WEG CFW11M G2 Series User manual

Motors I Automation I Energy I Transmission & Distribution I Coatings
Frequency Inverter
CF W11M G2
User's Manual

User's Manual
Series: CFW-11M G2
Language: English
Document: 10004198735 / 00
Models: 634...3012 A/380...480 V
496...2356 A/500...600 V
439...2585 A/660...690 V
Publication Date: 06/2018

Summary of Reviews
The table below describes all revisions made to this manual.
Version Review Description
-R00 First edition

Contents
1 SAFETY INSTRUCTIONS ....................................................................... 1-1
1.1 SAFETY NOTICES IN THE MANUAL ..............................................................................................1-1
1.2 SAFETY WARNINGS ON THE PRODUCT......................................................................................1-1
1.3 PRELIMINARY RECOMMENDATIONS ..........................................................................................1-2
2 GENERAL INFORMATION......................................................................2-1
2.1 ABOUT THE MANUAL .....................................................................................................................2-1
2.2 TERMS AND DEFINITIONS USED IN THE MANUAL....................................................................2-1
2.3 ABOUT THE CFW-11M G2 ............................................................................................................. 2-4
2.4 IDENTIFICATION LABEL FOR THE UC11 G2 ................................................................................2-7
2.5 IDENTIFICATION LABEL FOR THE UP11 G2 ............................................................................... 2-8
2.6 HOW TO SPECIFY THE MODEL OF THE CFW-11M G2 (SMART CODE) .................................. 2-9
2.7 RECEIPT AND STORAGE..............................................................................................................2-10
3 INSTALLATION AND CONNECTION .....................................................3-1
3.1 MECHANICAL INSTALLATION ..................................................................................................... 3-1
3.1.1 Environment Conditions ....................................................................................................... 3-1
3.1.2 List of Components............................................................................................................... 3-1
3.1.3 Lif ting ...................................................................................................................................... 3-3
3.1.4 Panel Ventilation.................................................................................................................... 3-4
3.1.5 Panel Mounting of the UP11 G2 ........................................................................................... 3-4
3.1.6 Panel ....................................................................................................................................... 3-7
3.2 ELECTRICAL INSTALLATION.......................................................................................................3 -11
3.2.1 Input Rectifier.......................................................................................................................3-11
3.2 .1.1 Sizing .........................................................................................................................3 -11
3.2.1.2 Line Reactor .............................................................................................................3-11
3.2.1.3 Pre-Charge ...............................................................................................................3-12
3.2.1.4 Harmonics of the 6-Pulse Rectifier .......................................................................3-14
3.2.1.5 Harmonics of the 12-Pulse Rectifier .....................................................................3-15
3.2.1.6 Harmonics of the 18-Pulse Rectifier .....................................................................3-16
3.2.2 Busbars.................................................................................................................................3-17
3.2.3 Fuses ....................................................................................................................................3-17
3.2.4 General Wiring Diagram......................................................................................................3-17
3.2.5 Power Connections .............................................................................................................3-19
3.2.6 Input Connections .............................................................................................................. 3-22
3.2.7 Output Connections ........................................................................................................... 3-24
3.2.8 Grounding Connections..................................................................................................... 3-25
3.2.9 IT Networks ......................................................................................................................... 3-26
3.2.10 Terminals Recommended for Power Cables ................................................................. 3-27
3.2.11 Dynamic Braking ............................................................................................................... 3-27
3.2.12 Control Connections ........................................................................................................ 3-28
3.2.12.1 UP11 G2 Connections........................................................................................... 3-28
3.2.12.2 UC11 G2 Connections .......................................................................................... 3-31
3.2.12.3 CC11 Connections ................................................................................................ 3-35
3.2.12.4 Typical Control Connections............................................................................... 3-39
3.3 SAFETY STOP FUNCTION........................................................................................................... 3-42
3.3.1 Installation .......................................................................................................................... 3-43
3.3.2 Operation............................................................................................................................. 3-44
3.3.2.1 Truth Table ............................................................................................................... 3-44
3.3.2.2 Inverter State, Fault and Alarm............................................................................. 3-44
3.3.2.3 Indication of STO Status........................................................................................ 3-44
3.3.2.4 Periodical Test ........................................................................................................ 3-45
3.3.2.5 Examples of Wiring Diagrams of the Inverter Control Signal........................... 3-45
3.3.3 Technical Specifications.................................................................................................... 3-46
3.3.3.1 Electrical Control Characteristic.......................................................................... 3-46
3.3.3.2 Operating Safety Characteristic........................................................................... 3-46

