widos 6100 CNC 3.0 User manual

Ku nst sto ffschweißtechn i k
WIDOS Einsteinstr. 5 Phone [phone] - 0
. Dommer Söhne GmbH D-71254 Ditzingen-Heimerdingen Fax [phone] - 40
ebsite: www.widos.de Email: [e-mail]
Headquarters: D-71254 Ditzingen-Heimerdingen Country court Stuttgart HRB 200973 Managing director: Jürgen Dommer
Working Instructions
Translation
Heating element butt welding machine
with CNC control unit
WIDOS 6100 CNC 3.0
Keep for further use!

Ku nst sto ffschwei ßtec hni k
Product identification
27.10.2011 orking Instructions IDOS 6100 CNC 3.0 Page 2 of 76
Model: Heating element butt welding machine with
CNC control unit
Type: IDOS 6100 CNC 3.0
Serial number, year of construction: see type lable
Customer entries
Inventory-no.:
Place of working:
Order of spare parts and after sales ser ice:
Address of manufacturer WIDOS
. Dommer Söhne GmbH
Einsteinstr. 5
D -71254 Ditzingen-Heimerdingen
Phone: ++49 7152 / 99 39 - 0
Fax: ++49 7152 / 99 39 - 40
Address of the subsidiary companies
WIDOS
IDOS GmbH . Dommer Söhne AG
An der iesenmühle 15 St. Gallerstr. 93
D-09224 Grüna / Sachsen CH– 9201 Gossau
Phone: ++49 371 / 8 15 73 - 0 Phone: ++41 71 / 388 89 79
Fax: ++49 371 / 8 15 73 - 20 Fax: ++41 71 / 388 89 73

Ku nst sto ffschwei ßtec hni k
Introduction
27.10.2011 orking Instructions IDOS 6100 CNC 3.0 Page 3 of 76
Purpose of the document
These working instructions give you information about all important questions which refer to the
construction and the safe working of your machine.
Just as we are, you are obliged to engage in these working instructions, as well.
Not only to run your machine economically but also to avoid damages and injuries.
Should questions arise, contact our service team in the factory or in our subsidiary companies.
e will help you with pleasure.
According to our interest to continuously improve our products and working instructions, we
kindly ask you to inform us about problems and defects which occur in exercise.
Thank you.
Structure of the working instructions
This manual is arranged in chapters which belong to the different using phases of the
machine.
Due to this structure, the searched information can be easily found.
27.10.2011 WIDOS
. Dommer Söhne GmbH
Einsteinstraße 5
D-71254 Ditzingen-Heimerdingen
All rights reserved
Reprinting only allowed with permission of the corporation.
Any changes prior to technical innovations.

Ku nst sto ffschwei ßtec hni k
Contents
27.10.2011 orking Instructions IDOS 6100 CNC 3.0 Page 4 of 76
1. DESCRIPTION OF THE PRODUCT 7
1.1. Usage and purpose-oriented use 7
1.2. Safety measures 7
1.3. Conformity 7
1.4. Machine o er iew 8
1.5. Structure of the CNC 3.0 control unit 8
1.6. Designation of the product 9
1.6.1. Technical data 9
1.6.1.1. IDOS CNC 3.0 General data 9
1.6.1.2. Basic frame 10
1.6.1.3. Heating element 10
1.6.1.4. Planer 10
1.6.1.5. Reception box 10
1.7. Emergency power supply (optional) 11
1.8. Equipment and accessories: 11
2. SAFETY RULES 12
2.1. Explanation of the symbols and indications 12
2.2. Obligations of the owner 12
2.3. Obligations of the worker 13
2.4. Measures of organisation 13
2.5. Information about safety precautions 13
2.6. Instructions for the staff 13
2.7. Dangers while handling the machine 13
2.8. Specific dangers 14
2.8.1. Danger of stumbling over hydraulic and electric wires 14
2.8.2. Danger of catching clothes by the planer 14
2.8.3. Danger of being burnt by heating element and welding area 15
2.8.4. Danger of squeezing by clamping devices and guideways 15
2.9. Structural modifications on the machine 15
2.10. Warranty and liability 15
3. FUNCTIONAL DESCRIPTION 16
4. OPERATING AND INDICATING ELEMENTS 17
4.1. Elements on the CNC 3.0 control unit 17
4.2. EMERGENCY-stop push button 18
4.3. Separating de ice for heating element 18
4.4. Elements on the heating element and the planer 19
4.5. Lift-off de ice (optional) 20
4.5.1. Mounting of the machine 20
4.5.2. Mounting the lift-off device 20

