Wells F-88 User manual

PRINTED IN UNITED STATES OF AMERICA
WELLS BLOOMFIELD, LLC
2 ERIK CIRCLE, P. O. Box 280 Verdi, NV 89439
www.wellsbloomfield.com
telephone: [phone]
fax: [phone]
IMPORTANT: DO NOT DISCARD THIS MANUAL
This manual is considered to be part of the appliance and is to be given to the OWNER or
MANAGER of the restaurant, or to the person responsible for TRAINING OPERATORS of
this appliance. Additional manuals are available from your WELLS DEALER.
THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR
INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any
questions concerning installation, operation or maintenance of this equipment.
OPERATION MANUAL
MODEL
F-88
DUAL HEAD
COUNTERTOP
AUTOLIFT
FRYERS
with
SAFETY TEST
SYSTEM™
Includes
INSTALLATION
USE & CARE
304
p/n 304358 Rev. B ECN-13378 M304 071030 cps
Model F-88

304 p/n 304358 OpM CT Autolift Fryers STS
Unless otherwise specified, all commercial cooking
equipment manufactured by WELLS BLOOMFIELD, LLC is
warranted against defects in materials and workmanship for
a period of one year from the date of original installation or
18 months from the date of shipment from our factory,
whichever comes first, and is for the benefit of the original
purchaser only.
THIS WARRANTY IS THE COMPLETE AND ONLY
WARRANTY, EXPRESSED OR IMPLIED IN LAW OR IN
FACT, INCLUDING BUT NOT LIMITED TO, WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR ANY
PARTICULAR PURPOSE, AND/OR FOR DIRECT,
INDIRECT OR CONSEQUENTIAL DAMAGES IN
CONNECTION WITH WELLS BLOOMFIELD PRODUCTS.
This warranty is void if it is determined that, upon inspection
by an authorized service agency, the equipment has been
modified, misused, misapplied, improperly installed, or
damaged in transit or by fire, flood or act of God. It also
does not apply if the serial nameplate has been removed, or
if service is performed by unauthorized personnel. The
prices charged by Wells Bloomfield for its products are
based upon the limitations in this warranty. Seller’s
obligation under this warranty is limited to the repair of
defects without charge by a Wells Bloomfield factory
authorized service agency or one of its sub-service
agencies. This service will be provided on customer’s
premises for non-portable models. Portable models (a
device with a cord and plug) must be taken or shipped to
the closest authorized service agency, transportation
charges prepaid, for service. In addition to restrictions
contained in this warranty, specific limitations are shown in
the Service Policy and Procedure Guide. Wells Bloomfield
authorized service agencies are located in principal cities.
This warranty is valid in the United States and Canada and
void elsewhere. Please consult your classified telephone
directory, your foodservice equipment dealer or contact:
Service Department, Wells Bloomfield, LLC
P.O. Box 280, Verdi, Nevada 89439
phone [phone] or fax [phone]
for information and other details concerning warranty.
LIMITED WARRANTY STATEMENT
SERVICE POLICY AND PROCEDURE GUIDE and ADDITIONAL WARRANTY EXCLUSIONS
NOTE: For your protection, please note that equipment in
this shipment was carefully inspected and packaged by
skilled personnel before leaving the factory. Upon
acceptance of this shipment, the transportation company
assumes full responsibility for its safe delivery.
IF SHIPMENT ARRIVES DAMAGED:
1. VISIBLE LOSS OR DAMAGE: Be certain that any
visible loss or damage is noted on the freight bill or
express receipt, and that the note of loss or damage is
signed by the delivery person.
2. FILE CLAIM FOR DAMAGE IMMEDIATELY:
Regardless of the extent of the damage.
3. CONCEALED LOSS OR DAMAGE: if damage is
unnoticed until the merchandise is unpacked, notify the
transportation company or carrier immediately, and file
“CONCEALED DAMAGE” claim with them. This
should be done within fifteen (15) days from the date
the delivery was made to you. Be sure to retain the
container for inspection.
Wells Bloomfield cannot assume liability for damage or loss
incurred in transit. We will, however, at your request, supply
you with the necessary documents to support your claim.
SHIPPING DAMAGE CLAIM PROCEDURE
xi
1. Resetting of safety thermostats, circuit breakers, over
load protectors, and/or fuse replacements are not
covered by this warranty unless warranted conditions
are the cause.
2. All problems due to operation at voltages or phase
other than specified on equipment nameplates are
not covered by this warranty.
Conversion to correct voltage and/or phase must be
the customer’s responsibility.
3. All problems due to electrical connections not made
in accordance with electrical code requirements
and wiring diagrams supplied with the equipment are
not covered by this warranty.
4. Replacement of items subject to normal wear, to
include such items as knobs, light bulbs; and, normal
maintenance functions including adjustments of
thermostats, adjustment of micro switches and
replacement of fuses and indicating lights are not
covered by warranty.
5. Damage to electrical cords and/or plug due to exposure
to excessive heat are not covered by this warranty.
6. Full use, care, and maintenance instructions supplied
with each machine. Noted maintenance and
preventative maintenance items, such as servicing and
cleaning schedules, are customer responsibility. Those
miscellaneous adjustments noted are customer
responsibility. Proper attention to preventative
maintenance and scheduled maintenance procedures
will prolong the life of the appliance.
7. Travel mileage is limited to sixty (60) miles from an
Authorized Service Agency or one of its sub-service
agencies.
8. All labor shall be performed during regular working
hours. Overtime premium will be charged to the buyer.
9. All genuine Wells replacement parts are warranted for
ninety (90) days from date of purchase on non-
warranty equipment. This parts warranty is limited only
to replacement of the defective part(s). Any use of
non-genuine Wells parts completely voids any
warranty.
10. Installation, labor, and job check-outs are not
considered warranty and are thus not covered by this
warranty.
11. Charges incurred by delays, waiting time or operating
restrictions that hinder the service technician’s ability to
perform service are not covered by warranty. This
includes institutional and correctional facilities.

