weBoost Home MultiRoom 530044 User manual

ESPAÑOL ENGLISH
NEED HELP? support.weboost.com 866.294.1660
Installation Guide
Cell Signal Booster
Home MultiRoom
Home MultiRoom
A WILSON ELECTRONICS BRAND
GDE000204_HomeMultiRoom_Rev01_12-05-19.indd 1 12/5/2019 2:42:50 PM

Package Contents 1
Preparation 2
STEP 1-A & B: Inside Antenna & Booster Placement 3
STEP 2: Mount & Point Outside Antenna Toward Nearest Cell
Tower 5
STEP 3-A: Route & Connect Outside Antenna To Booster 8
STEP 3-B: Route & Connect Inside Antenna To Booster 9
STEP 4: Power Up The Booster & Optimize The System 10
Measuring Booster Performance 12
Light Patterns 14
Troubleshooting 15
Safety Guidelines 16
Specifications 18
Warranty 19
______
Index
GDE000204_HomeMultiRoom_Rev01_12-05-19.indd 2 12/5/2019 2:42:50 PM

1
HOME MULTIROOM CELL PHONE SIGNAL BOOSTER
ENGLISH
______
Package
Contents
Home
MultiRoom
Outside Antenna
Mounting Bracket
Window Entry
Cable
(951177)
Wall Mount Brackets
w/Command Strips
Cable Mounting
Clips Qty. 15
Inside
Antenna
(314440)
Outside
Antenna
(314445)
9.14 m & 2-4.57 m
Cables (950630),
(YX030-15W w/971129
Barrel Connector)
Power
Supply
(850018)
GDE000204_HomeMultiRoom_Rev01_12-05-19.indd 1 12/5/2019 2:42:51 PM

2
CELL PHONE SIGNAL BOOSTER HOME MULTIROOM
ENGLISH
______
Preparation
NOTE: These instructions will walk you through a “soft” install process to find
the optimal locations for the inside and outside antennas, then through the
process of the permanent installation.
You Will Need (tools not included)
Make sure the following materials are prepared and ready for your
installation.
o Ladder
o Drill (if routing cable through wall)
o 2.5cm-7.61cm diameter existing pole for mounting
Outside Antenna (#901117 Pole Mount can be
purchased separately if needed)
o Recommended: Power Strip with surge protection
1 to 2 hours
1 Person (2 people to make antenna calibration easier)
GDE000204_HomeMultiRoom_Rev01_12-05-19.indd 2 12/5/2019 2:42:51 PM

3
HOME MULTIROOM CELL PHONE SIGNAL BOOSTER
ENGLISH
NOTE: Do not connect booster to power until the system is fully installed.
______
Step 1-A & B: Inside Antenna
& Booster Placement
Place the Inside Antenna where you need the greatest signal boost
and place Booster in your desired location at least 61 cm away from
Inside Antenna.
TIP: The cable from the Inside Antenna can be
routed into the ceiling and connected to the
coax cable out-of-sight for a better look.
AT LEAST 61 cm APART
GDE000204_HomeMultiRoom_Rev01_12-05-19.indd 3 12/5/2019 2:42:51 PM

4
CELL PHONE SIGNAL BOOSTER HOME MULTIROOM
ENGLISH
Inside Antenna Mounting Options
Mounted
Vertical
Command
Strips
Command Strips
Mounted
Horizontal
Or use the
kickstand and
set on desktop
______
(STEP 1-A & B cont.)
The Inside Antenna can be mounted horizontal, vertical or on a
desktop. Command strips can be used to secure mounting bracket.
GDE000204_HomeMultiRoom_Rev01_12-05-19.indd 4 12/5/2019 2:42:52 PM

