weewell WTN500 User manual

NON-CONTACT THERMOMETER
THERMOMETRE SANS CONTACT
TEMASSIZ TERMOMETRE
WTN500
USER MANUAL
EN
MODE D’EMPLOI
FR
KULLANIM KILAVUZU
TR

Contents
General Description .........................................................3
Safety Information ...........................................................3
Features.............................................................................4
lntended Use.....................................................................4
Conguration....................................................................5
Indicator............................................................................5
Description of Symbols....................................................6
Technical Specications...................................................6
Advice For The 1st Use......................................................7
Use .....................................................................................7
Measuring Operation.......................................................8
Advice...............................................................................10
Maintenance and Cleaning.............................................10
Troubleshooting..............................................................10
This appliance conforms to the following standards ...12

WTN550 USER MANUAL I 3
General Description
Non-Contact Forehead IR Thermometer is specially designed to take the body
temperature of a person regardless of room temperature. Depending on
various skin types and thickness, there may be temperature dierence.
Safety Information
• Thisdevicemustonlybeusedforthepurposesdescribedinthisinstruction
manual.
• Thisdevicemustonlybeusedinanambienttemperaturerangebetween
10and40°C.
• Donotexposethisthermometertoelecticshocks.
• Donotexposethisthermometertoextremetemperatureconditionsof
>50°Cor<0°C.
• Donotusethedeviceinrelativehumidityhigherthan85%.
• Donotusethedevicenearlargeelectromagneticeldssuchasfoundwithcord-
lessorcellphones.
• Keepthedeviceawayfromwaterandheat,includingdirectsunlight.
• Donotdroporknockthedevice,anddonotuseifdamaged.
• Itmayaecttheaccuracyofmeasurementswhentheforeheadiscoveredby
hair,perspiration,caporscarf.(SeePart10-4)
• KeeptheMeasuringdistanceas5cm-15cm(2in-5.9in).(SeePart10-4)
• Whenthebodyinfraredthermometershouldbeleftinthatroomduring15to20
minutesbeforeusing.
• Itmayaecttheaccuracyofmeasurementswhentheforeheadiscoveredby
perspirationorotherfactors,pleasetakethetemperaturebehindtheearlobe.
(SeePart10-5)
• Cleantheglasswithacottonbudlightlymoistenedwith70%alcohol.
Importance:
• Beforetakingofthetemperaturemakesuretoremovehairandperspiration
fromtheforehead.
• Selecting“Body”modetomeasurethebodytemperature;Selecting
• “Surface”modetomeasurethesurfacetemperature.
• Useofthisthermometerisnotintendedasasubstituteforconsultationwith

4 IWTN550 USER MANUAL
yourphysician.
• Shouldaproblemoccurwithyourdevice.pleasecontactyourretailer.Donot
attempttorepairthedeviceyourself.
• AccordingtoEMCstandard,themedicalelectronicproductsshouldbemain-
tainedspecially.
Features
• Precisenon-contactmeasurements
• Userselectable°Cor°F
• SelectableBodyandSurfacetemp
• SetAlarmvalue
• Memorizationofthelast32measurements
• AutomaticDataHold&Autopowero
• AutomaticselectionrangeandDisplayResolution0.1°C(0.1°F)
• BacklightLCDdisplay
lntended Use
Non-Contact Forehead IR Thermometer is designed for body surface and
forehead temperature measurement for infants and adults without contact
to human body.
Non-Contact Forehead IR Thermometer can also be used to measure the
temperature of a baby-bottle or bath, or room temperature (by using the
Surface Temp function).
Normal Temperatures According To Measurement Method
Measurement Method Normal Temp °C Normal Temp °F
Rectal 36.6 to 38 97.8 to 100.4
Oral 35.5 to 37.5 95.9 to 99.5
Axillary 34.7 to 37.3 94.4 to 99.1
Ear 35.8 to 38 96.4 to 100.4
The temperature of the human body varies throughout the day. It can also be
inuenced by numerous external factors: age, sex, type and thickness of skin...

