WEG CFW100 series User manual

Motors | Automation | Energy | Transmission & Distribution | Coatings
Frequency Inverter
Convertidor de Frecuencia
Inversor de Frequência
CFW100 V3.1X
Quick Reference of Parameters, Alarms and Faults
Referencia Rápida de los Parámetros, Alarmas y Fallas
Referência Rápida dos Parâmetros, Alarmes e Falhas

Quick Reference of Parameters, Alarms and Faults
Series: CFW100
Language: English
Document: 10006259370 / 01
Software version: 3.1X
Build 1180
Publication Date: 04/2019

SUMMARY OF REVISIONS
Version Revision Description
3.0X R00 First edition.
3.1X R01 General Revision.

English
QUICK REFERENCE OF PARAMETERS, ALARMS AND FAULTS
Param. Description Adjustable Range Factory Setting Prop.
P000 Access to Parameters 0 to 9999 1
P001 Speed Reference 0 to 9999 ro
P002 Output Speed (Motor) 0 to 9999 ro
P003 Motor Current 0.0 to 10.0 A ro
P004 DC Link Voltage 0 to 524 V ro
P005 Output Frequency (Motor) 0.0 to 400.0 Hz ro
P006 Inverter Status 0 = Ready
1 = Run
2 = Undervoltage
3 = Fault
4 = Self-Tuning
5 = Configuration
6 = DC Braking
7 = Reserved
8 = Fire Mode
ro
P007 Output Voltage 0 to 240 V ro
P009 Motor Torque -200.0 to 200.0 % ro, VVW
P011 Power Factor 0.00 to 1.00 ro
P012 DI8 to DI1 Status 0 to FF (hexa)
Bit 0 = DI1
Bit 1 = DI2
Bit 2 = DI3
Bit 3 = DI4
Bit 4 = DI5
Bit 5 = DI6
Bit 6 = DI7
Bit 7 = DI8
ro
P013 (*) DO3 to DO1 Status 0 to 7 (hexa)
Bit 0 = DO1
Bit 1 = DO2
Bit 2 = DO3
ro
P014 (*) AO1 Value 0.0 to 100.0 % ro
P018 (*) AI1 Value -100.0 to 100.0 % ro
P020 (*) Potentiometer Signal Value -100.0 to 100.0 % ro
P022 FI Value in Hz 0 to 3000 Hz ro
P023 Main SW Version 0.00 to 99.99 ro
P024 (*) Accessory SW Version 0.00 to 99.99 ro
P027 Accessory Config. 0 = Without Accessory
1 = CFW100-HMIR
2 = CFW100-IOAR
3 = CFW100-CCAN
4 = CFW100-CBLT
5 = CFW100-IODR
6 = CFW100-IOADR
7 = CFW100-IOA
8 = CFW100-IOD
9 = Reserved
10 = CFW100-IOP
ro
P029 Power HW Configuration 0 to 999 According to the
Inverter Model
ro
P030 Module Temperature -200.0 to 200.0 ºC ro
P037 Motor Overload Ixt 0.0 to 100.0 % ro
P038 (*) Encoder Speed 0 to 270F (hexa) ro
P039 (*) Encoder Pulses Count 0 to FFFF (hexa) ro
P045 Fan Enabled Time 0 to FFFF (hexa) ro
P047 CONF Status 0 to 33 (Table 1.1 on page 23) ro
P048 Present Alarm 0 to 999 ro
P049 Present Fault 0 to 999 ro
P050 Last Fault 0 to 999 ro
P051 Current At Last Fault 0.0 to 10.0 A ro
P052 DC Link At Last Fault 0 to 524 V ro
P053 Frequency At Last Fault 0.0 to 400.0 Hz ro
P054 Temperature Last Fault 0.0 to 200.0 ºC ro
P060 Second Fault 0 to 999 ro
P070 Third Fault 0 to 999 ro
P080 Last Fault on Fire Mode 0 to 999 ro
P081 Second Fault on Fire Mode 0 to 999 ro
CFW100 | 5

