ARAMARK Manual Page 13 – Revision 10-31-21
SERVICE REQUIREMENTS
WARNING! Read and understand the contents of this manual before attempting to service
Aramark Countertop or Refresh Center. Failure to follow the instructions in this manual
could result in death, serious personal injury, or severe property damage. Only trained and
qualified technicians should attempt to install, maintain, or service Waterlogic Equipment.
1. Visually inspect all electrical and water connections for signs of wear or damage.
DANGER! HIGH VOLTAGE ELECTRICAL HAZARD. Unplug before inspection and service.
2. Waterlogic recommends changing the UV Lamp every 12 months.
NOTE: When replacing the UV Lamp Assembly*, the UV Lamp
wiring harness must also be replaced.
NOTE: The Glow Starter shown to the right may appear blackened
which is normal.
*If the Water Treatment System has an S2 Starter, it is fully interchangeable with the UV
Lamp with Glow Starter.
UV Lamp Assembly with S2 Starter:
Not available as a repair part
S2 Starter
UV Lamp Connectors
UV Lamp Assembly with Glow Starter Part #’s:
4-Watt Bulb 12-2350 (CT-2084)
8-Watt Bulb 10-2350 (CT-2083)
Glow Starter
UV Lamp Connectors
A. Disconnect Lamp Male and Female
Connection Clips from Ballast.
B. Remove the S2 Starter by pulling
upwards.
C. Remove UV Lamp.
D. Install Glow Starter UV Lamp.
E. Connect UV Lamp Male and Female
Connection Clips to Ballast.
Switching from S2 Starter to existing Glow-Starter UV Lamp Assembly Instructions

ARAMARK Manual Page 14 – Revision 10-31-21
WARNING! ULTRAVIOLET RADIATION. Protect your skin and eyes against ultraviolet rays.
Never look directly at an operating UV light. Disconnect before removing UV Lamp.
CAUTION! UV LAMPS ARE HAZARDOUS. Lamps are considered Hazardous Waste and must
be disposed of accordingly. Refer to Product MSDS sheet for details.
3. Clean the quartz sleeve that surrounds the UV lamp with a non-abrasive cloth, descaling solution,
or ultrasonic bath if needed when changing UV lamps.
CAUTION! UV SYSTEM IS FRAGILE. Never handle the UV lamp or Quartz Sleeve with bare
hands. UV Lamp and quartz sleeve must be free of oils and contaminants to ensure proper
operation. Use a soft non-abrasive cloth to clean.
4. Inspect the Quartz Sleeve O-ring for wear or damage and replace as necessary.
5. Ensure there is adequate (minimum of 2”) clearance around the Aramark Countertop or Refresh
Center and clean the condenser grill and compressor fan to provide efficient cooling system
operation.
6. Sanitize the cold tank per instructions in the pre-installation procedures.
7. Clean and sanitize external surfaces of the Aramark Countertop or Refresh Center.Use soap and
water or chemicals that are compatible with ABS plastic and will not damage or degrade the
product surfaces.
8. Remove and clean the Faucet. Replace as needed.
WARNING! SANITIZER MAY CONTAIN HAZARDOUS CHEMICALS. Use of proper personal
protective equipment such as rubber gloves and eye protection is required.

ARAMARK Manual Page 15 – Revision 10-31-21
HOT TANK PRINCIPLES OF OPERATION
All Waterlogic Hot Tanks have a built in Vent or
Expansion Chamber in the top of the tank except for
WL270 (GF) units.
The Vent Chamber allows for expansion of the water
when it is heated.
The chambers are separated by a welded-in tank
baffle.
Water always flows into the bottom of the tank and
out the top to the faucet.
The hot tank outlet tube has a restrictor in its base.
This ensures the reservoir is always full by allowing
more water in than out.
There is a small hole in the side of the tank outlet tube
that allows air and water to pass into the vent
chamber as it is heated.
Water in the vent chamber is suctioned back through
the outlet tube vent hole when water is dispensed.
Expansion of water as it is heated in the reservoir will
push the water out the faucet when the outlet tube
vent hole becomes plugged with debris or scale.
The small Outlet Vent Hole is susceptible to scale build
up and is a key indicator that descaling is required.
It is critical to descale the Hot Tank through the vent
line and outlet line on a regular basis to prevent this
problem.
Descaling through the inlet and/or outlet lines only
will not clean the vent chamber and outlet vent hole
properly.
Vent Outlet
Hot Tank Outlet
To Faucet
Outlet Vent
Hole
Expansion
Chamber
Outlet
Restrictor
Tank Baffle
Heater Element
Hot Tank Inlet

