Type TK17 H2
Operating instructions ⋅Betriebsanleitung Date: 09/22
WEH®Hydrogen fueling nozzle
WEH®Füllkupplung zur Wasserstoffbetankung

Die deutsche Version ist das Original.
Hersteller: WEH GmbH Gas Technology - im Nachfolgenden „WEH“ genannt.
The German version is the original.
Manufacturer: WEH GmbH Gas Technology - hereafter referred to as 'WEH'.
LANGUAGES
TYPE TK17 H2� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
WEH®Hydrogen fueling nozzle
TYP TK17 H2� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 50
WEH®Füllkupplung zur Wasserstoffbetankung
AE
DE

CONTENTS
1. INTRODUCTION 6
1.1 For your guidance 6
1.2 General information 7
1.3 Warranty and liability 7
1.4 General safety instructions 8
1.5 Definition of qualified personnel 9
2. INTENDED USE 9
3. PRODUCT OVERVIEW / PRODUCT DESCRIPTION 10
4. TECHNICAL DATA 14
5. STORAGE 17
5.1 Safety instructions for proper storage 17
5.2 Storage 18
6. REQUIRED TOOLS 19
7. INSTALLATION 20
7.1 Safety instructions for installation 20
7.2 Installation of filling hose 21
7.3 Installation of purging line (only TK17 H270 MPa with ENR) 21
7.4 Checking the connection for leak tightness 21
7.5 Connection of data cable (only TK17 H2with ENR) 22
7.6 Check of data interface function (Pos. 9) 22
7.7 Installation of braided protection hose 22
7.8 Optimization of fueling nozzle at a fueling station with a dispenser mounting with
integrated purging system (only TK17 H2with ENR) 23
Type TK17 H2
WEH®Hydrogen fueling nozzle
MD-10013-L51-R1.6.0-03
Page 4
Operating instructions
AE

The German version is the original.
Manufacturer: WEH GmbH Gas Technology - hereafter referred to as 'WEH'.
8. OPERATION 24
8.1 Safety instructions for operation 24
8.2 Connection 25
8.3 Disconnection 26
9. INSPECTION | MAINTENANCE 27
9.1 Safety instructions for inspection and maintenance 27
9.2 Maintenance intervals 28
9.3 Overview of minimum intervals for inspection and maintenance 29
9.4 Maintenance 30
10. LUBRICATION 40
10.1 Safety instructions for lubrication 40
10.2 Lubrication 40
11. CHECKING THE LEAK RATE 41
11.1 Measuring the leak rate using a concentration meter 41
11.2 Safety instructions for connecting the service receptacle 42
11.3 Checking the leak rate 42
12. EXAMINATION AFTER SEPARATION 44
13. TROUBLESHOOTING 45
14. DISPOSAL 47
15. ACCESSORIES | SPARE PARTS 47
MD-10013-L51-R1.6.0-03 Page 5
Operating instructions AE

1. INTRODUCTION
Dear Customer,
Thank you for deciding to use our products.
The WEH®TK17 H2Fueling nozzle was specifically developed for refueling vehicles with
compressed gaseous hydrogen (CGH2).
Observe and follow all instructions and warnings in these operating instructions�
Non-observance may result in personal injury and/or property damage�
1�1 For your guidance
The markings and symbols contained in these operating instructions have the following
meanings:
- Items are indicated by a dash
ÎCalls for action are indicated by an arrow
Figures
The illustrations and/or images used in these operating instructions are particularly provided
for illustrative purposes only and may differ in some details from the actual product. For
binding information, please refer to your individual orders.
Abbreviations / Definitions
For explanation of abbreviations and definitions of terms see applicable Technical
Appendix of the corresponding catalog or www.weh.com
Definition of signal words
Caution: A section marked with 'Caution' warns you about hazards that could result in a
slight, usually reversible personal injury if you do not comply with this instruction.
Attention: Sections marked ‘Attention’ warn you of situations that could lead to property
damage and disruptions in operation if you do not comply with the instruction.
Note: Sections marked ‘Note’ indicate that malfunctions in operation may occur if you
do not comply with the instruction.
Please note: Sections marked with ‘Please note’ provide you with additional information
for smooth operation.
MD-10013-L51-R1.6.0-03
Page 6
Operating instructions
AE

