WaterLogic ICE 900 User manual

Waterlogic Commercial Products, LLC
11710 Stonegate Circle
Omaha, NE 68164
[phone] www.waterlogic.us
Tech Portal Website: techportal.waterlogic.com
ICE 900
Supplemental
Service
Manual

ICE 900 Supplemental Service Manual Page 2Revision 3-19-2019
ICE 900 SUPPLEMENTAL MANUAL
Congratulations on your choice of the ICE 900. The ICE 900 is a fully programmable self-contained unit
that dispenses ice along with ambient, cold, and hot water. The versatile ICE 900 provides great tasting
ice and water with every use.
INTRODUCTION
This manual is a supplemental to ICE 900 instructions and manuals provided by ChungHo, the
manufacturer of the ICE 900. The Waterlogic ICE 900 is the ChungHo SUPER IGUASSU or ChungHo
IGUASSU ICE 900.
Carefully read and follow all instructions provided by ChungHo and included in this supplement to
ensure proper and efficient operation of your ICE 900.Documents include but are not limited to:
ChungHo SUPER IGUASSU ICE User’s Manual
ChungHo Iguassu ICE 900 Technical Manual
Waterlogic ICE 900 Supplemental Service Manual
Contact Waterlogic if you have any questions or need additional information about the ICE 900.
Waterlogic and Authorized Waterlogic Dealers employ trained servicepersonnel who are experienced
in the installation, function and repair of Waterlogic equipment. This publication is written for use by
these qualified individuals. Waterlogic encourages users to learn about products, however, we believe
that product knowledge and service is best obtained by consulting Waterlogic or an Authorized
Waterlogic Dealer.
Water treatment systems should be combined with selected water treatment components to create a
system specifically tailored for each application by trained and qualified personnel.
Waterlogic reserves the right to change the specifications referred to in this literature at any time,
without prior notice. Changes or modifications not expressly approved by Waterlogic could void the
warranty and user’s authority to operate the equipment.

ICE 900 Supplemental Service Manual Page 3Revision 3-19-2019
TABLE OF CONTENTS
USER GUIDE
•Safety Alert Symbols................................................................ 4
•Safety Precautions................................................................... 4
•Features and Benefits.............................................................. 6
•Model Designations and General Specifications..................... 7
•Electrical and Shipping Specifications..................................... 8
•Operating Instructions............................................................. 9
•Warranty ............................................................................... 10
SERVICE GUIDE
•ICE 900 Principles of Operation............................................. 11
•Display and System Function Settings................................... 12
•LOCK/ICE Functions............................................................... 12
•HOT/ECONO Functions.......................................................... 13
•Sound Function...................................................................... 13
•CONST Function..................................................................... 14
•Error Proofing the Front Display ........................................... 15
•Service Requirements............................................................ 16
•Design changes to PCB and Environmental Sensor............... 17
•Consumables and Spare Parts............................................... 19
•Overview Drawing………………….............................................. 23
•Flow Diagram ………………… .................................................... 24
•Filter Replacement…………………............................................. 25
•Ice Tray Motor and Coupler Replacement…………………......... 27
•Environmental, Cold, and Ice Sensor Replacement…………… 28
•Sensor Tables......................................................................... 31
•Hot Tank Reset ...................................................................... 32
•Electrical Schematic............................................................... 33
INSTALLATION GUIDE
•Pre-Installation...................................................................... 34
•Sanitization............................................................................ 37
•Draining................................................................................. 40
•Installation............................................................................. 42
•Condensate Pump (Drain) Installation.................................. 44
TROUBLESHOOTING GUIDE
•Error Codes............................................................................ 45
•Troubleshooting Tips............................................................. 46
•Ice Sample Pictures ............................................................... 46