ARAMARK Manual Page 16 – Revision 10-31-21
RESETTING THE HOT TANK OVERLOAD OR HIGH LIMIT SAFETY
1.
Red Heater and Compressor Switch must be in the OFF position
O=OFF
2. Unplug the Power Cord from rear of Aramark Countertop or Refresh Center.
3.
Refresh Center Model: Remove the Lower Front Panel by removing the Phillips Head Screws
underneath the Lower Front Panel.
Counter Top Model: Remove the Side Panel by removing Phillips Head Screws from Side
Panel.
4.
Locate the protective metal box on the rear of the Hot Tank.
As you look through the condenser coils on the rear of the
unit, you will see the Hot Tank located on the right-hand side.
5.
Reach up behind the Hot Tank and take hold of the Protective
Metal Box covering the Thermostat and Overload on the Hot
Tank.
There are nuts that secure the metal box to the Hot Tank.
However, the nuts are loose enough to allow you to remove
the metal box.
If the nuts on the metal box are too tight, loosen the nuts
securing the Hot Tank to the upper base of the unit and lower
the hot tank so you can remove the metal box.
For demonstrative purposes, photos below have lowered the
Hot Tank from the unit.

ARAMARK Manual Page 17 – Revision 10-31-21
6.
Press the reset button
7.
Reattach the metal box by depressing the top flap of the
Metal Box so it snaps back into its original position on the
Hot Tank.
8. Replace Panel on unit using Phillips head screws.
9. Plug in the Power Cord.
10
Make sure the Hot and Cold Tanks are filled with water BEFORE turning on the Red Heater and
Compressor Switch.
Verify the cooler is fully operational before installing it at the customers’ site.

ARAMARK Manual Page 18 – Revision 10-31-21
HOT TANK DESCALING INSTRUCTIONS
The Hot Tank requires removal of mineral deposits (descaling) on a regular basis. Typically
descaling should take place every 6 to 12 months to preserve the long-term health of your unit.
Use non-toxic cleaner such as ScaleKleen, DEZCAL, 20% Citric Acid Solution, or Undiluted Vinegar
Solution to remove mineral deposits as directed by the manufacturer depending upon filtration
and local water conditions.
Descaling is an important process that removes calcium deposits, or scale, that can build up
inside a tank over time. Calcium and scale is non-toxic but left unattended will hinder your
Aramark Countertop or Refresh Center’s performance.
WARNING! PERSONAL PROTECTIVE EQUIPMENT REQUIRED. Always ensure proper
ventilation and use rubber or nitrile gloves and eye protection when using chemicals. Refer to
Material Safety Data Sheet for specific requirements of each product.
CAUTION! STAINLESS STEEL TANK DESCALING.
The Hot Tank is made from stainless steel. Ensure descaling solution is compatible with
stainless and always flush the Aramark Countertop or Refresh Center completely. Dispose in
an environmentally safe manner.
Materials Needed:
•Personal Protective Equipment. Rubber or Nitrile Safety Gloves and Protective Eyewear
•Phillips Screwdriver
•Temperature Gauge
•Water Pitcher or Container to collect water from the faucet
•5-gallon container or drain basin
•Citric Acid Based Cleaner
•¼” Plastic Tubing, at least 4 feet in length, and assorted ¼” quick connect fittings
•Sanitizing Cartridge
•Food Coloring
1. Put descaler per directions and 3 drops of food coloring into the descaling cartridge.
2. Connect descaling cartridge to the inlet water supply and connect to inlet bulkhead fitting on the
back of the Aramark Countertop or Refresh Center. Turn on Water Supply.
3. Select Hot Water and depress the Main Dispensing Button on the Front Control Panel until
descaling solution (colored water) comes out of the faucet. Container and drain basic will be
required to catch water from the faucet.
4. Turn off water supply and remove sanitizing cartridge from inlet water supply. Reconnect water
supply to inlet fitting.