5
HOME MULTIROOM CELL PHONE SIGNAL BOOSTER
ENGLISH
______
Step 2: Mount & Point
Outside Antenna Toward
Nearest Cell Tower
NOTE: Mounting on existing roof exhaust pipe
would be a good time-saver option. Watch out for
power lines.
Outside Antenna
Mount
Bracket
Clamps
Pole mounting and wall mounting options are included. The pole mounting
option is preferred because it will be easier to adjust to the direction of
the cell tower.
Attach the Mount to the Outside Antenna and use the Bracket Clamps to
attach the Antenna to a pole or exhaust pipe.
Pole
(2.54cm-7.62cm dia.)
GDE000204_HomeMultiRoom_Rev01_12-05-19.indd 5 12/5/2019 2:42:52 PM

6
CELL PHONE SIGNAL BOOSTER HOME MULTIROOM
ENGLISH
Point the Outside Antenna toward the nearest cell phone tower. To find the
nearest tower, use an app such as ‘Open Signal’. This is the most critical
step of the installation process because it will determine the overall
performance of the booster system.
The greater the separation between the Inside and Outside Antennas, the
better performance you will get from the booster.
Outside Antenna
NOTE: The Outside Antenna must be at least
15.2 meters horizontal or 6.1 meters vertical
from the Inside Antenna for best performance.
Make sure the Inside Antenna and Outside
Antennas are setup so they are facing away
from each other.
Cell Tower
______
(STEP 2 cont.)
GDE000204_HomeMultiRoom_Rev01_12-05-19.indd 6 12/5/2019 2:42:53 PM

7
HOME MULTIROOM CELL PHONE SIGNAL BOOSTER
ENGLISH
If there’s not a pole to easily mount the Outside Antenna, this may be
mounted on the fascia by fastening the bracket as shown below.
______
(STEP 2 cont.)
Mounting On Side Of Roof (Fascia)
Cable Mounting Clips provided
Using only the back Bracket Clamp
for mounting
TIP: Make sure to do the optimization test on Step 4 to find the best side of
your house before you mount this on the fascia.
GDE000204_HomeMultiRoom_Rev01_12-05-19.indd 7 12/5/2019 2:42:53 PM

8
CELL PHONE SIGNAL BOOSTER HOME MULTIROOM
ENGLISH
______
Step 3-A: Route & Connect
Outside Antenna To Booster
The greater the separation, the better
the Booster performance
Connect the white RG-6 Cable to Outside Antenna and route cable
into the home. A Window Entry Cable is provided to help make cable
entry easier. All connections should be finger tightened only.
Route cable to the Home MultiRoom Booster and connect to the port
labeled ‘OUTSIDE ANTENNA’.
Outside
Antenna
connection
Window Entry
Cable
4.57 m RG-6
Cable
4.57 m RG-6
Cable
Outside
Antenna
Cell
Tower
Booster
Booster
Cable Mounting Clips
provided
GDE000204_HomeMultiRoom_Rev01_12-05-19.indd 8 12/5/2019 2:42:53 PM

9
HOME MULTIROOM CELL PHONE SIGNAL BOOSTER
ENGLISH
connection
______
Step 3-B: Route & Connect
Inside Antenna To Booster
Inside
Antenna
9.14 m RG-6 Cable
Booster
Connect the white 9.14 meter Cable to Inside Antenna and route to
the Home MultiRoom Booster and connect to the port labeled
‘INSIDE ANTENNA’.
The greater the separation, the better
the Booster performance
Outside
Antenna
Inside
Antenna
Cell
Tower
Booster
Cable Mounting Clips provided
GDE000204_HomeMultiRoom_Rev01_12-05-19.indd 9 12/5/2019 2:42:54 PM

10
CELL PHONE SIGNAL BOOSTER HOME MULTIROOM
ENGLISH
______
Step 4: Power Up The
Booster & Optimize The
System
Plug the Power Supply into wall outlet then connect to end of booster
labeled “ ” (turn 90° to lock connector).
Outside
Antenna
Cell
Tower
Booster
15.2 METERS HORIZONTAL OR 6.1
METERS VERTICAL DISTANCE
Inside
Antenna
to power
to power
NOTE: We strongly recommend using a power strip with surge protection.
Can
be wall
mounted
Command
Strips
GDE000204_HomeMultiRoom_Rev01_12-05-19.indd 10 12/5/2019 2:42:54 PM