ICE 900 Supplemental Service Manual Page 4Revision 3-19-2019
SAFETY ALERT SYMBOLS
Read and follow all safety information carefully. The signal words used in this manual are selected as
shown below and based on an assessment of the degree of potential injury or damage (severe or minor)
and the occurrence of injury (definitely occurs or has the potential to occur) when the warning is
ignored:
DANGER!
Indicates a situation which, when not avoided, results in death or severe injury.
WARNING!
Indicates a situation which, when not avoided, has the potential to result in death or severe
injury; and/or severe property damage.
CAUTION!
Indicates a situation which, when not avoided, results or has the potential to result in injury,
minor property damage or reduced product performance.
SAFETY PRECAUTIONS
Basic safety precautions should be followed, including the following:
Ensure all local, state, and federal laws and codes including health and safety guidelines are met when
installing the ICE 900. Only qualified service technicians should attempt installation and service of the
ICE 900. Always read the entire operating instructions before using the appliance and save these
instructions for future use.
DANGER! ELECTRICAL SHOCK HAZARD. Always unplug from power supply prior to service.
Always use a dedicated and properly grounded outlet that is protected by ground-fault circuit
interrupter (GFCI) or residual current device (RCD) having a rated residual operating current not
exceeding 30mA.
DANGER! ELECTRICAL SHOCK OR FIRE HAZARD. Only use power cord supplied withunit. Never use
extension cords, power strips or usemultiple electrical appliances in one power outlet simultaneously.
Do not use if the power supplycord is damaged. Do not bend the power supply cord excessively or put
heavy objects on the power supply cord.Keep power supply cord in a stable position and avoid heat
sources. Do not touch the power plug with wet hands or when standing in water.
DANGER! ELECTRICAL SHOCK OR FIRE HAZARD. Do not install the ICE 900 in or around largely damp
areas, at a place near flammable materials or at a place exposed to rain, snow, or freezing
temperatures.
WARNING! AUTHORIZED USE ONLY. This appliance is to be used for its intended purpose as
described in this manual, and untrained individuals who use this manual assume the risk of any
resulting property damage or personal injury. This appliance can be used by children from 8 years
and above and persons with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved.

ICE 900 Supplemental Service Manual Page 5Revision 3-19-2019
WARNING! SUPERVISE CHILDREN. Keep appliance and cord out of reach of children under the age of
8 years. Children under the age of 8 years must not use or play with the appliance.
WARNING! DO NOT OPERATE IF DAMAGED OR MALFUNCTIONING.Unplug if abnormal case
occurs. Contact Waterlogic or authorized dealer for repair, service, and installation to avoid hazards.
WARNING! UNIT PRODUCES HOT WATER. Water above 52oC (125oF) can cause severe burns or
scalding. Keep unauthorized people and children awayfrom the unit to avoid accidental dispensing
of hot water. Always use an appropriate heat-resistant container for hot water dispense.
WARNING! CONNECT TO POTABLE WATER SUPPLY. This system is to be used for water only and is
not intended for use where water ismicrobiologically unsafe or with water of unknown quality
without adequate disinfection. System is not intended for treatment of contaminated water.
WARNING! TIP HAZARD. Dispenser could tip or fall causing serious injury. Do not attempt to install
the ICE 900 on a surface on a sloped or unstable position. Never place heavy items on top of unit and
never climb, stand, or hang on unitor storage cabinet to prevent injury and damage. Do not tilt the
ICE 900 over 45° during transportation or installation as this may damage the compressor.
WARNING! UNIT IS HEAVY. TWO PERSON LIFT REQUIRED. Transport unit empty and always use
material handling equipment or two people with proper lifting technique to reduce injury risk.
WARNING! STORE AND TRANSPORT UNIT EMPTY. ALWAYS SANITIZE BEFORE USE.
The unit must be completely drained and sealed before storing to avoid stagnation and reduce
microbiological contamination (potential bacterial growth). Sanitize before use to eliminate any
potential microbiological contaminates
CAUTION! INDOOR USE ONLY. Never expose to direct sunlight, heat sources, or ambient air
temperature above 37°C (100°F) or below 2°C (35°F). Install indoors and keep unit away from
excessive humidity. Never expose to freezing temperatures. Ensure there is 4-inches of clearance
around the unit to allow refrigeration system condenser to dissipate heat. Warmer environments
require more clearancearound the unit. Minimum clearance around all surfaces of the machine is 2-
inches. Installs where the ambienttemperature exceeds 27°C (80°F), require a minimum of 4-inches
clearance for proper heat dissipation and efficient operation. Do not cover or block ventilation holes.
CAUTION! USE A WATER PRESSURE REGULATOR. Waterlogic will not be responsible for injury or
damage caused by excessive water pressure. Input or feed pressure must be 40 psi to 60 psi. Be
aware of any potential pressure surges caused by building/municipal pumping stations. Water block
devices and external leak detectors are stronglyrecommended. Locate the unit as close to the water
supply and the electrical connections as possible to minimize risk.
CAUTION! USE PROPER SUPPLY LINES AND FEED WITH POTABLE AMBIENT WATER ONLY.
Feed water over 37°C (100°F) may damage the treatment components. Always use supply lines with
adequate pressure rating and UV resistance. Close water supply valve and contactservice
representative if a leak is noticed. Contact Waterlogic for assistance or help finding an Authorized
Service Representative.