Ku nst sto ffschwei ßtec hni k
Contents
27.10.2011 orking Instructions IDOS 6100 CNC 3.0 Page 5 of 76
4.5.3. Transport 20
5. STARTING AND OPERATING 21
5.1. Safety indications 21
5.2. Replacing the reduction inserts 22
5.2.1. Using small reduction inserts 22
5.3. Connection with the basic machine 23
5.4. Operation with Emergency Power Supply 23
5.5. Description of the Display 24
5.6. Accessories for Reading the Data in and out 24
5.6.1. Legitimacy Cards 24
5.6.2. SD – card and drive 25
5.6.3. Barcode 25
5.6.4. Read-out ICON with USB card reader (optional) 25
5.7. Switching the CNC 3.0 on 26
5.8. Programming and welding with gas legitimacy card 27
5.9. Programming and welding with general legitimacy card or ISO legitimacy card 27
5.9.1. Setting the pipe data 28
5.10. Welding process 29
5.10.1. elding process with traceability 33
5.11. Error messages 34
5.12. More adjustemends 35
5.12.1. Setting the time and the date 35
5.12.2. Setting the language 36
5.12.3. Setting information of traceability and lenght of pipe 36
5.12.4. Setting of shortened cooling time 37
5.13. Administration of the welding data 38
5.13.1. Copying internal data onto SD-card and deleting them (RAM) 38
5.13.2. Storing data on the SD - card 39
5.14. Function of the emergency power supply (optional) 40
6. DIAGNOSIS PROGRAM 41
7. EQUIPMENT CARE / MAINTENANCE / REPAIR 43
7.1. Storage 43
7.2. Cleaning the machine 43
7.3. Clamping elements 43
7.4. Checking the hydraulic oil le el 43
7.5. Venting the hydraulic cylinders 44
7.6. Maintenance, inspection and repair 45
7.7. Sa ing the welding data 45
7.8. Error signals 46

Ku nst sto ffschwei ßtec hni k
Contents
27.10.2011 orking Instructions IDOS 6100 CNC 3.0 Page 6 of 76
7.9. Possible defects and their elimination 47
7.10. Accumulator for emergency power supply (optional) 48
7.11. Fuse for o erload safety de ice / printer plug box 48
7.12. Disposal 48
8. TRANSPORT 49
9. WIRING AND HYDRAULIC DIAGRAMS 50
10. SPARE PARTS LIST 64
10.1. Basic machine 64
10.2. CNC control unit 66
10.3. Planer 68
10.4. Heating element 70
10.5. Reception box 72
10.6. Lift off de ice (optional) 74
11. DECLARATION OF CONFORMITY 76

