Wells HDW-2D User manual

WELLS MANUFACTURING
10 Sunnen Dr., St. Louis, MO 63143
telephone: 314-678-6314
fax: 314-781-2714
www.wellsbloomfield.com
IMPORTANT: DO NOT DISCARD THIS MANUAL
This manual is considered to be part of the appliance and is to be given to the OWNER or
MANAGER of the restaurant, or to the person responsible for TRAINING OPERATORS of
this appliance. Additional manuals are available from your WELLS DEALER.
THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR
INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any
questions concerning installation, operation or maintenance of this equipment.
OWNERS MANUAL
BUILT-IN
DISHER WELL
WARMER
MODELS
HDW-2
HDW-2D
Includes
INSTALLATION
USE & CARE
EXPLODED VIEW
PARTS LIST
WIRING DIAGRAM
025
p/n 2M-Z14353 Rev. (C) M025 140224
HDW-2

Unless otherwise specied, all commercial cooking
equipment manufactured by Wells Manufacturing is
warranted against defects in materials and workmanship
for a period of one year from the date of original installation
or 18 months from the date of shipment from our factory,
whichever comes rst, and is for the benet of the original
purchaser only.
THIS WARRANTY IS THE COMPLETE AND ONLY
WARRANTY, EXPRESSED OR IMPLIED IN LAW
OR IN FACT, INCLUDING BUT NOT LIMITED TO,
WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR ANY PARTICULAR PURPOSE, AND/OR FOR
DIRECT, INDIRECT OR CONSEQUENTIAL DAMAGES IN
CONNECTION WITH WELLS BLOOMFIELD PRODUCTS.
This warranty is void if it is determined that, upon inspection
by an authorized service agency, the equipment has been
modied, misused, misapplied, improperly installed, or
damaged in transit or by re, ood or act of God. It also
does not apply if the serial nameplate has been removed,
or if service is performed by unauthorized personnel. The
prices charged by Wells Manufacturing for its products are
based upon the limitations in this warranty. Seller’s obligation
under this warranty is limited to the repair of defects without
charge by a Wells Manufacturing factory authorized service
agency or one of its sub-service agencies. This service
will be provided on customer’s premises for non-portable
models. Portable models (a device with a cord and plug)
must be taken or shipped to the closest authorized service
agency, transportation charges prepaid, for service. In
addition to restrictions contained in this warranty, specic
limitations are shown in the Service Policy and Procedure
Guide. Wells Manufacturing authorized service agencies are
located in principal cities. This warranty is valid in the United
States and Canada and void elsewhere. Please consult your
classied telephone directory, your foodservice equipment
dealer or contact:
Wells Manufacturing
10 Sunnen Dr., St. Louis MO 63143 USA
phone (314) 678-6314 or fax (314) 781-2714
for information and other details concerning warranty.
LIMITED WARRANTY STATEMENT
SERVICE POLICY AND PROCEDURE GUIDE and ADDITIONAL WARRANTY EXCLUSIONS
NOTE: For your protection, please note that equipment
in this shipment was carefully inspected and packaged
by skilled personnel before leaving the factory. Upon
acceptance of this shipment, the transportation company
assumes full responsibility for its safe delivery.
IF SHIPMENT ARRIVES DAMAGED:
1. VISIBLE LOSS OR DAMAGE: Be certain that any
visible loss or damage is noted on the freight bill or
express receipt, and that the note of loss or damage is
signed by the delivery person.
2. FILE CLAIM FOR DAMAGE IMMEDIATELY:
Regardless of the extent of the damage.
3. CONCEALED LOSS OR DAMAGE: if damage is
unnoticed until the merchandise is unpacked, notify the
transportation company or carrier immediately, and le
“CONCEALED DAMAGE” claim with them. This
should be done within fteen (15) days from the date
the delivery was made to you. Be sure to retain the
container for inspection.
Wells Manufacturing cannot assume liability for damage or
loss incurred in transit. We will, however, at your request,
supply you with the necessary documents to support your
claim.
SHIPPING DAMAGE CLAIM PROCEDURE
xi
1. Resetting of safety thermostats, circuit breakers, over
load protectors, and/or fuse replacements are not
covered by this warranty unless warranted conditions
are the cause.
2. All problems due to operation at voltages or phase
other than specied on equipment nameplates are
not covered by this warranty.
Conversion to correct voltage and/or phase must be
the customer’s responsibility.
3. All problems due to electrical connections not made
in accordance with electrical code requirements
and wiring diagrams supplied with the equipment are
not covered by this warranty.
4. Replacement of items subject to normal wear, to
include such items as knobs, light bulbs; and, normal
maintenance functions including adjustments of
thermostats, adjustment of micro switches and
replacement of fuses and indicating lights are not
covered by warranty.
5. Damage to electrical cords and/or plug due to exposure
to excessive heat are not covered by this warranty.
6. Full use, care, and maintenance instructions supplied
with each machine. Noted maintenance and
preventative maintenance items, such as servicing and
cleaning schedules, are customer responsibility.
Those miscellaneous adjustments noted are customer
responsibility. Proper attention to preventative
maintenance and scheduled maintenance procedures
will prolong the life of the appliance.
7. Travel mileage is limited to sixty (50) miles from an
Authorized Service Agency or one of its sub-service
agencies.
8. All labor shall be performed during regular working
hours. Overtime premium will be charged to the buyer.
9. All genuine Wells replacement parts are warranted
for ninety (90) days from date of purchase on non-
warranty equipment. This parts warranty is limited only
to replacement of the defective part(s). Any use of
non-genuine Wells parts completely voids any
warranty.
10. Installation, labor, and job check-outs are not
considered warranty and are thus not covered by this
warranty.
11. Charges incurred by delays, waiting time or operating
restrictions that hinder the service technician’s ability to
perform service are not covered by warranty. This
includes institutional and correctional facilities.
M025 2M-Z14353 Owners Manual for Built-In Disher Well Warmer