ARAMARK Manual Page 19 – Revision 10-31-21
5. Allow descaling solution to remain in the Hot Tank for 15 minutes (length of time may vary
depending on water conditions).
6. Place a pitcher, catch basin or other container under the faucet of the Aramark Countertop or
Refresh Center.
7. Flush the Hot Tank until water runs clear.
8. Once clear Water dispenses from the faucet the Hot Tank has been descaled. Always ensure the
Aramark Countertop or Refresh Center is performing to the customer’s satisfaction.
WARNING! HOT WATER HAZARD. The Aramark Countertop and Refresh Centers produce
Hot Water up to 86°C (187°F). Water above 52°C (125°F) can cause severe burns or scalding.
Hot water should be dispensed carefully into insulated container to avoid injury.
CAUTION!MUST REPLACE HOT TANK EVERY 3-5 YEARS DEPENDING ON USAGE
The Hot Tank and its controls must be replaced a minimum of every three to five years
depending on usage to ensure efficient and dependable operation.
WARNING! REINSTALL ALL PANELS AND COVERS. Always reinstall all Panels, protective
covers, and fasteners after servicing equipment. Failure to do so could result in severe
personal injury and will void the certifications and warranty of the equipment.

ARAMARK Manual Page 20 – Revision 10-31-21
LG COMPRESSOR UPGRADE
*Parts List in this manual updated to reflect these changes.
New LG Compressor 120V R134A 1/8HP CSB035LJCM with external start/run
capacitor.
New LG Compressor with External Start/Run Capacitor
External Capacitor
New LG CSB035 LJCM
Compressor
Repair/Replacement Parts for are
not interchangeable with
older/other compressors.
Older version of LG compressor is
obsolete and no longer available.
Part # CO-0017-L00-00 LG Compressor 120V CSB035LJCM-PTC Relay
Part # CO-0018-L00-00 LG Compressor 120V CSB035LJCM-Overload Protector
Part # CO-0019-L00-00 LG Compressor 120V CSB035LJCM-Capacitor
New LG CSB035LJCM 120V R134A 1/8HP Compressor Repair Parts

ARAMARK Manual Page 21 – Revision 10-31-21
REPLACEMENT COMPONENTS (CONSUMABLES)
Component
WLCP Part No.
Frequency of Replacement
UV Light, 4 Watts Assembly
Counter Top 12-2350 Every 12 months, or as required CT-2084
UV Light, 8 Watts Assembly
Refresh Center
10-2350
Every 12 months, or as
required CT-2083
Hot Tank 1.6 Liter (.42 Gallons) 87°C (189°F)
Counter Top
12-1406
Replace every 3-5 years
depending on usage HT-3018-A
Hot Tank 1.6 Liter (.42 Gallons) 87°C (189°F)
Refresh Center
12-1405
Replace every 3-5 years
depending on usage HT-3018
Black Quartz Sleeve O-Ring 10-2500
Each time Quartz Sleeve is
replaced CT-2006
GAC Filter - 10" Carbon Activated Inline
Filter - Optional FT-0035
Every 6-months or as required.
Local water conditions will
determine proper filter type
and maintenance schedule.
FT-0035-IL-WLT
Carbon Block - 10" CBC 1 Micron Lead and
Cyst Reduction Inline Filter – Optional FT-0063
Every 6-months or as required.
Local water conditions will
determine proper filter type
and maintenance schedule.
FT-0063-IL-WLT
Sediment Block - 10" Sediment 20 Micron
Inline Filter - Optional FT-0053
Every 6-months or as required.
Local water conditions will
determine proper filter type
and maintenance schedule.
FT-0053-IL-WLT
Replacement parts can be obtained from Waterlogic or an Authorized Waterlogic Dealer.
See Parts Layouts, Drawings, and Lists for additional repair parts.
Hot Tank Service
Hot Tanks (with controls) must be replaced at least every Replace every 3-5 years depending on
usage. Descaling hot tank may be required on a regular basis depending upon filtration and local
water conditions. See Service Section.
NOTE:
At the end of this product’s life, ensure that it is disposed of in an environmentally friendly manner
which is fully compliant with all Federal/State/Local Requirements and Guidelines.