Ku nst sto ffschwei ßtec hni k
WIDOS Einsteinstr. 5 Phone [phone] - 0
. Dommer Söhne GmbH D-71254 Ditzingen-Heimerdingen Fax [phone] - 40
ebsite: www.widos.de Email: [e-mail]
27.10.2011 orking Instructions IDOS 6100 CNC 3.0 Page 7 of 76
1. Description of the product
1.1. Usage and purpose-oriented use
The WIDOS 6100 CNC 3.0 has been designed only for heating element butt welding of pipes
and fittings made out of PE, PP, PVDF with their diameter range going from OD
min
= 355 mm up
to OD
max
= 630 mm (standar diameters: 355 / 400 / 450 / 500 / 560 / 630 mm.)
All use of this control going beyond is not purpose oriented.
The machine is only to be used in a technically perfect condition, as well as purpose oriented,
safety- and danger-conscious in compliance with the working instructions and the relevant safety
regulations (especially the regulations for the prevention of accidents).
The described plastic welding machine may only be operated, maintained and repaired by
persons who are trained and informed about the dangers.
The manufacturer is not responsible for any damages caused by inexpert handling or operation.
For personal injuries, material and immaterial damages resulting herefrom, only the user is
responsible!
The control unit is reliable in the use when it is used according to the prescriptions in connection
with a welding machine designed by IDOS.
Also part of the purpose oriented use is
• respecting all the indications of the working instructions and
• performing the inspection and maintenance works.
1.2. Safety measures
In case of wrong use, wrong operation or wrong maintenance, the machine itself or products
standing nearby can be damaged or destroyed.
Persons being in the endangered area may be injured.
Therefore these working instructions have to be thoroughly read and the corresponding safety
regulations must be necessarily adhered to.
1.3. Conformity
The machine corresponds in its construction to the valid recommendations of the European
Community as well as to the according European standard specifications.
The development, manufacturing and mounting of the machine were made very carefully.

Ku nst sto ffschwei ßtec hni k
Description of product Chapter 1
27.10.2011 orking Instructions IDOS 6100 CNC 3.0 Page 8 of 76
1.4. Machine o er iew
No. Denomination
1 Basic machine
2 Control unit
3 Lift off device (optional)
4 Heating element
5 Planer
6 Reception box
1.5. Structure of the CNC 3.0 control unit
No. Denomination
7 Display
8 Operating fields
9 Barcode reader
10 Pipe data card or general legitimacy card
11 SD card
2
6
5
4
3
1
7
10
9
11
8

Ku nst sto ffschwei ßtec hni k
Description of product Chapter 1
27.10.2011 orking Instructions IDOS 6100 CNC 3.0 Page 9 of 76
1.6. Designation of the product
The product is designated by type labels.
The type labels are attached at the control unit, at the heating element, at the planer and at the
basic machine.
They contain the type, the serial number and the year of construction of the machine.
1.6.1. Technical data
All important technical data of each single component are listed.
This allows a quick information about working capacity and structure.
1.6.1.1. IDOS CNC 3.0 General data
eight (without transport box):
Dimensions (l x w x h):
450 kg
appr. 630x430x510 (mm)
Covering: 16 A
Voltage: 400 V (± 10%)
Frequency: 50 Hz
Phase shift: appr. 18°
Control voltage: 5 V
Insulation system: IP 44
Hydraulic oil tank: appr. 1 l
Attached elements: Connection cable with CEE - motor protective plug 16 A
Power of emergency set: 6.5 kVA / 400 V/3~
Emissions - Noises exceeding 80 dB (A) may occur; during planing it
is obligatory to wear ear protection!
- hen using the named pipe materials and when welding
below 260°C no toxicant damp arises
Ambient conditions in the welding
area
- take care for cleanness (no dust at the welding area)
- if secured by an appropriate measurement that allowed
conditions for welding are indicated, it is possible to work
in any outside temperature condition as far as the welder
is not constrained in its manual skill.
- avoid humidity, if necessary use a welding tent
- avoid strong sun rays influence
- protect from wind, shut the pipe ends
Electro motor and pump:
Power: 0,56 k
Current: 4,7 A
Driving speed: 2720 rpm
Max. working pressure of the
pump:
110 bar
orking pressure: 100 bar
Volume flow: 3,5 l/min.

