weBoost DRIVE X FLEET User manual

PROFESSIONAL VEHICLE CELL
SIGNAL BOOSTER KIT
DRIVE X FLEET
A WILSON ELECTRONICS BRAND
NEED HELP? support.weboost.com
Use our weBoost App to guide you through the installation.
See inside page for more details.
1-866-294-1660
Installation Guide

Download the weBoost App
Use our app to guide you through setting up a weBoost cell phone
signal booster in your home, business, or vehicle. Boost every
network, including 5G, right away.
Download the weBoost App
Videos to guide you
through installation
Antenna positioning guide
for optimal performance
Before and after cell
signal readings

______
Index
Package Contents 1
STEP 1: Drill Cable Entry Hole To Your Vehicle 2
STEP 2: Mount NMO Outside Antenna 5
STEP 3: Mount In-Vehicle Antenna 6
STEP 4: Wire The Power Supply 7
STEP 5: Connect Coax Cables To Booster 8
STEP 6: Connect Power Supply To Booster 9
Light Patterns 10
Troubleshooting 11
Safety Guidelines 13
Specifications 14
Warranty 15

1PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT DRIVE X FLEET
________
Package
Contents
Drive X
Booster
& Bracket
Outside NMO
Antenna +
Connector
Mounting Cable
In-Vehicle
Antenna Power
Supply
Optional Antenna
Extension Cable Protective Tape For Installation O-Ring Lubricant Packet

DRIVE X FLEET PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT 2
______
Step 1: Drill Cable Entry Hole
To Your Vehicle
Identify a location for NMO outside antenna on the
top of your vehicle that is:
 Near the center of the roof
 At least 12 inches away from any other antennas
 At least 12 inches away from any windows
(for best performance install on top of vehicle)
Do a ‘soft install’ before drilling the hole for the
cable entry.
Set up the system by routing the cable through
an open door or window, completing the setup
instructions, verifying the system works as desired,
and then drilling the hole.
12 in. away from windows
(including sunroofs)
Good NMO Outside
Antenna Placement

3PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT DRIVE X FLEET
Place the protective tape on the
vehicle in the desired location.
Using a 3/4” hole saw, drill a
hole in the center of the
protective tape.
______
(STEP 1 cont.)
After completing the ‘soft install’ and identifying NMO
outside antenna location:
protective tape
vehicle surface
protective tape
3/4” bit

DRIVE X FLEET PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT 4
apply silicone grease
apply silicone grease
After hole has been drilled, insert NMO Mounting Cable
through (SMA connector end first) and remove collar.
Position threads of the cable mount above vehicle surface.
Apply included silicone grease to the o-ring on the collar
then screw the collar to the base mount. Ensure the mount is
centered in the hole and tighten with wrench.
screw collar
to base mount
For a professional installation, we recommend routing the cable
under the headliner and down through the side trim panel to
the desired booster location on the floor of the vehicle.
side trim panel
headliner
r
u
n
c
a
b
l
e
f
r
o
m
N
M
O
O
u
t
s
i
d
e
A
n
t
e
n
n
a
t
o
b
o
o
s
t
e
r
remove
collar
insert through hole
______
(STEP 1 cont.)

5PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT DRIVE X FLEET
Before attaching the antenna, apply a thin layer of silicone
grease to the threads, only, to the NMO mount and to the
o-ring on the antenna. Screw the antenna onto the NMO
mount and hand tighten into place.
hand tighten and make sure
gasket is touching vehicle
surface
screw on
NMO Antenna
______
Step 2: Mount NMO
Outside Antenna
apply silicone grease
apply silicone grease
NOTE: DO NOT apply silicone grease to the antenna pin contact surface.