1�2 General information
ÎFirst read these operating instructions to avoid misuse and resulting damage.
- In these operating instructions you will find all the necessary information and
instructions for the WEH®Product.
ÎThen check the contents of your delivery. Each delivery must contain:
- a delivery note
- an original WEH Test report (not applicable to spare parts)
- WEH operating instructions
ÎIf any documents are missing, please contact WEH or your responsible distributor.
1�3 Warranty and liability
- Our General Terms and Conditions apply.
ÎRead these operating instructions and safety instructions carefully and follow the
information contained therein.
- The information in these operating instructions reflects to the state of knowledge at
the time of printing. Failure to comply may void the warranty. Any side agreements
to these operating instructions require the written approval of the Head of the Quality
Department at WEH.
- Violation of these operating instructions result in the lapse of all warranty claims.
WEH will accept no liability for consequential damage, in particular damage due to
personal injury and/or other legal interests.
Caution: WEH®Products may only be repaired by WEH.
ÎContact WEH or the responsible distributor if the WEH®Product requires
maintenance. Special maintenance work that may be performed by the operator is
described in these operating instructions and is specially marked.
ÎOnly use original WEH®Spare parts. These are exactly suited to the intended
application and subject to strict quality controls.
- You yourself are solely responsible for the proper performance of the replacement or
repair. WEH is not responsible for the performance or any damage and/or losses aris-
ing from it. WEH assumes no guarantee, warranty, product liability or other liability
for any replacement or repair of the WEH®Product performed by you or a third party.
If you or a third party does not have the necessary skills and qualification for proper
performance, you must refrain from performing replacement or repair. Otherwise,
there is a particular risk of endangering yourself and third parties.
MD-10013-L51-R1.6.0-03 Page 7
Operating instructions AE

1�4 General safety instructions
ÎAlways comply with all applicable local, national and international requirements,
stipulations, decrees, laws, standards, provisions, directives, norms, regulations,
prohibitions and instructions as well as all applicable industrial, quality and tech-
nical standards. In particular, make sure that you and all users comply with the ap-
plicable requirements related to occupational health and safety as well as product
safety requirements and that all required permissions, certificates and approvals
have been obtained.
ÎThese operating instructions should be provided to anyone responsible for the
installation, operation and maintenance of this WEH®Product.
- The WEH®Product and these operating instructions are intended for use by
qualified personnel (see Chapter 1.5). Make these operating instructions available
in particular to the qualified personnel responsible for the individual phases of the
life cycle (especially for storage, installation, operation, inspection and mainte-
nance, troubleshooting and disposal) of the WEH®Product. The qualified personnel
must have read and understood these operating instructions.
ÎContact WEH before using the WEH®Product if the instructions in these operating
instructions are unclear in any way.
ÎTake appropriate safety measures if operating conditions exist that could endanger
the user.
ÎIn case of any damage that may affect the proper functioning of the WEH®Product,
do not use the WEH®Product until the situation has been clarified. Disassembly of
the WEH®Product may only be performed by WEH.
ÎComply with the assembly data indicated in these operating instructions. Tight-
ening with higher torques/assembly turns can result in damage or even fractures
when the system is pressurized.
ÎDo not use any auxiliary materials or cleaning agents other than those indicated
in these operating instructions. Using other auxiliary materials or cleaning agents
may cause damage to the WEH®Product or to downstream components.
- WEH is not responsible for damage caused by external forces or other external
influences.
- Proper transport and storage of the WEH®Product is assumed.
ÎDo not apply any external forces to the WEH®Product. Therefore, do not lean on the
(connected) WEH®Product, do not hang on the WEH®Product and do not climb on
the WEH®Product under any circumstances. In addition, refrain from hammering
on the WEH®Product or similar. Such force effects can lead to damage to property
and personal injury. Also make sure that the WEH®Product is protected from being
stepped on or run over in any way.
MD-10013-L51-R1.6.0-03
Page 8
Operating instructions
AE