Ku nst sto ffschwei ßtec hni k
Description of product Chapter 1
27.10.2011 orking Instructions IDOS 6100 CNC 3.0 Page 10 of 76
1.6.1.2. Basic frame
Material frame: Construction steel
Material clamping inserts: Aluminium
eight: appr. 226 kg
Cylinder-Ø: 60 mm
Piston rod-Ø: 50 mm
Stroke length of cylinder: 300 mm
Max. force: (F=P*A) 17,30 kN (at 100 bar)
Velocity os piston rod: 3,4 cm/s
1.6.1.3. Heating element
Power: 6,0 k
Voltage: 400 V (± 10 %)
Current: 15 A
Frequency: 50 Hz
Outside-Ø: 684 mm
Surface: nonstick-coated
Attached elements: - electronic temperature control
- control lamps
- cable with 16 pole plug
eight: appr. 36 kg
1.6.1.4. Planer
Motor: Alternating current motor
Power: 1.1 k
Voltage: 400 V (± 10 %)
Current: 3,5 A
Frequency: 50 Hz (± 10 %)
Driving speed appr. 140
eight: appr. 103 kg
Attached elements: - cable with plug CEE 16A
- locking device
1.6.1.5. Reception box
Dimensions: 870 x 610 x 740 mm
eight: appr. 62 kg
See spare parts list for order numbers and single parts

Ku nst sto ffschwei ßtec hni k
Description of product Chapter 1
27.10.2011 orking Instructions IDOS 6100 CNC 3.0 Page 11 of 76
1.7. Emergency power supply (optional)
In order to avoid an abortion of the welding in case of power failure during the cooling time, a
lead accumulator is provided in the control (12 V / 3.4 Ah).
1.8. Equipment and accessories:
Following accessories are part of the delivery:
5 - General legitimacy card
1 - Key for front plate / hydraulic system
1 - SD card (64 MB storage capacity)
1 - Tool bag for 10 parts
1 - Socket wrench S 27
1 - Allan key, angle size 12
1 - Allan key with T-grip size 7
1 - Torx screw driver T10
Following optional accessories are available on request:
- Pipe data card
- Program ICON for reading out the data (possibility of displaying included in SD-card)
- Gas legitimacy card
- ISO legitimacy card

Ku nst sto ffschwei ßtec hni k
WIDOS Einsteinstr. 5 Phone [phone] - 0
. Dommer Söhne GmbH D-71254 Ditzingen-Heimerdingen Fax [phone] - 40
ebsite: www.widos.de Email: [e-mail]
27.10.2011 orking Instructions IDOS 6100 CNC 3.0 Page 12 of 76
2. Safety rules
The base for the safe handling and the fault-free operation of this machine is the knowledge of
the basic safety indications and rules.
• These working instructions contain the most important indications to run the machine safely.
• The safety indications are to be followed by all persons working on the machine.
2.1. Explanation of the symbols and indications
In the working instructions, following denominations and signs are used for dangers:
This symbol means a possible danger for the life and the health of persons.
• The disrespect of these indications may have heavy consequences for the
health.
This symbol means a possible dangerous situation.
• The disrespect of these indications may cause light injuries or damages on
goods.
This symbol gives important indications for the proper use of the machine.
• The disrespect of these indications may conduct to misfunctions and damages
on the machine or on goods in the surrounding.
This symbol means a possible dangerous situation due to hot surfaces.
• The disrespect of these indications may conduct to heavy burns, respectively to
self-ignition or even fire.
This symbol means a possible dangerous situation by moving parts of the
machine
• The disrespect of these indications may cause heavy crushings of parts of the
body resp. damages of parts of the machine.
This symbol means a possible risk of injury by noises exceeding 80 dB(A).
• Ear protection is obligatory
Under this symbol you get user tips and particularly useful information.
• It is a help for using all the functions on your machine in an optimal way and
helps you to make the job easier.
The regulations for the pre ention of accidents are alid (UVV).
2.2. Obligations of the owner
The owner is obliged only to let persons work at the machine, who
• know about basic safety and accident prevention rules and are instructed in the handling of
the machine, as well as who
• have read and understood the safety chapter of this manual and certify this by their signature.