1
M025 2M-Z14353 Owners Manual for Built-In Disher Well Warmer
WARRANTY xi
FEATURES & OPERATING CONTROLS 2
PRECAUTIONS & GENERAL INFORMATION 3
AGENCY LISTING INFORMATION 3
INSTALLATION 4
OPERATION 6
MAINTENANCE INSTRUCTIONS 7
CLEANING INSTRUCTIONS 8-9
TROUBLESHOOTING SUGGESTIONS 10
WIRING DIAGRAM 11
EXPLODED VIEW & PARTS LIST 12-13
PARTS & SERVICE 17
CUSTOMER SERVICE DATA 17
Thank You for purchasing this Wells Manufacturing appliance.
Proper installation, professional operation and consistent maintenance of this appliance will ensure that it
gives you the very best performance and a long, economical service life.
This manual contains the information needed to properly install this appliance, and to use and care for the
appliance in a manner which will ensure its optimum performance.
TABLE OF CONTENTS
INTRODUCTION
SPECIFICATIONS
MODEL VOLTS AMPS WATTS POWER SUPPLY CORD
HDW-2, HDW-2D, HDW-2F 120 VAC 1ø 2.5A 300W NEMA5-15 PLUG

2
M025 2M-Z14353 Owners Manual for Built-In Disher Well Warmer
FEATURES & OPERATING CONTROLS
A. CONTROLS
1. Units are equipped with a lighted power switch which illuminates when the
unit is turned on.
2. When the unit begins heating, ll the basin with water.
A temperature of 145°F to 160°F (62°C to 71°C) will be maintained.
B. MOUNTING
1. Units are equipped with Bowl Clamps (qty 3) which are designed to secure
the unit rmly in place on a stainless steel countertop.
NOTE:This appliance is designed to be used on stainless steel countertop only.
2. See the Installation Instructions, supplied with the this appliance, for
details.
C. DRAINS
1. These units are equipped with an overow drain and a Stand Pipe
Assembly. When the Stand Pipe is removed the entire bowl drains.
Faucet
(optional with some models)
Stand Pipe &
Drian Overflow
3/4” Drain
Power Cord
See Detail A
Lighted
Power Switch
Nameplate
IL2157a
IL2158
MOUNTING
BRACKET
Detail A