- The WEH®Product can become very hot or very cold due to the possible fluids
flowing through it, depending on the application and operating situation. In this
regard, observe the national and international regulations on occupational health
and safety to prevent injuries.
1�5 Definition of qualified personnel
- Qualified personnel, as defined by these instructions, are persons who, based on
their professional training, their knowledge (including the relevant standards and
regulations), experience and manual skills, can independently assess and properly
perform assigned work tasks (in conjunction with WEH®Products) and can thus
independently recognize and prevent potential dangers at an early stage.
2. INTENDED USE
- The WEH®TK17 H2Fueling nozzle was specifically developed for refueling vehicles
with compressed gaseous hydrogen (CGH2).
- The WEH®TK17 H2Fueling nozzle with ENR is additionally equipped with a purging
line, that allows purging with dry nitrogen or dried air (dew point < -40°C) during
and after fueling process. This can prevent ingress of moisture and formation of ice
crystals when fueling with pre-cooled hydrogen. The efficiency of the purging line
has been successfully tested in compliance with the freezing test 7.26 from
ISO 17268.
ÎEnsure that the current valid specifications for the purity and quality of hydrogen for
vehicles are complied with.
ÎAlways ensure that the WEH®Product is used only for its intended use. Please note in
particular the technical data of the WEH®Product in Chapter 4 as well as the marking
on the WEH®Product itself.
- When used at sea or in the vicinity of the sea, increased salt and moisture content of
the air may cause faster wear and corrosion of the product. Please observe the spe-
cial maintenance instructions in Chapter 9.2 Maintenance intervals on page 28.
- This WEH®Product is generally classified as pressure accessory in accordance
with Article 2 (5) of the Pressure Equipment Directive 2014/68/EU and is
considered to be similar to piping. This WEH®Product may not be used as safety
accessory. Furthermore, it is pointed out, that this WEH®Product is designed and
placed on the market in accordance with the requirements of Article 4 (3) of the
Pressure Equipment Directive 2014/68/EU. The assessment with regard to a
different classification can, however, be made on request.
Caution: Any use beyond the scope of application is considered as unintended use
and may result in personal injury and/or property damage.
MD-10013-L51-R1.6.0-03 Page 9
Operating instructions AE

3. PRODUCT OVERVIEW / PRODUCT DESCRIPTION
Product overview - WEH®TK17 H2Fueling nozzle
TK17 H2without ENR*TK17 H2with ENR*
Series Car Truck Pressure PN Part no�
35 MPa 70 MPa
TK17 H235 MPa X X C1-174292
TK17 H235 MPa
High-Flow X X C1-160246
TK17 H235 MPa ENR*X X
C1-174293 (ATEX)
C1-174294 (NEC)
C1-174295(KTL)
TK17 H235 MPa ENR*
High-Flow X X
C1-162701 (NEC)
C1-160247 (ATEX)
C1-169447 (KTL)
TK17 H270 MPa X X C1-162708
TK17 H270 MPa ENR*X X
C1-160702-X01 (ATEX)
C1-160701-X01 (NEC)
C1-164846 (KTL)
C1-171177 (CCC)
*ENR = exchangeable infrared data interface
MD-10013-L51-R1.6.0-03
Page 10
Operating instructions
AE

Overview of Pressure Stage / Coding
Overview Receptacle TN1 H2
TN1 H2for IR*
TN1 H2High-Flow
TN1 H2High-Flow
for IR*
TN1 H270 MPa
TN1 H270 MPa
for IR*
Fueling nozzle Pressure PN 35 MPa 35 MPa 70 MPa
TK17 H235 MPa 35 MPa X X X
TK17 H235 MPa
High-Flow 35 MPa X X
TK17 H235 MPa ENR** 35 MPa X X X
TK17 H235 MPa ENR**
High-Flow 35 MPa X X
TK17 H270 MPa 70 MPa X
TK17 H270 MPa ENR** 70 MPa X
*IR = infrared data interface
** ENR = exchangeable infrared data interface
MD-10013-L51-R1.6.0-03 Page 11
Operating instructions AE

Product description
TK17 H2without ENR
Pos� Description
1 Impact protection
2 Cold protection
3 Logo cap
4250° swivel joint
(plastic thermal protection)
5 Locking lever
6 Actuation lever
7 Hand grip
Definition of ports
B1 Media inlet
B1
4
12 3
7
6
5
MD-10013-L51-R1.6.0-03
Page 12
Operating instructions
AE