WTN550 USER MANUAL I 5
Normal Temperatures According To Age
Configuration
1 IRSensor2-LCDDisplay
3 ModeSelection4-DownButton
5 UpButton6-ModeButton
7 MeasurementTrigger
8 BatteryCover
Indicator
1 SurfacemodeSymbol
2 BodymodeSymbol3-Digitalreadout
4 BatterySymbol5-Theordernumber
6 Savedatareadout
7 Temperature°C(Celsius)/“F(Fahrenheit)Scale
8 Buzzersymbol
Age Te m p °C Temp °F
0-2 years 36.4 to 38.0 97,5 to 100.4
3-10 years 36.1 to 37.8 97.0 to 100.0
11 -65 years 35.9 to 37.6 96,5 - 99,7
>65 years 35.8 to 37.5 96.4 - 99.5

6 IWTN550 USER MANUAL
Description of Symbols
Technical Specifications
Normal Conditions of Use
Display Resolution 0.1°C (0.1 °F)
Operating Temperature 10to40°C(50to104°F)
Storage Temperature 0to50°C(32to122°F)
Humidity Rate <85%
Power DC 3V (2 x“AA”batteries)
Size 149x77x43 mm/5.9x3x1.7 in (LxWxH)
Weight Gross 400g/ Net 172g
Measuring Range
In Body Mode 32.0to42.5°C(90to108°F)
In Surface Temp Mod 0to60°C(32to140°F)
Accuracy ±0.3°C (0.54°F)
Measuring Distance 5 cm-15 cm (2 in-5.9 in)
Automatic Stop 7 sec.

WTN550 USER MANUAL I 7
Non-contact Body Infrared Thermometer Precision
32to35.9°C/93.2to96.6°F ±0.3°C/0.5°F
According to ASTM Standard E1965-
1998 (2003)
36to39°C/96.8to102.2°F ±0.2°C/0.4°F
39 to 42.5°C/102.2 to 108.5°F ±0.3°C/0.5°F
Advice For The 1st Use
For stable and reliable results, it is essential to check the Non-contact Body
Infrared Thermometer and change as needed, as follows:
1st step: take the temperature of a person using a conventional thermometer;
you will get 37.5°C (99.5°F) for instance.
2nd step: take the temperature of the same person using the Non-contact
Body Infrared Thermometer keeping the 5 to 15 cm (2 in to 5.9 in) distance
between the thermometer and the forehead (Take care to remove any
obstacle which could alter the measurement (hair, perspiration...). If you get
37.5°C (99.5°F), the Non-contact Body Infrared Thermometer is properly set
and ready for use. If you get a lower temperature, 36.4°C (97.4°F) for example,
your dierence is 1.1°C (2.2°F).You should adjust the temperature on the Non-
contact Body Infrared Thermometer and add the dierence, i.e. 1.1°C(2.2°F).
To do it, press the “MODE” button for 2 seconds, the screen displays F1, press
“MODE” button again until you get F3. You will see F3 for few seconds and
then there will appear some numbers (0.0 for new product). Press“UP”button
in order to increase that number which will be added to the measured value
and display calibrated measurement (in our example, 1.1°C- 2.2°F). If the
measured value is high, then you have to apply same procedure with“DOWN”
button for subtraction.
3rdstep: To check, take the temperature again using the Non-contact Body
Infrared Thermometer.
Use
1. Installbattery
2. Fortherstuseorwheninsertingnewbatterieswaitbetween10minutesforthe
warm-upoftheapparatusandwheninsertingthenewbatteries.
3. Ifthedeviceisnotusedforalongtime,onceyouturnitonagain,thedevicewill
testtheroomtemperaturerstandwilldelayturningonforoneortwoseconds.

8 IWTN550 USER MANUAL
4. Aimtowardstheforehead(seethediagrambelowforthepositioning),froma
distanceof5cm(2in),pressthemeasuringkey,thetemperatureisdisplayedim-
mediately.Makingsurethereisnohair,perspiration,cosmeticorcapcoveredon
theforehead
5. Whentheroomtemperatureissignicantdierence,orthereisperspirationon
theforehead.Youcantakethetemperaturebehindtheearlobe.Makingsure
thereisnohair,perspiration,cosmeticorcapcovered.
Measuring Operation
1. ChoosingTheTemperatureUnit-F1FunctionPress“MODE”buttonfor2seconds,
thescreendisplays:F1.Select“DOWN”fordegreesCelsius,“UP”fordegrees
Fahrenheit.
2. AlarmSetup-F2MenuPress“MODE”touchfor2seconds,thescreendisplays:
F1.Presstwice“MODE”touchtogetF2.Select“UP”toincreasethethresholdby
0.1°C(0.1°F),“DOWN”toreduceitby0.1°C(0.1°F).
Note:Thealarmthresholddefaultvalueis38°C(100.4°F).
3. TotalDierence-F3MenuToadjustthetotalvariationofyourtheNon-contact
BodyInfraredThermometer.Press“MODE”buttonfor2seconds,thescreen
displays:F1.Press“MODE”buttontwotimestogetF3.Select“UP”toincrease
thedierenceby0.1°C(0.1°F),“DOWN”toreduceitby0.1°C(0.1°F).lnthecases
ofseasonalorenvironmentalchangesavericationandadjustmentshouldbe
carriedout.Note:ThisfunctionisonlyeectiveBody

