 12
6x50mm 4
Bolt
pcs
pcs
pcs
1
Plastic wedge 12
Screw
3x17mm
M4 HexKey
12
HardwareList
The hardware quantities listed above are required for proper assembly.
Someextrahardware may also have been included.
Philipshead screwdriverrequired forassembly
(not included)
P.4
pcs
Camlock
15x11mm 12
pcs
30mm 12
Sticker
pcs
6x12mm 10
Bolt
pcs
4
Handle
Copyright ©2019 byWalker Edison Furniture Co., LLC. All rightsreserved.
pcs
6x25mm 9
Bolt
pcs
12
Shelf support pin
pcs
4x22mm 8
Bolt
Q
R
S
T
U
V
W 1 pc Glue tube
2pcs Screw
2pcs Screw
2pcs Plastic strap
2pcs Nut
4pcs
West hinge
36 pcs
3.5x14mm Screw
2pcs
West hinge

P.5
Copyright 2019byWalker Edison Furniture Co., LLC. All rightsreserved.
Step 1
A
A
A
A
A
A
A
A
C
C
C
C
23
Insert wooden dowel (A) into parts (2,3),using cam bolt (C) secure part (2) with Philips head
screwdriver as per diagram.

P.6
Copyright 2019byWalker Edison Furniture Co., LLC. All rightsreserved.
Step 2
A
A
AA
A
A
AA
C
C
C
CC
C
568
9
Insert wooden dowel (A) into parts (8,9),using cam bolt (C) secure parts (5,6) with Philips head
screwdriver as per diagram.

Step 3
P.7
Copyright 2019byWalker Edison Furniture Co., LLC. All rightsreserved.
21 3
B
B
2
8
Using cam lock (B) secure part (8) to part (2) with Philips head screwdriver as per diagram.

Step 4
P.8
Copyright 2019byWalker Edison Furniture Co., LLC. All rightsreserved.
21 3
B
B
29
Using cam lock (B) secure part (9) to part (2) with Philips head screwdriver as per diagram.

P.9
Copyright 2019byWalker Edison Furniture Co., LLC. All rightsreserved.
Step 5
2
8
9
13
Insert part (13) into parts (2,8,9) as per diagram.

P.10
Copyright 2019byWalker Edison Furniture Co., LLC. All rightsreserved.
Step 6
E
F
3
8
9
Using bolt (E) secure part (3) into parts (8,9) with hex key (F) as per diagram.

P.11
Copyright 2019byWalker Edison Furniture Co., LLC. All rightsreserved.
Step 7
14
14
3
2
Insert part (14) into parts (2,3) as per diagram.

P.12
Copyright 2019byWalker Edison Furniture Co., LLC. All rightsreserved.
Step 8 21 3
B
B
B
B
2
3
5
Using cam lock (B) secure parts (2,3) into part (5) with Philips head screwdriver as per diagram.

P.13
Copyright 2019byWalker Edison Furniture Co., LLC. All rightsreserved.
Step 9
F
G
G
4
5
7
Using bolt (G) secure part (4,7) into part (5) with hex key (F) as per diagram.

P.14
Copyright 2019byWalker Edison Furniture Co., LLC. All rightsreserved.
Step 10 21 3
B
BB
B
FG
G2
3
4
6
7
F
F
G
G
H
10
Using bolt (G) and cam lock (C) secure part (4,7) into parts (2,3,6) ,and using bolt (H) secure
part (7) to part (3) with hex key (F) as per diagram.

P.15
Copyright 2019byWalker Edison Furniture Co., LLC. All rightsreserved.
Step 11
F
H
1
5
6
4
Using bolt (H) secure part (1) to parts (4,5,6) with hex key (F) as per diagram.

P.16
Copyright 2019byWalker Edison Furniture Co., LLC. All rightsreserved.
Step 12
M
N
N
Using screw (M) secure plastic wedge (N) with Philips head screwdriver as per diagram.

P.17
Copyright 2019byWalker Edison Furniture Co., LLC. All rightsreserved.
Step 13
D
DD
D
D
D
D
Put sticker (D) cover the holes as per diagram.

P.18
Copyright 2019byWalker Edison Furniture Co., LLC. All rightsreserved.
Step 14
J
JJ
J
JJ
J
JJ
5
6
8
9
Insert shelf support pin into parts (5,6,8,9) as per diagram.

P.19
Copyright 2019byWalker Edison Furniture Co., LLC. All rightsreserved.
Step 15
11
12
12
Put parts (11,12) as per diagram.

P.20
Copyright 2019byWalker Edison Furniture Co., LLC. All rightsreserved.
Step 16
K
K
K
K
LL
P
P
R
R
15
Using screw (R) secure west hinge (P) to part (15) , using bolt (K) secure part (15) to handle (L)
with Philips head screwdriver as per diagram.