TK17 H2with ENR
Pos� Description
1 Impact protection sleeve
2 Countersunk screws (3x)
3 Logo cap
4250° swivel joint
(plastic thermal protection)
5 Locking lever
6 Actuation lever
7 Hand grip
8 Data cable
9Data interface
(inside)
10 Purging line
Definition of ports
B1 Media inlet
P1 Purging line
10
4
1 2 3
7
6
8
5
9
B1
P1
MD-10013-L51-R1.6.0-03 Page 13
Operating instructions AE

4. TECHNICAL DATA
TK17 H2without ENR
Characteristics Basic version
Nominal bore (DN) 4 mm
Pressure range
PN = 35 MPa | PS = 45 MPa (High-Flow)
PN = 35 MPa | PS = 49 MPa
PN = 70 MPa | PS = 87.5 MPa
Maximum allowable op-
erating pressure (when
not connected)*PS = 50 MPa (valid only for TK17 H270 MPa)
Media temperature
range -40 °C to +85 °C
Ambient temperature
range -40 °C to +85 °C
Part materials Wear-resistant stainless steel, corrosion-resistant surfaces
Sealing materials Hydrogen-resistant
Nozzle type Type C acc. to SAE J2600:2015 and previous resp. ISO 17268:2012
and previous
Design With plastic thermal protection, cold protection and hand grip
Weight Approx. 1.8 kg - 1.9 kg
Conformities /
Tests /
Approvals
- Tests acc. to SAE J2600:2002
*Note: If the fueling nozzle is loaded with pressures > 50 MPa when not connected, leackages
may occur that are higher than that defined by international standards.
MD-10013-L51-R1.6.0-03
Page 14
Operating instructions
AE

TK17 H2with ENR
Characteristics Basic version
Nominal bore (DN)
fuelling nozzle 4 mm
Nominal bore (DN)
purging line 4 mm
Pressure range
fueling nozzle
PN = 35 MPa | PS = 45 MPa (High-Flow)
PN = 35 MPa | PS = 49 MPa
PN = 70 MPa | PS = 87.5 MPa
Maximum allowable
operating pressure
(when not connected)*PS = 50 MPa (valid only for TK17 H270 MPa)
Flow rate during
purging** 500 Nl/h at max. 12 bar purging pressure
Medium for purging** Nitrogen
Media temperature range
fueling nozzle -40 °C to +85 °C
Ambient temperature
range fueling nozzle -40 °C to +85 °C
Media temperature range
purging medium** -20 °C to +85 °C
Part materials Wear-resistant stainless steel, corrosion-resistant surfaces
Sealing materials Hydrogen-resistant
Nozzle type Type C acc. to SAE J2600:2015 and previous resp.
ISO 17268:2012 and previous
Design
With plastic thermal protection, cold protection, hand grip with
magnet, exchangeable data interface acc. to SAE TIR J2799 and
integrated purging line
Weight Approx. 2.4 kg
Conformities /
Tests /
Approvals
Fueling nozzle:
- Tests acc. to SAE J2600:2002
IR data interface:
- SAE TIR J2799
- ATEX, NEC, KTL or CCC
* Note: If the fueling nozzle is loaded with pressures > 50 MPa when not connected,
leackages may occur that are higher than that defined by international standards.
** The efficiency of the purging line has been successfully tested in compliance with the
freezing test 7.26 from ISO 17268
MD-10013-L51-R1.6.0-03 Page 15
Operating instructions AE

Data interface
Characteristics Basic version
Signal input format J2799
Signal output format RS485
Sensitivity level 0.57 - 0.060 A/W
Band width 870 - 950 nm
Mains voltage 5 V DC
Minimum voltage 3.7 V
Allowable current 20 mA
Allowable power
supply voltage 16 V
Data voltage 0 - 5.5 V
Output voltage level 0 - 6 V
Protection class IP66
Pin assignment of connector on the data cable
Connector Color Signal
1 Brown 5 V DC voltage
2 Blue 5 V DC ground
3 White RD 458 Data +
4 Black RD 458 Data -
42
13
MD-10013-L51-R1.6.0-03
Page 16
Operating instructions
AE