ARAMARK Manual Page 22 – Revision 10-31-21
ARAMARK COUNTERTOP DRAWING AND PARTS LIST
Yellow = Consumables
Green = Recommended
spare parts

ARAMARK Manual Page 23 – Revision 10-31-21
No WLCP Part No. Description Part No Stocked?
Consumables
1 12-2350 4W Lamp Assembly CT-2084 Yes
2 12-1406
Hot Tank 1.6 Liter (.42
Gallons) 87°C (189°F) –
Counter Top
Recommend stocking 2 each
per every 10 units purchased
HT-3018-A Yes
Not
Shown FT-0035
GAC Filter - 10" Carbon
Activated Inline Filter –
Optional
FT-0035-IL-WLT Yes
Not
Shown FT-0063
Carbon Block - 10" CBC 1
Micron Lead and Cyst
Reduction Inline Filter –
Optional
FT-0063-IL-WLT Yes
Not
Shown FT-0053
Sediment Filter - 10"
Sediment 20 Micron Inline
Filter – Optional
FT-0053-IL-WLT Yes
Recommended Spare Parts
2.1 12-1360
Overload with Manual Reset
- 97°C (206°F)
Recommend stocking 2 each
per every 10 units purchased
HT-3012 Yes
2.2 12-1303
Hot Tank Thermostat - 87°C
(189°F)
Recommend stocking 2 each
per every 10 units purchased
HT-3013A Yes
2.3 12-6900
Thermostat and Overload
Metal Cover
Recommend stocking 2 each
per every 10 units purchased
ST-8290 Yes
3 10-2500
Black O-Ring for Quartz
Sleeve
Recommend stocking 1 each
per every 10 units purchased
CT-2006 Yes
4 14-1051
Quartz Sleeve for 4W Lamp
Recommend stocking 1 each
per every 10 units purchased
CT-2026 Yes
5 12-1500
Solenoid Valve 1000 mm
Recommend stocking 2 each
per every 10 units purchased
PU-4016 Yes
5.1 CU-0001
Solenoid Cushion
Recommend stocking 2 each
per every 10 units purchased
CU-0001 Yes

ARAMARK Manual Page 24 – Revision 10-31-21
6 10-3010
UV Lamp Ballast 110V/60Hz
Recommend stocking 2 each
per every 10 units purchased
EL-5006-A CN Yes
7 12-3135
Silicon Button Key Mat
Recommend stocking 5 each
per every 10 units purchased
PL-1239-CN Yes
8 12-8057
Button Label
Recommend stocking 2 each
per every 10 units purchased
LP-7084 Yes
9 12-3140
Drip Tray Grill – Silver
Recommend stocking 4 each
per every 10 units purchased
PL-1242-CN Yes
10 12-3130
Drip Tray - Charcoal with
Aramark Logo
Recommend stocking 4 each
per every 10 units purchased
PL-1237-CN Yes
Not
Shown 10-3048
Faucet Nipple – Blue with
Screen
Recommend stocking 2 each
per every 10 units purchased
PL-1013 Yes
Not
Shown 10-2600
Natural Faucet O-Ring –
Silicon White
Recommend stocking 2 each
per every 10 units purchased
CT-2007 Yes
Not
Shown 01-2076
ScaleKleen
Recommend stocking 2 each
per every 10 units purchased
NA Yes
Remaining Parts
11 12-3145 Flat Top Cover - Charcoal
with Texture PL-1242-B Yes
11.1 NA Metal Cover (Under Top
Cover) ST-0049-L00-00 Yes
12 10-8085 UV Lamp Fixing Rubber CT-2001-B Yes

ARAMARK Manual Page 25 – Revision 10-31-21
13 12-1210 UV Lamp Retaining Threaded
Nut PL-1128 Yes
14 12-3165 Upper Shelf ST-8150 Yes
Not Shown
- on Top
Shelf
12-8510 UV 3minutes Timer PCB - Hot
and Cold AK-0008-A Yes
Not Shown
- on Top
Shelf
NA 3minutes UV Timer PCB
Fixing Bracket ST-8287 No
15 12-3110 2L UV Cold Tank Assembly CT-2060 Yes
16 12-3185 Side Panel – Silver ST-8241 Yes
17 12-3120
Front Upper Drip Tray Insert
Panel – when purchasing,
also request Hot Water
Caution Label KB-11 to
adhere to front of this panel.
PL-1201-CN Yes
17.1 KB-11
Hot Water Caution Label –
adhere to Front Upper Drip
Tray Insert Panel.
NA Yes
18 12-3160 PCB Cover PL-1298 Yes
19 12-3115 PCB for Hot and Cold for
Leak Detection System EN-6085-A Yes
19.1 10-3017 PCB Stand-off Pin EN-6059 Yes

