widos 8000 WM SPA User manual

WIDOS Einsteinstr. 5 Phone [phone]
Wilhelm Dommer Söhne D-71254 Ditzingen-Heimerdingen Fax [phone]
GmbH Website: www.widos.de Email: [email protected]
Headquarters: D-71254 Ditzingen-Heimerdingen Country Court Stuttgart HRB 200973 Managing directors: Jürgen Dommer, Dr. Kai Dombrowski
Working Instructions
Translation
Heating Element Butt Welding Machine
WIDOS 8000 WM SPA
OD 1200 mm; T-90° with additional cylinder
Keep for further use!

Product identification
09.06.15 Working Instructions WIDOS 8000 WM SPA page 2 of 108
Model: Workshop machine
Type: WIDOS 8000 WM SPA
Serial no: / Year of construction: see type label
Customer‘s entries
Inventory no.:
Location:
Order of spare parts and sales service:
Manufacturer’s address: WIDOS
W. Dommer Söhne GmbH
Einsteinstr. 5
D-71254 Ditzingen-Heimerdingen
Phone: [phone]
Fax: [phone]
E-mail: [e-mail]
Website: www.widos.de

Introduction
09.06.15 Working Instructions WIDOS 8000 WM SPA page 3 of 108
Purpose of the document
These working instructions give you information about all important questions which refer to the construction
and the safe working of your machine.
Just as we are, you are obliged to engage in these working instructions, as well.
Not only to run your machine economically but also to avoid damages and injuries.
Should questions arise, contact our advisers in the factory or in our subsidiary companies.
We will help you with pleasure.
According to our interest to continuously improve our products and working instructions, we kindly ask you to
inform us about problems and defects which might appear in practical experience.
Thank you.
Structure of the working instructions
This manual is arranged in chapters which belong to the different using phases of the machine. Therefore the
searched information can be easily found.
6/9/2015 WIDOS
W. Dommer Söhne GmbH
Einsteinstraße 5
D-71254 Ditzingen-Heimerdingen
All rights reserved
Reprinting only allowed with permission of the corporation.
Any changes are subject to technical innovations.

Contents
09.06.15 Working Instructions WIDOS 8000 WM SPA page 4 of 108
1. DESCRIPTION OF PRODUCT ................................................................................................................7
1.1. Application and intended use................................................................................................................7
1.2. Safety measures...................................................................................................................................7
1.3. Conformity............................................................................................................................................7
1.4. Designation of product .........................................................................................................................7
1.4.1. Technical data ................................................................................................................................................................ 8
1.4.1.1. WIDOS 8000 General data ................................................................................................................................. 8
1.4.1.2. Basic frame / table.............................................................................................................................................. 8
1.4.1.3. Heating element .................................................................................................................................................. 8
1.4.1.4. Planer.................................................................................................................................................................... 9
1.4.1.5. Hydraulic aggregate........................................................................................................................................... 9
1.5. Wear parts ...........................................................................................................................................9
1.6. Equipment (optional)...........................................................................................................................10
1.7. Tools and accessories ........................................................................................................................11
2. SAFETY RULES .................................................................................................................................... 12
2.1. Explanation of the symbols and indications.........................................................................................12
2.2. Obligations of the owner.....................................................................................................................13
2.3. Obligations of the user........................................................................................................................13
2.4. Measure of organization.....................................................................................................................13
2.5. Information about safety precautions..................................................................................................13
2.6. Instructions for the staff .....................................................................................................................13
2.7. Dangers while handling the machine ..................................................................................................14
2.8. Specific dangers ................................................................................................................................14
2.8.1. Danger of stumbling over electric wires and hydraulic hoses............................................................................. 14
2.8.2. Danger of drawing-in of clothes by the planer ....................................................................................................... 14
2.8.3. Risk of injury by noise.................................................................................................................................................. 15
2.8.4. Danger of combustion by heating element and welding area.............................................................................. 15
2.8.5. Danger of crushing ...................................................................................................................................................... 15
2.9. Structural modifications on the machine.............................................................................................15
2.10. Warranty and liability .........................................................................................................................16
3. FUNCTIONAL DESCRIPTION .............................................................................................................. 17
4. OPERATING AND INDICATING ELEMENTS ...................................................................................... 18
4.1. Machine overview ..............................................................................................................................18
4.2. Operator console................................................................................................................................19
4.2.1. Operator panel.............................................................................................................................................................. 19
4.2.2. Switch cupboard .......................................................................................................................................................... 21
4.3. Service unit and pneumatic valves......................................................................................................22
4.3.1. Service unit ................................................................................................................................................................... 22
4.3.1.1. Service unit ........................................................................................................................................................ 22
4.4. Hydraulic aggregate ...........................................................................................................................23
4.5. Horizontal adjustment (mismatch compensation) ................................................................................24
4.6. Additional cylinder (optional) ..............................................................................................................24
4.7. Clamping tools with 15° / 22,5° (optional) ............................................................................................25