3
M025 2M-Z14353 Owners Manual for Built-In Disher Well Warmer
PRECAUTIONS AND GENERAL INFORMATION
E27255
AGENCY LISTING INFORMATION
Refer to the product nameplate for the specic appliance for agency
listings. In general:
This appliance conforms to NSF Standard 2 for sanitation only if
installed in accordance with the supplied Installation Instructions.
UL Listed warmers are U Listed under UL File E27255.
STD 2
UL Listed Warmers
WARNING:
SHOCk HAzARD
All servicing requiring
access to non-insulated
electrical components must
be performed by a factory
authorized technician.
DO NOT open any access
panel which requires the use
of tools. Failure to follow this
warning can result in severe
electrical shock.
CAUTION:
RISk OF
DAMAGE
DO NOT connect or energize
this appliance until all
installation instructions are
read and followed. Damage
to the appliance may result
if these instructions are not
followed.
CAUTION:
HOT SURFACE
Exposed surfaces can be hot
to the touch and may cause
burns.
This appliance is intended for use in commercial establishments only.
This appliance is a perpetual-ow sink used to rinse utensils
being used for food preparation
. No other use is
recommended or
authorized by the manufacturer or its agents.
Operators of this appliance must be familiar with the appliance use,
limitations and associated restrictions. Operating instructions must be
read and understood by all persons using or installing this appliance.
Cleanliness of this appliance is essential to good sanitation. Read and
follow all included cleaning instructions and schedules to ensure the
safety of the food product.
Disconnect this appliance from electrical power before performing any
maintenance or servicing.
This appliance is not jet stream approved. Do not direct water jet
or steam jet at this appliance, or at any control panel or wiring. Do
not splash or pour water on, in or over any controls, control panel or
wiring.
Exposed surfaces of this appliance can be hot to the touch and may
cause burns.
Do not operate this appliance if the control panel is damaged.
Call your Authorized Wells Service Agent for service.
The technical content of this manual, including any wiring diagrams,
schematics, parts breakdown illustrations and/or adjustment
procedures, is intended for use by qualied technical personnel.
Any procedure which requires the use of tools must be performed by a
qualied technician.
This manual is considered to be a permanent part of the appliance.
This manual and all supplied instructions, diagrams, schematics,
parts breakdown illustrations, notices and labels must remain with the
appliance if it is sold or moved to another location.
This appliance is made in the USA. Unless otherwise noted, this
appliance has American sizes on all hardware.

4
M025 2M-Z14353 Owners Manual for Built-In Disher Well Warmer
NOTE: DO NOT discard
the carton or other packing
materials until you have
inspected the appliance for
hidden damage and tested it
for proper operation.
Refer to SHIPPING DAMAGE
CLAIM PROCEDURE on the
inside front cover of this
manual.
WARNING:
RISk OF INjURY
Installation procedures must
be performed by a qualied
technician with full knowledge
of all applicable electrical and
plumbing codes. Failure can
result in personal injury and
property damage.
CAUTION
FIRE HAzARD
Avoid storing ammable or
combustible materials in, on
or near the appliance.
NOTE: Damage caused
by leaks due to improper
installation is NOT covered by
warranty.
UNPACkING & INSPECTION
Carefully remove the appliance from the carton. Remove all protective
plastic lm, packing materials and accessories from the Appliance
before connecting electrical power or otherwise performing any
installation procedure.
Carefully read all instructions in this manual and the Installation
Instruction Sheet packed with the appliance before starting any
installation.
Read and understand all labels and diagrams attached to the
appliance.
Carefully account for all components and accessories before
discarding packing materials. Store all accessories in a convenient
place for later use.
INSTALLATION NOTES
1. Installation and start up of built-in warmers MUST be performed
by an authorized installation company.
2. It is the RESPONSIBILITY OF THE INSTALLER to verify that
this warmer installation is in compliance with the specications listed in
this manual and on the specication sheet provided.
3. It is the RESPONSIBILITY OF THE INSTALLER to check with
the AUTHORITY HAVING JURISDICTION, in order to verify
that this warmer installation is in compliance with local code
requirements.
4. Water supply and drain installation must meet all applicable
local, state and federal plumbing codes and ordinances.
5. Refer to Installation Instructions included with the warmer for
Underwriters Laboratories conditions of acceptability, electrical
requirements and other installation concerns.
BUILT-IN WARMERS
1. This is a GENERAL GUIDE. For specic cutout dimensions
and other installation details, refer to the Installation Instructions
supplied with the warmer.
2. Cutout dimensions for disher well and optional faucet are listed on the
Installation Instructions provided with the warmer.
NOTE: Verify the dimensions are correct for the installation before
making the cutout.
3. Securing the disher well to a stainless steel countertop:
a. Verify that provided sealants are applied to the underside
of the warmer top ange prior to setting the unit into the cutout.
b. Units are equipped with Bowl Clamps (qty 3) which are designed
to secure the unit rmly in place on a stainless steel countertop.
c. Apply a thin bead of food-grade silicone sealant around the
ange to seal it to the counter.
NOTE: IF THE WARMER IS INSTALLED ABOVE A FOOD STORAGE
CABINET. A SEALED BARRIER MUST BE PROVIDED BELOW THE
WARMER
INSTALLATION
3 1/8”
6” Dia.
3 1/8”
45°
OPTIONAL FAUCET
0.875” for Wells Supplied
Faucet Other Faucets
Sizes May Vary
FRONT
IL2159a