ARAMARK Manual Page 26 – Revision 10-31-21
20 12-3125
Front Hatch Panel Charcoal
with UV logo
Sold Separately:
Button Label (P/N 12-8057) &
Silicon Button Key Mat (P/N 12-
3135)
PL-1236-L00-SI Yes
21 10-2700 Faucet Assembly PL-1011 Yes
Verify compressor in machine before ordering parts as the Compressor P/N CO-0020-L00-00 and
10-2200 (CO-0001A) and related parts are not interchangeable.
CO-0020-L00-00 Compressor
22A.1 CO-0020-L00-00 LG Compressor 120V R134A
CSB035LJCM CO-0020-L00-00 Yes
22A.2 CO-0019-L00-00 Compressor Capacitor CO-0019-L00-00 Yes
22A.3 ST-0216-L00-00 Capacitor Bracket ST-0216-L00-00 Yes
22A.4 CO-0017-L00-00 PTC Relay CO-0017-L00-00 Yes
22A.5 CO-0018-L00-00 Overload Protector CO-0018-L00-00 Yes
CO-9001-A / 10-2200 Compressor
22B.1 10-2200 Compressor (R134a 1/8HP)
120V/60Hz CO-9001-A Yes
22B.2 10-3003 Compressor Starter Relay CO-9016 Yes
22B.3 10-5018 Compressor Overload CO-9015 Yes
23 12-3150 Unit Rubber Feet PL-1251-CN Yes
24 12-3170 Bottom Tray ST-8151 Yes
25 12-3155 Leak Tray PL-1294 Yes

ARAMARK Manual Page 27 – Revision 10-31-21
26 12-3180 Leak Containment Tray Clip
(sensor 0.5mm) ST-8207-CN Yes
26.1 NA Leak Sensor Wire EL-5076-KR No
27 12-3175 Filter Bracket ST-8152 Yes
27.1 10-3099 3” Filter Clip PU-4024 Yes
27.2 10-3098 2” Filter Clip for In-Line Filter PU-4025 Yes
28 12-3195 Leak System Inlet Solenoid
Bracket ST-8244 Yes
29 Purchase from
John Guest
JG Equal Tee Connector ¼”
(P10208S) PU-4011 No
30 Purchase from
John Guest
JG Reducing Elbow
Connector 5/16” * ¼”
(PI211008S)
PU-4007 No
31 Purchase from
John Guest
JG Equal Elbow Connector ¼”
(PI0308S)
PU-4008
No
32 10-3067 Bulkhead Union ¼” x ¼” John
Guest P/N PI1208S PU-4028-A Yes
32.1 Purchase from
John Guest
JG 1/4" Stopper PI0808S
(used with Bulkhead Union ¼” x
¼” John Guest P/N PI1208S)
PU-4086 Yes
33 12-3100 Wire Condenser CO-9031 Special
Order
33.1 12-1001 Filter Dryer CO-9008 Yes

ARAMARK Manual Page 28 – Revision 10-31-21
34 10-4013
Power Line Noise Filter,
ElectroMagnetic Interference
filter (EMI)
EL-5016 Yes
35 10-3014 Fuse Holder and Fuse 120V /
15A with One Wire EL-5053 Yes
35.1 10-3013 Fuse 120V / 15A EL-5010 Yes
36 10-3008 Red Compressor and Heater
Switch EL-5004 Yes
37 12-1101 Cold Tank Thermostat CT-2016 Yes
37.1 PL-0326 Cold Thermostat Cover Label PL-0326-L00-00 Yes
38 12-8061 Silver Back Panel ST-8216 Yes
39 12-3117 Power Transformer 120V EL-5003-A Yes
Not
Shown
Purchase from
John Guest
JG LLD PE Tube - Blue
O.D.1/4"John Guest P/N PE-
08-BI-1000F-B
PU-4031-A No
Not
Shown 10-3062
JG LLDPE Tube - Blue 8mm
John Guest P/N PE-0806-
100M-B
PU-4014-A No
Not
Shown 10-7040 Silicon Tube 5/16” for Hot
Water PU-4064 Yes
Not
Shown 10-3007 Power Cord 120V – 1840 mm EL-5001-B Yes

ARAMARK Manual Page 29 – Revision 10-31-21
ARAMARK REFRESH CENTERS DRAWING AND PARTS LIST
Yellow = Consumables
Green = Recommended
spare parts Wetted Drawing