WARRANTY xi
SPECIFICATIONS 1
FEATURES & OPERATING CONTROLS 2
PRECAUTIONS & GENERAL INFORMATION 3
AGENCY LISTING INFORMATION 4
INSTALLATION 4
OPERATION 6
CLEANING INSTRUCTIONS 7
MAINTENANCE 8
TROUBLESHOOTING SUGGESTIONS 8
PARTS&SERVICE 9
CUSTOMER SERVICE DATA 9
Thank You for purchasing this Wells Bloomfield appliance.
Proper installation, professional operation and consistent maintenance of this appliance will ensure that
it gives you the very best performance and a long, economical service life.
This manual contains the information needed to properly install this appliance, and to use and care for
the appliance in a manner which will ensure its optimum performance.
TABLE OF CONTENTS
SPECIFICATIONS
INTRODUCTION
1
MODEL VOLTS AMPS WATTS POWER SUPPLY CORD
208 VAC 1 ø n/a n/a n/a
F-88 (208V) 208 VAC 3ø L1=31.9A
L2=31.9A
L3=31.9A 11,500W NOT SUPPLIED
240 VAC 1ø 47.9A 11,500W NOT SUPPLIED
F-88 (240V) 240 VAC 3ø L1=27.6A
L2=27.6A
L3=27.6A 5750W NOT SUPPLIED
304 p/n 304358 OpM CT Autolift Fryers STS

FEATURES & OPERATING CONTROLS
2
Fig. 1 F-88 Countertop Fryer Features & Operating Controls
304 p/n 304358 OpM CT Autolift Fryers STS