Contents
3.4 INSTALLATIONS ACCORDING TO THE EUROPEAN ELECTROMAGNETIC
COMPATIBILITY DIRECTIVE ............................................................................................................. 3-46
3.4.1 Conformal Installation ........................................................................................................ 3-46
3.4.2 Definition of the Standards ............................................................................................... 3-47
3.4.3 Emission and Immunity Levels Met.................................................................................. 3-48
4 HMI...........................................................................................................4-1
4.1 INTEGRAL KEYPAD - HMI-CFW11M G2....................................................................................... 4-1
4.2 PARAMETER STRUCTURE ........................................................................................................... 4-4
5 FIRST TIME POWER-UP AND START-UP.............................................5-1
5.1 PREPARE FOR START-UP ............................................................................................................. 5-1
5. 2 START-UP........................................................................................................................................ 5-2
5.2.1 Password Setting in P0000.................................................................................................. 5-2
5.2.2 Oriented Start-up.................................................................................................................. 5-2
5.2.3 Setting of the Basic Application Parameters.................................................................... 5-4
5.3 SETTING DATE AND TIME............................................................................................................. 5-8
5.4 LOCKING OF PARAMETER MODIFICATION ............................................................................... 5-8
5.5 HOW TO CONNECT A PC .............................................................................................................. 5-8
5.6 FLASH MEMORY MODULE ........................................................................................................... 5-9
5.7 OPERATION WITH A REDUCED NUMBER OF POWER UNITS.................................................5-10
6 TROUBLESHOOTING AND MAINTENANCE ........................................6-1
6.1 OPERATION OF THE FAULTS ........................................................................................................ 6-1
6.2 FAULTS, ALARMS AND POSSIBLE CAUSES............................................................................... 6-2
6.3 SOLUTIONS FOR THE MOST FREQUENT PROBLEMS.............................................................6-11
6.4 INFORMATION NECESSARY FOR CONTACTING TECHNICAL SUPPORT..............................6-11
6.5 PREVENTIVE MAINTENANCE......................................................................................................6-12
6.5.1 Cleaning Instructions ..........................................................................................................6-14
7 ACCESSORIES........................................................................................ 7-1
7.1 SAFETY STOP FUNCTION ..............................................................................................................7-1
7.2 ACCESSORIES.................................................................................................................................7-1
8 TECHNICAL SPECIFICATIONS..............................................................8-1
8.1 POWER DATA .................................................................................................................................. 8-1
8.2 ELECTRONICS/GENERAL DATA .................................................................................................. 8-4
8.2.1 Codes and Standards........................................................................................................... 8-5
8.3 MECHANICAL DATA ....................................................................................................................... 8-6

Safety Instructions
CFW-11M G2 | 1-1
1
1 SAFETY INSTRUCTIONS
This manual contains the necessary information for the correct use of the CFW-11M G2 frequency inverter.
Only trained and qualified personnel should attempt to install, start-up, and troubleshoot this type of equipment.
1.1 SAFETY NOTICES IN THE MANUAL
The following safety warnings are used in this manual:
DANGER!
The procedures recommended in this warning have the purpose of protecting the user against dead,
serious injuries and considerable material damage.
DANGER!
Les procédures concernées par cet avertissement sont destinées à protéger l'utilisateur contre des
dangers mortels, des blessures et des détériorations matérielles importantes.
ATTENTION!
The procedures recommended in this warning have the purpose of avoiding material damage.
NOTE!
The text intents to supply important information for the correct understanding and good operation
of the product.
1.2 SAFETY WARNINGS ON THE PRODUCT
The following symbols are attacheds to the product as safety warnings:
High voltages present.
Components sensitive to electrostatic discharges. Do not touch them.
Mandatory connection to the protection earth (PE).
Connection of the shield to the ground.
Hot surface.