Contents
09.06.15 Working Instructions WIDOS 8000 WM SPA page 5 of 108
4.7.1. How to mount clamping tools on machine tables................................................................................................... 26
4.8. Structure of 15° / 22,5°-clamping tools (optional) ................................................................................27
4.8.1. Structure clamping tools for straight pipes ............................................................................................................. 27
4.8.2. Structure clamping tools for for angles with 30° / 45°........................................................................................... 27
4.8.3. Structure 15° / 22,5-clamping tools for other angles.............................................................................................. 28
4.8.4. Reduction inserts ......................................................................................................................................................... 28
4.9. Clamping tools for T–piece 90° (optional) ............................................................................................29
4.10. Clamping tools for T-45° welding (optional) .........................................................................................30
4.11. Clamping tools for T-60° welding (optional) .........................................................................................33
4.12. Reduction inserts for T-clamping tools (optional) ................................................................................36
4.13. How to clamp pipes in the T–tools ......................................................................................................36
4.13.1. How to support the pipes (optional).......................................................................................................................... 37
4.14. Beam for unilateral planing (optional) .................................................................................................38
4.15. Stub end holder (optional) .............................................................................................................39
5. STARTING AND OPERATING ............................................................................................................. 40
5.1. Safety indications...............................................................................................................................40
5.2. Starting ..............................................................................................................................................40
5.3. How to adjust the heating element temperature ..................................................................................41
5.4. SD card and drive (optional) ...............................................................................................................42
5.5. USB – adapter (optional).....................................................................................................................42
5.6. How to switch on the machine ............................................................................................................43
5.7. How to set the machine type...............................................................................................................44
5.8. How to set language, time and date ....................................................................................................45
5.9. How to set the pipe data .....................................................................................................................46
5.10. Lab program for the pipe and welding parameters.....................................................................48
6. WELDING PROCESS ........................................................................................................................... 52
6.1. How to insert and clamp the pipes ......................................................................................................52
6.2. Welding process with SPA 600............................................................................................................53
6.2.1. Drag pressure measurement ..................................................................................................................................... 53
6.2.2. Dimension...................................................................................................................................................................... 54
6.2.3. Planing ........................................................................................................................................................................... 55
6.2.4. Compensation of mismatch ........................................................................................................................................ 55
6.2.5. Bead up.......................................................................................................................................................................... 56
6.2.6. Heating up ..................................................................................................................................................................... 57
6.2.7. Change over .................................................................................................................................................................. 57
6.2.8. Pressure ramp .............................................................................................................................................................. 57
6.2.9. Joining / Cooling........................................................................................................................................................... 58
6.2.10. Completion of welding................................................................................................................................................. 58
6.2.11. Signification of error codes........................................................................................................................................ 59
6.2.12. How to copy internal data on SD card and deleting internal data (RAM) .......................................................... 59
6.2.13. How to read out the welding data ............................................................................................................................. 60
6.3. Welding process without SPA 600.......................................................................................................61
6.3.1. Drag pressure measurement ..................................................................................................................................... 61