3
This appliance is intended for use in commercial establishments
only.
This appliance is intended
to prepare food for human consumption.
No other use is
recommended or authorized by the manufacturer or its
agents.
Operators of this appliance must be familiar with the appliance use,
limitations and associated restrictions. Operating instructions must be
read and understood by all persons using or installing this appliance.
Cleanliness of this appliance is essential to good sanitation. Read and
follow all included cleaning instructions and schedules to ensure the
safety of the food product.
Disconnect this appliance from electrical power before performing any
maintenance or servicing.
DO NOT submerge this appliance in water. This appliance is not jet
stream approved. Do not direct water jet or steam jet at this appliance,
or at any control panel or wiring. Do not splash or pour water on, in or
over any controls, control panel or wiring.
Exposed surfaces of this appliance can be hot to the touch and may
cause burns.
The technical content of this manual, including any wiring diagrams,
schematics, parts breakdown illustrations and/or adjustment
procedures, is intended for use by qualified technical personnel.
Any procedure which requires the use of tools must be performed by a
qualified technician.
This manual is considered to be a permanent part of the appliance.
This manual and all supplied instructions, diagrams, schematics, parts
breakdown illustrations, notices and labels must remain with the
appliance if it is sold or moved to another location.
This appliance is made in the USA. Unless otherwise noted, this
appliance has American sizes on all hardware.
CAUTION:
RISK OF
DAMAGE
DO NOT connect or
energize this appliance
until all installation
instructions are read and
followed. Damage to the
appliance will result if
these instructions are not
followed.
CAUTION:
HOT SURFACE
Exposed surfaces can be hot
to the touch and may cause
burns.
PRECAUTIONS AND GENERAL INFORMATION
DANGER: BURN HAZARD
Contact with hot oil will cause severe burns. Always wear protective clothing and heat
resistant gloves when operating the fryer or filtering the oil.
WARNING: ELECTRIC SHOCK HAZARD
All servicing requiring access to non-insulated components must be performed by
qualified service personnel. DO NOT open any access panel that requires the use of
tools. Failure to heed this warning may result in severe electric shock.
CAUTION: BURN HAZARD
Contact with hot oil may cause burns.
DO NOT fill fryer beyond MAX OIL line on frypot.
For disposal of oil use only a container specifically designed for the disposal of hot oil.
DO NOT fill hot oil disposal container beyond MAX OIL line.
304 p/n 304358 OpM CT Autolift Fryers STS

AGENCY LISTING INFORMATION
STD 4
E6070
INSTALLATION
NOTE: DO NOT discard
the carton or other packing
materials until you have
inspected the appliance for
hidden damage and tested it
for proper operation.
Refer to SHIPPING DAMAGE
CLAIM PROCEDURE on the
inside front cover of this
manual.
IMPORTANT:
This installation must comply
with all applicable Federal,
Local and NFPA codes.
UNPACKING & INSPECTION
Carefully remove the appliance from the carton. Remove all
protective plastic film, packing materials and accessories from the
Appliance before connecting electrical power or otherwise performing
any installation procedure.
Carefully read all instructions in this manual and the Installation
Instruction Sheet packed with the appliance before starting any
installation.
Read and understand all labels and diagrams attached to the
appliance.
Carefully account for all components and accessories before
discarding packing materials. Store all accessories in a convenient
place for later use.
COMPONENTS
2 ea. FRYPOT
2 ea. FRY BASKET
4 ea. ADJUSTABLE LEGS
SETUP
Setup the appliance only on a firm, level, non-combustible surface.
Verify local codes for requirements. Concrete, tile, terrazzo or metal
surfaces are recommended. Metal over combustible material may not
meet code for non-combustible surfaces.
Install one adjustable leg at each corner of the fryer by screwing the leg
into the fitting on the bottom. With a spirit level, check that the appli-
ance is level front-to-back and side-to-side. Verify that the unit sits
firmly ON ALL FOUR LEGS.
The lower portions of the legs are adjustable by turning; adjust as
required to level the appliance. All four legs must be adjusted to firmly
contact the counter in order to prevent tipping.
Refer to the Installation Instruction Sheet for required clearances.
Maintain required clearances between the appliance and adjacent
combustible surfaces.
Avoid storing flammable or combustible materials in, on or near the
appliance.
This appliance conforms to NSF Standard 4 for sanitation only if
installed in accordance with the supplied Installation Instructions and
maintained according to the instructions in this manual.
This appliance is UListed under UL File E6070 for 240V single
phase, and 208V and 240V three phase.
4
Fig. 2 Adjustable Legs
304 p/n 304358 OpM CT Autolift Fryers STS