5
M025 2M-Z14353 Owners Manual for Built-In Disher Well Warmer
INSTALLATION
ELECTRICAL INSTALLATION
1. Refer to the product nameplate. Verify the electrical service power.
Voltage and phase must match the nameplate specications.
Wiring the warmer to the wrong voltage can severely damage the
unit or cause noticeably decreased performance.
2. Available electrical service amperage must meet or exceed the
specications listed on the specication sheet provided with the
warmer.
3. Warmer and control unit must be connected to an appropriate
building ground. Ground connection will be marked “GND” or
” “ .
NOTE: Wire gauge, insulation type and temperature rating , as
well as type, size and construction of conduit, must meet or exceed
applicable specications of local codes and of the National
Electrical Code.
E. PLUMBING INSTALLATION
For use in the State of Massachusetts, this appliance must be
installed in compliance with Massachusetts Fuel Gas and
Plumbing Code CMR 248.
1. IMPORTANT: All plumbing installations must be performed by
a qualied plumber.
2. These units are equipped with a 3/4” drain and will require a
DRAIN LINE: Some jurisdictions may require an approved air
gap or other back-ow prevention device in the drain. It is the
responsibility of the plumber to determine such requirement, to
provide and properly install the required device.
3. For HDW-2 units, the 3/4” drain must be attached with a union
at the drain line tting. This is necessary to provide for future
maintenance to the unit.
CAUTION:
SHOCk HAzARD
The ground lug of this
appliance must be connected
to a suitable building ground.
IMPORTANT:
Contact a licensed electrician
to install and connect electrical
power to the appliance.
IMPORTANT:
Damage due to being
connected to the wrong
voltage or phase is NOT
covered by warranty.
IMPORTANT: Electrical
installation other than as
specied on the specication
sheet will void the UL listing,
and may void the warranty.
NOTE: Plumb connections
must be made in compliance
with all Federal, State and
Local Plumbing Codes and
Ordinances.
NOTE: Damage caused
by leaks due to improper
installation is NOT covered by
warranty.

6
M025 2M-Z14353 Owners Manual for Built-In Disher Well Warmer
OPERATION
WET OPERATION for DISHER WELL
1. This unit is designed to be used for WET operation, add tap water
before turning the warmer on. Allow the disher well to preheat for
approximately 30 minutes prior to using.
a. Check the water level frequently and add water as necessary
to refresh the water in the basin, or to prevent the warmer from
running dry.
b. If your wet-operation warmer is allowed to run dry, turn it OFF and
allow to cool to room temperature before adding water.
4. Damage caused by allowing a wet-operation warmer to run dry,
is NOT covered by warranty. Damage caused by adding water
to a dry warmer when hot is NOT covered by warranty.
OPERATION
1. Use this appliance as a safe location to store and rinse your
utensils, DO NOT place food directly into the warmer.
2. Check water level in the warmer frequently during use.
3. DO NOT use metal tools, steel wool, or caustic or abrasive cleanser to
clean warmer pan.
CAUTION:
HOT SURFACE
Exposed surfaces can be hot
to the touch and may cause
burns.
CAUTION:
SHOCk HAzARD
DO NOT splash or pour water
onto control panel or wiring.
DO NOT place food directly
into the warmer.
DO NOT put ice into a
warmer pan. This will cause
condensation on the inside of
the warmer. Damage caused
by condensation is NOT
covered by warranty.