Safety Instructions
1-2 | CFW-11M G2
1
1.3 PRELIMINARY RECOMMENDATIONS
DANGER!
Only qualified personnel, familiar with the CFW-11M G2 frequency inverter and related equipment
must plan or perform the installation, start-up, operation and maintenance of this equipment.
Such personnel must follow the safety instructions described in this manual and/or defined by local
standards.
Failure to comply with the safety instructions may cause risk of death and/or equipment damage.
DANGER!
Seulement personnes avec la qualification adéquate et familiarisation avec le CFW-11 et équipements
associés doivent planifiquer ou implementer l'installation, mise en marche, operation et entretien de
cet équipement.
Cettes personnes doivent suivre toutes les instructions de sécurités indiquées dans ce manuel, et/
ou définies par normes locales.
L'inobservance des instructions de sécurité peut résulter en risque de vie et/ou dommages de cet
équipement.
NOTE!
For the purposes of this manual, qualified personnel are those trained and able to:
1. Install, ground, power up and operate the CFW-11M G2 according to this manual and the legal
safety procedures in force.
2. Use the protective equipment according to the standards.
3. Give first aid.
DANGER!
Always disconnect the main power supply before touching any electrical component associated to
the inverter.
Several components can remain charged with high voltages or remain in movement (fans) even after
the AC power is disconnected or switched off.
Wait for at least ten minutes so as to ensure the full discharge of the capacitors.
Always connect the equipment frame to the protection earth (PE) at the suitable connection point.
DANGER!
Débranchez toujours l'alimentation principale avant d'entrer en contact avec un appareil électrique
associé au variateur.
Plusieurs composants peuvent rester chargés à un potentiel électrique élevé et/ou être en movement
(ventilateurs), même après la déconnexion ou la coupure de l'alimentation en courant alternatif.
Attendez au moins 10 minutes que les condensateurs se déchargent complètement.
Raccordez toujours la masse de l'appareil à une terre protectrice (PE).
ATTENTION!
Electronic boards have components sensitive to electrostatic discharges. Do not touch directly
on components or connectors. If necessary, touch the grounded metallic frame before or use an
adequate grounded wrist strap.
Do not perform any withstand voltage test!
If necessary, consult WEG.

Safety Instructions
CFW-11M G2 | 1-3
1
NOTE!
Frequency inverter may interfere with other electronic equipment. In order to reduce these effects,
take the precautions recommended in the Chapter 3 INSTALLATION AND CONNECTION on page
3-1 in order to minimize those effects.
NOTE!
Read the user manual completely before installing or operating the inverter.
DANGER!
Crushing hazard
In order to ensure safety in load lifting applications, electric and/or mechanical devices must be
installed outside the inverter for protection against accidental fall of load.
DANGER!
This product was not designed to be used as a safety element. Additional measures must be taken
so as to avoid material and personal damages.
The product was manufactured under strict quality control, however, if installed in systems where its
failure causes risks of material or personal damages, additional external safety devices must ensure
a safety condition in case of a product failure, preventing accidents.
DANGER!
Risque d'écrasement
Afin d'assurer la sécurité dans les applications de levage de charges, les équipements électriques et/
ou mécaniques doivent être installés hors du variateur pour éviter une chute accidentelle des charges.
DANGER!
Ce produit n'est pas conçu pour être utilisé comme un élément de sécurité. Des précautions
supplémentaires doivent être prises afin d'éviter des dommages matériels ou corporels.
Ce produit a été fabriqué sous un contrôle de qualité conséquent, mais s'il est installé sur des systèmes
où son dysfonctionnement entraîne des risques de dommages matériels ou corporels, alors des
dispositifs de sécurité externes supplémentaires doivent assurer des conditions de sécurité en cas
de défaillance du produit, afin d'éviter des accidents.
ATTENTION!
When in operation, electric energy systems – such as transformers, converters, motors and cables
– generate electromagnetic fields (EMF), posing a risk to people with pacemakers or implants who
stay in close proximity to them. Therefore, those people must stay at least 2 meters away from such
equipment.