5
INSTALLATION (continued)
WARNING: ELECTRIC SHOCK HAZARD
All servicing requiring access to non-insulated electrical components must be
performed by a factory authorized technician.
DO NOT open any access panel which requires the use of tools. Failure to follow this
warning can result in severe electrical shock.
CAUTION:
RISK OF
DAMAGE
DO NOT connect or energize
this appliance until all
installation instructions are
read and followed. Damage
to the appliance will result if
these instructions are not
followed.
CAUTION:
ELECTRIC
SHOCK HAZARD
The ground lug of F-58 and
F-68 fryers must be
connected to a suitable
building electric ground.
IMPORTANT:
Damage due to being
connected to the wrong
voltage or phase is NOT
covered by warranty.
F-88 FRYER ELECTRICAL INSTALLATION
F-88 fryers must be connected directly to a suitable electric circuit.
Conduit and strain relief must be provided by the electrician.
F-88 fryers are not rated for single phase operation at 208VAC.
Single phase F-88 fryers require a 240VAC 50 amp 1ø circuit with
ground;
Three phase F-88 fryers require a 208VAC or 240VAC 3ø, 40 amp
circuit with ground,
Raise the element head, remove the frypot and the cover at the rear of
the fryer to gain access to the terminal block. The electrical inlet is
provided by a knock-out in the rear panel.
FRYERS ARE SHIPPED FROM THE FACTORY WIRED FOR 3ø.
Conversion to single phase is the responsibility of the electrician.
304 p/n 304358 OpM CT Autolift Fryers STS

OPERATION
6
NORMAL OPERATION
NOTE: The two sections of the fryer are completely separate, and can
be used and controlled individually.
1. a. Be sure the TEMPERATURE CONTROL KNOB is turned to
OFF.
b. Lower the ELEMENT HEAD into the frypot by pulling back on
the ELEMENT LIFTING HANDLE, raising the ELEMENT HEAD
SUPPORT ROD, then carefully lowering the elements into the
frypot.
2. Fill the FRYPOT with commercial-grade liquid shortening to the
MIN OIL line.
Capacity: 30 pounds (15 pounds each frypot).
IMPORTANT: DO NOT overfill the frypot. Cold oil will expand as it
heats. Adding too much oil will allow the frypot to overflow during
operation.
For best results, always use top grade commercial shortening made
specially for frying. Maintain proper oil level in frypot during
operation.
3. Turn the TEMPERATURE CONTROL KNOB to the desired
temperature. The HEAT INDICATOR will glow. When the oil
reaches the desired temperature, the heat indicator will go out. The
heat indicator will go off and on during operation as the thermostat
cycles to maintain temperature.
For best results: DO NOT set temperature control to a temperature
setting higher than is required for the food product.
4. Load either or both baskets no more than 1/2 full with food product.
DO NOT overload fry baskets. For best results, load baskets
uniformly to half full. Hang the basket on the BASKET LIFT.
5. Set the TIMER DIAL to the desired cooking time. Press the "PUSH"
button on the timer to lower the basket into the hot oil.
When food is cooked, the basket will be lifted out of the oil.
Handle the hot basket only by the basket handle.
DANGER: BURN HAZARD
Contact with hot oil will cause severe burns.
Always wear protective clothing and heat resistant gloves when operating the fryer.
CAUTION:
HOT SURFACE
Exposed surfaces can be hot
to the touch and may cause
burns.
Fig. 3 Temperature Control
Knob
Fig. 4 Oil Level Marking
Fig. 5 Timer
304 p/n 304358 OpM CT Autolift Fryers STS

7
OPERATION (continued)
6. When the heat indicator light cycles off, the fryer is ready to cook
the next load.
7. Reduce temperature control to 225ºF during idle periods to save
power and extend the life of the oil. The fryer will return to
operating temperature in just a few minutes when needed.
8. Keep the fryer clean at all times. Rinse baskets frequently, and dry
thoroughly, in order to prevent oil contamination.
9. Drain the frypot completely after use. Filter the oil daily, or more
often during heavy use.
DANGER: BURN HAZARD
Contact with hot oil will cause severe burns.
Always wear protective clothing and heat resistant gloves when operating the fryer.
CAUTION:
HOT SURFACE
Exposed surfaces can be hot
to the touch and may cause
burns.
NOTE: If the oil temperature
exceeds 440ºF, the hi-limit
safety will shut down the unit,
and light the red TROUBLE
light. To reset:
Allow the oil to cool, then
press the red button on the
back of the element head
until it “clicks” and stays in.
If tripping persists, see
Troubleshooting Suggestions,
page 9.
304 p/n 304358 OpM CT Autolift Fryers STS