ICE 900 Supplemental Service Manual Page 6Revision 3-19-2019
ICE 900 FEATURES AND BENEFITS
ICE Making Capacity
22 kg (44 pounds) of ice making per day with a 4 kg (8.8 pound) insulated storage bin.
High Volume Storage and Water Capacity
17 liters (4.5 gallons) of Ambient storage combined with 3.8 liters (1 gallon) Cold and 5.3 liter (1.4
gallon) Hot Tank.
Large Dispense Area
8 inch dispense height for Ice dispense and 8½ inches for water dispense height with full width drip tray.
Reverse Osmosis Filtration
ICE 900 is an innovative hybrid of a reverse osmosis water purification system.
Pure ice production utilizing the freezing point method
Principle that purest water freezes at 0°C (32°F) while non-pure water will freeze ata temperature
below that (Patent application: No.2005-99663, 2005-365293, 200510127096.9, 11/342,117).
Energy Efficient Design
Energy-efficiently designed Super Iguassu Ice delivers purified water to the ice makingunit to make
pure ice while simultaneously sending cooled water to Cold-water tank.
Power Saving function
Light detection sensor activates power save function to turn off Hot and reduce consumption at night.
24 Hour natural water circulation system (N.W.P.W.)
The ICE 900 purification system is designed to allow water to continuously flow for 24 hours within the
water purifier by adopting a natural circulation method. This mode, entitle N.W.P.W., applies the
natural weight of water pressure to always supply clean and fresh water. (Patent: No.105585)
Child Safeguard (Ice Dispensing and Hot Water Locking Function)
Setting the Ice Cube /Hot water locking function using Lock / Hot touch sensor buttons prevents ice
cube and hot water from being dispensed from the unit. The ICE 900 automatically defaults to cold-
water mode when after 5 seconds.
Separate water delivery from a single spout
Ambient, Cold and Hot Water come out from a single spout. Programmable continuous dispense
available in 1 Liter, 1.5 Liter, 4.5L, and 8 Liter dose.
Audible Signals
Programmable audible controls provide user feedback and can be disabled.
Leak Detection
ICE 900 comes standard with a leak detection sensor at the bottom of the unit, which protects unit by
closing water supply valve and alarminguser if a leak is noticed.

ICE 900 Supplemental Service Manual Page 7Revision 3-19-2019
MODEL/PART DESIGNATIONS
BRAND NAME DESCRIPTION MODEL – PART NUMBER
ICE 900 ICE 900 Ambient, Cold, Hot and Ice CHP-5070S
SPECIFICATIONS
ITEM
ICE 900
Water Input Potable Water 39-100°F <300ppm hardness ¼” Quick Connect Input
Cold-water Temperature 3°C (37°F) Thermistor Controlled
Hot Water Temperature 90°C (199°F) Automatic Thermostat with 105°C (221°F) Manual Reset Hi Limit
Service Pressure 7-120 psi Supply – Internal Pressure Reducer
Environmental Temperature
35° - 100°F (2° - 37°C)
Refrigerant Gas R134a – 98 grams (3.46 ounces)
Tank Capacities
Ambient – 16.9 Liters (4.5 Gallons)
Hot – 5.3 Liters (1.4 Gallon)
Cold – 1.8 Liters (1 Gallon)
Ice Storage Bin – 4 Liters (8.8 Pounds)
SPECIFICATIONS
Ice Making Capacity (differ
depending on ambient
temperature)
Ambient Temperature20°C (68°F) Ambient Temperature 30°C (86°F)
Ice Cycle Time 11 +/- 1 minutes per cycle 12 +/- 1 minutes per cycle
Daily Ice Production Capacity 20 Kg (44 pounds) per day 17 Kg (38 pounds) per day
Ice Size 13 Grams +/- 1 gram
Number of Ice Cubes per Cycle
12 cubes per cycle
*may haveone ice cubes thatdrops into the cold water
Ice Storage Bin 4 Liters (8.8 Pounds)