DRIVE X FLEET PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT 6
The location should be at least 18 inches but no more than
36 inches from where the cell phone device will be used.
Adhesive and Velcro® mounting options are included.
In-Vehicle Antenna
Identify a place to mount the in-vehicle antenna, either on
the side of the seat or on the dash and mount.
______
Step 3: Mount In-Vehicle
Antenna
clean surface of dash before attaching
adhesive strip
dash option
seat option
In-Vehicle
Antenna

7PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT DRIVE X FLEET
Before connecting the power supply, disconnect the vehicle battery
leads to avoid any electrical shocks during installation.
Locate a place where cables are already running through the firewall
(rear wall of engine bay) to the inside of the cabin.
Locate the same firewall hole from inside of the vehicle cabin.
Route the power cables of the power supply from the inside of the
vehicle cabin out through firewall hole.
Note: The cables must be routed inside to outside since the power
supply brick won’t fit through the firewall holes. The power supply
brick should remain inside the vehicle cabin.
Connect the positive lead of the power supply (lead with red tape)
to the disconnected positive (+) lead of the battery (not the positive
terminal on the battery itself).
Connect the negative lead of the power supply (lead without tape)
to the disconnected negative (-) lead of the battery (not the negative
terminal on the battery itself).
Connect the positive (+) lead back to the vehicle battery.
Connect the negative (-) lead back to the vehicle battery.
Use steps below as a draft/template of the general install of
the power supply.
______
Step 4: Wire The Power
Supply
1
2
3
4
5
6
7
8
NOTE: Having the power supply directly connected to the battery may
drain the battery’s life. Please review the vehicle’s owner’s manual for more
information. Adding a “fuse tap” may be another solution. A “fuse tap” is an
electrical part that functions as a power splitter and is meant to be installed
in the car’s fuse box, making the amp shut o when the vehicle’s ignition
switch is turned o.

DRIVE X FLEET PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT 8
______
Step 5: Connect Coax Cables
To Booster
Connect the cable from the NMO outside antenna to the port
labeled “Outside Antenna” on the Drive X booster.
Connect the cable from the in-vehicle antenna to the port labeled
“Inside Antenna” on the booster.
from NMO Outside Antenna
from Inside Antenna
NOTE: Bracket can be used to fasten booster in a specific location if desired.

9PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT DRIVE X FLEET
______
Step 6: Connect Power
Supply To Booster
Connect the power supply cord to the end of the Drive X
labeled “Power.” Congratulations! Once your booster is running
please allow some time for your phone to adjust to your
new signal.
NOTE: Do NOT connect the power to the signal booster until you have
connected both the Inside and outside antennas.
Power Supply

DRIVE X FLEET PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT 10
______
Light Patterns
Solid Green
This indicates that your booster is functioning properly and there are no issues
with installation.
Blinking Red, Then Solid Green
This indicates that one or more of the booster bands has reduced power due
to a feedback loop condition called oscillation. This is a built in safety feature
to prevent harmful interference with a nearby cell tower. If you are already
experiencing the desired signal boost, then no further adjustments are necessary.
If you are not experiencing the desired boost in coverage then refer to the
Troubleshooting section.
Solid Red
This is due to a feedback loop condition called oscillation. This is a built in safety
feature that causes a band to shut off to prevent harmful interference with a nearby
cell tower. Refer to Troubleshooting section.
Light O
If the Drive X signal booster’s light is off, verify your power supply has power.
NOTE: The signal booster can be reset by disconnecting and reconnecting
the power supply.
After troubleshooting you must initiate a new power cycle by disconnecting and
then reconnecting power to the booster.
NEED HELP? support.weboost.com 1-866-294-1660