Contents
09.06.15 Working Instructions WIDOS 8000 WM SPA page 6 of 108
6.3.2. How to plane pipes ...................................................................................................................................................... 61
6.3.3. How to compensate misalignment............................................................................................................................ 61
6.3.4. Aligning .......................................................................................................................................................................... 62
6.3.5. Heating........................................................................................................................................................................... 62
6.3.6. Change over .................................................................................................................................................................. 62
6.3.7. Joining............................................................................................................................................................................ 62
6.3.8. End of welding .............................................................................................................................................................. 63
6.4. How to weld segmented bends......................................................................................................63
6.5. Factors for the welding of angle and T-piece ......................................................................................64
6.6. How to prepare the pipes for T–pieces ...............................................................................................64
7. WELDING LOG AND TABLES ............................................................................................................. 66
7.1. Formulas for the welding of pipes with different diameters .................................................................66
8. EQUIPMENT CARE / MAINTENANCE / REPAIR ................................................................................ 72
8.1. Maintenance and care........................................................................................................................72
8.2. Clamping elements .............................................................................................................................72
8.3. Transport............................................................................................................................................73
8.4. Planer.................................................................................................................................................73
8.5. Service unit ........................................................................................................................................73
8.6. How to check the hydraulic oil level / refilling.....................................................................................74
8.7. Protect machine parts against corrosion ............................................................................................74
8.8. Disposal .............................................................................................................................................74
9. WIRING DIAGRAMS ........................................................................................................................... 75
10. DECLARATION OF CONFORMITY..................................................................................................... 108

WIDOS Einsteinstr. 5 Phone [phone]
Wilhelm Dommer Söhne D-71254 Ditzingen-Heimerdingen Fax [phone]
GmbH Website: www.widos.de Email: [email protected]
09.06.15 Working Instructions WIDOS 8000 WM SPA page 7 of 108
1. Description of product
This chapter gives important basic information about the product and its prescribed use.
All technical details of the machine are put together as a general arrangement.
1.1. Application and intended use
The WIDOS 8000 WM SPA is a workshop machine for the heating element butt welding of pipes and
T-pieces 90° out of PE and PP from OD = 500 mm up to OD = 1200 mm.
(The standard diameter for clamping inserts: OD = 500 / 630 / 710 / 800 / 1000 / 1200 mm).
The right-hand clamping tools are axially displaceable by means of a thread spindle for the compensation of
diameter tolerances.
Any other use of this machine is non-intended.
The machine is only to be used in a technically perfect condition as well as intended, safety- and danger-
conscious in compliance with the working instructions and the relevant safety regulations (especially the
regulations for the prevention of accidents).
All use going beyond is not prescribed.
The manufacturer is not responsible for damages caused by misuse.
The risk is held only by the user.
Also part of the purpose oriented use is
the respect of all the indications of the working instructions and
performing the inspection and maintenance work.
1.2. Safety measures
In case of wrong use, wrong operation or wrong maintenance, the machine itself or products standing
nearby can be damaged or destroyed.
Persons in the endangered area may be injured.
Therefore these working instructions have to be thoroughly read and the corresponding safety regulations
must necessarily be observed.
1.3. Conformity
The machine corresponds in its construction to the valid recommendations of the European Community as
well as to the European standard specifications.
The development, manufacturing and mounting of the machine were executed very carefully.
1.4. Designation of product
The product is designated by a type label.
It contains the type of the machine, the serial number and the year of construction.

Description of product Chapter 1
09.06.15 Working Instructions WIDOS 8000 WM SPA page 8 of 108
1.4.1. Technical data
All important technical data of the individual components is listed.
The data provides quick information on the capability and construction.
1.4.1.1. WIDOS 8000 General data
Material: PE, PP, PVC
Tube dimensions: OD = 500 – 1200 mm (900 mm)
Emissions: - Noise exceeding 80 dB (A) may occur; while planing it is obligatory
to wear ear protection!
- In case of use of the prescribed plastic materials and if the work is
performed inside the temperature range up to 260 °C / 500 °F no
toxic fumes will be generated.
Environmental conditions in the
welding area:
- Be aware of cleanliness (no dust at the welding point)
- Prevent from moisture influence
- If secured by an appropriate measurement that allowed conditions
for welding are indicated, it is possible to work in any outside
temperature condition as far as the welder is not constrained in its
manual skill.
Dimension (w x d x h): appr. 3200 x 5000 x 2700 mm (without operator control)
Feeding: 39 kVA / 380 V – 400 V / 50 Hz - 60 Hz
1.4.1.2. Basic frame / table
Material basic frame: Construction steel
Ø of cylinder- / Ø of piston rod: (2 pieces) 50 / 32 mm
max. force (F = P*A): 23,18 kN (at 100 bar)
1 bar at pressure gauge = 232 N
Additional Ø of cylinder- / Ø of piston rod: 50/ 32 mm
max. force include additional cylinder (F = P*A): 34,77 kN (at 100 bar)
1 bar at pressure gauge = 348 N
max. working pressure: 240 bar
1.4.1.3. Heating element
Power: 31,046 kW
Voltage: 380 V – 400 V
Current: 135 A / phase
Frequency: 50 Hz - 60 Hz
Surface: anti-stick coating