5. STORAGE
5�1 Safety instructions for proper storage
ÎMake sure that you always comply with these following safety instructions and
storage time.
Attention: Improper storage of the WEH®Product can significantly reduce the
maximum service life.
ÎProtect the WEH®Product against damage, contamination, inappropriate storage
and excessive temperature fluctuations.
ÎStore the WEH®Product, the accessories and spare parts in the original packaging
until they are used for the first time and during periods when they are not being used.
ÎStore the WEH®Product within a temperature range of -40 °C up to +40 °C.
Storage temperatures outside this range may affect the service life of the
WEH®Product.
ÎDo not store the WEH®Product in the vicinity of heat sources. Avoid humidity and
condensation. The ideal relative air humidity for storage is approx. 65%.
ÎDo not store the WEH®Product together in the same space with solvents, chemicals,
acids, fuels or disinfectants.
ÎProtect the WEH®Product against light, in particular direct sunlight, oxygen, ozone,
heat, UV radiation, and other negative environmental influences. The service life of
parts made of elastomer or plastic may be substantially reduced by such
environmental factors.
ÎDo not stack WEH®Products. For storage and retrieval, follow the first-in-first-out
(FIFO) principle.
MD-10013-L51-R1.6.0-03 Page 17
Operating instructions AE

5�2 Storage
ÎFollow the safety instructions in Chapter 5.1 and observe the following storage times.
The allowable storage time is valid from the date of delivery (invoice/goods issue
date from WEH or the distributor) on the label of the packaging. If the WEH®Product
is installed in a complete system, the storage time depends on the component with
the shortest storage time.
Up to 3 years
ÎBefore use, check the surfaces of the external seals for cracks.
Attention: Any elastomer seals with fine cracks on the surface must
be replaced.
Note: If you should have any doubts about the aging state of the
stored WEH® Product, please contact WEH.
Attention: Before commissioning, check the WEH® Product for leak
tightness. On this topic, see Chapter 7. Installation on page 20.
> 3 years - Before use, all elastomer seals must be replaced.
ÎFor this, send the WEH®Product to WEH for maintenance.
MD-10013-L51-R1.6.0-03
Page 18
Operating instructions
AE

6. REQUIRED TOOLS
Part no� Description Installation Checking
the leak rate
Mainte-
nance &
Lubrication
C1-148079 WEH®TNS1 H2
Service receptacle X X X
WKZ-148012 WEH®Assembly tool X X
-- Open-ended wrench A/F14 X X
-- Calibrated torque wrench
(suitable for corresponding torque) X X
-- Hexagonal bit insert A/F2
(suitable for corresponding torque) X X
-- Hexagonal screwdriver A/F2 X X
-- Crosshead bit insert PH2
(suitable for corresponding torque) X
-- Hexagonal bit insert with ball
point A/F4
(suitable for corresponding torque) X
-- Hexagonal screwdriver A/F2.5 X
-- Slotted screwdriver X
-- Crosshead screwdriver PH2 X
-- Hexagonal key wrench A/F4 X
-- Vice with plastic jaws X
E99-88933 WEH®Lubricant X
E99-90160 WEH®Threadlocking adhesive X
E99-35 WEH®Adhesive X
E99-9 WEH®Degreasing spray X
E99-44923 WEH®Maintenance spray X
MD-10013-L51-R1.6.0-03 Page 19
Operating instructions AE

7. INSTALLATION
Please note: Subsequent mentions of descriptions and position numbers refer to
Chapter 3. Product overview / product description on page 10.
7�1 Safety instructions for installation
ÎCheck the information provided in these operating instructions and the label on the
WEH® Product. The information must conform to your application.
ÎOnly connect the WEH®Product to faultless connections.
ÎCheck the WEH®Product for transport damages, contamination and other damage.
If you should detect anything wrong with the WEH®Product, it may no longer be used.
Replace the WEH®Product or send it to WEH for maintenance.
ÎRemove transport securing devices (such as protection caps) before installing the
WEH®Product. Transport locks are designed to protect the product and the
connections during transport and storage. The transport securing devices are not,
for example, designed to withstand pressure or to be used as plugs.
ÎEnsure that the system is depressurized. Installation must only be effected in
depressurized condition.
ÎBefore installation, check if the counterparts are designed to withstand the assembly
data (see Chapter 7.2 Installation of filling hose) that WEH determined for this
WEH®Product.
Note: The assembly data (torques, assembly turns etc.) are values which apply
exclusively to the components delivered by WEH.
ÎBefore commissioning, make sure that the used hoses and the breakaway coupling
are also suitable for the application (e.g. filling with cryogenic medium).
MD-10013-L51-R1.6.0-03
Page 20
Operating instructions
AE