Safety Instructions
1-4 | CFW-11M G2
1

General Information
CFW-11M G2 | 2-1
2
2 GENERAL INFORMATION
2.1 ABOUT THE MANUAL
This manual exposes how to install, to start-up in V/f (scalar) mode, the main characteristics and shows how to
troubleshoot the most common problems of the CFW-11M G2 inverter series.
It is also possible to operate the CFW-11M G2 in the following control modes VVW, Sensorless Vector and Vector
with Encoder. For further details on the inverter operation with other control modes, refer to the programming manual.
ATTENTION!
The operation of this equipment requires installation instructions and detailed operation provided
in the user manual, programming manual and manuals/guides for kits and accessories. The user's
manual and the parameters quick reference are supplied in a hard copy together with the inverter. The
user guides are also provided in a hard copy along with the kit/accessories. The other manuals are
available at www.weg.net. A printed copy of the files available on WEG’s website can be requested
at your local WEG dealer.
For information on other functions, accessories and operating conditions, refer to the following manuals:
Programming manual, with a detailed description of the parameters and advanced functions of the CFW-11.
Incremental encoder interface module manual.
I/O expansion module manual.
RS232/RS485 Serial communication manual.
CANopen Slave communication manual.
Anybus-CC communication manual.
2.2 TERMS AND DEFINITIONS USED IN THE MANUAL
Normal Duty (ND): the duty cycle that defines the steady state current value Inom-ND and an overload of 110 % during
1 minute. It is selected by programming P0298 (Application) = 0 (Normal Duty (ND)). It must be used for driving
motors that are not subject in that application to high torques with respect to their rated torque, when operating
at constant speed, during start, acceleration or deceleration.
Inom-ND:corrente nominal do inversor para uso com regime de sobrecarga normal (ND = Normal Duty).
Overload: 1.1 x Inom-ND/ 1 minute.
Heavy Duty (HD): the duty cycle that defines the steady state current value Inom-HD and an overload of 150 %
during 1 minute. It is selected by programming P0298 (Application) = 1 (Heavy Duty (HD)). It must be used for
driving motors that are subject in that application to high torques with respect to their rated torque, when operating
at constant speed, during start, acceleration or deceleration.
Inom-HD:inverter rated current for use with heavy duty cycle (HD = Heavy Duty).
Overload: 1.5 x Inom-HD / 1 minute.
Current Imbalance (%):
Unbalance at power unit X - phase Y = .100
IYX - IYAVG
IYAVG
IYAVG =IY1 + IY2 + ... + IYN
N