Ku nst sto ffschwei ßtec hni k
Safety rules Chapter 2
27.10.2011 orking Instructions IDOS 6100 CNC 3.0 Page 13 of 76
The safety-conscious working of the staff has to be checked in regular intervals.
2.3. Obligations of the worker
All persons who are to work at the machine are obliged before working:
• to follow the basic safety and accident protection rules.
• to have read and understood the safety chapter and the warnings in this manual and to
confirm by their signature that they have well understood them.
• to inform themselves about the functions of the machine before using it.
2.4. Measures of organisation
• All equipment required for personal safety is to be provided by the owner.
• All available safety equipment is to be inspected regularly.
2.5. Information about safety precautions
• The working instructions have to be permanently kept at the place of use of the machine.
They are to be at the operator's disposal at any time and without effort.
• In addition to the manual, the common valid and the local accident protection rules and
regulations for the environmental protection must be available and followed.
• All safety and danger indications on the machine have to be in a clear readable condition.
• Every time the machine changes hands or is being rent to third persons, the working
instructions are to be sent along with and their importance is to be emphasized.
2.6. Instructions for the staff
• It must be clearly defined who is responsible for transport, mounting and dismounting, starting
the operation, setting and tooling, operation, maintenance and inspection, repair and
dismounting.
• Only skilled and trained persons are allowed to work at the machine.
• A person who is being trained may only work at the machine under supervision of an
experienced person.
2.7. Dangers while handling the machine
The heating element butt welding machine IDOS 6100 CNC 3.0 is constructed according to
the latest technical standard and the acknowledged technical safety rules.
However, dangers for the operator or other persons standing nearby may occur. Also material
damages are possible.
The machine should only be used
• According to the purpose oriented usage
• In safety technical impeccable status
Disturbances, which may affect the safety of the machine must be cleared immediately.

Ku nst sto ffschwei ßtec hni k
Safety rules Chapter 2
27.10.2011 orking Instructions IDOS 6100 CNC 3.0 Page 14 of 76
Only skilled persons are allowed to work at electrical appliances.
• The electrical equipment of the machine has to be checked regularly.
Loose connections and damaged cables have to be replaced immediately.
• All electric tools (heating element, planer, basic machine with clamps and control unit)
have to be protected from rain and dropping water (if need be use a welding tent).
• According to VDE 0100, the use on construction sites is only allowed with a power distributor
with a FI-safety switch.
• Replace damaged front foil at the control unit in order to avoid water coming in.
System parts and pressure hoses should be made pressureless before beginning
of any repair works.
There is a danger of injuring the eyes by hydraulic oil squirting out. The hydraulic oil
can be hot !
• Damaged hydraulic hoses have to be immediately replaced.
• Make a visual inspection of the hydraulic hoses before each work beginning.
• The hydraulic oil is inedible !
• The hydraulic oil has to be handled and disposed of properly.
2.8. Specific dangers
2.8.1. Danger of stumbling o er hydraulic and electric wires
Make sure that nobody has to step over the cables.
Make sure that the cables lay in such a way that the danger is maintained in a
minimum. Do not squeeze, buckle, etc. the cables. Avoid the hydraulic cables from
being heated up (increase of pressure!).
2.8.2. Danger of catching clothes by the planer
You can cut yourself or even get bones broken!
For some machines the planer may shortly turn when switching the machine on!
• Only wear clothes tight to the body.
• Do not wear rings or jewellery during the work.
• If necessary wear a hair-net.
• Always put the planer back into the reception box after and before each use.
• Only transport the planer at the handle or eye bolt. Do not touch the surfaces.
2.8.3. Risk of injury by noises
Noises exceeding 80 dB (A) may occur; during planing it is obligatory to wear ear
protection!