ICE 900 Supplemental Service Manual Page 8Revision 3-19-2019
SHIPPING SPECIFICATIONS
ITEM
Width/Depth/Height of ICE 900 430 x 492 x1490 mm (17” x 19 ½” x 50”)
Weight – Dry (w/o packaging) 53.5 kg (118 pounds)
Shipping Information
(length x width x height) 533 x 584 x 1575 mm (21” x 23” x 62”) 4 units per pallet
Shipping Weight – Dry 59 kg (130 pounds)
ELECTRICAL SPECIFICATIONS
ELECTRICAL SUPPLY
120V/60Hz
15 Amp Service
+
COMPONENT
POWER (approximate)
AMP DRAW (approximate)
Heater 500 Watts 4.16 Amps
Compressor
200 Watts
1.67 Amps
Pump 20 Watts 0.17 Amps
ICE 900 TOTAL
720 Watts
6.00 Amps
POWER CONSUMPTION
110V/60Hz
15 Amp Service
+
POWER (approximate)
AMP DRAW (approximate)
Hot 500 Watts 4.16 Amps
Cold
155 Watts
1.29 Amps
Ice Making 220 Watts 1.16 Amps

ICE 900 Supplemental Service Manual Page 9Revision 3-19-2019
OPERATING INSTRUCTIONS
UCTIONS
Hold water selection touch screen icon for 3 seconds until LED indicated water selection is active.
Hot Water Selection
Cold-water Selection
Ambient Water Selection
HOT COLD AMBI
Touch to select Ice
Dispense
Water Dispensing Button
Push Cup against pad to activate water
dispense
Temperature Selection Buttons

ICE 900 Supplemental Service Manual Page 10 Revision 3-19-2019
CHUNGHO U.S.A. APPLIANCE WARRANTY
ONE YEAR LIMITED WARRANTY
For one year fromthe date of purchase, when thisproduct is operated and maintained according to instructionsattached to
or furnished with theproduct, ChungHo U.S.A. (hereafter “ChungHo”) will pay for replacement parts and repair labor* to
correct defects in materials orworkmanship or replace the product at ourdiscretion. Service must be provided by a
ChungHo designated service company. This warranty doesnot cover the sealed refrigeration system(*repair labor provided
by local area dealer)
FIVE YEAR (EXTENDED) LIMITED WARRANTY ON THE SEALED SYSTEM (OPTIONAL UPON PURCHASE)
For five years fromthe date of purchase, when this product is operated and maintained according to the instructions
attached to or furnished with the product, ChungHo will pay for replacement parts and repair labor* to correct defects in
materials or workmanship in the sealed refrigeration system, including the compressor, evaporator, or replace the product
at our discretion. Service must be provided by a ChungHo designated service company (*repair labor providedby local area
dealer).
ITEMS CHUNGHO WILL NOT PAY FOR
1. Service calls to correct the installation of your product, instruct you how to use your product, to replace house fuses
or reset circuit breakers, replace or clean filters, or to correct house wiring.
2. Service calls to repair or replace water filters. Those consumable parts are excluded from warranty coverage.
3. Repairs when your product is used for other than normal water purification needs.
4. Damage resulting fromaccident, alteration, misuse, abuse, fire, flood, acts of God, improper installation, installation
not in accordance with electrical or plumbing codes, or use of products not approved by ChungHo.
5. Replacement parts or repair labor costs for units operated outside the United States or Canada.
6. Pickup and delivery. This product isdesigned to be repaired at the customer site.
7. Repairs to parts or systems resulting from unauthorized modifications made to the appliance.
8. Expenses for travel and transportation for product service in remote locations.
9. The removal and reinstallation of your appliance it if is installed in an inaccessible location or is not installed in
accordance with published installation instructions.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMERS SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED
HEREIN. IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE,
ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW. CHUNGHO SHALL NOT BE LIABLE FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES. SOME STATES AND PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES OF
MERCHANTAILTY OR FITNESS, SO THESE EXCLUSIONS OR LIMITATIONS MAY NOT APPLY TO YOU. THISWARRANTY GIVES
YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY, FROM STATE TO STATE OR PROVINCE
TO PROVINCE.
Outside the 50 United States and Canada, this warranty does not apply. Contact your authorized ChungHo dealer to
determine if another warranty applies.
If you need service, first see the “Troubleshooting”section of the User’s Manual Guide. After checking “troubleshooting”,
additional help can be found by contacting your local certified ChungHo dealer.
You must provide proof of purchase orinstallation date for in-warranty service. 03/05