8
OPERATION—SAFETY TEST SYSTEM™
DANGER: BURN HAZARD
Contact with hot oil will cause severe burns. Allow the fryer to cool before cleaning.
Always wear protective clothing and heat resistant gloves when performing this test.
1. Fill the frypot to the MIN OIL line. Fresh oil is recommended to
minimize smoking.
2. Clip the TEST THERMOMETER to a
FRYER BASKET. Lower the fryer
basket into the oil. Be sure the dial
of the test thermometer can be
clearly viewed.
3. Turn the TEMPERATURE
CONTROL KNOB to the maximum
setting, then press the POWER
SWITCH to ON. Allow the oil to heat
until the test thermometer reads to
“START TEST” (350ºF).
4. Press and hold the red TEST
SWITCH. The temperature of the
oil will rise, and the test thermometer
will read “TEST ZONE”.
IMPORTANT: DO NOT hold the TEST switch for more than
2-1/2 minutes.
When the oil temperature reaches the setting of the hi-limit
thermostat, the hi-limit will trip, the red TROUBLE light will glow,
and the heating element will be de-energized.
If the hi-limit thermostat trips while the test
thermometer is in the TEST ZONE, the test is
complete. The function of the hi-limit
thermostat is normal. Reset the hi-limit
thermostat and resume normal operation.
If the test thermometer rises above the TEST
ZONE, the hi-limit is not operating properly.
Release the TEST switch, turn the power
switch OFF and contact an Authorized Wells
Service Agent for repairs.
5. Reset the hi-limit thermostat:
a. Turn the power switch OFF
b. Allow the oil to cool
c. Press the red button on the back of the element head until it
“clicks” and stays in.
6. Remove, clean and store the test thermometer.
Set the temperature control knob to the normal operating
temperature. Turn the power switch ON and resume normal
operation.
The Safety Test System™
allows a positive test of the
function of the temperature
limiting (hi-limit) thermostat.
The hi-limit thermostat is
factory set for 440ºF (227ºC).
It will trip if the oil temperature
exceeds this setting, and
interrupt power to the heating
element.
CAUTION
FIRE HAZARD
Do not hold the TEST switch
for more than 2-1/2 minutes.
Should the oil temperature not
reach the hi-limit setting within
2-1/2 minutes, turn the power
switch OFF and contact an
Authorized Wells Service
Agent for repairs.
FAIL!
Fig. 5 Test Thermometer
304 p/n 304358 OpM CT Autolift Fryers STS