General Information
2-2 | CFW-11M G2
2
Where:
N = number of the power units.
IYN = current of phase Y (U, V or W) of the power unit N (P0815 to P0829).
IYAVG = average current of phase Y.
Rectifier: input circuit of the inverters which converts the AC input voltage into DC. Formed by thyristors or power
diodes.
Pre-Charge Circuit: it charges the DC link capacitors with a limited current, thus avoiding higher current peaks
when powering the inverter.
DC link: inverter intermediate circuit; DC voltage obtained from the rectification of the AC input voltage or from
an external power supply. It feeds the inverter output IGBTs bridge.
DC+: Positive terminal of the DC Link.
DC-: Negative terminal of the DC Link.
U, V, W Arms: set of two IGBTs forming the inverter output phases U, V, and W.
IGBT: insulated Gate Bipolar Transistor, basic component of the output inverters. They work as an electronic
switch in the saturated (closed switch) and cut-off (open switch) modes.
Braking IGBT: It works as a switch to turn on the braking resistors. It is controlled by the DC link level.
PTC: resistor whose resistance value in ohms increases proportionally to the temperature; used as temperature
sensor on motors.
NTC: resistor which resistance value in ohms decreases proportionally to the temperature increase; used as a
temperature sensor in power modules.
HMI: Human-Machine Interface; it is the device that allows the control of the motor, the visualization and the
modification of the inverter parameters; it's also known as keypad. The CFW-11M G2 HMI presents keys for
commanding the motor, navigation keys and a graphic LCD display.
FLASH Memory: nonvolatile memory that can be electrically written and erased.
RAM memory: random access memory.
USB: Universal Serial Bus; serial communication protocol conceived to work according to the plug-and-play
concept.
PE: Protective earth.
RFI Filter: radio Frequency Interference Filter; filter to reduce interference in the radio frequency band.
PWM: Pulse Width Modulation; a pulsed voltage that feeds the motor.
Switching Frequency: switching frequency of the IGBTs of the inverter bridge, normally expressed in kHz. Also
known as carrier frequency.
General Enable: when activated, it accelerates the motor via acceleration ramp. When deactivated, this function
immediately blocks the PWM pulses. The general enable function can be controlled through a digital input
programmed for this function or via serial communication.

General Information
CFW-11M G2 | 2-3
2
Run/Stop: inverter function that when activated (Run) accelerates the motor with the acceleration ramp until
reaching the speed reference, and when deactivated (Stop) decelerates the motor with the deceleration ramp down
to stop. It can be commanded through a digital input programmed for that function or via serial communication.
The HMI (Run) and (Stop) keys operate in a similar way.
Heatsink: piece of metal designed to dissipate heat generated by power semiconductors.
UP11 G2: power Unit of the CFW-11M G2.
UC11 G2: control Unit of the CFW-11M G2
PLC: programmable logic controller.
Amp, A: ampere.
°C: degrees celsius.
AC: alternate current.
DC: direct current.
CFM: cubic feet per minute; a flow measurement unit.
cm: centimeter.
ft: foot.
hp: horse power = 746 Watts; unit of power, usually used to indicate mechanical power of electric motors.
Hz: hertz.
in: inch.
kg: kilogram = 1000 grams.
kHz: kilohertz = 1000 Hertz.
l/min: liters per minute.
lb: pound.
m: meter.
mA: milliampere = 0.001 ampere.
min: minute.
mm: millimeter.
ms: millisecond = 0.001 second.
Nm: Newton meter; torque measurement unit.
rms: root mean square; effective value.
rpm: revolutions per minute; unit of rotation.
s: second.
V: volts.