Description of product Chapter 1
09.06.15 Working Instructions WIDOS 8000 WM SPA page 9 of 108
1.4.1.4. Planer
Motor: Three-phase motor
Power: 2,5 kW
Voltage: 380 V – 400 V
Current: 6,25 A
Frequency: 50 Hz - 60 Hz
Speed planer disc: appr. 7,5 U/min
1.4.1.5. Hydraulic aggregate
Power: 3,6 kW
Voltage: 380 V – 400 V
Current: 7,8 A
Frequency: 50 Hz - 60 Hz
Driving speed: 1450 (U/min)
max. working pressure of the pump: 240 bar
Flow velocity for moving: 16 l/min
Flow velocity for pressure: 3,9 l/min
Hydraulic oil tank: appr. 170 l
1.5. Wear parts
Pieces: Name: Order no.:
16 Blade 170 mm MES170
96 Flat-head screw M 3x8 with Torx drive 0965C008TX
1 Drive gear ¾ x 7/16”, Z = 16 teth (for planer) 1474005
2 Temperature probe PT 1000 H09086
1 Heating plate (OD 1200 bow) 1475F701
10 Heating cartridge Ø 16 x 1415 L / 440 V / 2900 W on request
1 Heating cartridge Ø 16 x 1375 L / 440 V / 2800 W on request
1 Heating cartridge Ø 16 x 1270 L / 440 V / 2600 W on request
2 PTFE foil for heating plate 1475F708
1 l Hydraulic oil HLDP35

Description of product Chapter 1
09.06.15 Working Instructions WIDOS 8000 WM SPA page 10 of 108
1.6. Equipment (optional)
The following accessories can be included in the first deliveries:
Pieces: Name:
1 set 15°-Clamping tool withOD 1200 mm
1 set
8
15°-Reduction insert OD 1000 mm in 15°- clamping tool OD 1200 mm
Pan-head screw M 12 x 100 DIN 912
1 set
8
15°- Reduction insert OD 900 mm in 15°- reduction insert OD 1000 mm
Pan-head screw M 12 x 50 DIN 912
1 set
8
15°- Reduction insert OD 800 mm in 15°- reduction insert OD 1000 mm
Pan-head screw M 12 x 100 DIN 912
1 set
8
15°- Reduction insert OD 710 mm in 15°- reduction insert OD 1000 mm
Pan-head screw M 12 x 150 DIN 912
1 set
8
15°- Reduction insert OD 630 mm in 15°- reduction insert OD 1000 mm
Pan-head screw M 12 x 200 DIN 912
1 set
4
15°- Reduction insert OD 500 mm in 15°- reduction insert OD 630 mm
Pan-head screw M 12 x 65 DIN 912
1 set T-90°-Spannwerkzeug mit OD 900 mm
1 set
12
T-90°- Reduction insert OD 710 mm in T–90°- clamping tool OD 900 mm
Pan-head screw M 12 x 110 DIN 912
1 set
12
T-90°- Reduction insert OD 630 mm in T–90°- clamping tool OD 900 mm
Pan-head screw M 12 x 140 DIN 912
1 set
12
T-90°- Reduction insert OD 500 mm in T–90°- clamping tool OD 900 mm Z
Pan-head screw M 12 x 200 DIN 912
1 set T-45°/60°-Spannwerkzeug mit OD 900 mm
1 set
8
T-45°/60°- Reduction insert OD 710 mm in T-45°/60°- clamping tool OD 900 mm
Pan-head screw M 12 x 110 DIN 912
1 set
8
T-45°/60°- Reduction insert OD 630 mm in T-45°/60°- clamping tool OD 900 mm
Pan-head screw M 12 x 140 DIN 912
1 set
8
T-45°/60°- Reduction insert OD 500 mm in T-45°/60°- clamping tool OD 900 mm
Pan-head screw M 12 x 200 DIN 912
1 Additional cylinder complete
1 Stub end holder OD 1200 mm
4 Clamping jaw 1477F709
3 Clamping jaw for T-45°, 2. welding 1477F7092
6 Pan-head screw M 16 x 130 DIN 912
12 Washer M 16 DIN 9021
12 Hexagon nut M 16 DIN 934
Order numbers and spare parts can be ordered at WIDOS.