CLEANING INSTRUCTIONS
DANGER: BURN HAZARD
Contact with hot oil will cause severe burns. Allow the fryer to cool before cleaning.
Always wear protective clothing and heat resistant gloves when cleaning the fryer.
CAUTION:
ELECTRIC
SHOCK HAZARD
Disconnect fryer from electric
power before cleaning.
CAUTION:
BURN HAZARD
Allow fryer to cool completely
before cleaning.
CAUTION:
ELECTRIC
SHOCK HAZARD
Do not submerge fryer in
water.
IMPORTANT: DO NOT spill
or pour water into controls,
control panel or wiring.
DO NOT submerge fryer in
water. Damage to internal
components will occur.
Damage to internal
components from water
damage is not covered by
warranty.
IMPORTANT: DO NOT use
steel wool or abrasive
cleansers for cleaning the
fryer cabinet or frypot.
To remove carbonization from
frypot and element, see
PERIODIC CLEANING on
page 12.
IMPORTANT:
Nickel plated frypot must be
dried completely in order to
prevent rusting, and to
eliminate water contamination
of the cooking oil.
PREPARATION Turn temperature control to OFF
Allow fryer to cool completely before cleaning
Unplug fryer from receptacle before cleaning
FREQUENCY Daily, or as needed
TOOLS Mild Detergent, Non-abrasive cleanser
Soft Cloth or Sponge, Plastic Scouring Pad
Container for disposal of used oil.
CLEANING
1. Turn temperature control to OFF. Unplug the fryer.
2. Remove fry baskets, then swing the element heads up and out of
the frypots.
NOTE: The element support rod is spring-loaded. When the
element head is raised, the support rod will automatically swing
into position to keep the element head raised.
3. Allow the oil to cool to a safe temperature (120ºF or less).
Carefully remove the frypots: wearing heat-resistant gloves, lift the
frypots by the handles. Drain the oil into a suitable container.
4. Frypots and baskets may be washed in a dishwasher, or with warm
water and mild detergent. Rinse thoroughly and dry completely.
5. Wipe/brush all crumbs, breading and cooking debris from the
elements. Pay particular attention to the area between the element
and the thermobulbs. Be careful that the capillary tubes of the
thermobulbs are not moved or damaged during cleaning.
6. Keep all exterior surfaces free from splashed grease by wiping with
a clean cloth dampened with warm water and mild detergent. A
non-abrasive detergent and plastic scouring pad may be used for
stubborn deposits.
IMPORTANT: DO NOT use steel wool or abrasive cleansers
as these will damage the surface finish.
IMPORTANT: DO NOT submerge fryer in water. DO NOT spill or
pour water into controls, control panel or wiring. Damage to
internal components will occur.
7. Be certain frypots are completely dry, then reinstall in fryer.
a. Be sure the TEMPERATURE CONTROL KNOB is turned to
OFF, then plug unit into receptacle.
b. Lower the ELEMENT HEADS into the frypot by pushing back
on the ELEMENT LIFTING HANDLE, raising the SUPPORT
ROD, then carefully lowering the elements.
c. Add new or filtered oil to the MIN OIL line in frypots
Procedure is complete.
9
304 p/n 304358 OpM CT Autolift Fryers STS

10
DISPOSAL OF USED OIL
DANGER: BURN HAZARD
Contact with hot oil will cause severe burns. Allow the fryer to cool before cleaning.
Always wear protective clothing and heat resistant gloves when handling hot oil.
PREPARATION Turn temperature control to OFF
Allow fryer to cool completely before draining
FREQUENCY Daily, or as needed
TOOLS Container for disposal of used oil.
OIL DISPOSAL
1. Turn temperature control to OFF.
2. Allow the oil to cool to a safe temperature (120ºF or 50ºC).
3. Raise the element head and lift the frypot out of the fryer by the
frypot handles.
4. Dispose of the used oil in an approved oil disposal receptacle, or
filter the oil for reuse.
5. Wipe the frypot and reinstall in the fryer.
Procedure is complete.
CAUTION:
BURN HAZARD
Allow fryer to cool completely
before draining.
CAUTION:
SLIP AND FALL
HAZARD
Clean up oil spills
immediately. Slipping in oil
can cause injury.
CAUTION:
HEALTH
HAZARD
Clean up oil spills
immediately. Oil provides an
environment for the growth of
bacteria, which presents a
health hazard.
304 p/n 304358 OpM CT Autolift Fryers STS

DESCRIPTION POSSIBLE PROBLEM SUGGESTED REMEDY
Fryer will not heat Not plugged in or circuit breaker
tripped Plug into proper receptacle Reset circuit breaker
Fuse blown Contact Wells Authorized Service
Agency for repairs
Temperature control knob not set to
desired temperature Set to desired temperature
Hi-limit safety tripped Clean element1, reset hi-limit
Damaged internal component Contact Wells Authorized Service
Agency for repairs
Fryer will not maintain
temperature Temperature control thermostat thermobulb contaminated with
cooking debris
Clean element2
Damaged internal component Contact Wells Authorized Service
Agency for repairs
Fryer leaks oil Damaged frypot Contact Wells Authorized Service
Agency for repairs
Element head will not
raise
Element head will not
stay in the up position
Frypot out of position, or has excess
cooking debris in bottom
Check frypot for position
Clean frypot
Element head will not
lower Damaged hinge bracket or support rod Contact Wells Authorized Service Agency for repairs
Basket lift will not lower Timer not set Set to desired cook time
Timer "PUSH" button not pushed Push to start
Damaged internal component Contact Wells Authorized Service
Agency for repairs
Basket lift will not raise Damaged internal component Contact Wells Authorized Service
Agency for repairs
1The hi-limit safety is designed to shut down the fryer if the oil temperature exceeds 440ºF. A build-up
of cooking debris between the heating element and the thermobulb of the hi-limit safety will cause the
hi-limit to trip prematurely. Clean the element so that oil may circulate freely between the element
and the thermobulb. Reset the safety by pressing the red button on the back of the element head.
2A build-up of cooking debris between the heating element and the thermobulb temperature control
thermostat will cause inconsistent temperatures. Clean the element so that oil may circulate freely
between the element and the thermobulb.
TROUBLESHOOTING SUGGESTIONS
11
304 p/n 304358 OpM CT Autolift Fryers STS