ICE 900 Supplemental Service Manual Page 11 Revision 3-19-2019
ICE 900 PRINCIPLES OF OPERATION
The ice making system of the ICE 900 automatically operates according to designed program settings
based upon inputs from the Cold-water, Ice, and Environmental Sensors. You must allow time for water
fill and refrigeration system to cool before the ICE 900 will start to make ice.
1. Ensure the ICE making function is enabled (Red ICE LED should be on as shown:
2. Level of purified water must be at proper operating level. The compressor and heater will turn
on once minimum water level is reached.
3. To produce cold-water, the compressor and circulation pump must operate properly. (The cold-
water production process automatically operates according to designated programming).
Cold-water operation: This refers to an operation that makes cold-water by continuously
circulating and supplying water over the cooling fingers in the ice tray and into the cold-water
reservoir. Water temperature in the cold-water tank is automatically checked by the cold-water
temperature sensor, and if it drops below the set temperature, the cold-water operation will
automatically stop (set point is reached).
4. Cold-water reservoir mustbe cold before the ice making system will start to produce ice.
a. Water supply action: this refers to an action to supply about .25g (1L) of cold-water
every 50 seconds into ice making mechanism to make ice.
b. Ice making action: this refers to the making of ice by way of an ice tray by supplying cold
refrigerant onto the fingers with tray full of water.
c. Harvest action: this refers to an action to separate the ice created in the ice tray by
supplying hot refrigerant into fingers to release the cubes.
5. When the ice storage house if full, the ice detection sensor will automatically stop the ice
making process.
6. If ice in the storage house is not used for long periods of time, Ice may melt, and during ice
dispensing, smaller melted ice cubes can come out.
TDSs (Total DissolvedSolids) of ice may increase depending on environment in which the ice is
created.
Higher temperatures surrounding the machine will result in longer ice making process her
temperatures surrounding the machine will result in longer ice making process
LOCK
ICE

ICE 900 Supplemental Service Manual Page 12 Revision 3-19-2019
CDS
DISPLAY AND SYSTEM FUNCTION SETTINGS
USB Port Auxiliary Charging port for cell phone and other
devices.
Light
Detection
Sensor
When in Power Saving Mode (ECONO LED is Red),
the ICE 900 detects the amount of light
surrounding the machine. The hot water will
automatically be turned off when there is no light
and turned on when there is sufficient light
surrounding the unit.
Ice Storage
Full Indicates when ice storage is full.
Ambient
Water Tank
Full Indicates when ambient water tank is full.
LOCK/ICE FUNCTIONS
The LOCK FUNCTION is a safety function that allows or prevents hot water and ice
from dispensing from the ICE 900.To change LOCK setting, touch and hold the
button for approximately 3 seconds until the LED light indicates the desired setting.
The ICE FUNCTION enables and disables ice making process. To change ICE setting,
touch and hold the button for approximately 10 seconds until the LED light indicates
the desired setting.
LOCK OFF - Hot water and Ice dispense are enabled
ICE OFF - Ice making is disabled
LOCK ON - Hot water and Ice dispense are disabled
ICE OFF - Ice making is disabled
LOCK OFF - Hot water and Ice dispense are enabled
ICE ON - Ice making is enabled
LOCK ON - Hot water and Ice dispense are disabled
ICE ON - Ice making is enabled
ICE FULL
WATER FULL
LOCK
ICE
LOCK
ICE
LOCK
ICE
LOCK
ICE
* Default Setting
Most Applications
USB