11
HOME MULTIROOM CELL PHONE SIGNAL BOOSTER
ENGLISH
After powering up your system, you are now ready to optimize your system.
Rotate the Outside Antenna in 1/8 turn increments, after each turn, unplug
and reconnect the booster to power while observing the signal level on
your cell phone from the Inside Antenna’s projected area. Secure the
Outside Antenna in place, pointing in the direction that gives you the
strongest signal. Enjoy your boosted signal!
After each rotation, observe signal level
on your cell phone from the Inside Antenna’s
projected area. This is done best by having someone
near the inside antenna taking signal measurements
after the person outside makes each rotation.
______
(STEP 4 cont.)
GDE000204_HomeMultiRoom_Rev01_12-05-19.indd 11 12/5/2019 2:42:55 PM

12
CELL PHONE SIGNAL BOOSTER HOME MULTIROOM
ENGLISH
______
Measuring Booster
Performance
Settings > About Phone > Status or Network > Signal Strength
or Network Type and Strength (exact options/wording
depends on phone model).
Android™
iPhone is a registered trademark of Apple Inc. Android is a trademark of Google Inc.
iOS 11 and later no longer displays the decibel (dBm) reading
in ‘Field Test Mode’. Tip: Using the dot signal strength indicator
on your cell phone can assist you in finding the strongest
signal direction as well as placing calls in dierent locations.
For changes/updates on this issue, periodically go to
weboost.com/signalstrength.
iPhone®
How To Get Signal Strength As A Number
All Other Phones & Alternate Methods
Go to www.weboost.com/test-mode-instructions/
GDE000204_HomeMultiRoom_Rev01_12-05-19.indd 12 12/5/2019 2:42:55 PM

13
HOME MULTIROOM CELL PHONE SIGNAL BOOSTER
ENGLISH
EXCELLENT GOOD FAIR POOR DEAD ZONE
3G/1x
4G/LTE
-70dBm
-90dBm
-71 to -85dBm
-91 to -105dBm
-86 to -100dBm
-106 to -110dBm
-101 to -109dBm
-111 to -119dBm
-110dBm
-120dBm
SIGNAL
STRENGTH
EXCELLENT GOOD FAIR POOR DEAD ZONE
3G/1x
4G/LTE
-70dBm
-90dBm
-71 to -85dBm
-91 to -105dBm
-86 to -100dBm
-106 to -110dBm
-101 to -109dBm
-111 to -119dBm
-110dBm
-120dBm
SIGNAL
STRENGTH
Having an accurate measurement of signal strength in decibels (dBm) is crucial when
installing your system. Decibels accurately measure the signal strength you are receiving.
DID YOU KNOW a signal increase of just 3dB is 2
times the power and signal amplification!
Compare Results
______
(MEASURING BOOSTER PERFORMANCE cont.)
Signal Strength with Booster
Note here:
Signal Strength without Booster
Note here:
GDE000204_HomeMultiRoom_Rev01_12-05-19.indd 13 12/5/2019 2:42:55 PM

14
CELL PHONE SIGNAL BOOSTER HOME MULTIROOM
ENGLISH
______
Light Patterns
Solid Green
This indicates that your booster is
functioning properly and there are
no issues with installation.
Blinking Green & Red
Band has reduced gain. This indicates
that one or more of the booster bands has reduced power due to a feedback loop
condition called oscillation. This is a built in safety feature to prevent harmful interference
with a nearby cell tower. If you are already experiencing the desired signal boost, then
no further adjustments are necessary. If you are not experiencing the desired boost in
coverage then refer to the Troubleshooting section.
Solid Red
Band has shutoff. This is due to a feedback loop condition called oscillation.
This is a built in safety feature that causes a band to shut off to prevent harmful
interference with a nearby cell tower. Refer to Troubleshooting section.
Blinking Green & Yellow
Band has reduced gain. This indicates that one or more of the booster bands has reduced
power due to overload from nearby cell tower. This is a built in safety feature to
prevent harmful interference with a nearby cell tower. If you are already experiencing
the desired signal boost, then no further adjustments are necessary. If you are not
experiencing the desired boost in coverage then refer to the Troubleshooting section.
Solid Yellow
Band has shutoff due to overload from nearby cell tower. Outside Antenna must be
adjusted. Refer to Troubleshooting section.
Light O
If the Signal Booster’s light is off, verify your power supply has power.
Home MultiRoom
GDE000204_HomeMultiRoom_Rev01_12-05-19.indd 14 12/5/2019 2:42:56 PM