Description of product Chapter 1
09.06.15 Working Instructions WIDOS 8000 WM SPA page 11 of 108
1.7. Tools and accessories
The following tools and accessories are part of the original delivery:
Pieces: Name:
1 Key for switch cupboard
Attention! Hand over the key to authorized personnel only.
1 Spanner wrench size 24
1 Combination spanner size 30
1 Ratchet tightener with nut size 24
1 Hexagon socket wrench size 46
each 1 Allan key with T-grip, size 10 / 14
1 Torx-screw driver TX10

WIDOS Einsteinstr. 5 Phone [phone]
Wilhelm Dommer Söhne D-71254 Ditzingen-Heimerdingen Fax [phone]
GmbH Website: www.widos.de Email: [email protected]
09.06.15 Working Instructions WIDOS 8000 WM SPA page 12 of 108
2. Safety rules
The base for a safe handling and the fault-free operation of this machine is the knowledge of the basic safety
advises and rules.
The safety instructions of this chapter represent the general part. Specially instructions are closed by the
according activity.
These working instructions contain the most important indications to run the machine safely.
The safety indications are to be followed by all persons working on the machine.
2.1. Explanation of the symbols and indications
In the working instructions the following denominations and signs are used for dangers:
This symbol means a possibly danger for the life and the health of persons by electrical energy.
The disrespect of these indications may have heavy consequences for the health.
This symbol means a possible general dangerous situation.
The disrespect of these indications may cause slight injuries or damages on goods.
This symbol means a possible dangerous situation due to hot surfaces.
The disrespect of these indications may conduct to heavy burns, respectively to self-
ignition or even fire.
This symbol means a possible dangerous situation by moving parts of the machine
The disrespect of these indications may cause heavy crushing of parts of the body resp.
damages of parts of the machine.
This symbol means a possible risk of injury by noise exceeding 80 dB(A).
Ear protection is obligatory
This symbol gives important indications for the proper use of the machine.
The disrespect of these indications may conduct to malfunctions and damages on the
machine or on goods in the surrounding.
Under this symbol you get user tips and particularly useful information.
It is a help for using all the functions on your machine in an optimal way and helps you to
make the job easier.
The regulations for the prevention of accidents are valid (UVV).

Safety rules Chapter 2
09.06.15 Working Instructions WIDOS 8000 WM SPA page 13 of 108
2.2. Obligations of the owner
The owner is obliged only to let persons work at the machine who
know about basic safety and accident prevention rules and are instructed in the handling of the machine,
as well as who
the workers also must have read and understood the safety chapter of this manual and certify this by their
signature
The safety-conscious working of the staff has to be checked in regular intervals.
2.3. Obligations of the user
All persons who are to work at the machine are obliged:
to follow the basic safety and accident protection rules,
to have read and understood the safety chapter and the warnings in this manual and to confirm by their
signature that they have well understood them,
to inform themselves about the functions of the machine before using it, before working.
2.4. Measure of organization
All equipment required for personal safety is to be provided by the owner.
All available safety equipment is to be inspected regularly.
2.5. Information about safety precautions
The working instructions have to be permanently kept at the place of use of the machine. They are to be at
the operator's disposal at any time and without much effort.
In addition to the manual, the common valid and the local accident protection rules and regulations for the
environmental protection must be available and followed.
All safety and danger indications on the machine have to be in a clear readable condition.
Every time the machine changes hands or is being rent by a third person, the working instructions are to
be sent along with and their importance is to be emphasized.
2.6. Instructions for the staff
Only skilled and trained persons are allowed to work at the machine.
It must be clearly defined who is responsible for transport, mounting and dismounting, and starting the
operation.
A person who is being trained may only work at the machine under supervision of an experienced person.