7
M025 2M-Z14353 Owners Manual for Built-In Disher Well Warmer
MAINTENANCE INSTRUCTIONS
CARE OF STAINLESS STEEL
Stainless steel is a marvelous material: strong, lustrous and low maintenance. With
a minimum of care, it will normally retain its beauty and durability for the life of the
equipment. In some applications, however, special care is required in order to maintain
stainless steel’s special properties.
External components, such as cabinets and control panels, are nished with a grain
pattern. This pleasing nish is best maintained by cleaning with a non-abrasive
cleanser applied with a soft cloth. Rub only in the direction of the grain. In the absence
of visible grain, rub only along the longest axis of the appliance.
Restore stainless steel’s luster by applying a polish specically made for stainless steel.
Spray on, wipe off with a soft cloth, rubbing in the direction of the grain.
Never use metal implements, wire brushes, abrasive scratch pads or steel
wool to clean stainless steel.
Warmer pans, insets and other vessels are subject to a harsher environment. Wells
Manufacturing uses an very high quality stainless steel (#304DDQ) for our food warmer
pans. Even the highest quality stainless steel, however, is mostly iron, and will rust, pit
and corrode under the following conditions:
Poor Water Quality: Hard water (water with a high content of dissolved miner-
als) will leave mineral deposits when allowed to dry. Calcium (lime) can buildup on
heated surfaces, even under water. If left unattended, hard water spots and lime
buildup can lead to rusting, corrosion and pitting.
Contact with Chlorides: Chlorides (specic compounds of chlorine) are found in
food, table salt and many cleansers. Chlorides can attack the surface of stainless
steel, resulting in corrosion and pitting.
Keep your stainless steel warmers clean and free from calcium buildup.
Use alkaline, alkaline chlorinated or non-chloride cleanser.
Use citric acid-based cleaners to remove calcium deposits.
For additional information, please read the NAFEM Stainless Steel Equipment and
Cleaning Guide. Contact NAFEM at :
North American Association of Food Equipment Manufacturers
401 N. Michigan Avenue
Chicago, Illinois 60611-4267
(312) 644-6610
•
•

8
M025 2M-Z14353 Owners Manual for Built-In Disher Well Warmer
DAILY CLEANING INSTRUCTIONS
PREPARATIONS: Turn main power switch to OFF. Allow warmer to
cool before proceeding.
Remove any insets, utinsils and/or inserts.
Drain or remove water from well..
FREQUENCY: Minimum - daily.
TOOLS: Mild Detergent
Solution: 10 Parts Warm Water to 4 Parts Vinegar
Plastic Scouring Pad
Clean Cloth or Sponge
Food-Grade Silicone Sealant
1. Wipe entire unit down using a clean cloth or sponge and mild
detergent.
2. Use a plastic scouring pad to remove any hardened food particles
or mineral deposits.
IMPORTANT: DO NOT use steel wool for cleaning.
3. Rinse warmer thoroughly with a vinegar and water solution to
neutralize all detergent cleanser residue.
4. Inspect warmer ange-to-counter seal. Reseal with food-grade
silicone sealant if necessary. Failure to do so may allow grease and
water to leak into insulation and heating element, causing a potential
re and/or electric shock hazard.
5. Clean the Stand-Pipe (drain/overow assy) and insert using mild
detergnet and warm water.
6. Install the Stand-Pipe & insert, add proper amount of water and
rinse the basin. Turn the main power switch ON and check for proper
operation.
Procedure Complete.
CLEANING INSTRUCTIONS
CAUTION:
SHOCk HAzARD
Do NOT splash or pour water
into or over any control panel
or wiring.
CAUTION:
SHOCk HAzARD
Disconnect warmer from
electric power before cleaning
CAUTION:
BURN HAzARD
Allow warmer to cool
completely before cleaning.