15
HOME MULTIROOM CELL PHONE SIGNAL BOOSTER
ENGLISH
______
Troubleshooting
FIXING ANY RED LIGHT ISSUES
FIXING ANY YELLOW LIGHT ISSUES
1
2
3
Verify Outside and Inside Antenna face away from each other. Un-plug and
re-plug in power supply.
Verify the Inside Antenna is at least 61 cm from the Booster and pointed away
from the Booster. Unplug and re-plug in power supply.
Tighten all cable connections (be sure to finger tighten only, do NOT use tools).
You may want to undo and redo the connection completely. Unplug and re-
plug in power supply.
Increase the distance (horizontally or vertically) between the Outside and
Inside antenna. Add included cable if needed. Un-plug and re-plug in
power supply.
Outside Antenna must be adjusted. Wait 10 seconds between adjustments for
the lights to reset.
4
This involves Solid Red & Blinking Green/Red lights.
This involves Solid Yellow & Blinking Green/Yellow lights.
IF YOU ARE HAPPY WITH THE COVERAGE, THESE LIGHT ISSUES DON’T HAVE TO
BE RESOLVED. YOUR CARRIER’S BAND HAS NOT BEEN AFFECTED.
Pole Mount Option: Rotate the Outside Antenna away from the strongest
cellular signal in small increments (45°) until the light turns green. Unplug
and re-plug in power supply.
Mounting On Side Of Roof Option: Change mount location. Move the
Outside Antenna to location of the home/building to see if the lights turn
green. Un-plug and re-plug in power supply. Then secure in place.
NEED HELP? support.weboost.com 866.294.1660
GDE000204_HomeMultiRoom_Rev01_12-05-19.indd 15 12/5/2019 2:42:56 PM

16
CELL PHONE SIGNAL BOOSTER HOME MULTIROOM
ENGLISH
______
Safety Guidelines
To uphold compliance with network protection standards, all active cellular devices must
maintain at least 1.8 m of separation distance from Inside Panel and Dome antennas and at
least 1.2 m of separation distance from desktop Antenna.
Use only the power supply provided in this package. Use of a non-weBoost product may
damage your equipment.
The Signal Booster unit is designed for use in an indoor, temperature-controlled
environment (less than 37.8°celsius). It is not intended for use in attics or similar locations
subject to temperatures in excess of that range.
RF Safety Warning: Any antenna used with this device must be located at least 20.3 cm
from all persons.
AWS Warning: The Outside Antenna must be installed no higher than 10 meters above
ground.
NEED HELP? support.weboost.com 866.294.1660
GDE000204_HomeMultiRoom_Rev01_12-05-19.indd 16 12/5/2019 2:42:56 PM