Safety rules Chapter 2
09.06.15 Working Instructions WIDOS 8000 WM SPA page 14 of 108
2.7. Dangers while handling the machine
The machine WIDOS 8000 WM is constructed according to the latest technical standard and the
acknowledged technical safety rules.
However, dangers for the operator or other persons standing nearby may occur. Also material damages are
possible.
The machine may only be used
according to the purpose-oriented use
in safety technical impeccable status
Disturbances which may affect the safety of the machine must be cleared immediately
Only skilled persons are allowed to work at electrical appliances.
The electrical equipment of the machine has to be checked regularly. Loose connections and damaged
cables have to be replaced immediately.
Protect the heating element and planer from rain and dropping water.
System sections which have to be opened in case of repair work have to be depressurized
before starting to repair.
There is a danger of hurting your eyes because of a sudden flow compressed air resp.
squirting hydraulic oil. The hydraulic oil can be hot!
Damaged hydraulic / pneumatic hoses have to be immediately replaced.
Before starting to work make a visual examination of the hydraulic / pneumatic lines.
The hydraulic oil is brackish!
The hydraulic oil is to be handled and disposed of in appropriate manner.
2.8. Specific dangers
2.8.1. Danger of stumbling over electric wires and hydraulic hoses
Pay attention that nobody has to step over the lines / hoses.
Favorably pass the lines / hoses in order that the danger is minimized.
Do not squeeze and kink the lines / hoses or anything likewise.
Avoid the heating-up of hydraulic hoses (rise in pressure!).
2.8.2. Danger of drawing-in of clothes by the planer
You can carry away cut injuries up to fractures!
Do wear formfitting clothes.
Do not wear any rings or jewelry during work.
If necessary wear a snood-type cap.
Take care that no person is standing in the swiveling area of the planer.
Only remove chips with the planer standing still.

Safety rules Chapter 2
09.06.15 Working Instructions WIDOS 8000 WM SPA page 15 of 108
2.8.3. Risk of injury by noise
Noise exceeding 80 dB (A) may occur; while planing it is obligatory to wear ear protection!
Ear protection is obligatory while drilling / planing!
2.8.4. Danger of combustion by heating element and welding area
You can burn yourself, inflammable materials can be ignited.
The heating element temperature is heated up to more than 250 °C / 482 °F!
Do not leave the machine with heated heating element unsupervised.
Do not touch the surfaces of the heating element.
Do wear safety gloves.
Take enough safety distance to inflammable materials.
2.8.5. Danger of crushing
Heavy injuries can result from crushing:
- upon opening / closing the clamping tools;
- upon inserting pipes / work pieces 7 stub end holder;
- upon driving in and out the planer and heating element;
- upon opening / closing the slides;
- upon mounting the reducer inserts.
Do not touch in-between clamped pipes resp. the clamping tools while driving the machine together and
do not carry foreign objects into this area.
Do not hinder the moving tables.
Do not reach into the driving area of the planer during the back and forth motion.
Do not touch the guide rails of the machine.
Do not reach into the swinging area while you close / open the clamping tool.
Do not reach between pipe and clamping tool while you insert the pipes.
Do not reach between upper clamping tool and pipe or lower clamping tool while you put the upper parts
onto the lower parts.
2.9. Structural modifications on the machine
No modifications, extensions or reconstructions may be made on the machine without permission of the
manufacturer. In case of disrespect the warranty or liability will expire resp. the EC declaration of
conformity will get obsolete.
Machine parts which are not in a perfect condition are to be immediately replaced.
Only use original WIDOS spare and wear parts.
In case of purchase orders please always indicate the machine number!

Safety rules Chapter 2
09.06.15 Working Instructions WIDOS 8000 WM SPA page 16 of 108
2.10. Warranty and liability
Our „General Sales and Delivery Conditions“ are principally valid.
They are at the owner's disposal at the latest when signing the contract.
Warranty and liability demands referring to damages of persons or objects are suspended if they are caused
by one or several of the following reasons:
not using the machine according to the prescriptions
improper transport, building-up, starting and operating the machine and maintenance
operating the machine with defective or improperly installed security measures
ignoring the information given in this manual
structural changes at the machine without permission
unsatisfactory checking of machine parts which are worn out
repairs performed in an inexpert way
catastrophes by external influence and Acts of God.