ICE 900 Supplemental Service Manual Page 13 Revision 3-19-2019
DISPLAY AND SYSTEM FUNCTION SETTINGS
HOT/ECONO FUNCTIONS
The HOT FUNCTION enables or disables the production of the Hot Water. To change HOT setting, touch
and hold the button for approximately 3 seconds until the LED light indicates the desired setting.
The ECONO FUNCTION enables and disables Power Saving Mode. To change ECONO setting, touch and
hold the button for approximately 10 seconds until the LED light indicates the desired setting.
When in Power Saving Mode, the ICE 900 detects the amount of light surrounding the machine. Hot
Water production will automatically be turned off when there is no light, and turned on when there is
sufficient light surrounding the ICE 900.
It may take up to 10 minutes for the hot tank to reach set point temperature when coming out of
ECONO Mode. Ensure customers understand ECONO function or we recommend disabling to avoid
needless service calls for no hot water upon initial use.
Hot Water production is disabled.
ECONO (Power Saving Setting) is disabled.
Hot Water production is enabled.
ECONO (Power Saving Setting) is disabled.
Hot Water production is enabled.
ECONO (Power Saving Setting) is enabled.
When in Power Saving Mode, the ICE 900 detects the amount of
light surrounding the machine. The hot water will automatically
be turned off when there is no light, and turned on when there
is sufficient light surrounding the ICE 900.
TURN ON / OFF SOUND FUNCTION
Turn off or on the Sound Function - Push and hold the HOT/ECONO button
and the Hot Product Select Button at same time for 5 seconds to turn on/off
sound function.
HOT
ECONO
*Default Setting
Most Applications
HOT
ECONO
HOT
ECONO
HOT
ECONO

ICE 900 Supplemental Service Manual Page 14 Revision 3-19-2019
CONST (CONTINUOUS DISPENSE) FUNCTION
The purpose of the CONST (Continuous Dispensing) function is to provide the option of continuous
dispensing of Ambient or Cold-water for 1, 1.5, 4.5 or 8 Liters (.26, .40, 1.2 or 2.1 Gallons) at a time.
Hot Water is not an option for continuous dispensing.
To enable the CONST (continuous dispensing) option, touch the touch sensor button for approximately
3 seconds until the 1 Liter (.26 Gallons) indication turns red. Touch the touch sensor button again until
the amount of water desired to continually dispense is selected.
1. Touch CONST (continuous dispense) touch sensor for 3 seconds
turn on CONST function. Repeatedly touch sensor to select the
amount of cold or ambient water amount desired. The 1, 1.5, 4.5,
or 8 Liters light will turn red to indicate selection.
2. Select Ambient or Cold-water to dispense. Hot Water is not an
option for continuous dispensing.
3. Place container big enough to hold the amount of water selected
to dispense at one time under the dispenser.
4. Push container against water dispensing button to start continuous
dispense.
1
2
3
CONST.
1
ℓ
8
ℓ
4.5
ℓ
1.5
ℓ
To STOP CONTINUOUS DISPENSE, touch the Hot, Cold, or Ambient water selection button

ICE 900 Supplemental Service Manual Page 15 Revision 3-19-2019
ERROR PROOFING THE FRONT DISPLAY
We strongly recommend covering the LOCK/ICE and the HOT/ECON buttons and LED indicators
once programmed to prevent users from disabling machine function inadvertently.
Covering programming buttons prevents accidental disabling of ICE making and Hot water
functions by end users and will reduce unnecessary emergency service calls accordingly.
Tip -Use black tape or Part Number 21-1280 to Cover Programming Buttons LED lights before
installing decal to help prevent light from coming thru.
Black Label to Cover
Programming Buttons
Part Number 21-1280
Programming
Buttons