Ku nst sto ffschwei ßtec hni k
Safety rules Chapter 2
27.10.2011 orking Instructions IDOS 6100 CNC 3.0 Page 15 of 76
2.8.4. Danger of being burnt by heating element and welding area
You can burn parts of your body and inflammable materials can also be ignited!
The heating element is heated up to more than 200°C!
• Do not touch the surfaces of the heating element.
• Do not leave the heating element unsupervised.
• Take enough safety distance to inflammable materials.
• Do wear safety gloves.
• Always put the heating element back into the reception box after and before each use.
• Only transport the heating element at the handle.
2.8.5. Danger of squeezing by clamping de ices and guideways
There is a danger of serious injuries: on the one hand between the inner clamping
devices and on the other hand between the outer clamping device and the end of
the guideway.
• Do not stand or put hands between clamped pipe ends.
• Do not stand or put hands between the inner clamping tools with not yet clamped pipes.
• Do not block opening and closing of the machine sledge.
2.9. Structural modifications on the machine
• No modifications, extensions or reconstructions may be made on the machine without
permission of the manufacturer. In cases of non-compliance, any guarantee and liability
demands shall expire (see chapter 2.5).
• Machine parts which are not in a perfect condition are to be replaced immediately.
• Only use original WIDOS spare and wear parts.
• In case of purchase orders please always state the machine and version number !
2.10. Warranty and liability
Fundamentally our "General Sales and Delivery Conditions" are valid.
They are at the owner's disposal latest when signing the contract.
Guarantee and liability demands referring to personal injuries or damages on objects are
excluded if they are caused by one or several of the following reasons:
• not using the machine according to the prescriptions
• inexpert building-up, starting, operating, maintenance and transport of the machine
• running the machine with defective or not orderly mounted safety appliances
• ignoring the information given in this manual
• structural modifications on the machine without permission
• unsatisfactory checking of parts of the machine, which are worn out
• repairs performed in an inexpert way
• In case of catastrophes and force majeure

Ku nst sto ffschwei ßtec hni k
WIDOS Einsteinstr. 5 Phone [phone] - 0
. Dommer Söhne GmbH D-71254 Ditzingen-Heimerdingen Fax [phone] - 40
ebsite: www.widos.de Email: [e-mail]
27.10.2011 orking Instructions IDOS 6100 CNC 3.0 Page 16 of 76
3. Functional description
The IDOS CNC 3.0 control unit performs a butt welding process with the plastic welding
machine IDOS 6100 after entering the type of material, the pipe diameter and the pipe wall
thickness.
The welding processes are recorded and can be printed out in a short or a long version over the
parallel interface, or be saved on a PCMCIA card or be transmitted over the serial interface e.g.
onto a laptop by means of the program ICON.
The corresponding pipe data are entered manually over the operation field or alternatively read
with the barcode reader.
Welding with the IDOS 6100 CNC 3.0 works as follows:
The plastic pipes are clamped by means of the clamping devices (basic machine) and the pipe
ends are cut plane and parallel by means of the planer.
As soon as the pipes are plane and parallel and the misalignment is smaller than 0,1 X pipe wall
thickness you can start welding.
The heating element has to be cleaned and checked before insertion and the desired
temperature prescribed by the DVS must have been reached.
The clamped pipes drive under pressure in direction of the heating element and are heated up
under the defined adjustment pressure (adjusting), the duration of the adjustment is called
adjusting time.
During the adjustment the bead prescribed by the DVS is performed.
After reaching the prescribed bead height, the control unit automatically switches into the
heating time.
During the heating time the basic machine is in a pressureless state and the pipe ends are
heated.
After expiration of the heating time, the sledges move apart and the heating element should be
removed as fast as possible.
The time period between the removal of the heating element and the closing of the pipes is called
change o er time.
After the maximum time prescribed by the DVS, the pipe ends are driven together and a
continuous welding pressure is built up.
The pipe then cools down under the prescribed welding pressure (cooling time).
After completion of the cooling time, the pressure on the pipe is automatically released and the
welded pipe can be unclamped.
The welding process is completed.
Heating element heats the pipes
up to welding temperature
Finished welded joint with
internal and external bead

Ku nst sto ffschwei ßtec hni k
WIDOS Einsteinstr. 5 Phone [phone] - 0
. Dommer Söhne GmbH D-71254 Ditzingen-Heimerdingen Fax [phone] - 40
ebsite: www.widos.de Email: [e-mail]
27.10.2011 orking Instructions IDOS 6100 CNC 3.0 Page 17 of 76
4. Operating and indicating elements
4.1. Elements on the CNC 3.0 control unit
No. Denomination
1 Operating field with display
2 Reafing unit for SD card
3 Main switch
4 Outside temperature sensor
5 Plug box for planer
6 Main connection cable for the control unit
7 EMERGENCY-Stop push button
8 Barcode reader
9 Connection for barcode reader
10 Connection for the travel sensor
11 Plug box with safety stirrup for heating element
12 Connections for hydraulic hoses
2
3
1
4
7
8
12
11
10
5
6
9