English
QUICK REFERENCE OF PARAMETERS, ALARMS AND FAULTS
Param. Description Adjustable Range Factory Setting Prop.
P082 Third Fault on Fire Mode 0 to 999 ro
P100 Acceleration Time 0.1 to 999.9 s 5.0 s
P101 Deceleration Time 0.1 to 999.9 s 10.0 s
P102 Acceleration Time 2nd Ramp 0.1 to 999.9 s 5.0 s
P103 Deceleration Time 2nd Ramp 0.1 to 999.9 s 10.0 s
P104 Ramp S 0 = Inactive
1 = Active
0 cfg
P105 1st / 2nd Ramp Selection 0 = 1st Ramp
1 = 2nd Ramp
2 = DIx
3 = Serial/USB
4 = Reserved
5 = CO/DN
6 = SoftPLC
0
P106 Emer. R. Acceleration Time 0.1 to 999.9 s 5.0 s
P107 Emer. R. Time Deceleration 0.1 to 999.9 s 5.0 s
P120 Speed Ref. Backup 0 = Inactive
1 = Active
2 = Backup by P121
1
P121 Reference via HMI 0.0 to 400.0 Hz 3.0 Hz
P122 JOG Reference -400.0 to 400.0 Hz 5.0 Hz
P124 Multispeed Ref. 1 -400.0 to 400.0 Hz 3.0 Hz
P125 Multispeed Ref. 2 -400.0 to 400.0 Hz 10.0 (5.0) Hz
P126 Multispeed Ref. 3 -400.0 to 400.0 Hz 20.0 (10.0) Hz
P127 Multispeed Ref. 4 -400.0 to 400.0 Hz 30.0 (20.0) Hz
P128 Multispeed Ref. 5 -400.0 to 400.0 Hz 40.0 (30.0) Hz
P129 Multispeed Ref. 6 -400.0 to 400.0 Hz 50.0 (40.0) Hz
P130 Multispeed Ref. 7 -400.0 to 400.0 Hz 60.0 (50.0) Hz
P131 Multispeed Ref. 8 -400.0 to 400.0 Hz 66.0 (55.0) Hz
P133 Minimum Frequency 0.0 to 400.0 Hz 3.0 Hz
P134 Maximum Frequency 0.0 to 400.0 Hz 66.0 (55.0) Hz
P135 Maximum Output Current 0.0 to 40.0 A 1,5 x Inom V/f
P136 Manual Torque Boost 0.0 to 30.0 % According to the
Inverter Model
V/f
P137 Automatic Torque Boost 0.0 to 30.0 % 0.0 % V/f
P138 Slip Compensation -10.0 to 10.0 % 0.0 % V/f
P139 Output Current Filter 0.000 to 9.999 s 0.050 s V/f, VVW
P140 Slip Com. Filter 0.000 to 9.999 s 0.500 s VVW
P142 Maximum Output Voltage 0.0 to 100.0 % 100.0 % cfg, V/f
P143 Intermediate Output Voltage 0.0 to 100.0 % 50.0 % cfg, V/f
P145 Field Weakening Speed 0.0 to 400.0 Hz 60.0 (50.0) Hz cfg, V/f
P146 Intermediate Frequency 0.0 to 400.0 Hz 30.0 (25.0) Hz cfg, V/f
P149 DC Link Comp. Mode 0 = Inactive
1 = Standard
2 = Overmodulation
3 = Extended
1 cfg, V/f
P150 DC/LC Regul. Type 0 = hold_Ud and decel_LC
1 = accel_Ud and decel_LC
2 = hold_Ud and hold_LC
3 = accel_Ud and hold_LC
0 cfg, V/f, VVW
P151 DC Link Regul. Level 325 to 460 V 430 V (P296 = 1)
380 V (P296 = 2)
781 V (P296 = 4)
781 V (P296 = 5)
781 V (P296 = 6)
781 V (P296 = 7)
V/f, VVW
P156 Rated Speed Overload Current 0.1 to 40.0 A 1,2 x Inom
P157 Overl.Curr.50 % Speed 0.1 to 40.0 A 1,2 x Inom
P158 Overl.Curr.20 % Speed 0.1 to 40.0 A 1,2 x Inom
P178 Rated Flux 50.0 to 150.0 % 100.0 % VVW
P200 Password 0 = Inactive
1 = Active
2 to 9999 = New Password
0 cfg
6 | CFW100