12
MAINTENANCE
Periodic cleaning is
necessary to remove
carbonization from the
elements and frypot.
Frypot may be cleaned by
the method described at
right, or with a commercial
frypot cleaner. Be sure to
follow the manufacturer's
directions.
Before cleaning, ALWAYS:
• Unplug the fryer and
allow to cool.
• Drain the oil and wipe
out the frypot.
PERIODIC CLEANING
Add 1/2 cup of granulated dishwasher detergent to frypot. Fill with water
to the MAX OIL line.
Lower the element into the frypot and set the control knob to 225ºF
Boil the mixture for five minutes. Turn the control knob to OFF. Allow the
mixture to set in the frypot overnight.
After the soak period, raise the elements and remove any remaining
carbonization with a stiff bristle brush. Be careful that the capillary tubes
of the thermobulbs are not moved or damaged during cleaning.
Drain the frypot and wash with warm water and mild detergent.
Reinstall the frypot in the fryer. Add 1 quart of vinegar, then fill to the MAX
OIL line with cold water.
Lower the elements into the vinegar solution. Allow to set for 15 minutes.
Drain the frypot and rinse with clean water. Dry the frypot and elements
thoroughly before returning the fryer to operation.
IMPORTANT: Nickel plated frypot must be dried completely in order to
prevent rusting, and to eliminate water contamination of the cooking oil.
304 p/n 304358 OpM CT Autolift Fryers STS

DESCRIPTION PART NO.
FRY BASKET, HALF-SIZE, FOR F-88 20161
FRY BASKET, FULL SIZE, FOR F-88 20162
FRYPOT, FOR F-88 20169
CRUMB CRADLE 20690
COVER, FRYPOT 21010
LEGS, ADJUSTABLE (Set of 4) 20563
PARTS & SERVICE
CUSTOMER SERVICE DATA
please have this information available if calling for service
RESTAURANT _____________________________ LOCATION _____________
INSTALLATION DATE ________________________ TECHNICIAN ___________
SERVICE COMPANY ________________________________________________
ADDRESS ___________________________ STATE ______ ZIP__________
TELEPHONE NUMBER (_____)_____-_________
EQUIPMENT MODEL NO. _______________
EQUIPMENT SERIAL NO. _______________
VOLTAGE: (check one)  208 3Ø  240 1Ø  240 3Ø
13
304 p/n 304358 OpM CT Autolift Fryers STS
IMPORTANT: Use only
factory authorized service
parts and replacement
filters.
For factory authorized
service, or to order factory
authorized replacement parts,
contact your Wells authorized
service agency, or call:
Wells Bloomfield, LLC
2 Erik Circle
P. O. Box 280
Verdi, NV 89439
Service Parts Dept.
phone: [phone]
fax: [phone]
Service Parts Department can
supply you with the name and
telephone number of the
WELLS AUTHORIZED
SERVICE AGENCY
nearest you.

Genuine Parts
Protect - YOU - All - Ways
SERVICE TRAINING - QUALITY SERVICE
SERVICE TRAINING - QUALITY SERVICE
CUSTOMER SATISFACTION
CUSTOMER SATISFACTION
Commercial Food Equipment Service Association
Wells Bloomfield proudly supports CFESA
Commercial Food Equipment Service Association
PRINTED IN UNITED STATES OF AMERICA
WELLS BLOOMFIELD, LLC
2 ERIK CIRCLE, P. O. Box 280 Verdi, NV 89439
www.wellsbloomfield.com
telephone: [phone]
fax: [phone]