General Information
2-4 | CFW-11M G2
2
Ω: ohms.
2.3 ABOUT THE CFW-11M G2
The CFW-11M G2 inverters are the second generation of the CFW-11M inverters. The main differences in relation
to the previous generation are the following:
Smaller. The CFW-11M G2 is shorter and slimmer than the CFW-11M, allowing the installation of 3 UP11 G2 in
panels featuring 800 mm wide and 2000 mm high columns.
More modern. State-of-the-art components increased the inverter power.
The CFW11 G2 is a high-performance product which enables speed and torque control of three-phase induction
motors. The main characteristic of this product is the "Vectrue" technology, which provides the following advantages:
High compactness and power density.
Scalar control (V/f), VVW or vector control programmable in the same product.
The vector control can be programmed as “sensorless” (which means standard motors, without requiring
encoder) or as “vector control” with encoder on the motor.
The “sensorless” vector control allows high torque and fast response, even at very low speeds or at the start.
The “vector with encoder” control allows high speed precision for the whole speed range (even with a standstill
motor).
"Optimal Braking" function for vector control, allowing the controlled braking of the motor, eliminating the use of
braking resistor in some applications.
"Self-Tuning" function for vector control: It allows the automatic setting of control parameters and regulators
based on the identification (also automatic) of the motor parameters and load.
The CFW-11M G2 inverters present a modular structure, with configurations from one to five power units (UP11
G2), one control unit (UC11 G2) and wiring cables. The modular assembly increases the reliability of the inverter
and simplifies its maintenance. There is a single control unit (UC11 G2) which can control up to 5 UP11s G2.
The UP11s and UC11 G2 are supplied trough a power supply of +24 Vdc. Figure 2.1 on page 2-5 shows a general
diagram of the inverter, considering the configuration with three UP11s connected in parallel.
The control of the power units is done by the UC11 G2 control unit. The control unit contains the control rack of
the CFW-11 line and the ICUP board. This board sends signals to all UP11 G2 (PWM, control signals, etc.), and it
receives signals from them (current, voltage feedback, etc.).

General Information
CFW-11M G2 | 2-5
2
220 Vac power
supply external fans
24 Vac power
supply external fans
UP11 3
UP11 2
Fans
U
V
WMotor
Feedback:
- voltage
- current
DC+
DC supply
Capacitor
brank
IGBT'S
RFI Filter
Power
Control
ICUP Power supplies and interfaces
between power and control
External 24
Vdc power
electronics UC11
Accessories
Expansion I/O
(slot 1 - white)
Encoder interface
(slot 2 - yellow)
COMM 1
(slot 3 - green)
COMM 2
(anybus) (slot 4)
USB
HMI
HMI (remote)
Software SuperDrive G2
Software WLP
Digital inputs
(DI1 to DI6)
Analog inputs
(AI1 to AI6)
FLASH
memory
module
Analog outputs
(AO1 and AO2)
CC11
Control
board with
a 32 bits
"RISC"
CPU
Digital outputs DO1
(RL1) to DO3 (RL3)
PC
PWM
PE
DC-
Fans
Power unit IGBT'S
Fans
UP11 1
Figure 2.1: Block diagram for the CFW-11M G2

General Information
2-6 | CFW-11M G2
2
Figure 2.2: Power Unit (UP11)
Figure 2.3: Control Unit (UC11)

General Information
CFW-11M G2 | 2-7
2
NOTE!
Several additional items are necessary for mounting the complete drive, such as input rectifier, fuses
in the DC supply of each power unit UP11, external pre-charge circuit and an input reactor with a
minimum impedance of 3 % in case of a 6 pulse rectifier.
NOTE!
The inclusion of a current transformer (CT) in the drive for the output short-circuit to the ground
protection is not necessary because each UP11 has its own internal protection.
2.4 IDENTIFICATION LABEL FOR THE UC11 G2
The UC11 nameplate is located on the control rack.
Manufacturing date (30
corresponds to the week
and L to the year)
WEG part number
UC11 model
Serial number
Figure 2.4: Nameplate of the UC11
Nameplate
Figure 2.5: Nameplate location