English
QUICK REFERENCE OF PARAMETERS, ALARMS AND FAULTS
Param. Description Adjustable Range Factory Setting Prop.
P202 Type of Control 0 = V/f
1 = Quadratic V/f
2 to 4 = Not Used
5 = VVW
0 cfg
P204 Load/Save Parameters 0 to 4 = Not Used
5 = Load 60 Hz
6 = Load 50 Hz
7 = Load User
8 = Not Used
9 = Save User
10 = Not Used
11 = Load Default SoftPLC
12 to 13 = Reserved
0 cfg
P205 Main Display Parameter 0 to 999 2
P207 Bar Graph Parameter 0 to 999 3
P208 Ref. Scale Factor 1 to 9999 600
P209 Ref. Eng. Unit 0 to 1 = Without unit
2 = Volt (V)
3 = Hertz (Hz)
4 = Without unit
5 = Percent ( %)
6 = Without unit
7 = Rotation/min. (rpm)
3
P210 Ref. Decimal Point 0 = wxyz
1 = wxy.z
2 = wx.yz
3 = w.xyz
1
P213 Bar Scale Factor 1 to 9999 1,0 x Inom
P219 Red. Switch. Freq. 0.0 to 15.0 Hz 5.0 Hz cfg
P220 LOC/REM Selection Source 0 = Always Local
1 = Always Remote
2 to 3 = Not Used
4 = DIx
5 = Serial/USB (LOC)
6 = Serial/USB (REM)
7 to 8 = Not Used
9 = CO/DN (LOC)
10 = CO/DN (REM)
11 = SoftPLC
0 cfg
P221 LOC Reference Sel. 0 = HMI
1 = AI1
2 = Not Used
3 = Potentiometer
4 = FI
5 to 6 = Not Used
7 = E.P.
8 = Multispeed
9 = Serial/USB
10 = Not Used
11 = CO/DN
12 = SoftPLC
13 = Not Used
14 = AI1 >0
15 = Not Used
16 = Potentiometer >0
17 = FI >0
0 cfg
P222 REM Reference Selection See options in P221 2 cfg
P223 LOC FWD/REV Selection 0 = Foward
1 = Reverse
2 to 3 = Not Used
4 = DIx
5 = Serial/USB (FWD)
6 = Serial/USB (REV)
7 to 8 = Not Used
9 = CO/DN (FWD)
10 = CO/DN (REV)
11 = Not Used
12 = SoftPLC
0 cfg
P224 LOC Run/Stop Sel. 0 = HMI Keys
1 = DIx
2 = Serial/USB
3 = Not Used
4 = CO/DN
5 = SoftPLC
0 cfg
CFW100 | 7

English
QUICK REFERENCE OF PARAMETERS, ALARMS AND FAULTS
Param. Description Adjustable Range Factory Setting Prop.
P225 LOC JOG Selection 0 = Disabled
1 = Not Used
2 = DIx
3 = Serial/USB
4 = Not Used
5 = CO/DN
6 = SoftPLC
1 cfg
P226 REM FWD/REV Selection See options in P223 4 cfg
P227 REM Run/Stop Selection See options in P224 1 cfg
P228 REM JOG Selection See options in P225 2 cfg
P229 Stop Mode Selection 0 = Ramp to Stop
1 = Coast to Stop
0 cfg
P230 Dead Zone (AIs and FI1 ) 0 = Inactive
1 = Active
0 cfg
P231 (*) AI1 Signal Function 0 = Speed Ref.
1 to 3 = Not Used
4 = PTC
5 to 6 = Not Used
7 = PLC Use
8 = Application Function 1
9 = Application Function 2
10 = Application Function 3
11 = Application Function 4
12 = Application Function 5
13 = Application Function 6
14 = Application Function 7
15 = Application Function 8
16 = Control Setpoint
17 = Process Variable
0 cfg
P232 (*) AI1 Input Gain 0.000 to 9.999 1.000
P233 (*) AI1 Input Signal 0 = 0 to 10 V / 20 mA
1=4to20mA
2=10V/20mAto0
3=20to4mA
0
P234 (*) AI1 Input Offset -100.0 to 100.0 % 0.0 %
P235 (*) AI1 Input Filter 0.00 to 16.00 s 0.00 s
P241 (*) Potentiometer Signal Function 0 = Speed Ref.
1 to 6 = Not Used
7 = SoftPLC
8 = Application Function 1
9 = Application Function 2
10 = Application Function 3
11 = Application Function 4
12 = Application Function 5
13 = Application Function 6
14 = Application Function 7
15 = Application Function 8
16 to 17 = Not Used
0 cfg
P242 (*) Potentiometer Signal Gain 0.000 to 9.999 1.000
P244 (*) Potentiometer Signal Offset -100.0 to 100.0 % 0.0 %
P245 Potentiometer and FI1 Filter 0.00 to 16.00 s 0.00 s
P246 FI1 Input Function 0 = Inactive
1 = Active in DI1
2 = Active in DI2
3 = Active in DI3
4 = Active in DI4
0 cfg
P247 FI1 Input Gain 0.000 to 9.999 1.000
P248 FI1 Minimum Input 1 to 3000 Hz 100 Hz
P249 FI1 Input Offset -100.0 to 100.0 % 0.0 %
P250 FI1 Maximum Input 1 to 3000 Hz 1000 Hz
8 | CFW100