11 PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT DRIVE X FLEET
FREQUENTLY ASKED QUESTIONS
How can I contact customer support?
Customer Support can be reached Monday thru Friday by calling 1-866-294-1660, or
through our support site at support.weboost.com.
Why do I need to create distance between the booster and the antenna?
Antennas connected to a booster create spheres of signal. When these spheres
overlap, a condition called oscillation occurs. Oscillation can be thought of as noise,
which causes the booster to scale down it’s power or shut down to prevent damage.
The best way to keep these spheres of signal from overlapping is to maximize
separation between the inside and outside antennas.
______
Troubleshooting
FIXING BLINKING OR SOLID RED ISSUES
This section is only applicable if the booster is red or blinking red and you are not
experiencing the desired signal boost.
1
2
3
Unplug the booster’s power supply.
Relocate the inside and outside antenna further from each other. The objective
is to increase the separation distance between them, so that they will not
create this feedback condition discussed before.
Plug power supply back in.
Monitor the indicator light on your booster. If, after a few seconds of ‘power
on’, a solid or blinking red light appears, repeat steps 1 through 3. Increase the
separation distance until the condition is corrected and/or desired coverage
area is achieved. Note: Horizontal separation of the two antennas typically
requires a shorter separation distance than perpendicular separation.
If you are having any diculties while testing or installing your booster, contact
our weBoost Customer Support team for assistance (1-866-294-1660).
4
5

DRIVE X FLEET PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT 12
______
Antenna Kit Options
The following accessories are certified by the FCC to be used with the Drive X.
This radio transmitter 4726A-460021 has been approved by innovation, Science and
Economic Development Canada to operate with the antenna types listed below, with the
maximum gain indicated. Antenna types not included in this list that have a gain greater than
the maximum gain indicated for any type listed are strictly prohibited for use with this device.
Outside antenna maximum permissible
antenna gain (dBi) 50
Inside antenna maximum permissible
antenna gain (dBi) 50
4.5 4.2 4.6
4.16 4.16 6.09 6.66 9.77
BAND 12/17 BAND 13 BAND 5 BAND 4 BAND 25/2
3.81 4.74
Ω
50
50
50
50
Antenna Type
Mini-Mag Antenna SMA
OTR Antenna Truck Edition
12” Mag Mount
NMO Vehicle Antenna
Coax Type
LMR-100
LMR195
RG-174
RG-58
Kit #
301126
311229
311125
314405
Ln(ft)
10
15
12.5
14
MOBILE OUTSIDE ANTENNA KIT OPTIONS
Ω
50
Antenna Type
Low Profile In-Vehicle SMA
Coax Type
LMR-100
Kit #
314401
Ln(ft)
10
MOBILE INSIDE ANTENNA KIT OPTIONS

13 PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT DRIVE X FLEET
______
Safety Guidelines
Use only the power supply provided in this package. Use of a non-weBoost product may damage
Low profile antennas must have at least 1.5’ separation distance from all active users.
Connecting the Signal Booster directly to the cell phone with use of an adapter will damage the
cell phone.
RF Safety Warning: Any antenna used with this device must be located at least 8 inches
from all persons.
FOR MORE INFORMATION ON REGISTERING YOUR SIGNAL BOOSTER WITH YOUR
WIRELESS PROVIDER, PLEASE SEE BELOW:
T-Mobile/Sprint/MetroPCS: https://www.t-mobile.com/support/coverage/register-a-signal-booster
Verizon Wireless: http://www.verizonwireless.com/wcms/consumer/register-signal-booster.html
AT&T: https://securec45.securewebsession.com/attsignalbooster.com/
U.S. Cellular: http://www.uscellular.com/uscellular/support/fcc-booster-registration.jsp
This is a CONSUMER device.
BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your
provider’s consent. Most wireless providers consent to the use of signal boosters. Some providers
may not consent to the use of this device on their network. If you are unsure, contact your
provider.
In Canada, BEFORE USE you must meet all requirements set out in ISED CPC-2-1-05.
You MUST operate this device with approved antennas and cables as specified by the
manufacturer. Antennas MUST be installed at least 20 cm (8 inches) from (i.e., MUST NOT be
installed within 20 cm of) any person.
You MUST cease operating this device immediately if requested by the FCC (or ISED in Canada) or
licensed wireless service provider.
WARNING. E911 location information may not be provided or may be inaccurate for calls served by
using this device.
FOR MORE INFORMATION ON REQUIREMENTS SET OUT IN ISED CPC-2-1-05,
SEE BELOW:
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08942.html