ARAMARK Manual Page 30 – Revision 10-31-21
No WLCP PN Description Part No
12-RCPC-1
Plastic Top
Cold Only
12-RCP-1
Plastic Top
Hot & Cold
12-RC-1
Stone Top
Hot & Cold
Stocked?
Consumables
1 10-2350
8W UV Lamp
Assembly (includes
UV Lamp Fixing
Silicon Rubber – PN
CT-2001-B)
CT-2083 X X X Yes
2 12-1405
Hot Tank Stainless
Steel 1.6 Liter (87°C -
189°F)
Recommend stocking
2 each per every 10
units ordered
HT-3018 X X Yes
3
FT-0035
GAC Filter - 10"
Carbon Activated
Inline Filter –
Optional
FT-0035-IL-
WLT X X X Yes
FT-0063
Carbon Block - 10"
CBC 1 Micron Lead
and Cyst Reduction
Inline Filter –
Optional
FT-0063-IL-
WLT X X X Yes
FT-0053
Sediment Block - 10"
Sediment 20 Micron
Inline Filter –
Optional
FT-0053-IL-
WLT X X X Yes
Recommended Spare Parts
2.1 12-1360
Overload with
Manual Reset - 97°C
(206°F)
Recommend stocking 2
each per every 10 units
ordered
HT-3012 X X Yes
2.2 12-1303
Hot Tank Thermostat
- (87°C - 189°F)
Recommend stocking 2
each per every 10 units
ordered
HT-3013A X X Yes
2.3 12-6900
Hot Tank
Supplemental Steel
Enclosure
Recommend stocking 2
each per every 10 units
ordered
ST-8291 X X Yes
4 12-3140
Drip Tray Grill
Recommend stocking 2
each per every 10 units
ordered
PL-1242-CN X X X Yes
5 10-2500
Black O-Ring for
Quartz Sleeve
Recommend stocking 2
each per every 10 units
ordered
CT-2006 X X X Yes

ARAMARK Manual Page 31 – Revision 10-31-21
6 10-1400
Quartz Sleeve for 8W
Lamp
Recommend stocking 2
each per every 10 units
ordered
CT-2002 X X X Yes
7 12-3130
Drip Tray Body with
Aramark Logo
Recommend stocking 2
each per every 10 units
ordered
PL-1237-CN X X X Yes
8 12-1500
Solenoid Valve
DC24V 1000mm
Recommend stocking 2
each per every 10 units
ordered
PU-4016 X X X Yes
9 10-3048
Blue Faucet Nipple,
with Stainless Steel
Gauze
Recommend stocking 2
each per every 10 units
ordered
PL-1013 X X X Yes
9.1 10-2600
White Silicon Faucet
O-Ring
Recommend stocking 2
each per every 10 units
ordered
CT-2007 X X X Yes
10
12-8057
Button Label
Hot and Cold
Recommend stocking 2
each per every 10 units
ordered
LP-7084 X X Yes
12-8610
Button Label
Cold Only
Recommend stocking 2
each per every 10 units
ordered
LP-7085 X Yes
11
12-3135
Silicon Button Key
Mat
Hot and Cold
Recommend stocking 2
each per every 10 units
ordered
PL-1239-CN X X Yes
12-8600
Silicon Button Key
Mat
Cold only
Recommend stocking 2
each per every 10 units
ordered
PL-1100 X Yes
Not
Shown 01-2076
ScaleKleen
Recommend stocking 2
each per every 10 units
ordered
NA X X X Yes
Remaining Parts
12 10-2700 Faucet Assembly –
Hot and Cold PL-1011 X X X Yes

ARAMARK Manual Page 32 – Revision 10-31-21
NA Faucet
Cold Only PL-1012 X X X Yes
13 12-3120 Front Panel for Drip
Tray Insert PL-1201-CN X X X Yes
14 12-3160 PCB Cover PL-1298 X X X Yes
15
12-8103 PCB for Hot and Cold EN-6085 X X Yes
12-8615 PCB for Cold Water EN-6086 X Yes
15.1 10-3017 PCB Stand-off Pin EN-6059 X X X Yes
16 12-3125 Front Upper Panel PL-1236-
L00-SI X X X Yes
17 12-3220 Silver Side Panel ST-8192-CN X X X Yes
18 12-8058 Side Panel Plastic
Handle PL-1123 X X X Yes
19
Purchase
from John
Guest
JG ¼” Stopper
PI0808S PU-4086 X X X No
20 10-3067
Bulkhead Union ¼” x
¼” John Guest P/N
PI1208S
PU-4028-A X X X Yes
21 12-3205 Front Lower Panel PL-1202-CN X X X Yes