WTN550 USER MANUAL I 9
4. BuzzerON/OFF-F4(F3)MenuPress“MODE”buttonfor2seconds,thescreen
displays:F1.Pressthree(two)times“MODE”buttontogetF4(F3).Select“UP”to
openthebuzzer(asoundicon“4”isdisplayedontheLCDscreen),press“DOWN”
tostopit(theicondisappear).
5. ExitingTheSettingModePress“MODE”buttonuntilthescreenturnso.
6. TheNon-contactBodyInfraredThermometerisspeciallydesignedtotakethe
bodytemperatureofahumanbeing.Forthis,usetheBodymode.Measurement
rangeforBodymode:32to42.5°C(86to108°F)YoucanalsousetheNon-contact
BodyInfraredThermometertomeasurethetemperatureofanareaoranobject,
afood,aliquidoraroomtemperature.Forthis,usetheSurfacemode.Meas-
urementrangeforSurfacemode:0to60°C(32to140°F)Important:Thearea
temperaturediersfromtheinternalbodytemperature.Toobtaintheinternal
temperaturealwaysusetheBodymode.PleasemakesuretoselecttheBody
modeforaninternaltemperaturereadingandtheSurfacemodeforanexternal
areareading(bottle,bath,room...).
7. DataMemoryDatamemoryautomaticallyaftertemperaturemeasurements,
whichwilldisplayattherightcornerofLCD.Press“UP”or“DOWN”buttonto
displaythelasttemperaturemeasurement.Undertheconditionofpowero,
press“UP”and“DOWN”buttontogetherfortwoseconds,todisplaythelasttem-
peraturemeasurement.Atthismodeifchangetheordernumberto0andpress
“MODE”button,thendeleteallmemorydata.
8. ChangingTheBatteriesDisplay:whentheLCDscreendisplays“ “,thebatteryis
used.Operation:Openthelidandchangethebatteries,takinggreatcarewith
thecorrectpositioning.Amistakewiththiscouldcausedamagetotheappara-
tusandcompromisetheguaranteeofyourNon-contactBodyInfraredTher-
mometer.Neveruserechargeablebatteries.Useonlybatteriesforsingleusage.
Removethebatteryfromtheinstrumentifitisnotrequiredforextendedperiods
oftimeinordertoavoiddamagetothethermometerresultingfromaleaking
battery.
9. LongevityUseTheNon-contactBodyInfraredThermometerwasconceivedfor
anintenseandprofessionaluse,itslongevityisguaranteedfor40000takings.

10 IWTN550 USER MANUAL
Advice
• Theprotectiveglassoverthelensisthemostimportantandfragilepartofthe
thermometer,pleasetakegreatcareofit.
• Donotrechargenonrechargeablebatteries,donotthrowinre.
• Donotexposethethermometertosunlightorwater.
Maintenance and Cleaning
• TheInfraredSensoristhemostprecisepart,mustbeprotectedcarefully.
• Cleanthedevicewithacottonbudlightlymoistenedwith70%alcohol.
• Donotcleanthedevicewithcorrosivedetergent.
• Keepthedeviceawayfromwaterorotherliquid.
• Storethedeviceinadryenvironment,andkeepitawayfromdustanddirect
sunlight.
Troubleshooting
If you happen to have one of the following problems while using your the
non-contact forehead IR thermometer please refer to this breakdown service
guide to help resolve the problem. If the problem persists please contact our
customer service.
The screen displays the body temperature inferior to 32°C (89.6°F) If you’re on
Surface mode the 32°C(89.6°F) temperature displayed is showing the external
temperature that your body releases
The screen displays the message “HI” When using the Non-
contact Body Infrared Thermometer the message HI can show
on the screen.
The analysis is above the measurement range selected, either
superior to 42.5°C (108°F) in Body mode or superior to 60°C
(140°F) in Surface mode.