9
M025 2M-Z14353 Owners Manual for Built-In Disher Well Warmer
CLEANING INSTRUCTIONS
MONTHLY CLEANING INSTRUCTIONS
PREPARATIONS: Remove any insets, utinsils.
Drain or remove water from well.
FREQUENCY: Weekly, or whenever lime or scale is seen
accumulating on the sides of the warmer pans.
TOOLS: Commercial Delime Cleaner
Plastic Scouring Pad
Clean Cloth or Sponge
1. Add water to pans until water is at normal operating level
or covers accumulated scale.
2. Heat water to maximum temperature (145ºF).
3. Pour contents of one package of commercial delime cleaner
into each basin. Stir to dissolve cleaner. Turn heat control OFF.
4. Allow solution to soak at least one hour, or overnight for heavy
scale buildup.
5. Drain water from well. Scrub with a plastic scouring pad.
Rinse thoroughly with hot water, then dry.
6. Rell pans with tap water and resume operation.
7. Heavy scale buildup may require additional treatments.
CAUTION:
CHEMICAL BURN
HAzARD
Deilimng chemicals may be
caustic. Wear appropriate
personal protective equipment.
Follow cleaner manufacturer’s
instructions for safest use.

10
M025 2M-Z14353 Owners Manual for Built-In Disher Well Warmer
TROUBLESHOOTING SUGGESTIONS
There are no user-serviceable components in this appliance.
In all instances of damage or malfunction, contact your Authorized Wells Service Agency for repairs.
SYMPTOM POSSIBLE CAUSE SUGGESTED REMEDY
No power to warmer Circuit breaker off or tripped Reset circuit breaker
Warmer will not heat Temperature control not set Set control to desired temperature
Warmer trips circuit breaker
Wet insulation Verify ange-to counter seal is sound, or
reseal with food-grade silicone sealant
Pan leaking or other internal damage Contact yourAuthorized Wells Service
Agency for repairs
Internal damage Contact yourAuthorized Wells Service
Agency for repairs
Warmer slow to heat
Mineral deposits on pan acting as a
insulator Clean pan(s) with delime cleaner
Wired to wrong voltage Verify supply voltage - must match
voltage on warmer nameplate
Drain-equipped unit will not hold
water
Drain valve not fully closed Check drain valve for debris and close
fully
Drain valve damaged or pan(s) leaking Contact yourAuthorized Wells Service
Agency for repairs

11
M025 2M-Z14353 Owners Manual for Built-In Disher Well Warmer
WIRING DIAGRAM
WHITE
BLACK
GROUND
1
8
3
4
5
6
7
HEATING
ELEMENT
THERMOSTAT
POWER
SWITCH
HIGH LIMIT
THERMOSTAT
2
HDW-2 Wiring Diagram SK2488

12
M025 2M-Z14353 Owners Manual for Built-In Disher Well Warmer
EXPLODED VIEW: HDW-2 DISHER WELL
Model: HDW-2 DISHER WELL SK2489, Rev. B, 2/24/2014
1
2
6
7
8
9
10
11
12
11
131415
16
20
26
25
23
24
20
22
21
17
18
19
20
11
3
4 5