General Information
2-8 | CFW-11M G2
2
2.5 IDENTIFICATION LABEL FOR THE UP11 G2
The nameplate is located on the front of the UP11 G2.
MOD.: UP11-01 G2
MAT.: 13353741 MAX. TA: 40 ºC (104 °F)
OP.: 8888888888 SERIAL#: 8888888888
PESO/WEIGHT: 94 kg (42,6 lb) 12 0
LINK DC
OUTPUT
SALIDA
SAÍDA
574-970 V DC 0-0,71*VDC
VAC 3~
A (ND)
60s/3s 570 A 496 A 496 A / 744 A
A (HD)
60s/3s 437 A 380 A 570 A / 760 A
758-1150 V DC 0-0,71*VDC
VAC 3~
A (HD)
60s/3s 505 A 439 A 483 A / 744 A
A (HD)
60s/3s 390 A 340 A 570 A / 680 A
Hz 50/60 Hz 0-200 Hz
FABRICADO NO BRASIL
HECHO EN BRASIL
MADE IN BRAZIL
WEG, CP420 - 89256-900
Jaraguá do Sul - Brazil
UP11-01 G2
13353741
SERIAL#: 8888888888 12 0
7 909322 138893
Model of the UP11
WEG part number
Inverter net weight
Rated input data (voltage, rated
currents for operation with normal
duty and heavy duty, frequency)
Current specifications for
operation with normal duty (ND)
Current specifications for
operation with heavy duty (HD)
Manufacturing date (48 corresponds
to the week and H to the year)
Maximum ambient temperature
around the inverter
Rated output data (voltage, number of
phases, rated currents for operation
with normal duty (ND) and heavy duty
(HD), overload currents for 1 min and
3 s and frequency band)
Serial number
Figure 2.6: UP11 G2 nameplate
Nameplate
Figure 2.7: Location of the Nameplates

General Information
CFW-11M G2 | 2-9
2
2.6 HOW TO SPECIFY THE MODEL OF THE CFW-11M G2 (SMART CODE)
In order to specify the model of the CFW-11M G2, replace the smart code values with the desired rated supply
voltage and rated output current in the respective fields for operation under normal duty (ND), as shown in the
example of Table 2.1 on page 2-9.
Table 2.1: Smart code
Inverter Model Available Options
See the list of models in Chapter 8 TECHNICAL
SPECIFICATIONS on page 8-1, which also contains the
technical specifications of the inverters
See Chapter 7 ACCESSORIES on page 7-1 for further
details on the optional items
Example BR CFW11MG2 0634 T 4 (*) S _ _ _ _ _ _ _ _ Z
Field denomination
Market identification (sets the language of the manual and factory settings)
WEG frequency inverter - series 11
Rated output current for use under normal duty (ND)
Number of output phases
Rated output voltage
Optional items
Braking Safety stop Special
hardware
Special software
Final coding indicator digit
Possible options
2 characters T = Three-
phase
4 = 380...480 V 5 = 500...600 V 6 = 660...690 V
S = standard product O = Product with optional item
Blank = standard (no internal dynamic braking) RB = regenerative braking
Y = with safety stop according to EN-954- 1 category 3
Blank = standard H1 = special hardware #1
Blank = standard S1 = special software #1

General Information
2-10 | CFW-11M G2
2
E.g.: CFW11MG21205T4OYZ corresponds to a CFW-11M G2 three-phase inverter of 1205 A, with input supply
voltage from 380 V to 480 V, with optional safety stop. The options for the inverter rated current under normal
duty (ND) are in Table 3.2 on page 2-10, according to the inverter rated output voltage.
Table 3.2: Rated currents under normal duty (ND)
380-480 V 500-600 V 660-690 V
0634 = 634 A 0496 = 496 A 0439 = 439 A
1205 = 1205 A 0942 = 942 A 0834 = 834 A
1807 = 1807 A 1414 = 1414 A 1251 = 1251 A
2409 = 2409 A 1885 = 1885 A 1668 = 1668 A
3012 = 3012 A 2356 = 2356 A 2085 = 2085 A
2.7 RECEIPT AND STORAGE
The power units of the CFW-11M G2 are supplied in a wooden box.
The control units of the CFW-11M G2 are supplied in a cardboard box.
There is an identification label affixed to the outside of the package, the same as the one fixed on the inverter.
In order to open the package:
1. Remove the front cover of the package.
2. Remove the styrofoam protection.
Check if:
1. The nameplates correspond to the models purchased.
2. There were any damages during transportation.
Report any damage immediately to the carrier.
If the products are not immediately installed , store them in a clean and dry location (temperature between –
25 ºC and 60 ºC), with a cover to prevent the ingress of dust.
Figure 2.8: Do not tilt the power units