WIDOS Einsteinstr. 5 Phone [phone]
Wilhelm Dommer Söhne D-71254 Ditzingen-Heimerdingen Fax [phone]
GmbH Website: www.widos.de Email: [email protected]
09.06.15 Working Instructions WIDOS 8000 WM SPA page 17 of 108
3. Functional description
All international and national process guidelines are to be basically followed!
The plastic pipes are clamped by means of corresponding clamping tools.
Insert the plastic pipes and clamp them by means of the clamping tools.
Afterwards, the planer is driven into the machine and the front sides of the pipes are planed in parallel by
means of the planer, and the pipe displacement is checked. The planer is then driven back to its basic
position.
Then the heating element is driven inside and the pipes are pressed onto the heating element under the
defined pressure (this process is called: „adjustment time“).
After reaching the prescribed bead height the pressure is being reduced and this is the start of the heating
time.
The function of this time is to bring the pipe ends onto the welding temperature.
After completion of the heating time the machine is opened the heating element quickly driven out and the
pipes are again driven together hydraulically.
The time gap from driving out the heating element to the joining of the pipes is called change over time.
They are put together with the prescribed welding pressure and then cool down under pressure (cooling
time).
The welding connection can now be unclamped: the welding process is completed.
Heating element heats the pipes
up to welding temperature
Completed welding joint
with in- and outside bead

WIDOS Einsteinstr. 5 Phone [phone]
Wilhelm Dommer Söhne D-71254 Ditzingen-Heimerdingen Fax [phone]
GmbH Website: www.widos.de Email: [email protected]
09.06.15 Working Instructions WIDOS 8000 WM SPA page 18 of 108
4. Operating and indicating elements
4.1. Machine overview
Machine with 15°-clamping tools:
Machine with T-90°-clamping tools:
Additional cylinder
Planer
Left table
Set screw
15°-clamping tools
Right table with
horizontal adjustment
Control panel
Heating element
Holder for additional cylinder
(including cylinder)
Hydraulic aggregate
Protective cover
Couplings for cylinders
Service unit and
Pneumatic valves
T90°- clamping tool
(large part)
Block for pipe
T90°- clamping tools
(small
p
arts)

Operating and indicating elements Chapter 4
09.06.15 Working Instructions WIDOS 8000 WM SPA page 19 of 108
4.2. Operator console
4.2.1. Operator panel
No. Denomination Function
1 Display (optional) - to display the necessary parameters (for welding and
programming).
- Two values can be displayed at the same time.
1
2
3
4
5
7
8
11
12
14
13
15
16
17
9
10
6
Switch cabinet
SD card drive
Main switch
Guide roller, lockable
Operator panel
Heat sink

Operating and indicating elements Chapter 4
09.06.15 Working Instructions WIDOS 8000 WM SPA page 20 of 108
No. Denomination Function
2 Buttons for operation
(optional)
- Drag pressure measurement;
- to set the pipe data and project number;
- to set the type of the machine;
- to print the welding data;
-Diagnosis menu;
-to reset to the previous item of the menu
3 Turning switch 0 / I - to switch the heating element on <I> and <0> off
4 Temperature regulator - to set the heating temperature
5 Joystick heating element -Heating element out of machine
-Heating element into machine
6 Joystick Planer -Planer out of machine
-Planer into machine
-Planer rotate (planing pipes)
7 Joystick (cylinder 1) left
clamping tool
-To open left clamping tool
-To close left clamping tool
-To clamp left clamping tool (option)
-To release left clamping tool (option)
8 Joystick (cylinder 2)
clamping tool (optional)
-To open clamping tool
-To close clamping tool
-To clamp clamping tool (option)
-To release clamping tool (option)
9 Joystick (cylinder 4) right
clamping tool
-To open right clamping tool
-To close right clamping tool
-To clamp right clamping tool (option)
-To release right clamping tool (option)
10 Joystick (cylinder 3)
clamping tool (optional)
-To open clamping tool
-To close clamping tool
-To clamp clamping tool (option)
-To release clamping tool (option)
11 Pressure gauge -Pressure indication [bar]
12 Pressure controller -Adjust bead-up pressure (Reading: on pressure gauge)
13 Joystick tables -To close tables for bead-up
-To open tables
-To close tables for joining / cooling
-To close tables for planing
14 Pressure controller -Adjust welding pressure (Reading: on pressure gauge)
15 Pressure controller -Adjust planing pressure (Reading: on pressure gauge)