13
M025 2M-Z14353 Owners Manual for Built-In Disher Well Warmer
Model: HDW-2 Dipper Well
Fig No Part No Qty Description Applications
1P2-Z14195 1WELLINSERT HDW-2, HDW-2F
2 HDW-2D
22V-Z14203 1 STAND-PIPEASSEMBLY HDW-2, HDW-2F
2V-Z15955 2 STANDPIPEASSY HDW-2D
3 2I-Z14209 1O-RING HDW-2, HDW-2F
4 HDW-2D
4P2-WL0183 1 WELLASSEMBLY
52K-Z14206 1 FAUCET, DIPPER HDW-2D, HDW-2F
6P2-Z15039 1 ELEMENT, PLATE
7 2N-Z14199 1 ELEMENT 300W 120V
8 2C-Z14325 1 WASHER FLAT .75OD X .344ID COPPER
92T-Z14200 1 THERMOSTAT
10 P2-Z14190 1 CLAMP, THERMOSTAT
11 2C-Z6929 710-24 KEPS NUT S.S. HDW-2
9 HDW-2D
12 P2-Z14196 1 HOUSING, ELEMENT
13 2K-H5417 1 BUSHING, HEYCO #SR-6P-3-4
14 P2-Z14191 1 COVER, CONTROL
15 2C-6349 2 SCREW #8 x 3/8 B THPSTLNP
16 P2-WL0198 1 CORDSET HDW-2
17 2C-1494 1 SCREW #8 -32 X .5 RH NP
18 P2-Z14506 1 BRACKET - HIGH LIMIT
19 2T-Z14503 1 THERMOSTAT 325°F
20 2C-73457 7 8-32 KEPS NUT SS
21 P2-Z14189 3 CLAMP BOWL
22 2M-Z14204 1 LABEL- WELLS LOGOAND CAUTION
23 2E-Z14201 1 SWITCH, STST-LIGHTED
24 P2-Z14193 1 WIRE CHANNEL
25 P2-Z18249 1 WIRE COVER
26 2C-1810 3 WASHER 3/16” STL
PARTS LIST: HDW-2 DISHER WELL
February 24, 2014

14
M025 2M-Z14353 Owners Manual for Built-In Disher Well Warmer
NOTES

15
M025 2M-Z14353 Owners Manual for Built-In Disher Well Warmer
NOTES

16
M025 2M-Z14353 Owners Manual for Built-In Disher Well Warmer
NOTES
M025 2M-Z14353 Owners Manual for Built-In Disher Well Warmer

17
M025 2M-Z14353 Owners Manual for Built-In Disher Well Warmer
CUSTOMER SERVICE DATA
please have this information available if calling for service
RESTAURANT _____________________________ LOCATION _____________
INSTALLATION DATE ________________________ TECHNICIAN ___________
SERVICE COMPANY ________________________________________________
ADDRESS ___________________________ STATE ______ ZIP__________
TELEPHONE NUMBER (_____)_____-_________
EQUIPMENT MODEL NO. _______________
EQUIPMENT SERIAL NO. _______________
VOLTAGE:(checkone) 120 208 240
DESCRIPTION PART NO.
PARTS & SERVICE
IMPORTANT: Use only factory
authorized service parts and
replacement lters.
For factory authorized service,
or to order factory authorized
replacement parts, contact
your Wells authorized service
agency, or call:
Wells Manufacturing
10 Sunnen Dr.,
St. Louis MO 63143 USA
Service Dept.
phone: (314) 678-6314
fax: (314) 781-2714
Service Parts Department
can supply you with the name
and telephone number of
the WELLS AUTHORIZED
SERVICE AGENCY
nearest you.
M025 2M-Z14353 Owners Manual for Built-In Disher Well Warmer

WELLS MANUFACTURING
10 Sunnen Dr., St. Louis, MO 63143
telephone: 314-678-6314
fax: 314-781-2714
www.wellsbloomfield.com
This manual suits for next models
1
Table of contents
Other Wells Food Warmer manuals

Wells
Wells MOD-300T User manual

Wells
Wells HW-10 User manual

Wells
Wells MOD-100T User manual

Wells
Wells MOD-500TDMAF User manual

Wells
Wells HW/SMP-6D User manual

Wells
Wells SW-10 User manual

Wells
Wells MOD-100D User manual

Wells
Wells BMW-206ULST User manual

Wells
Wells HT-227AF User manual

Wells
Wells HT-200AF User manual
Popular Food Warmer manuals by other brands

Hatco
Hatco GLO-RAY GRSDH Series Installation and operating manual

True
True TR1HRT89-1S-1S Specifications

Bartscher
Bartscher Hot display unit 8x1/6GN-R instruction manual

Vollrath
Vollrath Cayenne HS-7 Operating and safety instructions

Hatco
Hatco Glo-Ray GRSDS Series Installation and operating manual

Delfield
Delfield Concepts installation manual