DRIVE X FLEET PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT 14
DriveX
Product Number U471010
Model Number 460021
FCC ID: PWO460021
IC ID: 4726A-460021
Connectors SMA-Female
Antenna Impedance 50 Ohms
Frequency 699-716 MHz, 729-756 MHz, 777-786 MHz, 824-894 MHz, 1850-1995 MHz, 1710-1755 MHz/2110-2155 MHz
Maximum Power
Power output for single cell
phone (Uplink) dBm
700 MHz
Band 12/17
24.84
700 MHz
Band 13
24.35
800 MHz
Band 5
23.4
1700 MHz
Band 4
21.3
1900 MHz
Band 2
24.43
Power output for single cell
phone (Downlink) dBm
700 MHz
Band 12/17
2.87
700 MHz
Band 13
2.79
800 MHz
Band 5
2.8
2100 MHz
Band 4
2.0
1900 MHz
Band 2
1.92
Noise Figure 5 dB nominal
Isolation > 90 dB
Power Requirements 6 V 2 A
______
Specifications
Each Signal Booster is individually tested and factory set to ensure FCC compliance. The Signal Booster cannot be adjusted without
factory reprogramming or disabling the hardware. The Signal Booster will amplify, but not alter incoming and outgoing signals in order
to increase coverage of authorized frequency bands only. If the Signal Booster is not in use for five minutes, it will reduce gain until a
signal is detected. If a detected signal is too high in a frequency band, or if the Signal Booster detects an oscillation, the Signal Booster
will automatically turn the power o on that band. For a detected oscillation the Signal Booster will automatically resume normal
operation after a minimum of 1 minute. After 5 (five) such automatic restarts, any problematic bands are permanently shut o until the
Signal Booster has been manually restarted by momentarily removing power from the Signal Booster. Noise power, gain, and linearity
are maintained by the Signal Booster’s microprocessor.
The term “IC” before the radio certification number only signifies that Industry Canada technical specifications were met. This device
complies with Part 15 of FCC rules. This device contains licence-exempt transmitter(s)/receiver(s that comply with Innovation, Science
and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may
not cause interference, and (2)) This device must accept any interference, including interference that may cause undesired operation of
the device. Changes or modifications not expressly approved by weBoost could void the authority to operate this equipment.
NEED HELP? support.weboost.com 1-866-294-1660

15 PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT DRIVE X FLEET
2 YEAR WARRANTY
weBoost Signal Boosters are warranted for two (2) years against defects in
workmanship and/or materials. Warranty cases may be resolved by returning the
product directly to the reseller with a dated proof of purchase.
Signal Boosters may also be returned directly to the manufacturer at the
consumer’s expense, with a dated proof of purchase and a Returned Material
Authorization (RMA) number supplied by weoost. weBoost shall, at its option,
either repair or replace the product.
This warranty does not apply to any Signal Boosters determined by weBoost
to have been subjected to misuse, abuse, neglect, or mishandling that alters or
damages physical or electronic properties.
Replacement products may include refurbished weBoost products that have been
recertified to conform with product specifications.
RMA numbers may be obtained by contacting Customer Support
DISCLAIMER: The information provided by weBoost is believed to be complete
and accurate. However, no responsibility is assumed by weBoost for any business
or personal losses arising from its use, or for any infringements of patents or other
rights of third parties that may result from its use.

DRIVE X FLEET PROFESSIONAL VEHICLE SIGNAL BOOSTER KIT 16
NEED HELP? support.weboost.com 1-866-294-1660
Notes

3301 East Deseret Drive, St. George, UT
1.866.294.1660 www.weboost.com support.weboost.com
Copyright © 2019 weBoost. All rights reserved.
weBoost products covered by U.S. patent(s) and pending application(s)
For patents go to: weboost.com/us/patents
NOT AFFILIATED WITH WILSON ANTENNA GDE000465_Rev01_03.16.22