ICE 900 Supplemental Service Manual Page 16 Revision 3-19-2019
SERVICE REQUIREMENTS
WARNING! Read and understand the contents of this manual before attempting to service ICE
900 Water Treatment System. Failure to follow the instructions in this manual could result in
death, serious personal injury, or severe property damage. Only trained and qualified
technicians should attempt to install, maintain, or service the ICE 900.
DANGER! HIGH VOLTAGE ELECTRICAL HAZARD. Unplug before inspection and service.
Annual preventative maintenance is the key to performance and should be performed off-site
if possible as this takes approximately 4 hours to complete. Rotating inventory is strongly
encouraged.
1. Visually inspect all electrical and water connections for signs of wear or damage.
2. Visually inspect the water inlet solenoid (SV Raw Water) for heat damage.
Replace the water inlet solenoid #21-1095 if any sign of heat damage (discoloration or melting) is
noticed. Recommend changing inlet solenoid annually as proactive preventative maintenance.
3. Change Filters. Filter replacement based upon20 liters (5.3 gallons) usage per day. Local water
conditions will dictate your exact filters requirements and service intervals
Sediment Filter (5 micron) #21-1200 – every 6 Months
Pre-Carbon Filter (10 micron) #21-1205 – every 12 Months
RO Membranes (0.0001 micron) #21-1210 – every 24 Months or once TDS is > 10% incoming supply.
2 each 80 gallon per day RO membranes are in parallel for increased production and recovery rates.
Post-Carbon Filter (1 micron) #21-1210 – every 12 Months
Flush 19 Liters (5 gallons) of water through the carbon filters to rinse carbon fines. Do not rinse the
Filters through the unit Solenoid Valve(s) and Tanks if at all possible to avoid contamination.Flush
RO membrane to rinse preservative from the membrane for 4 hours.
4. Change the ice (#21-1040), cold (#21-1030), and environmental (#21-1045) sensors *See “Design
changes to main PCB and environmental sensor affecting serial numbers Z-10369 and beyond”
elsewhere in this manual” on a regular basis (annually) to prevent unexpected downtime and avoid
emergency service calls.
5. Ensure there is adequate (minimum of 4”) clearance aroundthe unit and clean the condenser grill
and Compressor fan to provide efficient cooling system operation.
6. Test the drip tray overflow function. Water should drain through the Drain Outlet into a floor drain.
Clean and dry out the drip tray. Clean or replace the drain pump if present.
7. Sanitize entire unit including cold reservoir, ice making tray, and ice storage bin per instructions.
8. Clean and sanitize external surfaces of the unit. Use soap and water or chemicals that are
compatible with ABS plastic and will not damage or degrade the product surfaces.
WARNING! SANITIZER MAY CONTAIN HAZARDOUS CHEMICALS. Use of proper personal
protective equipment such as rubber gloves and eye protection is required.

ICE 900 Supplemental Service Manual Page 17 Revision 3-19-2019
DESIGN CHANGES TO MAIN PCB AND ENVIRONMENTAL SENSOR
Change implemented effective Serial Numbers Z-10369
Environmental Sensors are not interchangeable – verify sensor part number to the
applicable serial number listed below.
Location of Environmental Sensor
Environmental Sensor Part Number Changes
OLD LOCATION
Serial Numbers: Prior to Z-10368
Date of Manufacture: Prior to 7-6-2017
WLCP PN 21-1045
Iguassu PN 45-0022-0
NEW LOCATION
Serial Numbers: Z-10369 and beyond
Date of Manufacture: After 7-6-2017
WLCP PN 21-1046
Iguassu PN 41-1354-0

ICE 900 Supplemental Service Manual Page 18 Revision 3-19-2019
Main PCB Design Changes
The two different designs of the Main PCB are not interchangeable – verify Main PCB
part number to the applicable serial number listed below.

ICE 900 Supplemental Service Manual Page 19 Revision 3-19-2019
CONSUMABLES AND RECOMMENDED SPARE PARTS DRAWINGS
Yellow = Consumables
Green = Recommended
spare parts
Power
Transformer
Environmental
Sensor
Main PCB
Cold Solenoid
Dispensing
Solenoid
Cold-water Level
Sensor Probe
Circulation
Pump
Ice Coupler – install
between micro switches
Cold Water
Sensor
Inlet Solenoid
Raw Water
Ice Full
Transmitter
Motor
Ice Sensor
Water Level
Sensor
Ice Full Receiver

ICE 900 Supplemental Service Manual Page 20 Revision 3-19-2019
CONSUMABLES AND RECOMMENDED SPARE PARTS DRAWINGS
Cold Inlet Solenoid
Optical Level Control
(Water Level Sensor)
Main PCB Located
under Cover
Ice Dispense
Outlet
Environmental
Sensor
