Whitehall Thermalator T-8-M Operation and maintenance manual

INSTRUCTIONS FOR
OPERATION AND CARE OF
Mobil 8 Pack
Thermalator
Model T-8-M
Mobil 8 Pack
Thermalator, 220 Volt
Model ET-8-M
6701-105-000
800-782-7706 • 626-968-6681 • www.whitehallmfg.com
P.O. Box 3527 • City of Industry, CA, 91744-0527, U.S.A.
Division of
®
Acorn Engineering Company
Revised: October 2018

WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
a
Failure to follow these instructions could result in damage
to your new heating appliance and/or injury
! !
PLEASE READ THIS ENTIRE
BOOKLET BEFORE OPERATING
YOUR NEW THERMALATOR
This symbol on the product or on its packaging indicates that this product must not be disposed of with regular waste. Instead,
it is the user's responsibility to dispose of waste equipment according to the local laws. Separate collection and recycling of
the waste equipment at the time of disposal will help conserve natural resources and ensure it is recycled in a manner that
protects human health and the environment. For information about where the user can drop off the waste equipment for
recycling, please contact your local waste collection authority. See Page 14 for instructions on how to disassemble the
equipment for recycling purposes.
The presence of the CE Mark on Whitehall equipment means that it has been designed, tested and certified as complying
with all applicable European Union regulations and recommendations.
Waste Electrical and Electronic Equipment (WEEE)
General Warning or Caution
Electric Shock
European Union CE Mark
The Exclamation Symbol appears in Warning and Caution statements. This symbol designates where personal injury or
damage to the equipment is possible.
The Electric Shock Symbol is used to indicate a hazard arising from dangerous voltage. Any mishandling could result in
irreparable damage to the equipment and/or personal injury or death.
WARNING
To avoid electric shock, connect the instrument to properly earth-grounded, GFCI protected, 3-prong
receptacles only. Failure to observe this precaution can result in severe injury.
ŸDO NOT operate the appliance without properly filling with water. Under no circumstance should the appliance be
operated without water, as operating the appliance without water may result in damage to the heating element. Fill
appliance with water to the prescribed level before plugging into an electrical receptacle.
ŸCONNECT the appliance into a properly polarized G.F.C.I. (Ground Fault Circuit Interrupter) electrical receptacle for
protection against electrical shock. Have a qualified electrician verify the wall socket is properly polarized and grounded.
Use only the power cordset provided with the unit. The Thermalator appliance must be properly grounded.
ŸDO NOT use the lid knob to lift or transport appliance. Use the side handles to lift or move.
ŸDO NOT use in the presence of flammable liquids or gases, as these may present a fire and/or explosion hazard.
ŸAVOID skin contact with HOT water at all times! Carefully place thermal packs into the Thermalator to avoid splashing onto
skin or coming into contact with HOT water. DO NOT reach into HOT water with bare hands to remove heated thermal
packs. Use a grasping device, such as tongs, to remove thermal packs from HOT water.
ŸPREVENT the power cord or any electrical wires from touching the hot surfaces.
ŸNEVER leave appliance operating unattended for long periods of time. Water can evaporate and cause appliance to over-
heat which may result in damage to the heating element. Turn "OFF" when not in use.
ŸCAUTION: The enclosure surfaces are hot. Avoid skin contact with the hot surfaces and the cabinet.
ŸALWAYS allow the appliance to cool down before draining water or moving unit.

WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
Instructions for Operation and Care of Mobil 8 Pack Thermalator
3
TABLE OF CONTENTS
DESCRIPTION .......................................2
SET UP INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
What's included? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Unpacking my Thermalator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Where do I put my Thermalator? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Pre-soaking Thermal Packs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Filling my unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Emptying my unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
USING YOUR THERMALATOR . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Before the first use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
How do I use the Thermal Packs? . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
How do I change the temperature? . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
How do I use different size Thermal Packs? . . . . . . . . . . . . . . . . . . . . . . . 8
STORAGE ..........................................9
MAINTENANCE ......................................9
TROUBLESHOOTING.................................10
CLEANING..........................................9
TECHNICAL INFORMATION ..........................11-14
Exploded view (T-8-M) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Replacement parts (T-8-M) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Replacement parts (ET-8-M). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Electrical Parts Disassembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
Instructions for Operation and Care of Mobil 8 Pack Thermalator
2
Congratulations on receiving your Mobil 8 Pack Thermalator.
Your Thermalator is a simple and trouble-free unit to operate. The tank body, lid, bottom and tank housing are all made from
type 304 stainless steel. The controls are an ON/OFF switch on the front of the unit and a thermostat on the rear to control the
water temperature. Unit is preset set to a normal operating temperature.
Side handles and a knob on the lid minimize contact with the hot surface. The unit has Thermal Packs with blue and white tabs
and a large stainless steel rack adapter that fits onto a stainless steel wire rack. Inside the unit is a heating element and a
temperature sensor. Side handles and locking casters below allow easy movement of the unit. A drain valve is located on the
back of the unit.
Model T-8-M
100-120 Volts, 50/60 Hz,
15 Amps
Model ET-8-M
200-240 Volts, 50/60 Hz,
6 Amps Lid
Handle
Blue tabs
Thermal
Pack
Large Rack
Adapter
Large
Wire Rack
ON/OFF
Switch
Hospital Grade
Power Cord
Conditions of use:
1. Indoor use only
4. Relative humidity maximum 80% for up to 31ºC, maximum 50% for up to 40ºC ambient
5. Mains supply voltage fluctuations up to +/-10% of the rated voltage
3. Ambient temperatures 5ºC to 40ºC
7. Pollution degree 2
6. Mains supply voltage shall be protected against temporary and transient over-voltage per category II requirements
2. Altitude 2,000 max

WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
3
Instructions for Operation and Care of Mobil 8 Pack Thermalator
1 Thermalator Model T-8-S or ET-8-S
8 Thermal Packs (8 Standard)
If you are missing anything, please call the phone
number listed on the back page.
1 Filler Hose
1 Wire Rack - Medium, Vinyl Coated
1 Instructions for Operation and Care
1 Left / 1 Right Rack Adapter (stainless steel)
Remove all the shipping material. Remove Thermal
Packs and wire rack from inside the tank. Remove all
packaging from inside the tank, especially from under
the heating element inside the tank. Clean the unit
thoroughly before using.
SETTING UP
1. Your new Thermalator includes the following:
2. Unpacking your Thermalator
3. Device Placement
Ÿbe trained in occupational therapy protocols.
Operator trainees need to:
TRAINING
Ÿread and understand this manual.
Skills:
Operators using the Thermalator need a working
knowledge of occupational therapy procedures.
WARNING
!
Untrained operators can cause injury or be injured.
Only trained personnel to operate the Thermalator.
WARNING
!
OPERATOR SKILLS AND TRAINING
INSPECTING THE THERMALATOR
ŸIs a properly-grounded and voltage-matched
hospital grade receptacle available?
Inspection Checklist
ŸIs the Thermalator free of excessive wear?
ŸIs the outlet equipped with a functioning GFI?
If there is visible damage to the instrument upon receipt,
inform the shipping company and Whitehall immediately.
— Inspect the contents for damage.
This Whitehall product has been carefully packaged at
the factory to minimize the possibility of damage during
shipping.
— Inspect the packaging for external signs of
damage.
WARNING
!
Do not attempt to operate this equipment if there is
evidence of shipping damage or you suspect the unit
is damaged. Damaged equipment may present
additional hazards to you. Contact Whitehall technical
support for advice before attempting to plug in and
operate damaged equipment.
WARNING
!
For operation, the Thermalator must be placed on a
non-flammable, non-combustible surface or material.
Avoid operating the unit in close proximity of any such
materials.
Presoak thermal packs (Critical, if not presoaked
properly, the tank may develop surface rust
during use). Inspect the packs for any tears and
damaged or loose threads before starting the presoak
process. If packs are damaged, do not use.
Before the first use, you must condition each Thermal
Pack.
1- Take the Thermal Pack by the corner loops - one
white and one blue or black - so the sections are
horizontal.
2- Gently shake the pack back and forth to evenly
distribute the filler material.
Shake to distribute
the dry material
4. Pre-Soaking Thermal Packs
Avoid operating this unit in close proximity of
materials subject to damage from moisture.

WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
4
Instructions for Operation and Care of Mobil 8 Pack Thermalator
3/4
FILLING your unit
Turn the packs
to upright
Make sure the unit
is unplugged and
all packaging has
been removed.
Check the drain valve
before filling. Use the hose
provided. Fill unit about
3/4 full with tap water.
Ensure that no liquids are
spilled into the unit. If
conductive materials enter
the enclosure, turn off the
unit and unplug from
power immediately.
Contact Whitehall or a
licensed technician for
service.
12
Place the wire rack
inside the unit. Be
careful of the
heating element.
Put the Pre-Soaked
Thermal Packs on
the wire rack. Place
all the blue or white
tabs up.
34
5- Soak the packs for two hours minimum, more is
recommended. If the presoak water turns cloudy,
change the presoak water and soak packs again.
Repeat until water is clear.
3- Place the thermal packs in a large plastic, stainless
steel or enamel container (do not use aluminum).
DO NOT use the Thermalator for presoaking
packs.
4- Fill the container with enough tap water to
completely cover the Thermal Packs.
6- Turn packs to upright position. The packs are now
ready to use.
The Thermalator is to operate only in ambient
temperatures of 5ºC to 40ºC.

WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
5
Instructions for Operation and Care of Mobil 8 Pack Thermalator
AC
EMPTYING your unit
Plug the power cord
into an AC outlet. A
Ground Fault Circuit
Interrupter is
recommended
because it will give
additional protection
from electric shock.
7
Facing the front of
the unit , turn the
power switch OFF.
The light will go out.
1
Caution! Do not
attempt to move
the unit with water
in the unit.
Add more water, if
necessary, to cover
the Thermal Packs.
Uncovered packs
may be damaged
during heating.
5
Facing the front of
the unit, turn the
power switch to the
ON position.
Indicator light
should be
illuminated.
8
Unplug the unit.
2
Close the lid.
6
Caution! Lid can
pinch fingers.

WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
6
Instructions for Operation and Care of Mobil 8 Pack Thermalator
Wrap the pack in a
Thermal Pack Cover
or 5 to 6 layers of
terry toweling.
3Put the wrapped
pack on the area to
be treated for a
pre-set treatment
time.
4
Open the lid.
1
1- For each use:
Let the water cool to
room temperature.
Remove the Thermal
Packs and the wire
rack.
3
Caution: the
Thermal Pack can
cause skin burns.
Using tongs,
carefully remove
the Thermal Pack.
2
4Attach filler hose to
the drain outlet.
Turn handle to
release water into a
sink or floor drain.
USING the Thermal Pack
WARNING
!
Use the Thermalator only as directed in this manual.
Any other use can cause injury.
WARNING
!

WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
7
BLUE
Instructions for Operation and Care of Mobil 8 Pack Thermalator
Remove the Thermal
Pack from the patient.
5Remove the
Thermal Pack Cover
or toweling. Hang to
dry or launder.
6
If the blue tab was
up, put the white tab
up now. Work your
way from first to last,
reversing tabs each
time.
Return the pack to
the Thermalator.
7Close the lid. The
Thermal Pack will
be reheated within
15 minutes and
ready for use.
8
Add more water, if
necessary, to cover
the Thermal Packs.
Uncovered packs
may be damaged
during heating.
1Place all the blue
tabs in the same
reference (either all
up or all down) to
start the day.
2
2- Daily use:

WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
8
Your Thermalator uses many different sizes of Thermal Packs. For Half, Cervical or Myofacial sizes, use the adapter as
shown. For Standard, Knee/Shoulder, 10" x 18" and 10" x 24" sizes, turn the adapter over. For oversize, use only the wire
rack.
Instructions for Operation and Care of Mobil 8 Pack Thermalator
Myofacial
10" x 24"
Oversize
10" x 18"
Cervical
Half
Knee/Shoulder
Standard
Large
Rack
Adapter
Facing the back of the
unit, find the metal
temperature stem
between the 2 screws
in the lower middle of
the unit. Attach knob.
5
USING the Wire Rack
CAUTION: Sensitive thermostat - a small adjustment
changes several degrees. Temperature range of 65°F
(18°C) to 175°F (79°C) ±5°F (-15°C).
Using the knob, turn clockwise to increase the
temperature. Allow the temperature to stabilize, and
measure the water temperature with the
thermometer.
6
TEMPERATURE
3- Periodic use:
The water temperature for normal operating conditions is about 165°F (74°C). The thermostat is very sensitive; even a
small adjustment can raise or lower the temperature several degrees. The thermostat has an adjustable temperature
range of 65°F (18°C) to 175°F (79°C) ±5°F (-15°C). To adjust the temperature, you need a Thermometer capable of
180° F (83° C).
This product is protected by a High Limit Thermostat which will disconnect power in the event that the unit reaches
excessive temperatures. If this condition does occur, have a licensed technician check the unit and reset the thermostat if
the cause of overheating is removed.

WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
9
Instructions for Operation and Care of Mobil 8 Pack Thermalator
•
•
•
•
•
•
•
•
MAINTENANCE
1. Routine Maintenance (As Needed)
The Thermalator design is nearly maintenance-free. It
should, under most conditions, give many years of reliable
service. Clean and replace the Thermal Packs as
described below.
Destroy or discard any contaminated Thermal Packs.
Always keep the Thermal Packs under water. Replace
any water that has evaporated.
See Care and Cleaning
•
2. Monthly Maintenance
See Care and Cleaning
Clean wire rack and insert using mild soap. Rinse
thoroughly with clean tap water. Dry with soft cloth.
Scrub your Thermal Packs with warm soap and
water.
Keep the pH (a measure of acidity of the water)
between 7.4 and 7.8 to reduce the scaling and residue
build-up.
3. Yearly Maintenance
Replace worn out Thermal Packs. When The packs
begin to wear out, the non-toxic filler oozes through the
fabric and seams. The individual cells seem empty.
These packs don't hold the heat. Throw away worn
Thermal Packs.
1 - Test for leakage current, dielectric strength, and
receptacle polarity and ground. If you need test
details, call the number listed on the back page.
2 - Check the power cord and plug. They should be
free of cuts, abrasion and other damage. Replace
the power cord assembly if it is damaged. Use only
factory authorized replacement parts.
3 - Remove the bottom cover and check all electrical
components and connections. Replace any parts
that are in questionable condition. Use only factory
authorized replacement parts.
Have a professional electrician thoroughly check the
following:
There are no user serviceable parts inside the unit.
Refer all service and repair to Whitehall or a licensed
technician. Do not attempt to take the unit apart,
modify or interfere with the components or electrical
parts. Doing so is hazardous and voids all warranties.
•
•
•
•
STORAGE
1. Storing the Thermalator
Place the Thermalator upright in a dry area away from
any chemicals.
See Care and Cleaning
2. Storing the Thermal Packs
Scrub your Thermal Packs with warm soap and
water.
1 - Put the moist Thermal Pack in a plastic bag.
Dry
Moist and Cold
2 - Seal the bag.
3 - Store the bag in the freezer (recommended) or
refrigerator.
1 - Air dry the Thermal Pack completely in a well
ventilated area. The filler will become
hard and caked. This doesn't hurt the bags;
more Pre- S o a k i n g t i m e i s t h e n
necessary.
•
Before cleaning the appliance, be sure to turn power
switch "OFF" and unplug the unit from the electrical
receptacle. If necessary, empty (drain) the appliance by
following instructions as outlined in the "EMPTYING your
unit" section.
CARE AND CLEANING
ŸUse only appropriate cleaning materials and tools for
cleaning the unit. Ensure all cleaning materials are
removed before use. It is the responsibility of the
user to decontaminate and clean any spillage of
hazardous materials before use.
ŸClean regularly for optimal service and operation.
ŸFill daily with water. Water is constantly lost during
operation due to evaporation.
ŸChlorine in regular tap water may be present in high
enough concentrations to damage the unit.
ŸInspect the power cord for wear, fraying, and other
visible damage during regular cleaning.
ŸInspect the heating element for pitting and other
visible damage during regular cleaning intervals.
ŸNo bleach or any cleaner with high chlorine content
should be used under any circumstance.

WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
10
REPAIR OF UNIT
It may be necessary or you may desire to return the Thermalator unit for service. In that case, we would appreciate you
contacting Whitehall Manufacturing directly. We will make arrangements for the unit to be returned to our production location.
When the unit is received by us, an estimate of repairs will be made and you will be contacted. Please- we appreciate
warranty repair or any other repair be arranged directly with Whitehall Manufacturing. If you are not satisfied with our
service, then and only then, contact your dealer.
TROUBLESHOOTING
Remove the ferrous metal
item from the unit -usually
a staple, paper clip, safety
pin, etc. Clean thoroughly.
Contact with ferrous metal
Rust in unit
Adjust the thermostatThe thermostat is set too
low
The thermostat is broken
There is a power failure
Thermal Packs too cool
Replace the thermostat
Check the circuit and turn
on the breaker
Replace the thermostatThe thermostat is broken
Thermal Packs too hot and
then too cool
Adjust the thermostat
The thermostat is broken
The thermostat is set too
high
Thermal Packs too hot
Replace the thermostat
Replace the Thermal
Packs
Drain, clean and refill
The Thermo Packs are
worn out (seeping)
Too long between cleaning
Water is cloudy
Replace the heating
element
Replace the thermostat
Adjust the thermostat
Thermostat is not working
Heating element is burned
out
Circuit breaker is off
Water doesn't get hot, even
though unit is plugged in
and switch is ON
Problem Cause Solution
Instructions for Operation and Care of Mobil 8 Pack Thermalator

WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
11
Instructions for Operation and Care of Mobil 8 Pack Thermalator
Exploded View
Delay Fuse.
See Item 12
Use only Time
The protective conductor terminal symbol in the above figure
identifies the location of the bonding terminal, which is bonded to
conductive accessible parts of the enclosure for safety purposes.
Protective Conductor Terminal
Fuse Location
Alternating Current
POWER INLET
GND
L
N
FUSE 1
OPERATING
THERMOSTAT
HEATING
ELEMENT
54
1 2
DPST
SWITCH
FUSE 2
HI TEMP
THERMOSTAT
35
6
7
8
9
10
11
12
15
16
17 11
31
5
32
20 22 23 24
25
26
27
28
30
2
3
4
19 1918
29
Fuse 1
Fuse 2
14
13
36
38
37
1
3334
5

WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
12
Instructions for Operation and Care of Mobil 8 Pack Thermalator
Model T-8-M (120 VAC 60 Hz)
38 Insert support loop, vinyl coated6702-560-001
Insert rack assembly, vinyl coated
Cervical hot pack rack adapter
6702-550-001
6702-045-199
6702-520-199
6702-050-002
6702-531-199
6702-151-199
6512-006-000
6507-058-000
6507-008-000
0710-232-000
6505-510-000
6505-511-000
6505-500-000
6505-056-000
0322-003-000
0108-103-000
0710-446-000
0338-004-000
0337-003-000
0308-010-000
0302-007-000
2803-300-000
0126-058-000
0116-010-000
0116-008-000
Electrical panel
Thermometer Clamp Assembly
Inner tank tensioner
Handle - Thermalator
Drain valve
3" caster with brake
3" caster
Fuse holder assembly 1/4" x 1-1/4" lg
On/Off switch
Thermostat (65-170 °) w/ washers & nuts
Heating Element (120VAC/1000W) w/ washers & nuts
Power cord 13A, 125V
#6 lock washer
#6-32 x 5/16" phillips screw
Thermal Overheating Sensor
Plastic washer
3/8" lockwasher
#10-32 nylon insert locknut
3/8"-16 hex nut
3/8"-16 x 1-1/4" hex head cap screw
1/4"-20 x 1-1/2" phillips screw
#10-32 x 1/2" truss phillips head screw
#6-32 x 3/16" phillips screw
11
10
1
26
20
22
17
27
21
2
7
31
32
33
34
16
18
35
6
8
25
12
19
15
23
5
3
9
24
36
37
DESCRIPTIONITEM
6702-518-001 Electrical cover assembly
14
4
6505-546-000 10A/15A 250VA Snap-in power inlet
13
28
29
30
PART NUMBER
0358-003-000
6700-041-000
Hose clamp
7/8" OD x 5/8" ID norprene tubing
6900-136-000 Fuse, ceramic 1/4" x 1-1/4" lg 15A 250VAC
6505-508-000 Thermostat knob
0302-011-000 #6-32 SST hex nut
1/4"-20 high crown acorn nut6502-520-000
6702-532-199 Handle Spacer
1/4-20 UNC x 1/2" carriage bolt stn stl
1/4" Fender washer
1/4-20 UNC stn stl hex nut
0118-001-000
0302-005-000
0331-031-000

WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
13
Instructions for Operation and Care of Mobil 8 Pack Thermalator
Model ET-8-M (220 VAC 50/60 Hz)
6505-501-000
Call for part #
Heating Element (220VAC/1000W) w/ washers & nuts
1/4" fender washer
0710-230-001 Fuse holder assembly 5mm x 20mm
0710-202-000 Fuse, ceramic 5mm x 20mm 6A 250V time delay
38 Insert support loop, vinyl coated6702-560-001
Insert rack assembly, vinyl coated
Cervical hot pack rack adapter
6702-550-001
6702-045-199
6702-520-199
6702-050-002
6702-531-199
6702-151-199
6512-006-000
6507-058-000
6507-008-000
6505-515-000
6505-511-000
0322-003-000
0108-103-000
0710-446-000
0338-004-000
0337-003-000
0308-010-000
0302-007-000
2803-300-000
0126-058-000
0116-010-000
0116-008-000
Electrical panel
Thermometer Clamp Assembly
Inner tank tensioner
Handle - Thermalator
Drain valve
3" caster with brake
3" caster
On/Off switch
Thermostat (65-170 °) w/ washers & nuts
Power cord 13A, 125V
#6 lock washer
#6-32 x 5/16" phillips screw
Thermal Overheating Sensor
Plastic washer
3/8" lockwasher
#10-32 nylon insert locknut
3/8"-16 hex nut
3/8"-16 x 1-1/4" hex head cap screw
1/4"-20 x 1-1/2" phillips screw
#10-32 x 1/2" truss phillips head screw
#6-32 x 3/16" phillips screw
11
10
1
26
20
22
17
27
21
2
7
31
32
33
34
16
18
35
6
8
25
12
19
15
23
5
3
9
24
36
37
DESCRIPTIONITEM
6702-518-001 Electrical cover assembly
14
4
6505-546-000 10A/15A 250VA Snap-in power inlet
13
28
29
30
PART NUMBER
0358-003-000
6700-041-000
Hose clamp
7/8" OD x 5/8" ID norprene tubing
6505-508-000 Thermostat knob
0302-011-000 #6-32 SST hex nut
1/4"-20 high crown acorn nut6502-520-000
6702-532-199 Handle Spacer
1/4-20 UNC x 1/2" carriage bolt stn stl
1/4-20 UNC stn stl hex nut
0118-001-000
0302-005-000
0331-031-000

WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone [phone] • [phone] • Fax [phone] • Web: www.whitehallmfg.com
14
Instructions for Operation and Care of Mobil 8 Pack Thermalator
ELECTRICAL PARTS DISASSEMBLY
Thermostat
Fuses
Fuse Holder
Power Inlet
Thermal Sensor
Switch
Heating Element

Mailing Address:
P.O. Box 3527 • City of Industry, CA 91744-0527 U.S.A
Physical Address:
15125 Proctor Avenue • City of Industry, CA 91746 U.S.A
Phone [phone] • 626-968-6681
Fax [phone]
Web: www.whitehallmfg.com
E-mail: [email protected]
NOTICE TO KEEP ORIGINAL PACKAGING- Regarding warranty claims: customer must retain original packaging
for one year upon receipt of product. If packaging is discarded, it is the customer's responsibility to provide adequate
packaging. Any shipping claims that are a direct result of customer-provided packaging materials will be handled by
the shipper.
Go to to fill out eWarranty Registration, keyword search: WARRANTY.www.whitehallmfg.com
This warranty does not cover installation or labor charges, and does not apply to materials which have been
damaged by other causes such as mishandling or improper care or abnormal use. The repair or replacement of
the defective materials shall constitute the sole remedy of the Buyer and the sole remedy of Whitehall under this
warranty. Whitehall shall not be liable under any circumstances for incidental, consequential or direct charges caused
by defects in the materials, or any delay in the repair or replacement thereof. This warranty is in lieu of all other
warranties expressed or implied. Product maintenance instructions are issued with each fixture, and disregard or non-
compliance with these instructions will constitute an abnormal use condition and void the warranty. Stainless steel
must be properly maintained after the water has been introduced into the fixture, or Whitehall's limited warranty is void.
If you have any questions or require technical assistance, please call 800-743-8219.
Whitehall Manufacturing Company warrants that its products are free from defects in material or workmanship under
normal use and service for a period of one year from date of shipment. Whitehall's liability under this warranty shall be
discharged solely by replacement or repair of defective material, provided Whitehall is notified in writing within one
year from date of shipment, F.O.B. Industry, California.
MANUFACTURER'S WARRANTY
Member of
Any questions regarding servicing of products in Europe or the Middle East should be directed to:
Acorn Powell, Limited • 5 Brearley Court, Baird Road Quedgeley, Gloucester GL2 2AF, United Kingdom
Phone [phone] • Fax [phone]
Web www.acornpowell.co.uk
[email protected]