17
HOME MULTIROOM CELL PHONE SIGNAL BOOSTER
ENGLISH
NEED HELP? support.weboost.com 866.294.1660
866.294.1660
______
Antenna Kit Options
B12/17 B13 B5 B4 B25/2
Outside antenna maximum permissible
antenna gain (dBi) 50 4.5 4.5 4.5 3.8 4.7
Inside antenna maximum permissible
antenna gain (dBi) 50 3.76 4.13 4.77 4.55 4.83
Fixed Outside Antenna Kit Options
314411-40075
Wide Band Directional Antenna With 75’ LMR 400
314411-5825
Wide Band Directional Antenna With 25’ RG-58
314475-0630
Wide Band Directional Antenna With 30’ RG-6
301111-0675
Yagi Antenna 301111 With 75’ RG-6
301111-5850
Yagi Antenna 301111 With 50’ RG-58
311203-40020
Omni Directional Antenna (311203) With 20’
LMR 400
314453-5825
Panel Antenna With 25’ RG-58
311203-5820
Omni Directional Antenna (311203) With 20’
RG-58
311201-0620
Omni Directional Antenna (311201) With 20’ RG-6
301126
Mini-Mag Antenna With 12.5’ RG-174
301111-11140
Yagi 301111 With 140’ RG-11
311201-1120
Omni Directional Antenna 311201 With 20’ RG-11
314453-40075
Panel Antenna With 75’ LMR 400
314473-0640
Panel Antenna With 40’ RG-6
311141-0620
Grey Brick w/20’ RG-6
311141-1120
Grey Panel With 20’ RG-11
314473-1175
Panel Antenna With 75’ RG-11
314475-1175
Wide Band Directional Antenna With 75’ RG-11
301111-400170
Yagi Antenna 301111 With 170’ LMR 400
304421-1120
Omni Consumer 304421 With 20’ RG-11
304421-17410
Omni Consumer 304421 With 10’ RG-174
304421-0610
Omni Consumer 304421 With 10’ RG-6
304421-5810
Omni Consumer 304421 With 10’ RG-58
304422-40020
Omni Enterprise 304422 With 20’ LMR 400
304422-5810
Omni Enterprise 304422 With 10’ RG-58
304422-1120
Omni Enterprise 304422 With 20’ RG-11
314445-1175
4G Directional Antenna 311245 With 75’
RG-11
314445-100100
4G Directional Antenna 311245 With 100’
LMR 100
314445-40075
4G Directional Antenna 311245 With 75’
LMR 400
314445-0630
4G Directional Antenna 311245 With 30’
RG-6
Fixed Inside Antenna Kit Options
311135-40060
Panel Antenna w/60’ Wilson 400
311155-40060
Panel Antenna w/60’ Wilson 400
311135-5825
Panel Antenna w/25’ RG-58
311155-0640
Panel Antenna w/40’ RG-6
301121-40010
Dome Antenna w/10’ Wilson 400
301151-0610
Dome Antenna w/10’ RG-6
309900-50N
2 Panel Antennas and a 50 Ohm 3-Way
Splitter - 40’ Wilson400
309902-75F
2 Panel Antennas and a 75 Ohm 3-Way
Splitter - 20’ RG-6
309903-75F
3 Panel Antennas and three 75 Ohm 2-Way
Splitter - 35’ RG-11
309904-75F
1 Panel Antenna and a 75 Ohm 2-Way
Splitter - 30’ RG-58
309905-50N
3 Panel Antennas and three 50 Ohm 2-Way
Splitter - 10’ RG-174
311155-1170
Panel Antenna w/70’ RG-11
304412-40010
Dome w/10’ Wilson 400
304412-5810
Dome Antenna w/10’ RG-58
304419-1110
Dome Antenna w/10’ RG-11
304419-17410
Dome Antenna w/10’ RG-174
304419-0610
Dome Antenna w/10’ RG-6
314440-1160
4G Panel Antenna w/60’ RG-11
314440-0630
4G Panel Antenna w/30’ RG-6
GDE000204_HomeMultiRoom_Rev01_12-05-19.indd 17 12/5/2019 2:42:56 PM

18
CELL PHONE SIGNAL BOOSTER HOME MULTIROOM
ENGLISH
______
Specifications
Home MultiRoom™
Model Number 530044
Connectors F-Female
Antenna Impedance 75 Ohms
Frequency 1850-1915 MHz, 1930-1995 MHz, 2110-2155 MHz
Power output for single cell
phone (Uplink) dBm AWGN
Band 2
22
Band 4
22
Band 5
22
Power output for single cell
phone (Downlink) dBm AWGN
Band 2
22
Band 4
21
Band 5
20
Noise Figure 5 dB nominal
Isolation > 110 dB
Power Requirements 4.2 V DC
GDE000204_HomeMultiRoom_Rev01_12-05-19.indd 18 12/5/2019 2:42:56 PM