Ku nst sto ffschwei ßtec hni k
Operating and indicating elements Chapter 4
27.10.2011 orking Instructions IDOS 6100 CNC 3.0 Page 18 of 76
4.2. EMERGENCY-stop push button
There is an EMERGENCY-Stop push button (chapter 4.1 No. 9) on the CNC control unit, for
interrupting the working process if the work piece, tools or persons are endangered by the
working pressure.
• The EMERGENCY-Stop push button snaps when it is operated.
The display then shows:
• In case the EMERGENCY-Stop push button was pushed, the system is pressure-less and the
sledge can only be moved manually.
• After elimination of the danger the EMERGENCY-Stop push button must be unlocked again
by turning it in direction of arrow and the functions of buttons <+> and <-> (open and close the
sledge) are possible again.
• For a new welding process, the main switch must be switched on and off again.
There is the danger of being burnt by the heating element cooling down very
slowly.
4.3. Separating de ice for heating element
There is a tear-off bar mounted between the
movable and the fixed clamping shells on the
basic machine. It prevents the heating element
from sticking to the heated-up pipe ends.
hen inserting the heating element take care
that it lies in the zone of the throat of the tear-
off bar (see arrow).
## emergency stop ##

Ku nst sto ffschwei ßtec hni k
Operating and indicating elements Chapter 4
27.10.2011 orking Instructions IDOS 6100 CNC 3.0 Page 19 of 76
4.4. Elements on the heating element and the planer
Name Function
Heating element:
Control lamps,
green
There are 3 different states:
• lightening, only interrupted by short switch-off pulses: the heating
element is being heated up, the desired temperature is not yet reached.
The desired and the actual temperature are displayed alternating on the
display of the control.
• blinking: the temperature of the heating element is maintained by a
pulse-position ratio.
• off: the desired temperature has been exceeded, the
heating element is cooled automatically onto desired temperature, or
the heating element is switched off.
Cable
- Connect the heating element at the corresponding plug box (chapter
4.1, no. 12) on the CNC control unit.
Eye bolt - For lifting / inserting the heating element / planer with the lift-off device.
Grip - For holding (transporting) the heating element when lifting / removing
Planer:
On/off-switch - During the planing process the planer has to be switched on at the
switch. The planing process is operated by the CNC control.
Cable - Connect the planer at the corresponding plug box (chapter 4.1, no. 13)
on the CNC control unit.
Handlebar - For holding (transporting) the planer when lifting / removing
Locking device - Locking the planer in basic machine, (In order to remove the planer, pull
handlebar into arrow direction
Control lamps green (3 pieces)
Connecting cable
with 16-pole plug
On- / off-switsch
Connecting cable with
plug 16 A CEE
Locking device
Eye bolt
Eye bolt
Grip
Handlebar

Ku nst sto ffschwei ßtec hni k
Operating and indicating elements Chapter 4
27.10.2011 orking Instructions IDOS 6100 CNC 3.0 Page 20 of 76
4.5. Lift-off de ice (optional)
• General description
• Safety rules
• Danger indications
• Starting and maintenance
4.5.1. Mounting of the machine
hen mounting the machine, follow the positioning sketch:
4.5.2. Mounting the lift-off de ice
• Insert the crane jib into the reception at the backside of the basic machine.
• Loosen the screw and the lock washer at the hook at the top of the mast, hang in the
chain hoist, tighten again lock washer and screw.
• Connect the chain hoist with the mains (230 V/50 Hz).
• The operation of the lift-off device can be started now (see the separate documentation)
4.5.3. Transport
Dismount the chain hoist from the mast for transportation of the machine.
Protection box
Lift-off device
Hydraulic aggregate
Basic machine
see the separate documentation (company ABUS) .