English
QUICK REFERENCE OF PARAMETERS, ALARMS AND FAULTS
Param. Description Adjustable Range Factory Setting Prop.
P251 (*) AO1 Output Function 0 = Speed Ref.
1 = Not Used
2 = Real Speed
3 to 4 = Not Used
5 = Output Current
6 = Not Used
7 = Active Current
8 to 10 = Not Used
11 = Motor Torque
12 = SoftPLC
13 to 15 = Not Used
16 = Motor Ixt
17 = Not Used
18 = P696 Value
19 = P697 Value
20 = Not Used
21 = Application Function 1
22 = Application Function 2
23 = Application Function 3
24 = Application Function 4
25 = Application Function 5
26 = Application Function 6
27 = Application Function 7
28 = Application Function 8
29 = Control Setpoint
30 = Process Variable
2
P252 (*) AO1 Output Gain 0.000 to 9.999 1.000
P253 (*) AO1 Output Signal 0 = 0 to 10 V
1=0to20mA
2=4to20mA
3=10to0V
4=20to0mA
5=20to4mA
0
P263 DI1 Input Function 0 = Not Used
1 = Run/Stop
2 = General Enable
3 = Quick Stop
4 = Foward Run
5 = Reverse Run
6 = Start
7 = Stop
8 = Direction of Rotation
9 = LOC/REM
10 = JOG
11 = Accelerate E.P.
12 = Decelerate E.P.
13 = Multispeed
14 = 2nd Ramp
15 to 17 = Not Used
18 = No Ext. Alarm
19 = No Ext. Fault
20 = Reset
21 to 23 = Not Used
24 = Disab.FlyStart
25 = Not Used
26 = Lock Prog.
27 to 31 = Not Used
32 = 2nd Ramp Multispeed
33 = 2nd Ramp Increase E.P.
34 = 2nd Ramp Decrease E.P.
35 = 2nd Ramp FWD Run
36 = 2nd Ramp REV Run
37 = Start / Inc. E.P.
38 = Dec. E.P. / Stop
39 = Stop
40 = Safety Switch
41 = Application Function 1
42 = Application Function 2
43 = Application Function 3
44 = Application Function 4
45 = Application Function 5
46 = Application Function 6
47 = Application Function 7
48 = Application Function 8
49 = Enable Fire Mode
50 to 54 = Not Used
55 = Run/Stop with Line Start Lockout
1 cfg
CFW100 | 9

English
QUICK REFERENCE OF PARAMETERS, ALARMS AND FAULTS
Param. Description Adjustable Range Factory Setting Prop.
P264 DI2 Input Function 0 = Not Used
1 = Run/Stop
2 = General Enable
3 = Quick Stop
4 = Foward Run
5 = Reverse Run
6 = Start
7 = Stop
8 = Direction of Rotation
9 = LOC/REM
10 = JOG
11 = Accelerate E.P.
12 = Decelerate E.P.
13 = Multispeed
14 = 2nd Ramp
15 to 17 = Not Used
18 = No Ext. Alarm
19 = No Ext. Fault
20 = Reset
21 to 23 = Not Used
24 = Disab.FlyStart
25 = Not Used
26 = Progr. Off
27 to 31 = Not Used
32 = 2nd Ramp Multispeed
33 = 2nd Ramp Increase E.P.
34 = 2nd Ramp Decrease E.P.
35 = 2nd Ramp FWD Run
36 = 2nd Ramp REV Run
37 = Turn ON / Ac. E.P.
38 = De. E.P. / Turn OFF
39 = Stop
40 = Safety Switch
41 = Application Function 1
42 = Application Function 2
43 = Application Function 3
44 = Application Function 4
45 = Application Function 5
46 = Application Function 6
47 = Application Function 7
48 = Application Function 8
49 = Enable Fire Mode
50 = PID Manual / Automatic
51 to 54 = Not Used
55 = Run/Stop with Line Start Lockout
8 cfg
10 | CFW100
